Limerick PJ's Comfort User manual

Owners Manual

Overview
Using your new PJ’s Comfort Multi-
User hospital grade breast pump
READ THE ENTIRE MANUAL BEFORE OPERATING PUMP
*This overview is not intended to provide complete user instructions.
1. Sanitize before use See page 8
2. Pump setup and assembly See page 11
3. Accessory kit setup and assembly See page 19
4. Using pump See page 14
5. Expressing milk See page 24
6. Storing milk See page 25
7. Accessory kit care and cleaning See page 31
8. Pump care and cleaning See page 30
This manual is also available at limerickinc.com/support
PJ’s Comfort Owner’s Manual ©2019

Symbols and the meaning
Warning!
Caution!
Sterile
Class B
Caution: If the accessory kit is not labeled sterile, see page
10-5 for instructions on sanitizing the accessory kit. Sanitizing the
accessory kit needs to be done before the rst time you use it. After
the rst time you use the pump, the accessory kit will only need a
simple cleaning procedure found on page 31.

Contents
Health and Safety 1
Important Safeguards 1
Pump Components 4
Accessory Kit Components 5
Introduction to Your
PJ’s Comfort Breast Pump 6
Pump Description 6
Purpose of PJ’s Comfort multi-user hospital grade breast pump 6
Reasons to use a breast pump 6
Benets of using PJ’s Comfort electric breast pump 7
Accessory Kit Sanitizing 8
Before using the accessory kit for the rst time 8
Disassemble the following parts as shown and boil them according
to the instructions 9
Pump Setup and Assembly 11
Controls and Features 12
Cycle speed/power adjustment knob 12
Vacuum adjustment knob 13
Secondary Features 14
Find your comfort settings 14
Recommended settings for rst-time use 14
Adjusting vacuum strength and cycle speed 14
Turning off pump 15

Display Functions and Indications 16
Functions 16
Timer display 16
Problem indication 16
Flashing 1, 2, 3 Lights 16
Flashing 4, 5, 6 Lights 17
Flashing 7, 8, 9 Lights 17
Flashing 10, 20 Lights 17
Other problems that may occur without a fault message 17
Situation “A” 17
Situation “B” 18
Situation “C” 18
Accessory Kit Setup and Assembly 19
Double Pumping Setup 22
Expressing milk from both breasts 22
Single Pumping Setup 23
Expressing milk from one breast at a time 23
Expressing Your Milk 24
Preparing to express breast milk 24
Testing vacuum cycling and suction before Pumping 24
Expressing breast milk 25
Storing breast milk for term infants at home or away 26
Pumping Methods and Patterns 27
Double pumping 27
Single pumping 27
Multiple User Instructions 29
Do not share these parts. 29

Pump Care and Cleaning 30
When to change the lter 30
How to change the lter 30
Transportation Information 30
Accessory Care and Cleaning 31
After each use 31
Wash these parts 32
Don’t wash these parts 32
Troubleshooting 33
Ordering Replacement Parts or Optional Accessories 36
Warranty 37
Register your pump at limerickinc.com 37
Customer Service 38

Page 1 Health and Safety
Health and Safety
Important Safeguards
When using your PJ’s Comfort multi-user hospital grade breast
pump, basic safety precautions should always be followed, including
the following.
READ ALL INSTRUCTIONS BEFORE USE
Caution: Every electrical devise has a potential for danger. To
reduce the risk of burns, electrocution, re, injury, or infection to
persons, take these procautions:
1. Always unplug your PJ’s Comfort multi-user hospital grade
breast pump immediately after use. Unplugging the breast
pump is the only way to assure the power is disconnected.
2. Do not use while bathing or showering.
3. Do not place or drop motor unit (pump) or power supply into
water or other liquid. If either part falls into water, unplug it
from the wall, then remove it from the water. Do not use pump
or power supply again; the pump and power supply cannot be
repaired after being in water.
4. Do not store or use your breast pump where it can fall or be
pulled into a tub, sink, or other water container.
5. To avoid damaging the power cord, do not wrap/wind power
cord around the power adapter.
6. Never operate your pump if it has a damaged power supply cord
or plug.
7. Only use the electric power supply/cord that comes with the PJ’s

Page 2 Health and Safety
Comfort multi-user hospital grade breast pump.
8. The accessory kit is a personal care item designed to be used by
one woman only. They are not to be shared between mothers.
9. The lter needs to be replaced if it gets wet. In the unlikely event
that milk enters the pump, discontinue use of the device and call
the company.
10. Make sure the voltage of the power supply is compatible with
the pump. If you plan to use this pump in another country where
voltage and outlet plugs may differ, a plug adapter may be
required. Please contact Limerick, Inc., for recommendations.
11. Do not use while sleeping or when overly drowsy.
12. Supervision is needed when using the pump near children.
13. On rare occasions the amount of suction may become strong
enough to cause pain. If that occurs, immediately pull the lter
(9 on page 15) off the pump’s lter connector (5) and turn the
pump off. Should the cup remain stuck with suction to your
breast after you have removed the lter and turned off the
power, insert your nger between the cup and your breast to
break the seal.
14. If the Accessory Kit is not marked sterile, see page 8-5
for sanitizing accessories before rst use and page 31 for
cleaning after each use.
15. To avoid the risk of electric shock, this equipment must only be
connected to a supply main with protective grounding.
16. In the case of an emergency, do not place the breast pump in an
area that restricts or prevents manual disconnection.
17. The electrical rating of the PJ’s Comfort pump is 12V 2A DC.

Page 3 Health and Safety
Comfort multi-user hospital grade breast pump.
8. The accessory kit is a personal care item designed to be used by
one woman only. They are not to be shared between mothers.
9. The lter needs to be replaced if it gets wet. In the unlikely event
that milk enters the pump, discontinue use of the device and call
the company.
10. Make sure the voltage of the power supply is compatible with
the pump. If you plan to use this pump in another country where
voltage and outlet plugs may differ, a plug adapter may be
required. Please contact Limerick, Inc., for recommendations.
11. Do not use while sleeping or when overly drowsy.
12. Supervision is needed when using the pump near children.
13. On rare occasions the amount of suction may become strong
enough to cause pain. If that occurs, immediately pull the lter
(9 on page 15) off the pump’s lter connector (5) and turn the
pump off. Should the cup remain stuck with suction to your
breast after you have removed the lter and turned off the
power, insert your nger between the cup and your breast to
break the seal.
14. If the Accessory Kit is not marked sterile, see page 8-5
for sanitizing accessories before rst use and page 31 for
cleaning after each use.
15. To avoid the risk of electric shock, this equipment must only be
connected to a supply main with protective grounding.
16. In the case of an emergency, do not place the breast pump in an
area that restricts or prevents manual disconnection.
17. The electrical rating of the PJ’s Comfort pump is 12V 2A DC.
Caution: To reduce the likelihood of malfunction, pump
failure, damage to pump, or damage to other property, take these
precautions:
1. Your PJ’s Comfort hospital grade electric breast pump should
never be left unattended when plugged into an electric outlet.
2. Use the pump only for its intended use as described in this
manual.
3. Use ONLY Accessory Kits manufactured by Limerick, Inc. Your
PJ’s Comfort breast pump operates differently than other
pumps, so other kits will not work properly with it. Use of
incorrect parts voids warranty.
4. Use the pump only in an upright position.
5. Never operate your pump if it’s not working properly.
6. Do not use outdoors or where pump could get wet.
7. Keep the cord and all components away from heated surfaces.
8. If the lter becomes plugged, replace the lter. Do not tamper
with the lter. See Caution on page 25 to prevent clogging.
9. DO NOT ATTEMPT TO REPAIR PJ’s Comfort hospital grade
electric breast pump. There are no user-serviceable parts inside.
10. Your pump has a temperature sensor that shuts it off if the
temperature inside gets too high. In the unlikely event that this
sensor should fail, and the pump begins to smell hot, turn it off
immediately, and call Limerick, Inc., to return it for repair.
11. In the unlikely event that the pump motor should stop running
or cycling with the power still connected, turn it off immediately
and call Limerick, Inc., to return it for repair.

Page 4 Pump Components
Pump Components
Power supply (8)
Timer 1-9 (3)power/cycle knob (1)
Timer 10 & 20 min (4)
Vacuum
adjustment
knob (2)
Storage container
holder slot (6)
Storage
container
holder (7)
Filter
connector (5)
The pump, power supply, and storage container holders may be
shared by two or more women. For details, See “Multiple User
Instructions” on page 29.

Page 5 Accessory Kit Components
Accessory Kit Components
This Accessory Kit with lter has been designed for single-
personal use and should not be shared between mothers.
Use ONLY Limerick parts; other brands will not work properly with
this pump. The use of other brands’ accessories will void the warranty.
x2 lter (9)
x2 white tube (10)
x1 Y connector (11)
x2 storage
container
cap (20)
x2 storage
container cap
insert (21)
x1 tube
clamp (19)
x1 cleaning
brush (22)
x2 clear
tubing (12)
x2 tube connector (13)
x2 storage
container (18)
x4 gasket (17)
x2
siliconebreast
cup (15)
x2 breast cup
assembly
cap (14)
x2 breast cup
brace (16)
x2 Breast cup assembly (23), parts (14
- 16) no need to take these apart.

Page 6 Introduction to Your PJ’s Comfort Breast Pump
Introduction to Your
PJ’s Comfort Breast Pump
Pump Description
The PJ’s Comfort® hospital grade multi-user breast pump is intended
to express and collect milk from a lactating woman’s breast. This
action helps to alleviate engorgement of the breast, maintain the
woman’s ability to lactate, and provide mother’s milk for future
feedings when mother and baby are separated.
Purpose of PJ’s Comfort multi-user
hospital grade breast pump
The purpose of the breast pump is to express and collect breast
milk. Milk can be collected from both breasts at the same time
(double pumping) or from just one breast (single pumping). Specic
instructions appear on page 22 and in the “Expressing Milk”
section beginning on page 24.
Multiple users: The pump can be used by several women (at different
times). For safety, it’s important that each woman have her own
accessory kit with lter. See page 29 for instructions.
Reasons to use a breast pump
The intended use of the PJ’s Comfort multi-user hospital grade breast
pump is to express milk from the breast of a lactating woman.
Breast milk is the best possible nutrition you can give your baby.
Breast-feeding allows you to give your baby the best possible start
in life. While putting your baby to the breast is one way the baby
will receive breast milk, there are several reasons for pumping and
feeding your baby expressed breast milk.

Page 7 Introduction to Your PJ’s Comfort Breast Pump
For information on reasons to use a breast pump, please go to
bfmed.org or nd this book at your library or bookstore:
Lawrence, RA, Lawrence, RM: Breastfeeding: A Guide for the Medical
Profession, Edition 8, Missouri, 2016, Mosby
Benets of using PJ’s Comfort electric breast pump
• Establish and maintain milk production by emptying the breast if
breast-feeding is temporarily interrupted
• Increase milk production
• Continue to provide infant with breast milk when mother and
infant are separated
For a list of optional accessories and replacements parts, see page
36-5. For a free catalog visit limerickinc.com

Page 8 Accessory Kit Sanitizing
Accessory Kit Sanitizing
Before using the accessory kit for the rst time
Caution! Unless there is a label stating sterile on the kit, the
accessory kit is not supplied sterile. It’s not necessary that the parts
be sterile, but some must be sanitized before the rst time you use
the pump. After the rst time you use the pump, the accessories will
only need a simple cleaning procedure, see page 31-5.
DO NOT BOIL THESE PARTS
The lter, tubing, connector, clamp, and “Y” connector do not need
to be sanitized as air is all that ows through the parts. The lter is
designed to last the duration of your current breast-feeding goals.
See “Caution” on page 25 to prevent clogging.
clear tubing (12)
lter
(9)
white
silicone
tubing (10)
Y
connector
(11)
tube
connector
(13)
tube
clamp
(19)

Page 9 Accessory Kit Sanitizing
Disassemble the following parts as shown and
boil them according to the instructions
1. Remove lter with tubing assembly (9-13) from both breast cup
assemblies (23)
2. Unscrew breast cup assembly (23) from storage container (18).
3. Remove the gaskets (17). It’s not necessary to remove the
breast cups (15) and breast cup braces (16) from the breast cup
assembly caps (14)
4. Place breast cup assembly (23), gaskets (17), and storage
container (18) in a 4-5-quart pan.
5. Fill pan with water to about one inch from the top of pan,
making sure all parts are covered with water.
6. Place pan on stove and bring to boil.
7. Boil for 2-5 minutes maximum.
Gasket (17)
Flat side
Ridge side
Storage
container (18)
Silicone breast
cup (15)
Breast cup
brace (16)
Breast cup
assembly
cap (14)
Breast cup assembly (23),
(parts 14-16), There is no
need to take these apart.

Page 10 Accessory Kit Sanitizing
8. Drain water and remove parts from pan using tongs.
9. Place on a clean towel and allow to air dry.
10. Before each use, visually inspect the individual components for
cracks, chips, tears, discoloration, or deterioration. In the event
that damage to the device is observed, please discontinue use
until the parts have been replaced. Dispose all waste products
according to applicable regulations.
Gasket (17)
Flat side
Ridge side
Storage
container (18)
Silicone breast
cup (15)
Breast cup
brace (16)
Breast cup
assembly
cap (14)
Breast cup assembly (23)
(parts 14-16): There is no
need to take these apart.

Page 11 Pump Setup and Assembly
Pump Setup and Assembly
1. Place pump on a level surface.
2. Insert the two storage container holders (6) into the storage
container holder slots ( 7 ) on either side of the base of the pump.
3. Connect the power supply cord (8) to the back of the pump and
the wall outlet. Insert this plug into back of pump
1
2
2
3
7
6
8
Insert this end
into back of pump

Page 12 Controls and Features
Controls and Features
The pump has two control knobs. Rotating the knobs adjusts the
settings. When a knob is adjusted, the time display automatically
changes to show the setting value, then switches back to time
shortly after the adjustment has stopped. The knobs increase/
decrease a displayed value. If you continue to rotate the knobs the
values will continue to change until the value reaches its limit. When
the setting reaches its limit, the setting will blink if you continue to
turn the knob, to let you know you have reached the limit. For knob
locations, see the illustration on page 11.
Cycle speed/power adjustment knob
Pressing the cycle speed/ Power knob starts and stops the pump
motor. Rotating the cycle speed/power knob controls the suction
rhythm (cycle). It does this by changing the speed of the pump motor
to pump faster or slower. Rotating the knob to the right increases
the speed and rotating the knob to the left decreases the speed. An
example of the suction rhythm (cycle) is when the soft silicone breast
cup collapses around the areola (dark area behind your nipple) and
releases. This can be related to how many times your baby sucks per
minute.
The slowest suction rhythm (cycle) is with a cycle speed of 1 (one).
This provides the fewest compressions per minute. A cycle speed of
30 (thirty) provides the greatest number of compressions per minute
and is the most comfortable setting. The suction rhythm (cycle) also
determines how long the suction strength (vacuum) is applied to
your breast. For example, a slow suction rhythm (cycle) would apply
suction strength (vacuum) for a slightly longer period of time. On
the other hand, a faster suction rhythm (cycle) would apply suction
strength (vacuum) for a shorter period of time (more comfortable).
Adjust the cycle speed only after you have used the pump 2-3 times

Page 13 Controls and Features
and feel comfortable with your PJ’s Comfort breast pump. The cycle
speed is used to ne-tune the suction rhythm to best mimic your
baby’s suckling.
Vacuum adjustment knob
The vacuum adjustment knob controls the suction strength
(vacuum) for balancing effectiveness and comfort and will also slow
down cycle speed as vacuum is increased. Rotating the vacuum
adjustment knob to the right increases the strength and rotating the
knob to the left decreases the strength. A vacuum setting of 1 (one)
applies a low suction strength (vacuum). A vacuum setting of 30
(thirty) applies a high suction strength (vacuum). Your PJ’s Comfort
breast pump always maintains a slight vacuum.
Since each mother/baby couple’s breast-feeding experience is
different, the adjustment of these knobs will be an individual choice.
The goal is to adjust the suction rhythm (cycle) to what best mimics
your baby’s sucking pattern and to adjust the suction strength
(vacuum) to a comfortable setting. Note that the vacuum setting will
also affect the suction rhythm (cycle). Increasing the vacuum level
will decrease the number of cycles per minute (slow cycles).
Adjusting the cycle speed will not change the vacuum level. Cycle
speed is independent of vacuum strength.
When you begin to use PJ’s Comfort breast pump, it’s recommended
that you use a fast suction rhythm (cycle) and low suction strength
(vacuum). The pump is programmed to start at this setting when
rst used or if pump is left off for more than 5 (ve) minutes. This will
create a utter like sensation and allow for a comfortable setting so
you can get used to the pump.
After 1-2 minutes of pumping, increase the suction strength (vacuum)
by rotating the vacuum adjustment knob to the right until it feels
comfortable and similar to your baby’s suckle.

Page 14 Controls and Features
Note: When vacuum strength is increased, the cycle speed will
decrease slightly.
Secondary Features
Dry Mode: To enter Dry Mode, turn the pump on and hold down the
cycle speed/power knob (1) until the number 5 light turns on (this will
take about 5 [ve] seconds). Release knob and the light will begin to
blink rapidly. Attach lter and tubing without breast cup assembly
and press power to start drying mode. Pump will turn on for 5 (ve)
minutes and display remaining time. If vacuum level gets too high
the pump will stop and the number 5 light will begin to blink rapidly
again. To cancel drying, press cycle speed/power knob while pump is
running and pump will turn off and reboot.
Find your comfort settings
Recommended settings for rst-time use
Cycle speed of 30 (thirty) and a vacuum setting of 1 (one).
The pump will automatically start up with these settings after being
unplugged or if the pump has been off for more than 5 minutes.
Adjusting vacuum strength and cycle speed
Vacuum: Pump for the rst minute or two before adjusting
the vacuum. It’s recommended to increase the vacuum in
small increments up to the level that feels comfortable to you.
Recommended pumping time is about 15-20 minutes or 2 minutes
after milk stops to ow.
Cycle: The cycle speed knob is used to ne-tune the suction rhythm
to best mimic your baby’s suckling. It’s recommended that you
wait to adjust the cycle speed until you’ve pumped several sessions
