Lightolier LUMINOSITIES “ADA Instructions for use

READ AND UNDERSTAND THESE INSTRUCTIONS BEFORE INSTALLING FIXTURE
This fixture is intended for installation in accordance with the National Electrical Code and local regulations.
To assure full compliance with local codes and regulations, check with your local electrical inspector before
installation. To prevent electrical shock, turn off electricity at fuse box before proceeding.
Retain these instructions for maintenance reference.
LIGHTOLIER a GENLYTE company.
631 Airport Road, Fall River, MA 02720
INSTRUCTION SHEET NO.
IS:40885
0998 Page 1 of 1
INSTRUCTION SHEET FOR INSTALLATION OF LUMINOSITIES™“ADA” WALL BRACKET SERIES
NOTE: This instruction sheet covers several fixture
styles. Backplate, lamp type and diffuser assembly
may vary slightly from that shown, although installa-
tion is the same.
BACKPLATE INSTALLATION:
1. Thread CROSSBAR MOUNTING SCREWS into
CROSSBAR as shown (Fig. 1).
2. Using appropriate slots in CROSSBAR, secure
CROSSBAR to OUTLET BOX using OUTLET BOX
SCREWS (provided with OUTLET BOX.)
3. While supporting BACKPLATE make connections: black
fixture lead or fixture lead without tracer marks to hot
(black) supply lead; white fixture lead or fixture lead with
tracer marks to neutral (white) supply lead. Uninsulated
fixture wire is a ground wire and must be connected to
grounding terminal or ground lead inside OUTLET BOX.
Use WIRE NUTS (local hardware item). Push supply
wires and connections back into OUTLET BOX.
4. Position BACKPLATE over CROSSBAR allowing
CROSSBAR MOUNTING SCREWS to come through
holes in BACKPLATE.
5. Secure BACKPLATE in position by installing two
BATTERY NUTS over CROSSBAR MOUNTING SCREWS
and tighten.
6. Install recommended lamp(s).
DIFFUSER INSTALLATION:
1. Slide METAL FRAME of DIFFUSER ASSEMBLY over outer
edge of backplate.
2. Secure DIFFUSER ASSEMBLY in position by tightening
two MOUNTING SCREWS on DIFFUSER ASSEMBLY into
holes in BACKPLATE.
CAUTION: MAXIMUM WATTAGE AS MARKED ON
FIXTURE MUST NOT BE EXCEEDED.
CAUTION: MAKE CERTAIN WIRES ARE NOT PINCHED
BETWEEN PARTS.
OUTLET BOX
WIRE NUT
GROUND WIRE
CROSS BAR
CROSS BAR
MOUNTING SCREW
OUTLET BOX SCREW
(PROVIDED WITH OUTLET BOX)
BACK PLATE
HOLE
BATTERY NUT
MOUNTING SCREW
METAL FRAME
DIFFUSER
ASSEMBLY
FIG. 1
WARNING: FOR SUPPLY CONNECTIONS USE WIRE
RATED FOR AT LEAST 90°C.
WARNING: RISK OF FIRE. MOST DWELLINGS BUILT
BEFORE 1985 HAVE SUPPLY WIRE RATED
60°C. CONSULT A QUALIFIED ELECTRICIAN
BEFORE INSTALLING.
