Calculite®ProSpec®Linear Downlight PB1P3075
Page 1 of 2 1 Light PAR30 Series B
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier a Genlyte Thomas Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • ( 08) 679-8131 • Fax ( 08) 674-4710
We reserve the right to change details of design, materials and finish.
© 2011 Genlyte Thomas Group LLC (Lightolier Division) • B0711
Features
1. Aperture Frame: Provides clean support for lamp holders and overlapping
flange or trimless installation. Extruded aluminum. Rigidly welded together
on all corners.
2. Media Cartridge: Allows convenient loading and removal of one accessory.
Easily installed and removed for lamping with a simple twisting motion.
Constructed of die-formed aluminum.
3. Ad ustable Ring: Allows 360° horizontal and 40° (on width) and 4 ° (on
diagonal) vertical adjustment.
4. Tortiontite Spring: For easy installation of aperture frame.
5. Housing: Die-formed 22 ga. steel. Finish: Black.
6. Mounting Brackets: Adjustable vertically from outside of housing
7. Thermal Protector: Meets NEC, UL, and CSA requirements.
8. Lampholder: Porcelain medium based; nickel plated screw shell. Prewired
with #18 SF-1 leads to junction box.
9. Junction Box: 14 ga. steel, 4" x 3 1/2" x 2" box. Allows inspection from
below.
10.Lamp and Accessory Support: .032" steel, flared for easy entry of Media
Cartridge.
11.Lens Retaining Ring: .093" spring steel rod. Holds accessories in place.
Electrical
UL/cUL listed for through branch circuit wiring with maximum of (8) no. 12 AWG,
90°C.
Ceiling Cutout: 7 3/16" L x 7 3/16" W
Ordering Information: PAR30 Series B
Cat. No. Lamp Ceiling Trim Aperture Finish
PB1P3075BL (1) 7 W PAR30 Overlap Black with White Flange
PB1P3075WL (1) 7 W PAR30 Overlap White with White Flange
PB1P3075BTL (1) 7 W PAR30 Trimless Black
PB1P3075WTL (1) 7 W PAR30 Trimless White
Finish
All painted finishes are powder coated baked enamel.
Options & Accessories
Accessories: 3 3/4" dia. series, filters, lenses, screens and louvers,(1) max.
Label
UL /cUL (Suitable for Damp Location), I.B.E.W.
PB1P3075BL = (Flanged) Black/White
PB1P3075WL = (Flanged) White
PB1P3075BTL = (Trimless) Black
PB1P3075WTL = (Trimless) White

Calculite®ProSpec®Linear Downlight PB1P3075
Page 2 of 2 1 Light PAR30 Series B
Lightolier a Genlyte Thomas Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • ( 08) 679-8131 • Fax ( 08) 674-4710
We reserve the right to change details of design, materials and finish.
© 2011 Genlyte Thomas Group LLC (Lightolier Division) • B0711
Job Information Type:
Lighting Performance Data
