Lytespan®Accent Lighting System 83B70SE
Page 1 of 1 PowerArc™ Modular 70W Electronic Metal Halide Ballast Module
Features
1. Housing: .10" thick extruded aluminum body with die cast end caps.
2. Track Attachment Fitting: Molded polycarbonate; rotates into track,
integral polarity key guard.
3. Brass Contact: Extends for connection to second circuit in Advent
Lytepsan track.
4. Safety Locking Lever: Locks and supports module in track.
5. On/Off Switch: Rocker switch to disconnect power to the ballast.
6. Power Connector: 5kv rated, insulated. Accepts power connector
from fixture.
7. Integral Track Groove: To mount PowerArc® Modular spots and wall
wash fixtures.
Electrical
Electronic Ballast
Input Voltage: 120V, 60Hz
Power Factor: High
Input Power: 77W
Max. Input Current: 0.64A
Total Harmonic Distortion: <10%
ANSI Code: M143, M139, M98
Do not use on dimming circuit.
Finish
All painted finishes are baked enamel.
Labels
UL, cUL
Ordering Information
Catalog No. Finishes Track Mountings Luminaires Lamp
83B70SEWH
83B70SEBK
83B70SEAL
Matte White
Matte Black
Metallic Aluminum
All Lytespan® Track Systems and Multipoint. DO NOT
USE with any other mounting accessories, stem mounted
Radius® Track, ProSpec®Track systems, or ATOM. Can be
wall mounted. NO REMOTE MOUNTING.
Use one of:
8313 83W4
8314 83W6
8316 83W7
8317
8318
70W Ceramic Metal
Halide
2 1/16"
(52mm)
2 1/2"
(64mm)
7 3/4"
(197mm)
2"
(51mm)
2 3/8"
(60mm)
6
2
34
1
5
7
