Lytecel LI / LC
Installation Instructions
Standard or Slot Grid Ceiling Systems
1ACCE PLATE
Remove Access Plate by
sliding Access Plate in the
direction of Arrow 1. To re-
move, lift up and slide in
the direction of Arrow 2.
Bend Fixture Tab up out of
body and make ground
and ballast connections.
Bend Fixture Tab back to
original position. Replace
Access Plate by reversing
removal instructions.
CONTINUOU ROW COUPLER (LC
UNIT ONLY) Remove screw as shown.
Rotate Continuous Row Coupler (both
sides of Fixtures) and secure Fixtures
5
Access
Plate
Access
Plate
Opening
Fixture
Tab
Ground
crew
Access
Plate
Opening
Tab
1.
2.
Access
Plate
Opening
T-bar
crew
Hold-down Clip
Continuous
Row Coupler
Fixtures
Continuous
Row
Coupler
Hold-
down Clip
T-bar
crew
Fixtures
together with crew. Tighten
all crews to secure Fixtures
to T-bar with Hold-down Clips.
HOLD-DOWN
CLIP
(LI UNIT
ONLY) Install
Hold-down
Clips at
beginning
and end
of rows.
4
END TRIM
Install End
Trim at be-
ginning and
end of row.
3Fixtures
crew
Hold-
Down Clip
Fixture
crew
End
Louver
T-bar
(by others) End Trim (for
beginning and
end of row)
End of Row
Fixture
T-bar
(by others)
Hold-down
Clip
crew
Coupler is used at end or begin-
ning of row to secure End of Row
Fixture to T-bar (by others)
2IN TALL FIXTURE onto
T-bars as shown.
T-bar
Fixture

FOR 2 LAMP
To open Louver, place
finger or small tool
thru Access Hole in
Louver and press
pring Latch in
direction of arrow.
To close, insert
louver into Fixture
until pring Latches
automatically
engage.
7
Fixtures pring
Latch
FOR 1 LAMP
To open Louver,
press pring Latch
in direction of Arrow.
To close, insert lou-
ver into Fixture
until pring
Latches auto-
matically engage.
6Fixtures pring
Latch
59-31123-001 Rev.A Printed in U. .A.
8LEN IN TALLATION (Individual, LI, unit only)
Follow disgrams 8a - 8c.
To remove lens reverse installation.
Lens with prismatic side
down (Away from lamp)
8c
8b
8a
