Lighttoys Boom products V2 User manual

Boom products V2
user manual
WWW.LIGHTTOYS.CZ

1
Introduction
Congratulation! You have just received your new Pyro-
terra Lighttoys Boom device, designed for safe use of
your purchased pyrotechnic effect (PE) during fire per-
formances.
Please take a brief moment to read the following in-
structions in order to ensure safe and trouble-free use.
!CAUTION! Use of pyrotechnics is always subject to
local laws and regulations. Please, consult them be-
fore use.

2
Safety first!
Whenever using Pyroterra Lighttoys Boom products
always follow these basic safety rules:
1) Never leave a loaded Boom device unat-
tended.
2) The person responsible for the control and fir-
ing of pyrotechnics must ensure that it is safe
to do so.
3) The loading and positioning of all devices must
be done with safety foremost.
4) Always take into account all personnel, scen-
ery and other objects on site. Take notice and
ensure that all fabrics in close proximity are
non-flammable. Beware: PE sparks can re-ig-
nite already burned-out fire spinning equip-
ment!
5) All pyrotechnics are potentially dangerous and
must be used strictly in accordance with the
manufacturer’s instructions and any relevant
data sheets.
6) Pyrotechnic devices must only be used by
competent adults. If misused they can be very
dangerous and cause serious injuries.

3
Proper use
In order to use Boom devices you need to purchase a
pyrotechnics effect (PE). We recommend stage effects
called: gerbs or silver fountains.
To obtain suitable PE we suggest contacting your local
pyrotechnic resellers, or search for suppliers on the in-
ternet. Pyroterra had good experience with the Le
Maitre Ltd. pyrotechnics provider: http://www.le-
maitreltd.com/.
BASIC TERMS
charging connector
main switch
trigger
status LED
terminal
pyrotechnics effect (PE)
2 ignitor wires
exhaust nozzle
metal contacts

4
How to attach PE to Boom
device
1) Remove any paper or plastic wrap from PE, in
order to prevent the PE from getting loose
during spinning.
2) Firmly attach the PE to the end of the Boom
device using strong adhesive tape (i.e. duct
tape). Make sure that the PE’s exhaust nozzle
is pointing away from the Boom device.
Note: Do not use any metal or plastic fasteners or
O-rings, in case of PE failure, they could shatter to
pieces and cause injury.
3) Optional: for Boom devices with multiple PEs
(Boom Stick, Fans, Dragon) switch on the main
switch and individually check each PE (one-by-
one) by plugging the metal contacts of the 2
ignitor wires into the nearest terminal. Be
careful not to touch the trigger and always
point the PE from your body.

5
The status LED should shine in red color. If not,
the ignitor in the PE is faulty and the PE must
be replaced. Switch off the main switch after
the test is over.
Note: To open the terminal, press on the plastic tabs
lightly.
4) Attach the ignitor wires of all the PEs to their
nearest terminals. Make sure the metal con-
tacts are not exposed and the 2 wires don’t
touch each other (it would create a short-cir-
cuit and the PE wouldn’t work).
5) To verify the connection of PE, turn on the
main switch and make sure the status LED is
shining in red color.
The Boom device is now ready for your spectacular
performance by pressing the trigger button!
Note: After the performance make sure to disconnect
all the PE wires from the terminals in order to prevent
any potential damage to the battery.

6
Maintenance and charging
Charging
The newer Boom device V2 is charged by any standard
5V USB charger via its USB-C charging connector.
The charging is indicated by the blue color of the status
LED. Once the charging is finished, the status LED stops
shining.
A fully charged battery, will last up to about 30 igni-
tions. We recommend charging the Boom device every
2-3 months, even if the device is not used. It’s also
good practice to charge before every major show.
The older Boom device V1 is charged via a proprie-
tary Lighttoys charger with a 3.5mm jack connector.
Maintenance
Periodically clean the terminal contacts mechanically
to protect them from chemical corrosion and pyro-
technic residue. You can also use damp cloth with iso-
propyl alcohol to do so.

7
Warranty and service
All Pyroterra Lighttoys Boom products are covered by
one year warranty. The warranty will be voided should
the product get in contact with water, misused or im-
properly maintained.
In case of any issue or further questions please refer
to our support page first:
www.lighttoys.cz/support.
You can also contact us via email at:
[e-mail]
Disclaimer
Usage of any of Pyroterra Lighttoys Boom products is
entirely at your own risk and Pyroterra Lighttoys do
not take any responsibility or liability for any potential
accidents, injury or damage.

8
Products
BOOM POI V2
Specially designed for pyro effect during poi spinning.
Used as a pair, each Boom Poi has one PE attached.
Weight:
122g (4.3oz) / 1 piece
Length:
28cm (11.0in)
No. of ignitions:
Up to 30 ignitions
Charging time:
1 hour / 1 piece
Battery:
Li-ion 3.7V
BOOM STICK V2
Specially designed for pyro effect on staff. 2 pieces of
PE are attached on each end of the staff.

9
Weight:
234g (8.3oz)
Length:
100cm (39.4in)
No. of ignitions:
Up to 30 ignitions
Charging time:
1 hour
Battery:
Li-ion 3.7V
BOOM FANS V2
Specially designed for greatest pyro output. You can
attach up to five pieces of pyrotechnics on one fan.
Weight:
380g (13.4oz) / 1 piece
Length of rod:
31cm (12.2in)
Center ring:
Diameter 8cm (3.1in)

10
No. of ignitions:
Up to 15 ignitions
Charging time:
1 hour / 1 piece
Battery:
Li-ion 3.7V
BOOM DRAGON STAFF V2
Specially designed for pyro effect during contact staff
spinning. 3 pieces of PE are attached on each end of
the staff.
Weight:
600g (21.6oz)
Length:
150cm (59.1in)
Diameter:
24mm (0.9in)
No. of ignitions:
Up to 15 ignitions
Charging time:
1 hour / 1 piece
Battery:
Li-ion 3.7V

CE CERTIFICATION
The device has been tested for electromagnetic com-
patibility and fulfills the CE- Norms.
The Boom products are powered by extra low voltage
(ELV), and meets the requirements set by DIN EN
61140 (VDE 0140-1) Safety class III.
Team Pyroterra Lighttoys
wishes you many hours of
spinning enjoyment...
