Lightolier On Series User manual

Radiante Normally On Series
ARCHITECTURAL LED EMERGENCY LIGHTING
Page 1 of 2
Job Information Type:
Job Name:
Cat. No.:
Notes:
Features
Illumination: Illumination is
provided by two 3 W, white
LEDs and a specular Miro 4
(Alanod™) aluminum reflector.
The lamp head assembly may
be rotated in five degree
increments over a range of 60
degrees for ideal distribution
along the egress path. Radiante
Normally On will provide one
footcandle average illumination
over a 12’ long path of egress
for a single fixture and 26’
centers for multiple fixtures.
Housing: Robust die cast
and extruded aluminum
housing. A full range of pleasing
architecturally inspired finishes
are available (see back). Wall
mount to standard 3 1/2”
octagonal junction box.
Operating Temperature
Range:
-22°F (-30°C) to 104°F (40°C)
Electronics: 120/277 VAC
dual voltage input.
Electrical Specifications:
0.10 A, 11.73 W (120 VAC)
0.04 A, 11.61 W (277 VAC)
Code Compliance
UL 924 and UL damp location
listed. NFPA 101, NEC, BOCA,
OSHA and IBC illumination
standards.
Warranty
Three year full electronics
warranty.
RDNON
13.1"
(33.3 cm)
4.5"
(11.4 cm)
6.0"
(15.2 cm)

Radiante Normally On Series
ARCHITECTURAL LED EMERGENCY LIGHTING
Page 2 of 2
Philips Lightolier
e: [email protected]
t: [phone]
w: www.lightolier.com
Radiante Normally On Series August 8, 2011
Specifications are subject to change without notice.
© Koninklijke Philips Electronics N.V., 2011.All rights reserved.
Job Information Type:
Ordering Information
Series
RDNO = Radiante
Normally On
Architectural LED
Luminaire
Optics
* The optics layout shown is intended to be used as reference only. Standard reflectances used were 80/50/20. Lightolier is not responsible for site specific conditions that
may alter the results.
TP = Tamperproof
Factory Installed Options Accessories (order as a separate item)
T10TPTOOL = Tamperproof Tool with Bit
RDNO
W= White
B= Black
A= Aluminum
G= Gunmetal
BR = Ornamental Bronze
AC = Aged Copper
VG = Velvet Green
N= Nickel
Consult factory for other
colors.
Housing Color
Wall Mounted, 7.5' AFF
Dual fixtures on 26 foot centers provide 1 footcandle average.
Single fixture provides 1 footcandle average over 12 feet.
7.5 ft.
12 ft.
3 ft.
.02 FC min. 1 FC avg.
Blank = 120/277 VAC No
Emergency
2CKT1 = 120/120 2 Circuit
2CKT2 = 277/277 2 Circuit
Input Voltage Options
