READ AND UNDERSTANDTHESE INSTRUCTIONSBEFORE INSTALLING FIXTURE INSTRUCTION SHEET NO.
is fixture is intendedfor installationin awordanca with the National Electrical Code and fosaf
gulations.To aaaure full compliance with local cades and regulations, chedr with your local electrical
speatorbefore installation. To prevent electrio-elshock, turnoff elestriahy at fuse b-axbefore proceeding. IS:5412
Retain these instructions for maintenance reference. 1291
INSTRUCTIONS FOR INSTALLATION OF HELIOS
COVERS FIXTUR~ 5412 and 5413
.FOR OCTAGONALOUTLETBOX MOUNTING.
1. ScrewCOVER PLATEtothebacksideofMOUNTINGPtATE withscrewsprovided.
2. Pullsupplywires from outlet box through tha WIREWAY HOLE in MOUNTING PLATE.
3. Using outlet box screws (provided with outlet box) secure MOUNTING PfATE to outlet box using the appropriate SLOTS in MOUNTING
PIATE.
4. Using the HOLES next to each MOUNTING STUD on MOUNTING PLATE secura MOUNTING PLATE directly’to wall using wood scfews
toggle bolts, or alternate fastener (not provided) depending on wall material.
.FOR HORIZONTALLY MOUNTED RECTANGULAR GEM OR SWITCH BOXES. (Diecard Coverplate)
i. Pull supply wires from outtet box through the WIREWAY HOLE in MOUNTING PLATE.
2. Using outlat box acrewa (providad with outlet box) secure MOUNTING PLATE to outlet box using the appropriate SLOTS in MOUNTING
PL4TE.
3. Using tha HOLES naxi to aach MOUNTING STUD on MOUNTING PLATE secure MOUNTING PLATE directly to wall using wood
screws, toggle bolts, or alternate fastener (not provided) depending on wall material.

NSTRUCTION SHEET NO.
1S:5412
1291 Page 2of2
A. INSTALLATION OF FIXTURE BODY
1. Remove both DIFFUSERS from FIKTURE BODY bygentlygrasping DIFFLfSERtowards end and pulling direc+yawayfrom DIFFUSER
PAN.
2. Hook HANGER LOOP over one of the HANGER TABS on MOUNTING PLATE and allow FIXTURE BODY to hang.
3. Make connections black fixture leads or fixture leads without trac?r marks to blask (hot) supply lead? white fixture leads or fixture leads
with tracer marks to white (neutral) supply leads. Uninsulated fixture wires are ground wires and all must be sbnnected to grounding
terminal or wire in “outlet box”. Use wirenuts (local hardware item).
CAUTION: Push supply wires and wirenut connections back into outlet box. \
4. Position FIXTURE BOOYover MOUNTING PLATE and gently push FIXTURE BODY against wall until both MOUNTING STUDS soma
through the SLOTS in DIFFUSER PAN. Sesure in plain using STAR WASHERS and BATTERY NUTS.
CAUTION: Make certain that nowireaare pinchadbefween mounting plata and tixfurebody.
5. InstallrecommendedlampsbyengaginglampbaseintoSOCKETandthensnappingintoLAMP CLIP.
6. Position open end of DIFFUSER into FIXTURE BODY@ and gantfy pueh DIFFUSER beck against DIFFUSER PAN until DIFFUSER
snaps into plaw @onto DIFFUSER CLIP. Repeat for second DIFFUSER.
NOTE: Support the back side of DIFFUSER PAN before snapping DIFFUSER into plats.
CAUTION: Uae lamp types/wattages ae marked on fixture. For horizontal mounting onfy.
