Lightspeed SR804n User manual

SR804n Cable Modem
User Manual
VER: 1.0

SR804n Cable Modem User Manual
i
Contents
1Safety Introductions.........................................................................................1
2Overview.........................................................................................................2
2.1 Application ..........................................................................................2
2.2 Features..............................................................................................2
2.3 Standards Compatibility and Compliance ............................................3
3Hardware Description and Hardware Installation .............................................4
3.1 Hardware Description..........................................................................4
3.1.1 Front Panel...............................................................................4
3.1.2 Rear Panel ...............................................................................5
3.2 Hardware Installation...........................................................................5
3.2.1 Connecting the Device..............................................................5
4PC Network Configuration and Login...............................................................7
4.1 PC Network Configuration...................................................................7
4.2 Logging In to the SR804N Cable Modem ............................................9
5Web-Based Management..............................................................................10
5.1 Status................................................................................................10
5.1.1 Software .................................................................................10
5.1.2 Connection............................................................................. 11
5.1.3 Security ..................................................................................12
5.1.4 Diagnostics.............................................................................12
5.1.5 Event Log...............................................................................13
5.2 Basic.................................................................................................14
5.2.1 Setup......................................................................................14
5.2.2 DHCP.....................................................................................16
5.2.3 DHCPv6 .................................................................................17
5.2.4 LAN IPv6................................................................................18
5.2.5 DDNS.....................................................................................18
5.2.6 Backup ...................................................................................19
5.3 Advanced..........................................................................................21
5.3.1 Options...................................................................................21
5.3.2 IP Filtering ..............................................................................23
5.3.3 MAC Filtering..........................................................................23

SR804n Cable Modem User Manual
ii
5.3.4 Port Filtering...........................................................................24
5.3.5 Forwarding..............................................................................25
5.3.6 Port Triggers...........................................................................26
5.3.7 DMZ Host...............................................................................26
5.3.8 RIP Setup...............................................................................27
5.4 Firewall .............................................................................................30
5.4.1 Basic ......................................................................................30
5.4.2 Local Log................................................................................31
5.4.3 Remote Log............................................................................32
5.5 Parental Control................................................................................33
5.5.1 User Setup .............................................................................33
5.5.2 Basic ......................................................................................34
5.5.3 ToD Filter................................................................................35
5.5.4 Local Log................................................................................35
5.6 VPN ..................................................................................................36
5.6.1 Basic ......................................................................................36
5.6.2 IPsec......................................................................................36
5.6.3 Event Log...............................................................................37
5.7 Wireless............................................................................................38
5.7.1 Radio......................................................................................38
5.7.2 Primary Network.....................................................................40
5.7.3 Guest Network........................................................................43
5.7.4 Advanced ...............................................................................45
5.7.5 Access Control .......................................................................47
5.7.6 WMM......................................................................................48
5.7.7 Bridging..................................................................................49
5.7.8 Media .....................................................................................50
5.8 TR69.................................................................................................50
5.8.1 TR-069 client..........................................................................51
5.9 USB ..................................................................................................51
5.9.1 USB Basic..............................................................................52
5.9.2 Approved Devices...................................................................52
5.9.3 Storage Basic .........................................................................53
5.9.4 Storage Advanced...................................................................53
5.9.5 Media Server..........................................................................54

SR804n Cable Modem User Manual
iii
6Q&A ..............................................................................................................56

SR804N Cable Modem User Manual
1
1 Safety Introductions
Read the following information carefully before operating the device. Please follow
the following precaution items to protect the device from risks and damage caused
by fire and electric power:
Use volume labels to mark the type of power.
Use the power adapter that is packed within the device package.
Pay attention to the power load of the outlet or prolonged lines.An
overburden power outlet or damaged lines and plugs may cause electric
shock or fire accident. Check the power cords regularly. If you find any
damage, replace it at once.
Proper space left for heat dissipation is necessary to avoid any damage
caused by overheating to the device. The holes on the device are designed
for heat dissipation to ensure that the device works normally. Do not cover
these heat dissipation holes.
Do not put this device close to a place where a heat source exits or high
temperature occurs.Avoid the device from direct sunshine.
Do not put this device close to a place where is over damp or watery. Do not
spill any fluid on this device.
Do not connect this device to any PC or electronic product, unless our
customer engineer or your broadband provider instructs you to do this,
because any wrong connection may cause any power or fire risk.
Do not place this device on an unstable surface or support.

SR804N Cable Modem User Manual
2
2 Overview
The SR804N is targeted towards DOCSIS/EuroDOCSIS3.0 cable modem, eMTA
and gateway. With eight downstream channels and four upstream channels, it
supports up to 400Mbs/160Mbs. The SR804N incorporates a variety of industry
standard peripheral interfaces including dual IEEE802.3 10/100/1000Mbps
interface, one with integrated GPHY, and dual USB2.0 interfaces(Host and
Host/Device) with integrated PHYs. The SR804N supports WLAN access. It
complies with IEEE 802.11,802.11b/g and 802.11n specifications, WEP, WPA, and
WPA2 security specifications. The WLAN of the SR804N supports 2T2R.
2.1 Application
Home gateway
SOHOs
Small enterprises
Higher data rate broadband sharing
Audio and video streaming and transfer
PC file and application sharing
Network and online gaming
2.2 Features
User-friendly GUI for web configuration
Several pre-configured popular games. Just enable the game and the port
settings are automatically configured.
Compatible with all standard Internet applications
WLAN with high-speed data transfer rates of up to 300 Mbps, compatible
with IEEE 802.11b/g/n, 2.4GHz compliant equipment
IP routing and bridging
Network/port address translation (NAT/PAT)
Wireless LAN security: WPA, 802.1x, RADIUS client
Universal plug-and-play(UPnP)
File server for network attached storage (NAS) devices
Web filtering

SR804N Cable Modem User Manual
3
Remote update
System statistics and monitoring
2.3 Standards Compatibility and Compliance
Support application level gateway (ALG)
DOCSIS/EuroDOCSIS3.0
IEEE 802.3
IEEE 802.3u
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n

SR804N Cable Modem User Manual
4
3 Hardware Description and Hardware Installation
3.1 Hardware Description
3.1.1 Front Panel
The following table describes the indicators on the front panel.
Indicator
Color
Status
Description
Power
Green
On
The device is powered on and the device
operates normally.
Off
The device is powered off.
D/S
Green
On
CM has locked D/S frequency
Blink
CM scan D/S frequency
Off
Device is powered off.
U/S
Green
On
CM has locked U/S frequency
Blink
CM is range and scan U/S frequency
Off
Device is powered off or CM scan D/S
frequency.
Ethernet
1/2/3/4
Green
On
The Ethernet interface is connected.
Blink
Data is being transmitted through the
Ethernet interface.
Off
The Ethernet interface is disconnected.
WLAN
Green
On
WLAN is enabled.
Blink
Data is being transmitted through the
wireless interface.
Off
WLAN is disabled.
WPS
Green
On
Connection succeeds under Wi-Fi
Protected Setup.
Blink
Negotiation is in progress under Wi-Fi
Protected Setup.
Off
Wi-Fi Protected Setup is disabled.
USB
Green
On
The connection of USB flash disk has
established.
Off
No signal is detected.

SR804N Cable Modem User Manual
5
3.1.2 Rear Panel
The following table describes the interfaces or the buttons on the rear panel.
Interface
Description
Antenna
The antenna interface, for connecting the antennas.
Cable
RF cable port, for connecting HFC cable.
Reset
Press the button for at least 1 second and then release it. System
restores the factory default settings.
Eth 4~1
RJ-45 port, for connecting the router to a PC or another network
device.
USB 0~1
USB port, for connecting other USB storage devices.
Power
Power interface, for connecting the power adapter.
Warning:
Do not press the Reset button unless you want to clear the current settings. The
Reset button is in a small circular hole on the rear panel. If you want to restore the
default settings, please press the Reset button gently for 1 second with a fine needle
inserted into the hole and then release the button. The system reboots and returns to
the factory defaults.
Ne pas appuyer sur le bouton de réinitialisation, sauf si vous voulez effacer les
réglages actuels. Le bouton de réinitialisation est dans un petit trou circulaire sur le
panneau arrière. Si vous souhaitez restaurer les paramètres par défaut, se il vous
plaît appuyez sur le bouton de réinitialisation doucement pendant 1 seconde avec
une fine aiguille insérée dans le trou, puis relâchez le bouton. Le système redémarre
et revient aux valeurs par défaut.
3.2 Hardware Installation
3.2.1 Connecting the Device
Please follow the steps below to connect the device.
Step1 Connect the Cable port of the CMRG with HFC cable.

SR804N Cable Modem User Manual
6
Step2 Connect the Eth port of the CMRG to the network card of the PC via an
Ethernet cable.
Step3 Plug one end of the power adapter to the wall outlet and connect the
other end to the Power port of the CMRG.

SR804N Cable Modem User Manual
7
4 PC Network Configuration and Login
4.1 PC Network Configuration
Each network interface on the PC should either be configured with a statically defined
IP address and DNS address, or be instructed to automatically obtain an IP address
using the network DHCP server. SR804N provides a DHCP server on its LAN and it
is recommended to configure your LAN to automatically obtain its IP address and
DNS server IP address.
The configuration principle is identical but should be carried out differently on each
operating system.
The following displays the TCP/IP Properties dialog box on Windows XP.

SR804N Cable Modem User Manual
8
Figure 1 IP and DNS configuration
TCP/IP configuration steps for Windows XP are as follows:
Step1 Choose Start > Control Panel > Network Connections.
Step2 Right-click the Ethernet connection icon and choose Properties.
Step3 On the General tab, select the Internet Protocol (TCP/IP) component
and click Properties.
Step4 The Internet Protocol (TCP/IP) Properties window appears.
Step5 Select the Obtain an IP address automatically radio button.

SR804N Cable Modem User Manual
9
Step6 Select the Obtain DNS server address automatically radio button.
Step7 Click OK to save the settings.
4.2 Logging In to the SR804N Cable Modem
To log in to the SR804Ncable modem, do as follows:
Step1 Open a Web browser on your computer.
Step2 Enter http://192.168.100.1 (the default IP address of the SR804Ncable
modem) in the address bar. The login page appears.
Step3 Enter the user name and the password. The default Username is admin
and the Password is admin.
Step4 Click OK to log in to the Web page. Otherwise, please click Cancel to exit
the login page.
Figure 2 Login page
After logging in to the SR804N cable modem, you can query, configure, and modify
all the settings, and diagnose the system.

SR804N Cable Modem User Manual
10
5 Web-Based Management
This chapter describes how to use Web-based management of the Cable Modem,
which allows you to configure and control all of cable modem residential gateway
features and system parameters in a user-friendly GUI.
5.1 Status
Choose Status, and the submenus of Status are shown as below.
Figure 3 Submenus of Status
5.1.1 Software
Choose Status > Software , and the following page appears.

SR804N Cable Modem User Manual
11
Figure 4 Software page
This page displays information about the hardware version, software version, MAC
address, cable modem IP address, serial number, system “up” time, and network
registration status.
5.1.2 Connection
Choose Status > Connection and the following page appears.
Figure 5 Connection information
This page displays information about the RF upstream and downstream channels,
including downstream channel frequencies, upstream channel IDs, and upstream and
downstream signal power and modulation.

SR804N Cable Modem User Manual
12
This page also displays IP lease information, including the current IP address of the
cable modem, the duration of both leases, the expiration time of both leases, and the
current system time from the DOCSIS timeserver.
The information on this page can be refreshed at any time by clicking your web
browser‟s Refresh button.
5.1.3 Security
Choose Status > Connection and the following page appears.
Figure 6 Security configuration
To restore factory defaults, select the Yes radio button and click Apply. This will
cause the device to reset. The factory default password is “Broadcom” and is
case sensitive.
Note that you can also change the security password from this page by entering a
new password in both the New Password and Re-Enter New Password fields, and
the current password in the Current User ID Password field. Clicking Apply will
change the password. You do NOT have to restore factory defaults to change the
password.
5.1.4 Diagnostics
Choose Status > Diagnostics and the following page appears.

SR804N Cable Modem User Manual
13
Figure 7 Diagnostic information
Two utilities are provided for troubleshooting network connectivity: Ping and
Traceroute.
Ping allows you to check connectivity between the CMRG and devices on the LAN.
Traceroute allows you to map the network path from the CMRG to a public host.
Selecting Traceroute from the drop-down Utility list will present alternate controls for
the traceroute utility: To run either utility, make any changes to the default parameters
and select Start Test to begin. The window will automatically be refreshed as the
results are displayed in the Results table.
5.1.5 Event Log
Choose Status > Event Log to display the following page.

SR804N Cable Modem User Manual
14
Figure 8 Event Log information
This page displays the contents of the SNMP event log.
5.2 Basic
Choose Basic and the submenus of Basic are shown as below.
Figure 9 Submenus of basic
5.2.1 Setup
Choose Basic > Setup , and the following page appears.

SR804N Cable Modem User Manual
15
Figure 10 Setup configuration
Enter the information from the Required Information section as indicated:
1.If your ISP uses DHCP, select “DHCP” for the WAN Connection Type, and enter
Host Name and Domain name if required. OR
If your ISP uses static IP addressing, select “Static IP” for the WAN Connection
Type, and enter the information provided by your ISP for Static IPAddress, Static IP
Mask, Default Gateway, Primary DNS, and Secondary DNS.
2.Enter a unicast MAC address in the Spoofed MAC Address field. Your ISP may
require this to be your PC‟s MAC address. If not, you can simply supply the WAN
side MAC address of the router as your CPE and leave the spoofed MAC address
entry set to all 0‟s, since there will be no spoofing required.
3.Select theApply button. This will reset the CMRG.
At this point, the CMRG is configured for basic use. To connect to the Internet,
you must do the following:
1.Power up the CMRG and wait for it to register with the CMTS and obtain an
Internet-routable IP address
2.Get an IP lease from the internal DHCP server for each PC attached to the
CMRG.

SR804N Cable Modem User Manual
16
Note that communication on the LAN will work regardless of whether the WAN
connection provided by the cable modem is up. However, you will not be able to
access the Internet until the WAN connection is enabled and has an IP address.
Some configurations settings are retrieved only once from non-volatile storage
when the CMRG first powers up. One such setting is changing the Static WAN IP
address parameters. Any changes to these settings will force the CMRG to reset
so that the new configuration can be read from non-volatile storage.
When this mandatory reset is required, the web interface will notify as follows:
Figure 11 Reload page
Simply wait for the modem to reboot and click on the “RELOAD” link to re-enter the
web interface where you made your last change.
Most configuration items may be changed on the fly without a reboot.
5.2.2 DHCP
Choose Basic > DHCP,and the following page appears.
