LightwaveRF JSJS LW380 Installation manual

Basic Adapter On/O Socket
Operation Manual
Model No: JSJS LW380
OVERVIEW:
connect
LightwaveRF
IMPORTANT: PLEASE RETAIN THESE INSTRUCTIONS
FOR FUTURE REFERENCE AND FOR GUIDANCE ON
THE ASSOCIATION OF REMOTE HANDSETS. FOR
HELP AND SETUP GUIDANCE PLEASE VISIT
www.lightwaverf.com
It is important to install this product in accordance
with the tting instructions below. Failure to do so
may render your guarantee void.

SETUP
Pairing using LEARNING MODE:
1.Ensure the adaptor is plugged in and ready with the
wall socket turned on.

2. Once plugged into the wall the adaptor will enter
LEARNING MODE for a duration of 5 seconds, this will
be illustrated by the red LED ashing on and o.
3. Whilst the adaptor is in learning mode, press the
desired ‘ON’ button on the remote; the LED on the
adaptor will stop blinking and any lamp plugged in
and turned on will ash twice to indicate that it is
paired.

NOTE: Learning Mode lasts for only 5 seconds; if no
signal is received from a remote handset during this
time then the adapter will automatically exit learning
mode without pairing the device.
Unpairing Remotes and clearing the Switch
memory
Removing single device:
1. Remove the plug adaptor from the wall socket and
after 5 seconds replace it.
2. Once plugged into the wall the adaptor will enter
LEARNING MODE for a duration of 5 seconds, this will
be illustrated by the red LED ashing on and o.
3. Whilst the adaptor is in leaning mode, on the
Remote press the‘OFF’ buttons of the paired channel
that needs to be unpaired; the LED on the adaptor will
stop blinking and any lamp plugged in and turned on
will ash twice to indicate that it is un-paired.

OPERATION
Switch ‘ON/OFF’ with Remote Handset
Press ‘ON’ on the handset to turn on adaptor(s)
paired to the selected channel.
Press ‘OFF’ on the handset to turn o adaptor(s)
paired to the selected channel.
NOTE: One channel can be programmed to turn
on more than one socket with a single key press to
create a group.

Changing the Remote Battery
1. Pull out the battery holder.
2. Remove old battery and replace with a fresh one.
3. Replace battery holder into transmitter
NOTE:
• Connect correctly and securely
• Do not recharge
• Keep away from children
• Do not swallow (If swallowed, seek medical advice
immediately)
• Please dispose of used batteries responsibly

Birmingham Science Park Aston
Faraday Wharf
Holt Street
Birmingham
B7 4BB
Tel: [phone]
Email: [e-mail]
SPECIFICATION
RF frequency: 433.92 MHz
Input rating : 220-230V~ 50Hz
Load : 13A
