Limerick PJ's Comfort User manual

Congratulations on your selection of PJ's multi-user electric breast pump.
We are certain you will be please with your purchase an fin it an
invaluable ai in provi ing your infant with the finest nutrition available:
your own milk.
Limerick,Inc.,is prou that PJ's b east pumps are esigne by breastfee ing
mothers for breast-fee ing mothers.Our company is owne by a mother
aughter team who are certifie lactation consultants with over 20 years
of experience assisting mothers who use our pumps in the workplace.
We want you to get the best results from your new breast pump.
This manual is esigne to help you operate it efficiently an safely.
Shoul you have any questions or concerns, our traine staff will be
please to assist you. Please fin our contact information on page 28
or on the back cover.
Best Wishes,
Patricia an Joan
breast pumps

Be ore operating your new PJ’s Comfort hospital grade,
multi user electric breast pump
or your new PJ’s Bliss multi user electric breast pump
please read the instructions completely.
View instructional DVD on Limerick’s web site
www.limerickinc.com
The Owner’s Manual an Instructional DVD can also be foun on the Limerick Inc website
Para instrucciones e ví eo, por favor visite nuestro sitio web en:
www.l imericki nc.com
To be in compliance with the Worl Health Organization(WHO) we are not sen ing
nipples with our storage containers. Any stan ar size nipple will work with the cap.
The Foo an Drug A ministration also known as the FDA has esignate
breast pumps as either multiple user or a single user pump. Most retail electric
breast pumps are single-user. Single-user pumps can never be share , borrowe
or even returne to a retailer. Potentially infectious particles may survive in
the breast pump an or its accessories for a surprisingly long time an cause
isease in the next baby or mom. Only multi-user breast pumps like PJ's breast
pumps are specifically esigne to ecrease the risk of contamination an
re-infection, an are safe to be use by more than one person in the hospital
setting, at work or at home.The esignation of “hospital gra e” in not recognize
by the FDA but is an in ustry terme .
The following is a efinition of terms:
Multi – User electric breast pump: This is an FDA esignation in icating that
this type of breast pump prevents contamination from a back flow of breast milk,
infectious particles an organisms between ifferent users (cross contamination)
ue to the pump’s filter/ esign. Different women using the same multi – user
pump shoul have their own in ivi ual, personal use Sof- touch™ kit which
contains a filter to prevent cross contamination. Multi – user esigne pumps
are also use by a single-user as their personal pump because they provi e
an extra level of safety.
Hospital Grade/ Rental-Grade Electric pump: These breast pumps are utilize
in the hospital setting an by rental after ischarge. There is an implication
that these types of breast pumps are inten e for multiple, ifferent users for
mother-infant ya s facing significant me ical challenges.
Limerick’s de inition o hospital grade, multi user breast pump –
PJ’s Comfort hospital gra e breast pump is research proven to initiate a milk
supply in the most challenge of mothers such as mothers of very low birth weight
infants or premature infants. PJ’s Comfort is a safe close system with a filter on
the Sof – touch™ kit that prevents milk, infectious particles an organisms from
entering the pump thus minimizing the risk for cross contamination. (Limerick’s
Sof – touch™ kit inclu es a 1 – micron filter that has a stu y to vali ate it prevents
bacteria virus an flui from passing through the filter.) PJ’s Comfort motor is
more robust an has a life expectancy of at least 3 years. When use in a hospital
setting a power cor meeting hospital requirements is supplie .

An overview of how to use your new multi-user breast pump
1. Sanitize storage containers, caps an gaskets . . . . See page 10
2. Learn use of pump controls . . . . . . . . . . . . . . . . . . . . . . See page 12
3. Accessory kit assembly . . . . . . . . . . . . . . . . . . . . . . . . . . See page 18
Some pa t may al eady be assembled
4. Attach power cor to back of pump . . . . . . . . . . . . . . See page 12
5. Express milk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . See page 22
6. Store milk properly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . See page 23
7. Cleaning accessory kit . . . . . . . . . . . . . . . . . . . . . . . . . . . See page 27
* This oveview is not inten e to provi e complete user instructions.
Rea the entire manual before operating pump.
Caution: If the accessory kit is not labeled sterile
see page 10 for instructions on sanitizing the accessory
kit. Sanitizing the accessory kit needs to be done before
the first time you use it. After the first time you use
the pump, the accessory kit will only need a simple
cleaning procedure found on page 27.

Owners Manual revision: May 2014
Page 2

Contents
Health and Sa ety In ormation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Important safeguar s
Pump and Accessory Kit Component identi ication. . . . . . . . . . . . . . . . . . . . . .6
Introduction to Breast Pumps. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Purpose of PJ’s multi –use elect ic b east pump
Reasons to use a breast pump
Benefits of using PJ’s multi –use elect ic b east pump
Accessory Kit Sanitizing (be ore irst use) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Controls and Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Pump assembly
Purpose of pump controls an timer
Accessory kit assembly
Double pumping setup
Single pumping setup
Expressing your Milk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Preparation for expressing breast milk
Expressing breast milk
Storage of milk at home
Ways to use PJ's b east pumpto express milk
Multiple user instructions
Pump and Accessory Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Pump care an cleaning
When an how to change the filter
Accessory kit cleaning instructions (after each use)
Troubleshooting and Customer Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Ordering Replacement Parts or Optional Accessories . . . . . . . . . . . . . . . . . 31
Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . 32
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
breast pumps

Health and Sa ety
IMPORTANT SAFEGUARDS
When using your PJ’s Com ort®multi–user hospital grade breast pump
and PJ’s Bliss™multi–user electric breast pump, basic sa ety precautions
should always be ollowed, including the ollowing:
READ ALL INSTRUCTIONS BEFORE USE
WARNING
Every electrical evise has a potential for anger. To re uce the
risk of burns, electrocution, fire, injuryorinfection to persons:
1. Always unplug your PJ's Comfo t®or PJ's Bliss™breast pump imme iately
after using. Unplugging the breast pump is the only way to assure the
power is isconnecte .
2. Do not use while bathing or showering.
3. Do not place or rop motor unit (pump)orpower supply into water
or other liqui . If either part falls into water, unplug from wall, then
remove it from the water.
Do not use pump or powersupply again;
the pump an power supply cannot be repaire after being in water.
4. Do not store or use your breast pump where it can fall or be pulle
into a tub, sink or other water container.
5. To avoi amaging the power cor o not wrap/win power cor
aroun the power a apter.
6. Never operate your pump if it has a amage power supply cor or plug.
7. Only use the electric power supply/cor that comes with the
PJ's Comfo t®or PJ's Bliss™electric breast pump.
8. The breast cup/storage container Accessory Kits are personal care items
esigne to be use by one woman only.
They are not to be share between mothers.
9. The filter nee s to be replace if it gets wet.
10. Make sure the outlet power is compatible with the pump. If you plan
to use this pump in another country where voltage an outlet plugs
may iffer, a plug a apter may be require . Please contact Limerick Inc.,
for recommen ations.
11. Do not use while sleeping or when overly rowsy.
12. Supervision is nee e when using pump near chil ren.
13. In the rare occasion the amount of suction becomes strong enough
to cause pain, imme iately pull the filter (part #9 on page15) off
the pump’s filter connector (#5) an turn pump off. Shoul the cup
remain stuck with suction to your breast after you have remove the
Page 4 continue on next page

WARNING, continued
filter an turne off the power, insert your finger between the cup an
your breast to break the seal.
14. If the Accessory Kit is not marke ste ile see pages 10 -11 for sanitizing
accessories before first use an pages 26-27 for cleaning after each use.
CAUTION
:
To re uce the likelihoo of malfunction, pump failure,
amage to pump or amage to other property:
1. Your PJ's Comfo t®or PJ's Bliss™ breast pump shoul never be left
unatten e when plugge into an electric outlet.
2. Use the pump only for its inten e use as escribe in this manual.
3. Use ONLY Accessory Kits manufacture by Limerick,Inc. Your PJ's Comfo t®
or PJ's Bliss™breast pump operates ifferently than other pumps, so other
kits will not work properly with it. Use o incorrect parts voids warranty.
4. Use the pump only in an upright position.
5. Never operate your pump if it is not working properly.
6. Do not use out oors or where pump coul get wet.
7. Keep the cor an all components away from heate surfaces.
8. If the filter becomes plugge , replace the filter.
Do not tamper with the filter.
9. DO NOT ATTEMPT TO REPAIR PJ's Com ort®or PJ's Bliss™
multi-user
electric breast pump. There are no user-serviceable parts insi e.
10. Your pump has a temperature sensor that shuts it off if the
temperature insi e gets to high. In the unlikely event that this
sensor shoul fail, an the pump begins to smell hot, turn it off
imme iately, an call Limerick, Inc., to return it for the repair.
11. In the unlikely event that the pump motor shoul stop running or
cycling an the power is still connecte , turn it off imme iately an
call Limerick, Inc., to return it for repair.
Page 5
WARNING continue

Pump Component Identi ication
Page 6
The pump, power supply and storage container holders may be shared by
two or more women.
See page 25 for etails
power supply (8)
storage
container
hol er (6)
filter connector (5)
timer 1-9 ( 3)
timer 10 & 20 min. (4)
power/cycle
knob (1)
vacuum
a justment
knob (2)
storage
container
hol er
slot ( 7 )
storage container hol er (6)

Accessory Kit Components
This Accessory Kit with ilter has been designed or single-person use and
should not be shared between mothers.
Use ONLY Limerick parts; other bran s will not work properly with this pump.
The use of other bran s of accessories will voi the warranty.
Page 7
silicone breast cup (15)
silicone breast cup (15)
breast cup
brace (16)
breast cup
brace (16)
tube
connector
(13)
tube
connector
(13)
storage
container
cap gasket
(17)
storage container
cap gasket (17)
storage container cap (14)
for breast cup assembly
storage container
cap (14 )
for breast cup
assembly
storage container
cap (20)
for milk storage
an fee ing
storage
container
(18)
storage
container
(18)
filter( 9 )
Y piece (11)
clear tubes (12)
clear
tubes (12)
clamp (19)
cleaning brush (22)
white
silicone
tubing (10)
storage container
cap insert ( 21)
for milk storage

Introduction to Breast Pumps
Purpose o PJ’s Comfort®multi-user hospital grade breast
pump and PJ’s Bliss™ multi-user breast pump.
The purpose of the breast pump is to express an collect breast milk. Milk can
be collecte from both breasts at the same time ( ouble pumping) or from just
one breast (single pumping). Specific instructions appear on page 21 an in
the “Expressing Milk” section beginning on page 22.
Multiple users: The pump can be use by several women (at ifferent times).
For safety, it is important that each woman have her own accessory kit with filter.
See page 25 for instructions.
Reasons to use a breast pump
Breast milk is the best possible nutrition you can give your baby. Breast-fee ing
allows you to give your baby the best possible start in life. While putting your
baby to the breast is one way the baby will receive breast milk, there are several
reasons for pumping an fee ing your baby expresse breast milk.
For information on reasons to use a breast pump,
please go to: www.bfme .org
or fin this book at your library or bookstore:
Lawrence,RA, Lawrence, RM: B eastfeeding: A Guide fo the Medical P ofession,
e 7, Missouri, 2005, Mosby.
Page 8

Bene its o using PJ’s Comfort®multi-user hospital grade
breast pump and PJ’s Bliss™ multi user breast pump.
•Maintain milk pro uction by emptying the breast if breast-fee ing is
temporarily interrupte
•Increase milk pro uction
•Continue to provi e infant with breast milk when mother an
infant are separate
•This portable, lightweight multi-use pump can easily be carrie
by the mother when she must be separate from her baby.
•Optional accessories are available to facilitate pumping away
from home:
✔A stylish tote bag can be worn over one shoul er or as
a backpack an is roomy enough for the pump, accessory
kit an a cooler for the storage containers.
✔An insulate cooler has room for 4 five-ounce storage containers
an 3 ice packs to keep milk col on the roa .
✔Extra storage containers for storage of milk
✔Ice packs to keep milk col
✔On the roa ? No problem! The PJ's Comfo t®or PJ's Bliss™
b east pump can be use in any vehicle with a lighter plug.
A special 12-volt a apter allows you to pump while traveling.
✔No outlet? No Problem! A rechargeable battery pack can be
purchase for times when electricity is not available.
Page 30 has a list of optional accesso ies and eplacements pa ts.
Fo a f ee catalog visit www.lime ickinc.com
breast pumps
Page 9

Accessory Kit Sanitizing
filter (9)
tube connectors (13)
Y piece (11)
clear tubes (12)
clamp (19)
white
silicone
tubing (10)
Caution: Unless there is a label stating sterile on the kit the accessory
kit is not supplie sterile. It is not necessary that the parts be sterile,
but some must be sanitize before the first time you use it. After the
first time you use the pump, the accessories will only nee a
simple cleaning proce ure foun on page 27.
Page 10
Be ore using the accessory kit or the irst time:
DO NOT BOIL THESE PIECES
1. Remove filter an white tube connector/clear tubing assembly (9-13)
from both breast cup storage containers assemblies (14-18).
DO NOT BOIL THE FILTER (9), TUBING (10 & 12), Y PIECE (11)
OR CONNECTORS (13).
These parts o not nee cleaning, as they o not come in contact
with your milk, if properly use .

Disassemble the ollowing parts as shown and boil them
according to the instructions below
Breast cup/storage container
cap assembly
(parts14-16)
There is no nee
to take these apart.
2. Unscrew storage container (18 ) from storage container caps (14 ).
3. Remove the storage container cap gaskets (17 ).It is not necessary to remove
the breast cups (15) an breast cup braces (16) from the storage container caps(14)
4. Place breast cup/ storage container cap units (14-16 ), cap gaskets (17),
an storage container (18) in a 4-5 quart pan.
5. Fill pan with water to about one inch from the top of pan,
making sure all parts are covere with water.
6. Place pan on stove an bring to boil.
7. Re uce heat an boil for 5-15 minutes maximum.
8. Drain water an remove parts from pan using tongs
9. Place on a clean towel an allow to air ry.
silicone breast cup (15)
storage container cap gasket (17)
storage container (14)
storage container (18)
Page 11
breast cup brace (16)

Controls and Assembly
Pump Assembly
1. Place pump on a level surface.
2. Make sure the power/cycle knob (1) is turne off - all the way to the left.
3. Turn vacuum a justment knob ( 2 ) all the way to the left.
4 Insert the two storage container hol ers (6) into the storage container hol er slots
(7) on either si e of the base of the pump.
5. Connect the power supply cor (8) to the back of the pump an the wall outlet.
power supply ( 8 )
storage
container
hol er (6)
storage
container
hol er (6)
timer 1-9 (3)
timer 10 & 20 min. (4)
power/cycle
knob (1)
vacuum a justment
knob (2)
storage
container
hol er
slot ( 7 )
Insert this plug
into back o pump
Page 12

Purpose o Pump Controls and Timer (5 pages)
For part locations, see the illustration on the facing page ( page 12 ).
Power/cycle knob (1):
The power/cycle knob (1) turns the pump on an controls the suction rhythm (cycle).
It oes this by changing the spee of the pump motor to pump faster or slower. An
example of the suction rhythm (cycle) is when the soft silicone breast cup collapses
aroun the areola ( ark area behin your nipple) an releases. This can be relate
to how many times your baby sucks per minute.
The slowest suction rhythm (cycle) is with the knob turne all the way to the left,
just above the on/off point. This provi es the fewest sucks per minute.
The fastest suction rhythm (cycle), with the knob turne all the way to the right
to the black ot labele "Start", provi es the greatest number of sucks per minute an
is the most comfortable setting.
The suction rhythm (cycle) also etermines how long the suction strength (vacuum) is
applie to your breast. For example a slow suction rhythm (cycle), woul apply suction
strength (vacuum) for slightly longer perio of time.
On the other han a faster suction rhythm (cycle) woul apply suction strength (vacuum)
for a shorter perio of time (most comfortable). A just the cycle knob only after you
have use the pumpe 2-3 times an feel comfortable with your PJ’s breast pump.
The cycle knob is use to fine tune the suction rhythm to best mimic your baby’s suckling.
Vacuum adjustment knob (2):
The vacuum a justment knob (2) controls the suction strength (vacuum) for balancing
effectiveness an comfort an also will slow own cycle spee as vacuum is increase .
The Vacuum knob set to the black ot labele "Start" applies a low suction strength
(vacuum). To provi e stronger suction strength (vacuum) turn clockwise (to the right).
Your PJ's breast pump always maintains a slight vacuum.
storage
container
hol er (6)
Fastest suction rhythm (cycle)
Most comfo table setting
Stronger suction strength
Slowe Cycle
Slowest suction rhythm (cycle)
Lower suction strength
Faste Cycle
Page 13

How to use the controls:
Since each mother/baby couple’s breast-fee ing experience is ifferent,
the a justment of these knobs will be an in ivi ual choice. The goal is to a just
the suction rhythm (cycle) to what best mimics your baby’s sucking pattern an
to a just the suction strength (vacuum) to a comfortable setting.
Note that thevacuum knob a justment will also affect the suction rhythm (cycle).
Increasing vacuum level (turning knob to right) will ecrease the number of cycles
per minute (slow cycles).
A justing the cycle spee will
not change the vacuum level
Cycle knob is independent o vacuum strength
When you begin to use PJ's electric breast pump, it is recommen e that you use
a fast suction rhythm (cycle) an low suction strength (vacuum). This will allow for
a comfortable setting so you can get use to the pump. To o this, turn the power/cycle
knob clockwise to the black ot labele "Start" an turn the vacuum a justment knob
to the black ot labele "Start". ( See picture )
You will feel a flutter-like sensation.
After 1 to 2 minutes of pumping, increase the suction strength (vacuum) by turning
the vacuum knob clockwise (to the right) to a suction strength that feels comfortable
to you an similar to your baby's suck.
To slow cycle own:
• Increase vacuum (turn knob to right) to slow the number
of cycles per minute
• If the vacuum is comfortable – turn the cycle knob to the left
to slow own the cycles per minute
Power/cycle knob ( 1)
Start at the black ot
Vacuum adjustment knob (2)
Start at the black ot
Page 14
Purpose o Pump Controls and Timer
(con’t)

Please Note: In the event of a problem or malfunction, it is possible to
experience a higher than normal suction strength (vacuum). Shoul you feel
pain, imme iately pull the filter (part 9 in rawing below) off the pump’s filter
connector (5). Turn off the pump. Shoul the cup remain stuck with suction
to your breast after you have remove the filter an turne off the power,
insert your finger between the cup an your breast to break the seal.
To remove the filter ( 9 )
from the filter connector (5)
pull outward.
filter connector (5)
filter ( 9)
si e view
Page 15
Recommended settings or 1st time user
•Setting or Cycle turn knob all the way to the right
to the start ot.
•Setting or Vacuum turn knob to the le t
on the start ot.
Adjust vacuum only
•Pump for the first minute or two before a justing
the vacuum. Recommen increasing the vacuum
by turning the knob to the right in small increments
up to the level that feels comfortable to you.
•Recommen e pumping time is about 15-20 minutes
or for 2 minutes after milk stops to flow.
Turn o pump prior to removing the breast cups
from breast.
Purpose o Pump Controls and Timer
(con’t)

Purpose o Pump Controls and Timer
(con’t)
Timer Functions
Minute timer:
The two-timer in icators (3& 4 ) allow a woman to know how many
minutes she has been pumping. This is especially useful for mothers who
work away from home an express milk on their breaks.
After1 minute of pumping the 1-minute light will be on ( 3 ). After 2
minutes the 2-minute light will be on an the 1-minute light will be off.
This pattern will continue for10 minutes. Then the 10-minute light ( 4 )only will be
on. After 11-minutes the 1-minute light will again be on ( 3 ) an the 10-minute ( 4 )
light will stay on. The minute lights will repeat the sequence above while the
10-minute light stays on. After 20-minutes the 10-minute light will turn off an the
20-minute light only will turn on.
At 21 minutes the 1-minute light turns on ( 3 ) an the 20-minute light ( 4 ) stays on.
The minute lights will repeat the sequence above while the
20-minute light stays on. After 30 minutes the 20-minute light turns off
an no lights will be on. At 31 minutes the 1-minute light will be on an
the process will start over again.
It is recommen e that you only pump for15 to 20 minutes or for2 minutes after milk
stops to flow. The pump will not automatically turn off. It is recommen e that you
turn o pump irst be ore removing breast cups rom breast and place storage
containers in storage container holders.
Timer 10 & 20 min. ( 4 )
Timer 1-9 min. (3)
Page 16

Purpose o Pump Controls and Timer
(con’t)
Problem indication:
A group of 3 flashing lights on the minute timer (3) in icates a problem.
When any of the 3 groups of lights flash, the timer will stop in icating time,
an the pump will stop working. When you start the pump again the timer
is reset an will start isplaying time after one minute.
Situation “a”:
Do not reset if the top 3 lights come on.
You will nee to return pump to Limerick for repair.
Situation “ b”:
To reset the pump, turn power/cycle knob off. Remove power plug from back of pump
for about 30 secon s. Place plug back into the back of the pump an turn pump on.
Other Situations that may occur and no lights will come on
Situation “ c”:
If tubing becomes kinke or milk back flows into the filter the pump will lose vacuum
an pulsate quickly. You will either nee to un-kink tubing or change the filter if milk is
in the filteras the filter can not be cleane . (filter is a safety feature that prevents milk,
bacterias an viruses from getting into the motor of the pump.) It is important to
remember to turn o pump irst be ore removing breast cups rom breast. This will
minimize risk for back flow of milk.
Situation “ d”:
You may see moisture accumulate in the tubing. This is normal ue to the ifference in
bo y temperature versus room temperature. If this occurs after you have finishe pumping
remove tubing from storage container caps an keep pump running for a few minutes to
allow air flow through tubing. This will help ry tubing.
Top three lights lashing:
excess vacuum level;
not user repairable; return
to factory for repair.
Bottom three lights lashing:
pump has overheate ;
turn pump off an allow to cool
for fifteen minutes; resume use.
If this happens often, return pump
to the factory for repair.
a
b
Page 17
Timer Functions (con’t)

Accessory Kit Assembly (4 pages)
Wash your han s thoroughly with soap an water
before assembling pumping accessories.
Step 1
Insert storage container cap gaskets (17)
into storage container caps (14).
The ridge on the outer edge
of gasket shoul face outwar ,
towar s storage container.
Step 2
Screw storage container (18) tightly
onto storage container caps (14)
to prevent air leaks.
NOTE: some parts
may already be
assembled when you
purchase the pump.
Caution: Use only Accessory Kits ma e by Limerick, Inc.
The PJ's Comfort®or PJ's Bliss™pump operates ifferently than other
pumps so other kits manufacture by another company will not
work properly with PJ’s breast pumps an will voi warranty.
Warning: The Accessory Kits are personal care items
an are not to be share between mothers. If two or more
women wish to share a pump, each must purchase her own
Accessory Kit with Filter. See page 30 for or ering information.
storage
container cap
gasket (17)
storage
container
cap (14 )
storage
container
cap (14 )
storage container (18)
gasket ri ge
bottom view
Page 18
