Lincat OE8601 Owner's manual

IS 599 ECN 3856 Page 1 of 9
Installation, Operating and Servicing
Instructions
Opus 800 Electric Wet Well Bain Marie
OE8601
Please make a note of your product details for
future use:
Date Purchased:_________________________
Model Number:__________________________
Serial Number:__________________________
Dealer:_________________________________
_______________________________________

IS 599 ECN 3856 Page 2 of 9
CONTENTS
Important Information
2
Warnings and Precautions
3
Technical Data
3
Checklist of Enclosures
3
Installation and Commissioning
3-4
Operating Instructions
5
Cleaning
6
Servicing, Maintenance and Component Replacement
7-8
Fault Finding
8
Spare Parts List
8
Accessories
8
Service Information and Guarantee
9
IMPORTANT INFORMATION
Read these instructions carefully before using this product, paying particular
attention to all sections that carry warning symbols, caution symbols and notices.
Ensure that these are understood at all times.
WARNING!
This symbol is used whenever there is a risk of personal injury.
CAUTION!
This symbol is used whenever there is a risk of damaging your Lincat product.
NOTE:
This symbol is used to provide additional information, hints and tips.
KEEP THIS MANUAL FOR FUTURE REFERENCE

IS 599 ECN 3856 Page 3 of 9
WARNINGS AND PRECAUTIONS
This appliance must be installed, commissioned and serviced by a qualified person
in accordance with national and local regulations in force in the country of
installation.
If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified person.
Ensure that the plug/socket is accessible at all times.
Strip plastic coating and clean the appliance before use.
During operation parts may become hot - avoid accidental contact.
Disconnect this appliance before servicing, maintenance or cleaning.
TECHNICAL DATA
Height (mm)
300
Width (mm)
400
Depth (mm)
800
Weight (kg)
25.0
Power Rating (kW)
1.8
Current (A)
6.8
CHECK LIST OF ENCLOSURES
Warranty card
Instructions manual
INSTALLATION AND COMMISSIONING
This appliance must be earthed.
An equipotential bonding terminal is provided to allow cross bonding with other
equipment.

IS 599 ECN 3856 Page 4 of 9
If replacing the plug connect the terminals as follows:
Green and Yellow wire Earth E
Blue wire Neutral N
Brown wire Live L
Supply cords shall be oil resistant, sheathed flexible cable not lighter than ordinary
polychloroprene or equivalent elastomer sheathed cord (code 60245 IEC 57)
Install this appliance on a level surface ensuring all vents are unobstructed. Any
partitions, walls or furniture must be of non-combustible material. Minimum
distances A 50mm B 1000mm –see Fig 1.
Fig 1
This appliance is supplied with an appropriate plug and lead for connection to a
230-240V supply.

IS 599 ECN 3856 Page 5 of 9
OPERATING INSTRUCTIONS
Only qualified or trained personnel should use this appliance.
Remove gastronorm dishes and fill water tank with water up to the level indicated
by the mark in the rear of the tank. Replace gastronorms.
Turn on the power supply at the isolating switch –the green neon illuminates
indicating power to the appliance.
Turn the control knob to the required setting –the amber neon illuminates indicating
that the element is energised.
When the set temperature is reached, the amber neon will extinguish and then
cycle with the operation of the element as it maintains temperature.
Check and maintain the water level in the tank –do not allow appliance to boil dry.
Shutdown
To shutdown, rotate the control knob to the ‘Off’ position and switch off at the
isolating switch.
Resetting the safety thermostat
In the event of the appliance boiling dry, the safety thermostat protecting the
element will operate, shutting down the appliance. Observe the following to reset:
Isolate the appliance from the electrical supply.
Leave to cool for at least 20 minutes before refilling the water tank to the correct
level.
Reset the safety thermostat by pressing the red button (accessed through a hole in
the RH side of the base, near the front of the appliance).
Reconnect to the electricity supply and operate as normal.

IS 599 ECN 3856 Page 6 of 9
CLEANING
Do not use a water jet or steam cleaner, and do not immerse this appliance.
Clean all panels with warm water and mild detergent, do not use abrasive materials
or cleaners containing chlorine. Dry with a soft cloth.
Scale
The formation of scale within a hot water system is common, and if left unchecked it
may cause problems to the functioning of the appliance. Check for scale build-up
frequently and de-scale as necessary.
De-scaling
Excessive scale may be difficult to remove –we recommend using approved
de-scaler MS19, available from Lincat.
To de-scale the appliance, first disconnect from the electricity supply.
Remove all gastronorm pots from the tank and fill the tank with water to the
indicated level.
Heat the water to boiling and then turn the thermostat off.
Add the de-scaling agent a little at a time, allowing the froth to subside. Some de-
scaling compounds may cause hot water to erupt –follow the manufacturer’s
instructions.
Heat the appliance again for 30 minutes before allowing it to cool.
Repeat the process if necessary.
On completion of successful de-scaling, isolate the appliance from the supply, drain
the tank via the drain tap and rinse with clean water.

IS 599 ECN 3856 Page 7 of 9
SERVICING, MAINTENANCE AND COMPONENT
REPLACEMENT
Your Lincat product has a manufacturer’s warranty. This requires you to maintain
and care for your product and follow maintenance instructions. If you fail to maintain
your unit or damage components Lincat may charge you for a warranty repair.
Please check the website for terms and conditions.
All servicing, maintenance and component replacement on this appliance should be
carried out by one of our recommended service engineers.
Component replacement
The following components are all accessed by turning the appliance either on to the
side or top and then removing the control panel and base panel section.
Neon
Remove the cables from the neon and unscrew the retaining collar.
Withdraw the neon.
Fit the new neon and reverse the procedure to reassemble.
Element
Disconnect the cables from the element terminals and withdraw the control
thermostat and safety thermostat bulbs.
Undo the nuts holding the element and support ring to the tank.
Remove the element and seal from the inside of the tank.
Ensure the mating face of the tank is clean. Fit new element and seal assembly.
Reverse the procedure to reassemble.
Control thermostat
Remove the control knob –do not loose the clip.
Slide the thermostat bulb from the element mounting.
Remove cables from the thermostat, unscrew thermostat from the facia panel.
Fit new thermostat and reverse procedure to reassemble.

IS 599 ECN 3856 Page 8 of 9
Safety thermostat
Remove the cables from the safety thermostat.
Remove the thermostat from the bracket and slide the bulb free from the element
mounting.
Fit new thermostat and reverse procedure to reassemble.
Please refer to the Service Help Desk number on the final page of this manual.
Part Number
Description
EL212
Element
KN500
Control knob
LE38
Leg
NE46
Green neon
NE47
Amber neon
PL202
Plug and lead
TH66
Control thermostat
TH67
Safety thermostat
Part Number
Description
OA8921
Floor stand
OA8971
Pedestal
TA71
1/1 GN container
TA45
1/1 GN container lid
TA38
½ GN container
TA39
½ GN container lid
TA85
1/3 GN container
TA44
1/3 GN container lid
FAULT FINDING
SPARE PARTS LIST
ACCESSORIES

IS 599 ECN 3856 Page 9 of 9
For help with the installation, maintenance and use of your Lincat equipment,
please contact our service department:
UK: 01522 875520
For non-UK customers, please contact your local Lincat dealer
All service work, other than routine cleaning should be carried out by one of our
authorised service agents. We cannot accept responsibility for work carried out by
other persons.
To ensure your service enquiry is handled as efficiently as possible, please tell us:
Brief details of the problem
Product code
All available on serial plate
Type number
Serial number
Lincat reserve the right to carry out any work under warranty, given reasonable
access to the appliance, during normal working hours, Monday to Friday, 08:30 to
17:00.
GUARANTEE
This unit carries a comprehensive UK mainland 2 year warranty. The guarantee is
in addition to, and does not diminish your statutory or legal rights.
The guarantee does not cover:
Accidental damage, misuse or use not in accordance with the manufacturer’s
instructions
Consumable items (such as filters, glass, bulbs, slot toaster elements and door
seals.)
Damage due to incorrect installation, modification, unauthorised service work or
damage due to scale, food debris build-up, etc.
The manufacturer disclaims any liability for incidental, or consequential damages.
Attendance is based on reasonable access to the appliance to allow the authorised
technician to carry out the warranty work.
Service calls to equipment under warranty will be carried out in accordance with the
conditions of sale. Unless otherwise specified, a maximum of 15 minutes of
administrative time, not spent directly carrying out servicing work, is provided for
within the warranty. Any requirement for staff attending the call to spend greater time
than 15 minutes due to administrative requirements, such as on health and safety risk
assessments, will be chargeable at the prevailing rate.
SERVICE INFORMATION
