LIGHTWEIGHT MEILENSTEIN User manual

Meilenstein tubular Disc
Meilenstein evo clincher Disc
WegWeiser evo clincher Disc
FernWeg evo clincher Disc
Owner's manual
403296 2019-03

Chip number Dealer

CONTENTS
3
ENGLISH
GRAPHICS
INTRODUCTION
Preface. . . . . . . . . . . . . . . . . 12
Explanation.of.symbols. . . . . . . 12
Lightweight.online. . . . . . . . . . 13
Your.wheel. . . . . . . . . . . . . . . 13
Registration. . . . . . . . . . . . . . 13
TECHNICAL DATA
Wheels. . . . . . . . . . . . . . . . . 14
Hubs.. . . . . . . . . . . . . . . . . . 15
SAFETY
Intended.use. . . . . . . . . . . . . . 16
In.your.own.interest. . . . . . . . . . 16
Fundamental.safety.precautions . . 16
Assembly.&.maintenance .. .. .. .. ..16
On.the.road. . . . . . . . . . . . . . 17
Transport.&.storage. . . . . . . . . 18
Safety.label .. .. .. .. .. .. .. .. .. .. .. .. .. ..18
Disposal.. . . . . . . . . . . . . . . .18
PREPARATORY WORK & ASSEMBLY
Before.every.ride.. . . . . . . . . . .19
Installing.wheel.adapters. . . . . . 19
Installing.the.cassette. . . . . . . . 19
Installing.disc.brake.rotor .. . . . .19
Fitting.the.valve.extension.. . . . .20
Adhesion.of.tubular.tyres. . . . . . 20
Installing.clincher.tyres. . . . . . . 21
Installing.the.wheels.. . . . . . . .22
Computer.magnet. . . . . . . . . . 22
RIDING
Before.every.ride.. . . . . . . . . . .23
On.the.road .. .. .. .. .. .. .. .. .. .. .. .. .. ..24
MAINTENANCE
Regular.maintenance .. .. .. .. .. .. .. ..25
Cleaning. . . . . . . . . . . . . . . . 25
Hubs. . . . . . . . . . . . . . . . . . 25
Rotor.replacement.. . . . . . . . . .26
RULES
Liability. . . . . . . . . . . . . . . . . 28
Service. . . . . . . . . . . . . . . . . 29
Crashreplacement. . . . . . . . . . 29
Fair.deal.promise.. . . . . . . . . .29

4
GRAPHICS
F
E
R
N
W
E
G
E
V
O
F
E
R
N
W
E
G
E
V
O
A1 A2
B1 B2

GRAPHICS
5
C1 C2
34
1
2
C3
1

6
GRAPHICS
D1
40 N·m (354 lbf·in) max.
D2
4
2
13
40 N·m (354 lbf·in) max.
D3
1
D4

GRAPHICS
7
E1
1
1
1– 2 mm min. !
1–2 mm min.
E2
5
2
4
3
5 mm min.
E3
2 mm min.
E4
1

8
GRAPHICS
F1
Shimano®/SRAM®:
Campagnolo®:
SRAM® XDR:
G1

GRAPHICS
9
40 N·m (354 lbf·in) max.
G2
31
2
G3
G4
3
4
65
78
G5

10
GRAPHICS
G8
3
G6
65
8
4
7
G7
9
9

GRAPHICS
11

12
INTRODUCTION
PREFACE
Congratulations.and.thank.you.–.you.have.selected.the.best.wheels.
in.the.world ..
Handmade.–.made.in.Germany
This.manual.is.an.integral.component.of.your.Lightweight.product.
and.it.provides.you.with.important.information.regarding.the.safe.
operation.of.your.Lightweight.wheels
You.can.find.the.illustrations.referred.to.in.this.manual.in.the.
graphics.section.in.the.fold-out
The.safety.of.our.customers.is.very.important.to.us .Please.read.this.
manual.carefully.before.installing.your.wheels.or.riding.on.them.for.
the.first.time .
Non-observance of the information contained in this
manual could result in a fatal or serious accident.
Our.information.is.there.for.a.reason.–.our.interest.in.your.personal.
safety!
Read.and.observe.all.assembly,.maintenance.and.usage.instructions.
and.please.remember.that.even.the.best.product.can.fail.if.it.is.im-
properly.treated ..
This.applies.for.components.from.other.manufacturers.whose.
.products.are.used.on.your.bicycle.(tyres,.quick.release.skewers,.
brakes.etc ) ..
Read.and.observe.all.user.instructions
Keep.this.manual.for.other.users.of.your.wheels .Make.sure.that.all.
users.read,.understand.and.observe.this.manual
If.you.ever.sell.or.give.away.your.wheels,.this.manual.should.be.
transferred.to.the.new.owner
We.hope.you.get.a.lot.of.enjoyment.from.your.Lightweight.wheels
Your Lightweight Team
Explanation of symbols
You.will.encounter.the.following.symbols.and.references.in.this.
manual:
.)The.index.finger.instructs.you.to.perform.a.particular.action
ÎÎThe.arrow.indicates.the.consequences.of.your.action.or.important.
prerequisites
 This.shows.additional.information.or.tips
(3).….refers.to.an.item.number.in.an.illustration
[A2].….refers.to.an.illustration.in.the.graphics.section
.This.content.refers.only.to.Lightweight.clincher.wheels.(Clincher)
.This.content.refers.only.to.Lightweight.tubular.tyre.wheels.(Tubular)
.This.content.refers.only.to.the.corresponding.series.or.
its.derivatives
The WARNING message indicates a hazardous situation
which, if not avoided, could result in a fatal or serious injury.
The CAUTION message indicates a hazardous situation
which, if not avoided, could result in minor or moderate injury.
The NOTICE message warns of a risk of material damage.
•Î The.dot.indicates.how.to.avoid.a.hazardous.situation.or.a.risk.of.
material.damage

INTRODUCTION
13
ENGLISH
Lightweight online
Visit.www.lightweight.info.for.information.that.you.will.find.interest-
ing .
Accessories,.spare.parts.and.clothing.in.the.shop,.frequently.asked.
questions.in.the.FaQs,.interesting.facts.in.neWs & press.and.much.
more
We.look.forward.to.meeting.you.there!
YOUR WHEEL
The.illustrations.in.this.manual.may.be.different.from.your.Light-
weight.wheel,.but.the.required.steps.are.the.same.for.all.wheel.
types,.unless.otherwise.specified
 The.model.name.of.your.wheel.is.on.the.hub.cover .[A1]
Registration
Every.Lightweight.wheel.is.provided.with.an.integrated.chip.with.a.
10-digit.code.–.the.chip.number .This.allows.every.single.wheel.to.
be.individually.registered
 Only.Lightweight.products.registered.by.the.original.owner.or.
reregistered.by.subsequent.owners.enjoy.our.service.provisions!
 To.register.your.Lightweight.wheels.or.change.the.registration,.
you.can.find.the.required.chip.numbers.either.on.the.external.
packaging,.in.the.rim.well.or.on.the.sticker.fixed.to.one.of.the.
protective.covers.of.the.wheel;.alternatively,.your.specialist.shop.
may.have.already.attached.it.to.the.appropriate.place.on.the.first.
page.of.this.manual .[A2]
.)Register.or.transfer.the.registration.of.your.Lightweight.wheels.at.
www.lightweight.info >>> service
ÎÎOur.service.provisions.are.available.to.you .
You.will.also.find.information.on.our.extended.service.offers.here

14
TECHNICAL DATA
*. Street.=.paved.or.asphalted.surface.·.Allround.=.street.and.cross-country
**. Approved.total.weight.=.rider.+.bicycle.+.luggage
WHEELS Spokes Approved use Approved
disc brake rotor
Approved
total weight
Approved
tyres
SERIES Ø max.
* (mm/inch) (kg/lb)**
MEILENSTEIN
FW 20
Allround
160./.6″
120/265 Tubular.tyres..
(Tubular)
RW 20 160./.6″.·.140./.5 5″
MEILENSTEIN EVO
FW 20
Allround
160./.6″
120/265 Clincher.tyres,.Tubeless..
(Clincher)
RW 20 160./.6″.·.140./.5 5″
WEGWEISER EVO
FW 20 160./.6″
RW 20 160./.6″.·.140./.5 5″
FERNWEG EVO
FW 20
Street
160./.6″
RW 20 160./.6″.·.140./.5 5″

TECHNICAL DATA
15
ENGLISH
 All.Lightweight.products.are.the.result.of.manual.labour .Deviations.in.colour.
and.surface.finish.are.characteristic.features.resulting.from.this.high.quality.
manufacturing.procedure .
For.more.details.and.information.on.the.manufacture.of.your.Lightweight.
wheels.please.consult.www.lightweight.info
*. The.size.of.the.supplied.right.rear.wheel.adapters.is.selected.by.you,.your.retailer.or.the.manufacturer.of.your.bicycle .
If.you.wish.to.install.your.wheel.in.dropouts.with.different.dimensions,.you.will.need.right.rear.wheel.adapters.with.correspondingly.different.dimen-
sions;.these.are.available.from.your.retailer.or.directly.from.CarbonSports
HUBS
Dimension* Rotor Brake disc holder Fixing*
wheel
Ø
(mm) (mm)
DT SWISS® 240s
FW 100 –
Shimano® Centerlock®
M31×1
9.(Thru.Bolt)
12.(Thru.Axle)
15.(Thru.Axle)
RW
135
Shimano®.11s
or.
SRAM®.XDR.12s
or.
Campagnolo®.C9./.C10./.C11./.C12
10.(Thru.Bolt)
12.(Thru.Axle)
142

16
SAFETY
INTENDED USE
Any use other than that intended can lead to accidents
resulting in fatal or serious injury.
Your.Lightweight.clincher.wheels.for.disc.brakes.(T/C.DISC).are.
designed.solely:.
ÎÎfor.installation.on.standard.race.and.time.trial.bikes.which.are.
designed.to.have.disc.brakes.fitted
ÎÎfor.use.with.disc.brakes
ÎÎfor.use.with.Thru.Bolt.or.Thru.Axle
ÎÎfor.the.installation.of.disc.brake.rotors.that.comply.with.the.
.Shimano®.Centerlock®.standard
ÎÎ.for.installation.(adhesion).of.tubular.tyres
ÎÎ.for.the.installation.of.clincher.or.foldable.clincher.tyres.or.
tubeless.tyre.systems.that.comply.with.the.ETRTO*.standards ..
(*.European.Tyre.and.Rim.Technical.Organisation)
ÎÎin.accordance.with.the.applicable.approvals.–see.Technical data,.
page.14
IN YOUR OWN INTEREST
Always.remember.that.riding.a.bicycle.involves.potential.danger.for.
both.yourself.and.other.road.users,.as.well.as.for.your.bicycle.and.
its.components .
Even.if.protective.equipment.and.safety.devices.are.used,.accidents.
resulting.in.death.or.serious.injury.can.still.occur .
Furthermore,.improperly.performed.assembly.and.maintenance.
work.could.also.result.in.a.loss.of.your.rights.with.regard.to.product.
liability.and.service!
Always.ensure.your.bicycle.is.maintained.in.a.flawless.condition .
Care.and.maintenance.will.prolong.the.service.life.of.your.bicycle.
and.its.components.and.improve.your.personal.safety!
You.should.also.rely.on.your.common.sense.and.avoid.any.unrea-
sonable.behaviour!
FUNDAMENTAL SAFETY PRECAUTIONS
Assembly & maintenance
Risk of accident due to damage wheels resulting from un-
professionally performed assembly and maintenance work.
•Î Do.not.overestimate.your.technical.ability .All.assembly.and.main-
tenance.work.should.be.performed.by.a.specialist.workshop.for.
bicycles .This.is.the.only.way.to.ensure.that.work.is.conducted.in.a.
professional.manner
•Î Always.maintain.all.specified.min /max .values.–see.Technical
data,.page.14
•Î When.conducting.assembly.steps.that.require.a.specific.tighten-
ing.torque,.always.use.an.appropriate.torque.wrench.that.is.de-
signed.for.the.tightening.torque.specified
•Î .Use.tubeless.tyre.systems.exclusively.with.wheels.of.the.EVO.
series .
Risk of accident due to tyre failure.
•Î Only.ever.use.high.quality.and.undamaged.tubular.tyres.and.suit-
able.adhesive
•Î Your.tubular.tyres.should.only.be.installed.(adhesion).by.an.expert.
bicycle.mechanic
•Î Observe.the.min /max .inflation.pressure.values.specified.by.the.
manufacturer
Risk of accident due to a bursting tyre.
•Î Never.use.latex.inner.tubes
•Î Never.exceed.the.tyre.inflation.pressure.approved.by.us,.because.
the.tyre.inflation.pressure.will.increase.considerably.as.a.result.of.
the.temperature.created.by.rolling.resistance.and.possibly.high.
ambient.temperature.–see. Installing clincher tyres,.page.21

SAFETY
17
ENGLISH
Greatly increased tyre wear.
•Î Do.not.combine.a.tubeless.tyre.system.with.an.inner.tube.other.
than.in.case.of.breakdown.and.then.only.for.a.short.distance
Corrosion and material damage due to penetration of
water.
•Î Never.use.a.pressure.washer.or.steam.cleaner.to.clean.your.
bicycle,.as.the.seals.of.your.bicycle.components.are.unable.to.
withstand.the.pressure .
Even.if.you.use.a.hose,.be.careful.–.never.aim.the.hose.directly.at.
the.bearing.components .[F1]
Corrosion on surface of your Lightweight components due
to incorrect cleaning.
•Î Never.use.aggressive.solvents.(e g .paint.thinner,.nitro.etc )
•Î It.is.best.to.use.water.and.standard.paintwork.cleaning.products
•Î Isopropanol,.spirits.or.petrol.may.be.used.carefully;.however,.
avoid.excessive.wiping.and.long.exposure.times.and.also.any.
contact.with.the.rim.decor
 We.recommend.our.specially.developed.Lightweight.cleaner For
brake track areas.for.cleaning,.available.from.your.specialist.
shop.or.directly.from.CarbonSports.–.but.avoid.all.contact.with.
the.rim.decor!
On the road
Risk of accident through damaged wheels.
•Î Never.exceed.the.maximum.approved.total.weight.–see.Technical
data,.page.14
•Î Avoid.riding.through.potholes.or.over.edges.and.steps
•Î Always.check.your.wheels.before.every.ride,.after.a.violent.shock.
and.after.a.blow-out.(dents,.scratches,.cracks,.large.areas.of.
abrasion.etc ) .Send.us.your.wheels.for.inspection.before.using.
them.again.if.there.is.visible.damage.or.if.you.have.any.doubts.
about.their.condition .
.In.particular,.always.check.the.sensitive.rim.flange.(1).for.dam-
age.before.every.ride,.after.every.hard.impact.and.after.every.
blow-out.(dents,.cracks.etc ) .[C3]
•Î Never.ride.with.your.wheels.in.combination.with.a.rim.brake
•Î Never.ride.with.damaged.wheels
•Î Never.continue.using.your.bicycle.after.a.serious.crash .
If.such.a.case.occurs,.send.your.wheels.to.us.for.inspection.even.
if.no.external.damage.is.visible ..
In.your.own.interest.you.should.deal.in.the.same.way.with.all.
components.on.your.bicycle.that.are.produced.by.other.manufac-
turers
•Î Do.not.use.your.wheels.below.-10.°C.(14.°F).or.above.45.°C.
(113.°F).ambient.temperature
Risk of accident caused by erratic riding or improper
equipment.
•Î Pay.particular.attention.when.riding.in.high.winds .
Front.wheels.are.more.sensitive.to.side.winds.from.a.rim.height.
of.30.mm.–.the.higher.the.rim.the.greater.the.sensitivity .
Unwanted.steering.movements.may.result
•Î Always.observe.the.traffic.regulations.of.the.country.where.you.
are.riding.your.bicycle
•Î When.riding.your.bicycle.always.wear.a.high.quality.cycling.
.helmet.(e .g .ANSI.certified),.that.is.in.excellent.condition.and.
close-fitting.but.not.restrictive.clothing
•Î Only.ride.your.bicycle.if.you.are.in.good.physical.condition.and.
your.bicycle.and.all.its.components.are.working.perfectly

18
SAFETY
Transport & storage
Risk of accident through damaged wheels.
•Î Protect.your.wheels.from.lateral.pressure .This.applies.particu-
larly.during.transport.and.particularly.to.disc.wheels.(runDkurs
Disc,.autobahn).and.also.for.the.FernWeg.series
•Î Do.not.store.your.wheels.below.-15.°C.(5.°F).or.above.55.°C.
(131.°F).ambient.temperature
The covers of the Lightweight Aero
wheels consist of 1 layer of carbon with reduced wall thickness and
they can be easily damaged.
•Î Do.not.hang.your.bicycle.on.a.hook.by.the.Aero.front.or.rear.
wheel
•Î When.transporting.your.bicycle.on.a.car.rack,.make.sure.that.the.
straps,.hooks.etc .cannot.damage.the.covers.–.use.suitable.pad-
ding.where.necessary.to.ensure.that.any.pressure.is.evenly.dis-
tributed.over.a.wide.area .[B1]
SAFETY LABEL
.A.safety.label.is.placed.on.both.sides.of.the.rim.on.every.Light-
weight.clincher.wheel .[B2]
Replace.the.safety.labels.if.they.become.illegible.or.damaged
Send.us.a.postage-paid.return.envelope.with.your.address .You.will.
then.receive.the.desired.safety.labels.at.no.extra.charge
DISPOSAL
If.defective.or.no.longer.in.use,.you.can.dispose.of.your.wheels.with.
your.non-recyclable.waste.or.domestic.refuse.or.ask.a.local.waste.
disposal.company.for.other.ways.of.disposal.(e g .recycling)
You.can.also.send.your.wheels.to.us .They.will.then.be.disposed.of.in.
a.way.that.is.harmless.to.the.environment.–see.Crashreplacement,.
page.29

PREPARATORY WORK & ASSEMBLY
19
ENGLISH
BEFORE EVERY RIDE
Risk of accident through damaged wheels.
•Î Read.and.observe.all.assembly.and.maintenance.instructions,.
including.those.specified.in.the.user.instructions.provided.by.
other.manufacturers.whose.products.are.used.on.your.bicycle.
(tyres,.Thru.Bolt.or.Thru.Axle,.cassettes,.brakes.etc )
•Î Do.not.overestimate.your.technical.ability.–.all.assembly.and.
maintenance.work.should.be.performed.by.a.specialist.workshop.
for.bicycles .This.is.the.only.way.to.ensure.that.work.is.conducted.
in.a.professional.manner
•Î Check.the.rims.and.spokes.of.your.wheels.for.damage.(dents,.
scratches,.abrasion.extending.over.a.large.area.etc )
•Î Never.ride.with.damaged.wheels
Installing wheel adapters
.)Make.sure.that.the.supplied.wheel.adapters.correspond.to.the.
dimensions.of.your.Thru.Bolt/Thru.Axles.as.well.as.the.dropouts.
of.your.bicycle.–see.Technical data,.page.14
.)Allocate.the.supplied.wheel.adapters.–.front.wheel,.right/left;.
rear.wheel,.right/left [C1]
Risk of accident due to rotor failure.
•Î Only.use.original.DT.Swiss.special.freewheel.grease.to.lubricate.
the.components .It.is.available.from.your.specialist.shop.or.di-
rectly.from.CarbonSports
.)Lightly.lubricate.the.wheel.adapter.–.particularly.inside [G7]
Loss of function – rotor jams.
•Î Do.not.replace.the.different.wheel.adapters.of.the.Campagnolo®,.
SRAM®.XDR.and.Shimano®.rotors
•Î Make.sure.that.the.outer.diameter.(Ø).of.the.wheel.adapter.accu-
rately.matches.the.inner.diameter.of.the.rotor.used [G7]
.)Put.the.adapters.onto.the.axle.and.press.on.by.hand.until.they.
noticeably.lock.in.place
Installing the cassette
 The.rotor.of.the.Lightweight.rear.wheels.can.be.replaced.in.the.
event.of.a.system.change.(Campagnolo®.<–>.SRAM®.XDR.<–>.
Shimano®).–see.Rotor replacement,.page.26
 If.necessary,.you.can.get.a.suitable.spoke.protector.from.your.
specialist.dealer .[D1]
.)Ensure.that.your.cassette.complies.with.the.rotor.type.of.your.
rear.wheel
 A.Shimano®.11-speed.road.rotor.(1).can.have.a.Shimano®/SRAM®
10s.cassette.(2).installed
In.this.case.use.a.spacer.(3).(t.=1 9.mm) .[D2]
 A.Campagnolo®.C9,.C10,.C11.or.C12.cassette.can.be.installed.on.
the.Campagnolo®.rotor.without.a.spacer
 A.SRAM® 12s.XDR.cassette.can.be.installed.on.the.SRAM® XDR.
rotor.without.a.spacer
.)Follow.the.instructions.of.the.manufacturer.when.installing.your.
cassette
.)Tighten.the.lock.ring.(4).with.tightening.torque.specified.by.the.
manufacturer.–.max. 40 N·m (354 lbf·in) .[D2]
Installing disc brake rotor
Risk of accident due to component failure.
•Î Exclusively.use.disc.brake.rotors.with.an.approved.diameter.–see.
Technical data,.page.14
•Î Exclusively.use.suitable.lock.rings.for.securing.your.disc.brake.
rotors.–see.Technical data,.page.14
.)Follow.the.instructions.of.the.manufacturer.when.installing.your.
disc.brake.rotors
.)Tighten.the.lock.ring.(1).with.tightening.torque.specified.by.the.
manufacturer.–.max. 40 N·m (354 lbf·in) .[D3]

20
PREPARATORY WORK & ASSEMBLY
Fitting the valve extension
.)Screw.the.valve.insert.(1).using.the.supplied.tool.(2).out.of.the.
valve.shaft,.which.may.be.too.short.(3) .[C2]
.)Screw.the.Lightweight.valve.extension.(4).into.the.valve.shaft.(3)
.)Screw.the.valve.insert.(1).into.the.valve.extension.(4)
Adhesion of tubular tyres
Rim width, outer
(mm)
Approved tyre sizes
min.–max.
24 0 24.–.34
Rim height
(mm)
Required valve length
(mm)
–48 60
–60 80
–80 100
Risk of accident due to tyre failure.
•Î Only.ever.use.high.quality.and.undamaged.tubular.tyres,.such.as.
the.Lightweight.tubular.tyres.from.Continental®,.and.suitable.
adhesives
•Î Use.puncture.protection.sealant .We.recommend.the.product.
from."ZEROFLATS"
•Î Your.tubular.tyres.should.only.be.installed.(adhesion).by.an.expert.
bicycle.mechanic
•Î Follow.all.the.processing.instructions.provided.by.the.adhesive.
and.tubular.tyre.manufacturer
•Î Observe.the.min /max .inflation.pressure.values.specified.by.the.
manufacturer
 The.lower.the.inflation.pressure.or.tyre.width.the.higher.the.risk.
of.a.pinch.flat
Risk of damage to health caused by improper handling of
solvents and adhesives.
•Î Follow.all.the.manufacturer's.safety.instructions
Only use suitable plastic tyre levers when removing your
tyres – do not use metal tyre levers under any circumstances. Avoid
excessive levering.
.)Before adhering.your.tubular.tyre,.install.the.valve.extension.if.
required,.because.this.will.not.be.possible.later.–see.Fitting the
valve extension,.page.20
.)Prior.to.adhesive.bonding,.fill.your.tubular.tyre.with.puncture.pro-
tection.sealant
.)Use.suitable.adhesive .We.recommend.the.tubular.tyre.cement.
produced.by.Continental®.(orange.for.aluminium.rims)
.)Only.roughen.the.rim.well.of.brand.new.wheels.carefully.by.using.
fine.sandpaper.(240.grit.or.finer)
.)Clean.the.rim.well.thoroughly
.)Adhere.the.tubular.tyre.in.accordance.with.the.instructions.pro-
vided.by.the.adhesive.and.tubular.tyre.manufacturer
