LightSpeed Technologies FOX1-KIT User manual

Version: V1.0.0
LightSpeed Technologies
24551 Production Circle, Suite 2
Bonita Springs, FL 34135
www.lightspeed-tech.com
User Manual
LightSpeed Technologies™ FOX1-KIT
4K UHD Uncompressed Video over Fiber Optic Cable

Important Safety Instructions
1. Do not expose this apparatus
to rain, moisture, dripping or
splashing and that no objects
filled with liquids, such as vases,
shall be placed on the apparatus.
6. Clean this apparatus
only with dry cloth.
2. Do not install or place this unit
in a bookcase, built-in cabinet or
in another confined space.
Ensure the unit is well ventilated.
3. To prevent risk of electric
shock or fire hazard due to
overheating, do not obstruct
the unit’s ventilation openings
with newspapers, tablecloths,
curtains, and similar items.
4. Do not install near any heat
sources such as radiators, heat
registers, stoves, or other
apparatus (including amplifiers)
that produce heat.
5. Do not place sources of naked
flames, such as lighted candles,
on the unit.
7. Unplug this apparatus
during lightning storms or
when unused for long
periods of time.
8. Protect the power cord
from being walked on or
pinched particularly at
plugs.
9. Only use attachments
/ accessories specified
by the manufacturer.
10. Refer all servicing to
qualified service
personnel.

FCC Warning
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and decoder.
-- Connect the equipment into an outlet on a circuit different from that to
which the decoder is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.

1
Contents
Introduction ...................................................................................................... 2
Images .................................................................................................... 3
Features .................................................................................................. 3
Package Contents ................................................................................... 4
Specifications .......................................................................................... 5
Panel Description .................................................................................... 7
Encoder ............................................................................................. 7
Decoder ............................................................................................. 8
Installation........................................................................................................ 9
Typical Applications ......................................................................................... 9
1. HDMI 2.0 Extender .............................................................................. 9

2
Introduction
LightSpeed Technologies™ FOX1-KIT (encoder and decoder) comes
in a compact size and is an economical, flexible HDMI extender
solution. It allows uncompressed true 4K@60Hz video to be extended
with zero frame latency at 300 meters over multi-mode fiber, and
20km over single-mode fiber with 10Gb SFP+ modules.
HDMI 2.0 and HDCP 2.2 Distribution with Zero Frame Latency
With HDMI 2.0 and HDCP 2.2 compliance, they support all HDMI 2.0
with a timing envelope of 594 MHz, e.g., 4K/60 8-bit 4:4:4, 4K/60 10-
bit 4:2:2 and 4K/60 12-bit 4:2:0 (HDR). Light compression technology
allows them to deliver video at lower compression ratios for keeping
picture quality identical to the original source when the raw data
exceeds the Ethernet bandwidth. Furthermore, the video is delivered
with zero frame latency.
Compact design and Cost-Effective Solution
The compact size design is suitable for installation in a tight space,
and provides a cost effective, flexible solution for HDMI extension.

3
Images
Models
FOX1
-
ENC
FOX1
-
DE
C
Images
Features
 Compact size and economical design
 HDMI 2.0 and HDCP 2.2 compliant
 Lossless distribution of most timing formats
 Light compression with the raw data rate exceeding 10Gb
Ethernet bandwidth
 Supports input and output resolutions up to 4096x2160@60Hz 8-
bit 4:4:4, 4096x2160@60Hz 10-bit 4:4:4 and 4096x2160@60Hz
12-bit 4:2:0 HDR
 Supports point-to-point transmission of 4K signal up to 300m over
multi-mode fiber, and 20km over single-mode fiber with 10Gb
SFP+ modules.
 Zero-frame latency

4
Package Contents
FOX1-ENC Encoder:
 1 x FOX1-ENC Encoder
 1 x 5VDC 2A Power Adapter (with US Pins)
 1 x SFP+ multi-mode optical transceiver
 2 x Mounting Brackets (with Screws)
FOX1-DEC Decoder:
 1 x FOX1-DEC Decoder
 1 x 5VDC 2A Power Adapter (with US Pins)
 1 x SFP+ multi-mode optical transceiver
 2 x Mounting Brackets (with Screws)

5
Specifications
Model FOX1-ENC FOX1-DEC
Video
Input Video Port 1 x HDMI 1 x SFP+ (10GBase-SR)
End-to-End Time
Latency
Zero-frame latency
Output Video Port 1 x SFP+ (10GBase-SR) 1 x HDMI
Input/Output Video
Resolutions
640x4808, 800x6008, 1024x7688, 1280x10248, 1360x7688,
1440x9008, 1440x10508, 1600x12008, 720x4807(480i59),
720x4807(480p59), 720x5766(576i50), 720x5766(576p50),
1280x7205(720p50), 1280x7207(720p59),
1280x7208(720p60), 1920x10806(1080i50),
1920x10807(1080i59), 1920x10808(1080i60),
1920x10801(1080p23), 1920x10802(1080p24),
1920x10803(1080p25), 1920x10804(1080p29),
1920x10805(1080p30), 1920x10806(1080p50),
1920x10807(1080p59), 1920x10808(1080p60),
3840x21601(2160p23), 3840x21602(2160p24),
3840x21603(2160p25), 3840x21604(2160p29),
3840x21605(2160p30), 3840x21608(2160p60), 4096x21605,
4096x21608
1 = at 23.98 Hz, 2 = at 24 Hz, 3 = at 25 Hz, 4 = at 29.97 Hz,
5 = at 30 Hz, 6 = at 50 Hz, 7 = at 59.94 Hz, 8 = at 60 Hz
Model FOX1-ENC FOX1-DEC
Audio
Input Audio Port 1 x HDMI 1 x SFP+ (10GBase-SR)
Output Audio Port 1 x SFP+ (10GBase-SR) 1 x HDMI
Input/Output Audio
Format
LPCM, 2.0/5.1/7.1 channel, 44.1/48/96/192 kHz
Dolby True HD, up to 7.1,192kHz
DTS-HD Master, up to 7.1,192kHz
Dolby Digital AC-3 (DVD format)
DTS version 1 (DVD format)

6
General
Operating
Temperature
32°F ~ 104°F (0°C ~ 40°C)
10% ~ 90%, non
-
condensing
Storage
Temperature
-4°F ~ 158°F (-20°C ~ 70°C)
10% ~ 90%, non-condensing
Power Supply 5V 2 A DC
Power Consumption
(Max) FOX1-ENC: 4.26W | FOX1-DEC: 4.78W
Transmission
Distance 300m with OM-3 multimode optical fiber cable
ESD Protection
Human body model:
 ±8kV (air-gap discharge)
 ±4kV (contact discharge)
Product Dimensions
(W x H x D) 64mm x 22mm x 87mm (2.52" x 0.87" x 3.43") each
Net Weight 0.35lb (0.16kg) each

7
Panel Description
Encoder
654321
No.
Name
Description
1 SYSTEM
LED
 On: The device is connected to a source
but doesn’t transmit any streams.
 Blinking quickly: The device is connected
to a source and transmitting streams.
 Blinking slowly: The device is not
connected to a source.

O
ff:
N
ot
connected to
a source.
2 VIDEO LED  On: Stable video signal is detected.

Off: No video signal
is detected.
3 HDMI Connect to an HDMI source.
4 10G FIBER Connect to an optical fiber cable using the
optical transceiver provided.
5 Reset Button
(Recessed)
Use a pointed stylus to press this button to
restart or reset the device.
 Short press: To restart the device.
 Long press for more than 5 seconds: To
reset the device to factory defaults.
Note: When you reset the device, your custom
data is lost. Therefore, exercise caution in
using this button.
6 5V Connect to the power adapter provided for DC
5V power input.

8
Decoder
654321
No.
Name
Descrip
tion
1 SYSTEM
LED
 On: The device is connected to a display
but doesn’t receive any streams.
 Blinking quickly: The device is connected
to a display and is receiving streams.
 Blinking slowly: The device is not
connected to a display.
 Off: The device is connected to neither a
display.
2 VIDEO LED
 On: Video signal is being transmitted to the
connected display.

Off: No video signal is transmitted.
3 HDMI Connect to an HDMI display.
4 10G FIBER Connect to an optical fiber cable using the
optical transceiver provided.
5 Reset Button
(Recessed)
Use a pointed stylus to press this button to
restart or reset the device.
 Short press: To restart the device.
 Long press for more than 5 seconds: To
reset the device to factory defaults.
Note: When you reset the device, your custom
data is lost. Therefore, exercise caution in
using this button.
6 5V Connect to the power adapter provided for DC
5V power input.

9
Installation
Typical Application
HDMI 2.0 Extender
Features:
 4K Video transmission
 Zero latency from end to end
 Maximum extension distance is 300 meters over multi-mode fiber,
and 20km over single-mode fiber

LightSpeed Technologies
24551 Production Circle, Suite 2
Bonita Springs, FL 34135
www.lightspeed-tech.com
