Lightspeed 955 Access User manual

Quick Start Guide
Remove microphone
from charger. Press
the mute button to
unmute, hold near
your mouth and
begin speaking.
Remove microphone
from charger and press
the mute button to
begin speaking.
USING THE FLEXMIKE CHARGE MICROPHONES NIGHTLY
USING THE SHAREMIKE
ALIGN WITH
COLLARBONE
TALK (BLUE)
MUTE (WHITE)
TALK (BLUE)
MUTE (WHITE)
POWER/MUTE BUTTON
ADJUST
VOLUME
POWER/MUTE
BUTTON
ADJUST
VOLUME
NORMAL OPERATION
CHARGING IN PROGRESS
CHARGING COMPLETE
POWER STATUS
LIGHT
Place the microphones into the cradle
charger. The power status light will glow red
when it is charging.
It takes about 5-6 hours to fully charge the
microphone battery.
When charging is complete,
the power status light will
glow green.
CONNECT
POWER TO THE
955 ACCESS
Connect the power supply
to 955 Access and plug the
cord into an AC outlet.
955 Access will power
on and the power
light will glow.
POWER
12
MICROPHONE AUDIO INTONE AUDIO OUT
MINMAX MINMAX TREBLE BASS MINMAX
POWER LIGHT
Instructional Audio System
You can connect your 2nd microphone to your computer’s USB port to
enable a wireless 2-way audio link.
SEND AUDIO FROM THE COMPUTER to the 955 Access to ensure all
audio from the computer (videos, video conferencing, audiobooks,
music, etc) can be played through the Lightspeed 955 system and
speakers.
SEND AUDIO TO THE COMPUTER from the 955 Access to ensure the
teacher’s Flexmike and any student microphones are clearly picked up by
a video conferencing solution.
USING A WIRELESS AUDIO LINK
Connect the microphone
to your computer using a
USB-C cable. Open your
computer sound settings to
select FlexmikeAudio as the
microphone and speaker.
USB cable sold separately. Lightspeed oers
a USB-A to USB-C cable for sale (part #USBC)

Quick Start Guide
For complete operating instructions, go to www.lightspeed-tek.com/955N-usermanual (or scan the 2D barcode). QSUS-
PAIRING MICROPHONES TO 955 ACCESS
Your system is shipped with microphones and base units pre-paired for quick and easy use.
If you ever need to pair new components, follow this pairing process:
With a paperclip, push the register button on
the back of 955 Access.
From a powered o state, press and hold the
power button for five seconds until the mic
1 and mic 2 lights start flashing, then release
the button and let the pairing process finish.
The ”status” light on 955 Access will light up
indicating the pairing process is complete.
The mic 1 or mic 2 light on the microphone
will stay illuminated.
1
2
3
MIC 2
MIC 1
POWER BUTTON
AUDIO INPUTS
ADU
DC INPUT
24V/2.5A
PAGEFIRST INPUT SPEAKER OUTPUTS
1
REGISTER
2
Insert paper clip to press register button
POWER
12
MICROPHONE AUDIO INTONE AUDIO OUT
MINMAX MINMAX TREBLE BASS MINMAX
STATUS LIGHT
