Lytecaster®Recessed Downlighting 2022LV
Page 1 of 1 3 3/4" Aperture MR16 Eyeball Reflector Trim .
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2011 Philips Group • J0911
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier is a Philips group brand
Features
1. Housing: Hydroformed aluminum, .040" thick (18 ga.).
2. Eyeball Housing: Die-formed, one piece, aluminum, .040" thick (18 ga.).
Provides 358˚horizontal rotation and 0˚ to 45˚ vertical adjustment; matte white
or polished brass finish.
3. Step Baffle: Die-cast aluminum with stepped conical surface for low
brightness; precision-fitted into eyeball housing; matte black finish.
4. Trim Flange: Die-formed, aluminum .040" thick (18 ga.). Matte white or
polished brass finish.
5. Frame-In Kit: (2000LV standard frame shown) Other frames shown on the right.
See Frame-In Kit specification sheets for more details.
Options & Accessories
Retaining Clips: 1955 - For Installing in Existing Ceiling
2022LV/2000LV Series
Standard MR16
2022LV/2000LVNT
Remote Transformer
Low Voltage
2022LV/2004ICV/N
0™AirSeal® Insulated Ceiling
5 3/8”
7 1/4”
5 3/8”
5 3/8”
2022LV/2000LVR
Remodeler/Non-IC
Labels
UL (Suitable for Damp Locations), I.B.E.W
Complete Fixture consists of Reflector Trim & Frame-In Kit. Select each separately.
Reflector Trim Frame-In Kit — See Individual Frame-In Kit Specification Sheets
Low Voltage
Frame-In Kit Installation Type Lamping Height
2022LV Matte White 2000LV Standard Non-IC 5 3/8"
w/Black Baffle 2000LVR Remodeler Non-IC 5 3/8”
2000LVRE1 Remodeler Non-IC 5 3/8"
2000LVE1 Electronic Low Voltage Non-IC 120V 20W-50W MR16 5 3/8"
2000LVE2 Electronic Low Voltage Non-IC 277V 5 3/8"
2004ICV/N Lytening AirSeal® IC 20W-37W MR16 7 1/4”
2000LVNT Low Voltage Remote Transformer 20W-42W MR16 5 3/8"
2000AICV AirSeal® IC 20W-35W MR16 7 5/16”
