Lincat Opus 800 OE8210 Owner's manual

IS 607 ECN 4345 Page 1 of 12
Installation, Operating and Servicing
Instructions
Opus 800 Electric Clam Griddle
OE8210, OE8211
Please make a note of your product details for
future use:
Date Purchased:_________________________
Model Number:__________________________
Serial Number:__________________________
Dealer:_________________________________
_______________________________________

IS 607 ECN 4345 Page 2 of 12
CONTENTS
Important Information
2
Warnings and Precautions
3
Technical Data
3
Checklist of Enclosures
4
Installation and Commissioning
4-5
Operating Instructions
6-7
Cleaning
7
Servicing, Maintenance and Component Replacement
7-9
Fault Finding
9
Spare Parts List
9
Accessories
10
Service Information and Guarantee
11
IMPORTANT INFORMATION
Read these instructions carefully before using this product, paying particular
attention to all sections that carry warning symbols, caution symbols and notices.
Ensure that these are understood at all times.
WARNING!
This symbol is used whenever there is a risk of personal injury.
CAUTION!
This symbol is used whenever there is a risk of damaging your Lincat product.
NOTE:
This symbol is used to provide additional information, hints and tips.
KEEP THIS MANUAL FOR FUTURE REFERENCE

IS 607 ECN 4345 Page 3 of 12
WARNINGS AND PRECAUTIONS
This appliance must be installed, commissioned and serviced by a qualified person
in accordance with national and local regulations in force in the country of
installation.
If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified person.
Ensure that the plug/socket is accessible at all times.
Strip plastic coating and clean the appliance before use.
During operation parts may become hot - avoid accidental contact.
Disconnect this appliance before servicing, maintenance or cleaning.
TECHNICAL DATA
OE8210
OE8211
Height (mm)
545
Width (mm)
800
400
Depth, excluding handles(mm)
800
Weight (kg)
160
85
Griddle cooking area WxD (mm)
766x525
366x525
Clam griddle cooking area WxD (mm)
330x500
Electricity supply requirements
3N~(three phase supply)
3N~+E
6.5kW
6.5kW
4.2kW
3N~E
3.25kW
3.25kW
2.1kW
Voltage 3N~Amps 3N~
400V
L1 –28.0
L2 –28.0
L3 –18.0
400V
L1 –14.0
L2 –14.0
L3 –9.0
Total amps
74A
37A
Total power rating
17.2kW
8.6kW
CHECK LIST OF ENCLOSURES
Warranty card
Instructions manual
Scraper
Teflon sheets (1 per head)

IS 607 ECN 4345 Page 4 of 12
INSTALLATION AND COMMISSIONING
This product is heavy; prior to installation a handling assessment should be made.
This appliance must be earthed. An equipotential bonding terminal is provided to
allow cross bonding with other equipment.
Means of isolation with at least 3mm contact separation in all poles must be
incorporated into the fixed wiring of this appliance.
The fixed wiring insulation must be protected by insulated sleeving having a
temperature rating of at least 60 Deg C.
Supply cords shall be oil resistant, sheathed flexible cable not lighter than ordinary
polychloroprene or equivalent elastomer sheathed cord (code 60245 IEC 57)
Install this appliance beneath an extraction canopy.
If using a stand fitted with castors, use caution at all times when manipulating or
moving, and lock castors when appliance is in position.
Install this appliance on a level surface ensuring all vents are unobstructed. Any
partitions, walls or furniture must be of non-combustible material (see Fig 1).
Minimum distances A 100mm B 1000mm.
Electrical connection
The electrical supply cable enters the unit through a cable gland in the rear panel.
Connection of the electrical supply cable is to a terminal block behind the facia
panel. The terminal block has a metal cover retained by two screws.

IS 607 ECN 4345 Page 5 of 12
Fig 1

IS 607 ECN 4345 Page 6 of 12
AA
B
B
CC
DE F
GH
I
OPERATING INSTRUCTIONS
Griddle plate preparation
Before using the appliance for the first time, wipe off protective oil from the griddle
plates and wash down with a warm detergent solution.
Griddle plate (stainless steel): Coat with a light film of cooking oil
Clam plate (Aluminium): Fit the Teflon sheets to the clam plate before cooking.
Do not use the appliance without the Teflon sheets fitted.
Fig 2
A –Amber neon clam head
B –Digital timer
C –Clam control knob
D –Base Control RH side
E –Base Control LH side
F –Amber neon base RH side
G –Amber neon base LH side
H –Green Neon mains power
I –Fat collection drawer
Only qualified or trained personnel should use this appliance.
Note: The OE8210 griddle plate is separated into two equal heat zones, each with
an individual control.

IS 607 ECN 4345 Page 7 of 12
Switching on
Refer to Fig 2. With the clam heads in the raised position, turn on the power supply
at the isolating switch; the green neon illuminates indicating power to the appliance.
Turn the relevant thermostat control knobs to the required temperature; the
associated amber neon’s will illuminate. When the griddle plates reach the selected
temperature, the amber neon’s will extinguish. Place product onto the griddle plate
and lower the clam heads.
It is important to run the appliance with the heads raised when not cooking.
Keeping the heads raised will greatly extend the longevity of the Teflon sheets,
keep the griddle plate cleaner and less susceptible to burnt oil, whilst also reducing
the risk of the appliance overheating.
Standby
When no product is being cooked, always raise the clam heads. The appliance
may then be left operating at maximum temperature for a quick return to cooking, or
may be turned down to the minimum temperature until required. Independent
controls allow the versatility of both the griddle plate and the raised heads being set
separately according to requirements at the time.
Shutting down
Turn all the control knobs to the ‘Off’ position and switch off at the isolating socket.
Be aware that the appliance will remain hot for some time.
CLEANING
Your Lincat product has a manufacturer’s warranty. This requires you to maintain
and care for your product and follow maintenance instructions. If you fail to maintain
your unit or damage components Lincat may charge you for a warranty repair.
Please check the website for terms and conditions.
Warning: The use of abrasive cleaners is damaging to electrical components.
For this reason, only use warm water with a mild detergent to clean all panels,
taking particular care when cleaning the control facias of both the lower plate and
the clam heads. Do not use abrasive cleaners or cleaners containing chlorine.
After cleaning, dry with a soft cloth.
Do not use a water jet or steam cleaner, and do not immerse this appliance.
Empty and clean the fat collection drawer regularly.
Griddle plate cleaning
Stainless steel griddle plate –scrape off any food residue and wash down with mild
detergent and water. Rinse thoroughly to remove any traces of detergent, and dry.
Aluminium clam plate –Remove and clean Teflon sheets. Wash aluminium plate if
necessary with mild detergent and water. Rinse to remove traces of detergent and

IS 607 ECN 4345 Page 8 of 12
dry. Cover with new or cleaned Teflon sheet. Do not use a scraper or abrasive
cleaners on the aluminium plate.
SERVICING, MAINTENANCE AND
COMPONENT REPLACEMENT
All servicing, maintenance and component replacement on this appliance should be
carried out by one of our recommended service engineers.
Neon replacement
Remove the screws beneath the facia panel, and remove the facia panel by rotating
the bottom forward.
Remove the cables from the neon. Unscrew the neon retaining nut to remove the
neon.
Reverse the sequence to fit new neon and reassemble.
Note: Remove top cover of clam when replacing clam neon, and follow sequence
as above.
Thermostat replacement
On the griddle plate:
Remove the screws beneath the facia panel, and remove the facia panel by rotating
the bottom forward.
Remove the control knob and undo the screws that hold the thermostat. Remove
the cables from the thermostat, noting their location.
Remove the screws that hold the bulb bracket and withdraw from the element
cartridge. Discard the failed thermostat.
Reverse the procedure to fit the new thermostat, ensuring that the capillary is
formed at a radius of at least 4mm and is free of kinks.
On the clam plate:
Remove the top panel of the clam top and disconnect the cables from the
thermostat, noting their location.
Remove the cover plate and release the rubber grommet from inside the head to
allow access to the stat bracket fixing screws.

IS 607 ECN 4345 Page 9 of 12
Remove the bracket and remove the stat.
Remove the control knob and the screws holding the thermostat to the clam facia.
Fit new thermostat by reversal of the above procedure. Do not damage the
capillary.
Ensure the stat bracket in not in direct contact with any part of the element sheath.
Element Replacement
On the griddle plate:
Remove the screws beneath the facia panel, and remove the facia panel by rotating
the bottom forward.
Disconnect the element cables from the terminal block, noting their location.
Remove the stat bracket containing the stat bulb from the element cartridge.
The elements are contained in a cartridge unscrew the M6 nuts of the cartridge
strap, this will allow the cartridge to drop down at the front.
Remove the element cartridge and fit the replacement, locating carefully reposition
the cartridge beneath the griddle plate and tighten up the cartridge strap.
Fit stat bracket and facia by reversal of the above procedure.
On the clam plate:
Remove the top panel of the clam arm and disconnect the element cables from the
terminal block, noting their location.
Remove the cover plate and release the rubber grommet from inside the head to
allow access to the stat bracket fixing screws and remove.
Remove the stat from the bracket.
Release the compression of the springs by backing off the adjustment nuts, firstly
making a note of the adjustment nuts position and lifting action ready for
reassembly.
Undo the fixing screws (x8) that attach the cover from the top plate and inner frame.
Lift the arm body allowing access to the element cartridge and replace with new.
Reverse the sequence to fit new element cartridge and reassemble.
Note: Adjust the compression springs during reassembly to give the correct lifting
action.

IS 607 ECN 4345 Page 10 of 12
Please refer to the Service Help Desk number on the final page of this manual.
Part Number
Description
EL306
Element
HA05
Handle –clam top
KN245
Control knob –clam top
KN509
Control knob –griddle
LE38
Leg
NE46
Green neon
NE47
Amber neon
SC01
Scraper
TH110
Control thermostat
TI40
Digital timer
Part Number
Description
Used on
OA8921
Floor stand
OE8211
OA8956
Floor stand
OE8210
OA8971
Pedestal with doors
OE8211
OA8974
Pedestal with doors
OE8210
OA8960
Plate height adjuster
All (Per plate)
TFS01
PTFE non-stick sheet
All
FAULT FINDING
SPARE PARTS LIST
ACCESSORIES

IS 607 ECN 4345 Page 11 of 12
For help with the installation, maintenance and use of your Lincat equipment,
please contact our service department:
UK: 01522 875520
For non-UK customers, please contact your local Lincat dealer
All service work, other than routine cleaning should be carried out by one of our
authorised service agents. We cannot accept responsibility for work carried out by
other persons.
To ensure your service enquiry is handled as efficiently as possible, please tell us:
Brief details of the problem
Product code
All available on serial plate
Type number
Serial number
Lincat reserve the right to carry out any work under warranty, given reasonable
access to the appliance, during normal working hours, Monday to Friday, 08:30 to
17:00.
GUARANTEE
This unit carries a comprehensive UK mainland 2 year warranty. The guarantee is
in addition to, and does not diminish your statutory or legal rights.
The guarantee does not cover:
Accidental damage, misuse or use not in accordance with the manufacturer’s
instructions
Consumable items (such as filters, glass, bulbs, slot toaster elements and door
seals.)
SERVICE INFORMATION

IS 607 ECN 4345 Page 12 of 12
Damage due to incorrect installation, modification, unauthorised service work or
damage due to scale, food debris build-up, etc.
The manufacturer disclaims any liability for incidental, or consequential damages.
Attendance is based on reasonable access to the appliance to allow the authorised
technician to carry out the warranty work.
Service calls to equipment under warranty will be carried out in accordance with the
conditions of sale. Unless otherwise specified, a maximum of 15 minutes of
administrative time, not spent directly carrying out servicing work, is provided for
within the warranty. Any requirement for staff attending the call to spend greater time
than 15 minutes due to administrative requirements, such as on health and safety risk
assessments, will be chargeable at the prevailing rate.
