Furniture of America St. Nicholas CM3224T-T/B User manual

MODEL #
Questions?
GIVE US A CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PT)
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
EASY DIFFICULT
2 - People
(Included)
Wrench
Recommended
CM3224T-T/B
VERSION # 21-07-08
1 / 9

Thank you for your purchase!
We hope you enjoy this new addition to your home for many years to come.
Our commitment to providing quality products does not simply end when you purchase
our product. We fully stand behind our products from start to finish. Our customer
service department is available Monday – Friday 8:30 AM – 5:30 PM Pacific Time and can
help with assembly questions as well as, if necessary, replacing damaged or missing
parts. To help expedite our service, please have these assembly instructions readily
available, along with your order receipt.
E-MAIL
[e-mail]
Furniture of America
WEBSITE
www.foagroup.com
FOA Intro
FurnitureOfAmerica
foagroup
Monday to Friday
8:30AM- 5:30PM (PT)
Consumer Hotline
Toll-Free 1-888-980-5122
Prep Time!
Please review the assembly instructions and all
diagrams prior to assembling.
Check out our Quick Tips!
We recommend reviewing the pre-assembly
handouts. Even experts need a refresher now and
then!
Are you missing anything?
Double-check all parts, hardware and
accessories listed are all acccounted for.
Should we send any replacements?
Are there any irregularities or flaws in the
parts? We can send replacements!
CHECK
BEFORE STARTING
2 / 9

PRE ASSEMBLY
INTRODUCTION
Suitable Location
Assembling near the area of the
intended location is highly
recommended.
Avoid Scratches
Use cardboard, blankets or a
carpeted area while assembling
furniture to prevent to prevent
Teamwork
ALWAYS have at least two people
to help with transporting and
assembling the product to avoid
potential injury and/or damage.
Flat Surface
Make sure the furniture rests on
a flat and level surface with each
leg evenly touching the floor.
Sufficient Space
Make sure you have enough
space to move around during the
assembly.
We understand building ready-to-assemble furniture can be a challenging
experience for some. To help avoid confusion, we have provided some helpful
tips that may speed up the process.
scratches and damages.
3 / 9

4 / XXXXX9

DINING TABLE
#1 1pc #2 1pc
#4 2pcs
#A 18pcs #B 18pcs #C 18pcs
Table Top
#3 2pcs
#D 1pc
Leaf Plate
Post
Hex Nut
Ø5/16" x 1/2"
Lock Washer
Ø5/16"
Flat Washer
Ø5/16"
Wrench
#5 6pcs
Leg
CM3224T-T/B
5 / 9

#1
#2
#5
#4
Exploded View
6 / 9

CM3224T-T/B is packed in 2 cases
Carton Disignation Part Hardware
CM3324T-T
#1
#2
#3
#4
#5
7 / 9
CM3324T-B
Table Top
Leaf
Plate
Post
Leg
#A x18pcs
#B x18pcs
#C x18pcs
#D x1pc

ASSEMBLY INSTRUCTIONS
#5
#A
#B
#C
#D
#4
#D
#A
#B
#C
#3
#1
x 2
1
Part #4 x1pc
Part #5 x3pcs
Hardware #A x6pcs
Hardware #B x6pcs
Hardware #C x6pcs
2
Part #1 x1pc
Hardware #A x6pcs
Hardware #B x6pcs
Hardware #C x6pcs
8 / 9
I. Insert the threaded ends of the
legs (#5) into the pre-drilled holes
along the sides of the post (#4).
II. From within the post (#4), insert
a flat washer (#C) then lock washer (#B)
and a nut (#A), in that order onto the threaded
ends. Secure using the wrench (#D)
I. Carefully place the table top (#1) onto a protected surface.
II. Insert the threaded ends of the posts into the center pre-
drilled holes on the plates (#3).
III. Once the posts are placed, insert a flat washer (#C), lock washer (#B),
then a nut (#A), in that order from below onto the threaded ends.
Secure using the wrench (#D).

ASSEMBLY INSTRUCTIONS
Adjusting table leg
3
4
Part #2 x1pc
#2
9 / 9
To insert or remove the leaf (#2), unlock/lock the latches from under the table top.
Carefully turn the completed table upright. Make sure the table is rested on a flat surface and does
not feel loose or wobbly. If it does, double check that the bolts are secured and properly tightened.
