Calculite®ProSpec®Linear Downlight PB4P3810
Page 1 of 2 4 Light PAR38 Series B
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier a Genlyte Thomas Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2011 Genlyte Thomas Group LLC (Lightolier Division) • B0711
Features
1. Aperture Frame: Provides clean support for lamp holders and overlapping
flange or trimless installation. Extruded aluminum. Rigidly welded together
on all corners.
2. Media Cartridge: Allows convenient loading and removal of up to one
accessory. Easily installed and removed for lamping with a simple twisting
motion. Constructed of die-formed aluminum.
3. Adjustable Ring: Allows 360° horizontal and 35°, max. 45° (on length); 40°
(on width) vertical adjustment.
4. Tortiontite Spring: For easy installation of aperture frame.
5. Housing: Die-formed 22 ga. steel. Finish: Black
6. Mounting Brackets: Adjustable vertically from inside or outside of housing.
7. Thermal Protector: Meets NEC and UL requirements.
8. Lampholder: Porcelain medium based; nickel plated screw shell. Prewired
with #18 SF-1 leads to junction box.
9. Junction Box: 14 ga. steel, 4” x 3-1/2” x 2" box. Allows inspection from
below.
10. Lamp and Accessory Support: .032" steel, flared for easy entry of Media
Cartridge.
11. Lens Retaining Ring: .093" spring steel rod. Holds accessories in place.
Electrical
UL listed for through branch circuit wiring with maximum of (8) no. 12 AWG,
90°C.
Finish
All painted finishes are powder coated baked enamel.
Ceiling Cutoff: 29 1/16"L X 8 3/16"W
Ordering Information: PAR38 Series B
Cat. No. Lamp Ceiling Trim Aperture Finish
PB4P3810BL (4) 100W PAR38 Overlap Black with White Flange
PB4P3810WL (4) 100W PAR38 Overlap White with White Flange
PB4P3810BTL (4) 100W PAR38 Trimless Black
PB4P3810WTL (4) 100W PAR38 Trimless White
Options and Accessories
Accessories: 4 3/4" dia. series, filters, lenses, screens, and louvers. (1) max.
Label
UL/cUL (Suitable for Damp Location), I.B.E.W.
PB4P3810BL = (Flanged) Black/White
PB4P3810WL = (Flanged) White
PB4P3810BTL = (Trimless) Black
PB4P3810WTL = (Trimless) White
