Lightolier OB Series User manual

Lightolier
45 INDUSTRIAL WAY, WILMINGTON, MA 01887
OVER BED (OB SERIES) INSTALLATION INSTRUCTIONS
1
© Lightolier 2003 59-31122-000 Printed in U.S.A.
DIMENSIONS
3/16" x 5/8" Oval K.O.’s (4)
1-7/8" Dia. K.O.
7/8" Dia. Holes (3)
5-61/64"
(151mm) 16" (406mm)
23-61/64" (608mm)
47-57/64" (1216mm)
32" (813mm)
Fixture
Wall
6'-0"
(1829mm)
Top Spring-loaded Latch (2)
Housing
Lens Bottom Spring-loaded Latch
12
34
3INSTALLING LAMPS
For lamp (by others) installation follow diagram.
Four (4) lamp - positions 1, 2, 3, 4
Three (3) lamp - positions 1, 2, 4
Two (2) lamp - positions 2, 4
2REMOVING LENS
Place fingers between Lens and Housing. Pull
Lens on Top and Bottom Spring-loaded Latches
away from Housing. Release Lens from Bottom
Spring-loaded Latches and lift Lens to clear Top
Spring-loaded Latches to remove Lens.
4REPLACING LENS
Hook Lens onto Top Spring-loaded Latches.
Hook Lens onto Bottom Spring-loaded Latches.
Push Lens and Spring-loaded Latches towards
Housing until Lens is secured to Housing.
Top Spring-loaded Latch (2)
Housing
Bottom Spring-loaded Latch
Lens
