Lincat Opus 800 Series Owner's manual

IS 598 ECN 4326 Page 1 of 9
Installation, Operating and Servicing
Instructions
Opus 800 Electric Griddles
OE8205, OE8206
Please make a note of your product details for
future use:
Date Purchased:_________________________
Model Number:__________________________
Serial Number:__________________________
Dealer:_________________________________
_______________________________________

IS 598 ECN 4326 Page 2 of 9
CONTENTS
Important Information
2
Warnings and Precautions
3
Technical Data
3
Checklist of Enclosures
3
Installation and Commissioning
4-5
Operating Instructions
5-6
Cleaning
6
Servicing, Maintenance and Component Replacement
7-8
Fault Finding
8
Spare Parts List
8
Accessories
8
Service Information and Guarantee
9
IMPORTANT INFORMATION
Read these instructions carefully before using this product, paying particular
attention to all sections that carry warning symbols, caution symbols and notices.
Ensure that these are understood at all times.
WARNING!
This symbol is used whenever there is a risk of personal injury.
CAUTION!
This symbol is used whenever there is a risk of damaging your Lincat product.
NOTE:
This symbol is used to provide additional information, hints and tips.
KEEP THIS MANUAL FOR FUTURE REFERENCE

IS 598 ECN 4326 Page 3 of 9
WARNINGS AND PRECAUTIONS
This appliance must be installed, commissioned and serviced by a qualified person
in accordance with national and local regulations in force in the country of
installation.
If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified person.
Ensure that the plug/socket is accessible at all times.
Strip plastic coating and clean the appliance before use.
During operation parts may become hot - avoid accidental contact.
Disconnect this appliance before servicing, maintenance or cleaning.
This appliance should only be used by a qualified adult.
TECHNICAL DATA
OE8205
OE8206
Height (mm)
420
Width (mm)
600
900
Depth (mm)
800
Weight (kg)
87
116
Total power rating (kW)
8.0
12.0
Supply 1N ~+E
230V 50-60Hz
Current (A)
34.8
52.2
Supply 3N~+E
400V 50-60Hz
Current (A)
L1 17.4
L2 17.4
L3 N/A
L1 17.4
L2 17.4
L3 17.4
CHECK LIST OF ENCLOSURES
Warranty card
Instructions manual
Plate scraper

IS 598 ECN 4326 Page 4 of 9
INSTALLATION AND COMMISSIONING
This product is heavy; prior to installation a handling assessment should be made.
This appliance must be earthed. An equipotential bonding terminal is provided to
allow cross bonding with other equipment.
Connect the terminals as follows:
Green and Yellow wire Earth E
Blue wire Neutral N
Brown wire Live L
Install this appliance on a level surface ensuring all vents are unobstructed. Any
partitions, walls or furniture must be of non-combustible material and the appliance
must be installed with minimum distances A 100mm B 1000mm –see Fig 1.
Fig 1

IS 598 ECN 4326 Page 5 of 9
Means of isolation with at least 3mm contact separation in all poles must be
incorporated into the fixed wiring of this appliance.
The fixed wiring insulation must be protected by insulated sleeving having a
temperature rating of at least 60 Deg C.
Supply cords shall be oil resistant, sheathed flexible cable not lighter than ordinary
polychloroprene or equivalent elastomer sheathed cord (code 60245 IEC 57)
The electrical supply cable enters the unit through a cable gland in the rear panel.
Connection of the electrical supply cable is to a terminal block behind the facia
panel. The terminal block has a metal cover retained by two screws.
MATERIAL
DRAWN
ECN
CREATED
BURR SIDE DOWN UNLESS OTHERWISE STATED
ALL DIMENSIONS IN mm
UNLESS OTHERWISE
STATED
GENERAL TOLERANCE ± REVISION No
DRG No
TITLE
DO NOT SCALE
MIKE PAYNE
Error: No reference Error: No reference
Error: No reference
23/02/2016
Error: No reference
Error: No reference
Error: No reference
Last Printed 22/02/2016 - Ref: Saved as \\MASTER1\Solid Edge\32k\32500\Draft_master.dft
© 2016 LINCAT LTD,
WHISBY ROAD, LINCOLN, LN6 3QZ
Area Error: No reference sqm
Bend Rad Error: No reference
Mat Thick Error: No reference
Error: No reference
SHEET
1 OF 1
Link?:
OPERATING INSTRUCTIONS
Only qualified or trained personnel should use this appliance.
Griddle plate preparation
Before first use, wipe off protective oil from the plate and wash it down with a warm
detergent solution. Prepare the plate as follows: This does not apply to Chromium
Plates
Spread approximately 2kg of household salt evenly over the plate. Turn the
appliance on full.
Run the appliance for 30 minutes until the salt discolours.
Turn the appliance off, allow the plate to cool and discard the salt.
The plate is now ready for cooking.

IS 598 ECN 4326 Page 6 of 9
AA
BB
CCD D
E EF F
Fig 2
Turn on the power supply, the green neon (A) will illuminate indicating power to the
appliance.
The cooking area is separated into two heat zones. Knob (B) controls the LH zone,
knob (D) the RH zone. The zones are split 50%-50%, on all models.
Turn the control knobs to the required setting. The amber neons will illuminate.
Neon (C) indicates the operation of the LH element, neon (E) that of the RH
element. When the set temperature is acquired, the amber neons will extinguish
and continue to operate in cycle with the elements.
To shutdown after use, rotate both knobs to the ‘Off’ position and switch off at the
isolating socket.
CLEANING
Your Lincat product has a manufacturer’s warranty. This requires you to maintain
and care for your product and follow maintenance instructions. If you fail to maintain
your unit or damage components Lincat may charge you for a warranty repair.
Please check the website for terms and conditions.
Do not use a water jet or steam cleaner, and do not immerse this appliance.
Cleaning of the Griddle Plate
Steel Plate
After cooking, scrape off any residue and wash plate with mild detergent and water.
Rinse to remove all traces of detergent. Dry thoroughly and protect with a light coat
of cooking oil.
For stubborn deposits use a reputable de-greasing agent.
Do not damage the surface with the edge of the scraper or nicks will form, allowing
debris to collect.
Chromium Plate
After cooking, scrape off any residue and wash plate with mild detergent and water.
Rinse to remove all traces of detergent. Dry thoroughly and protect with a light coat
of cooking oil.

IS 598 ECN 4326 Page 7 of 9
For stubborn deposits use a fine metal bristled brush to loosen deposits.
Do not damage the surface with the edge of the scraper or nicks will form, allowing
debris to collect.
Do not use sharp implements on chromium plates.
Do not use plastic implements for cooking.
General cleaning
Clean all panels with warm water and mild detergent, do not use abrasive materials
or cleaners containing chlorine. Dry with a soft cloth.
Empty and clean the fat collection drawer regularly.
SERVICING, MAINTENANCE AND
COMPONENT REPLACEMENT
All servicing, maintenance and component replacement on this appliance should be
carried out by one of our recommended service engineers.
Neon replacement
Remove the screws beneath the facia panel, and remove the facia panel by rotating
the bottom forward.
Remove the cables from the neon. Unscrew the neon retaining nut to remove the
neon.
Reverse the sequence to fit new neon and reassemble.
Element replacement
Remove the facia panel as above. Remove the cables including earth tag from the
faulty element.
The elements are contained in a cartridge, which may be lowered for access.
Unscrew the M8 nuts of the cartridge strap, this will allow the cartridge to hinge
down at the front.
Remove the element and fit the replacement, locating carefully in the cartridge.
Reposition the cartridge beneath the griddle plate and tighten up the cartridge strap.
Rewire the new element including earth tag.
Refit the facia.
Thermostat replacement

IS 598 ECN 4326 Page 8 of 9
Remove the relevant control knob. Remove the facia panel as above.
Disconnect the cables from the faulty thermostat; remove the screws which hold the
thermostat to the control panel.
Undo the screws that hold the thermostat bulb bracket to the cartridge and remove
the thermostat bulb from the bracket.
Fit the new thermostat by reversing the above procedure, ensuring the bulb is
pushed fully into the bracket, and the capillary is formed away from the bulb in a
smooth radius without kinking.
Please refer to the Service Help Desk number on the final page of this manual.
Part Number
Description
Used on
EL310
4kW element
OE8205 x 4, OE8206 x 6
KN500
Knob
All
LE38
Leg
NE46
Green neon
NE47
Amber neon
SC01
Scraper
TH110
Thermostat
All x 2, except chrome units x 4
Part Number
Description
Used on
OA8917
Floor stand
OE8205
OA8914
Floor stand
OE8206
OA8972
Pedestal with doors
OE8205
OA8973
Pedestal with doors
OE8206
FAULT FINDING
SPARE PARTS LIST
ACCESSORIES

IS 598 ECN 4326 Page 9 of 9
For help with the installation, maintenance and use of your Lincat equipment,
please contact our service department:
UK: 01522 875520
For non-UK customers, please contact your local Lincat dealer
All service work, other than routine cleaning should be carried out by one of our
authorised service agents. We cannot accept responsibility for work carried out by
other persons.
To ensure your service enquiry is handled as efficiently as possible, please tell us:
Brief details of the problem
Product code
All available on serial plate
Type number
Serial number
Lincat reserve the right to carry out any work under warranty, given reasonable
access to the appliance, during normal working hours, Monday to Friday, 08:30 to
17:00.
GUARANTEE
This unit carries a comprehensive UK mainland 2 year warranty. The guarantee is
in addition to, and does not diminish your statutory or legal rights.
The guarantee does not cover:
Accidental damage, misuse or use not in accordance with the manufacturer’s
instructions
Consumable items (such as filters, glass, bulbs, slot toaster elements and door
seals.)
Damage due to incorrect installation, modification, unauthorised service work or
damage due to scale, food debris build-up, etc.
The manufacturer disclaims any liability for incidental, or consequential damages.
Attendance is based on reasonable access to the appliance to allow the authorised
technician to carry out the warranty work.
Service calls to equipment under warranty will be carried out in accordance with the
conditions of sale. Unless otherwise specified, a maximum of 15 minutes of
administrative time, not spent directly carrying out servicing work, is provided for
within the warranty. Any requirement for staff attending the call to spend greater time
than 15 minutes due to administrative requirements, such as on health and safety risk
assessments, will be chargeable at the prevailing rate.
