LincPlus C1 User manual

C1
Portable Speakerphone
User Manual
(English|Deutsche|Français)
www.lincplus.com.cn

English

Packaging contents
1Bluetooth Status
2Power Status
3Volume Down
4Answer/End(Only for calls)
5Mute ⑥Volume Up
①Type-C Port ②On/off
③Bluetooth/USB Switch Botton
Product description
LincPlus C1 is a smart device designed for audio
and video conferencing.It supports many
connection methods, which enables it to satisfy
various demands under different circumstances.
Distinguished is its superb human voice tailored
woofer and microphones algorithms, which have
the best in class AEC and ANS without
sacrificing its AGC functionality.All of them are
introduced to bring in a delightful meeting
experience. Included in the package is a
LincPlus C1, a USB Type-C Cable and an User
Manual.
How to use
1、On/off
Press the button for three seconds to
activate or shut down the device.
2、Bluetooth/USB Switch Button.
2.1 Bluetooth connection:
1Press the power button for 3 seconds to
activate the device.
2During Bluetooth connection mode,
Bluetooth status light would be RED when not
connected to any Bluetooth device, during which
the name LincPlus Speakerphone can be found
via Bluetooth. The status light would turn BLUE
when the device is paired successfully.
Function display

4、
Power status button
1When the Type-C cable is not
connected to a computer or an adaptor, a
WHITE light would appear when the battery
is sufficient, a shimmering RED light is
introduced to warn users when the battery is
low.
3、Activation status
A white status light is introduced to inform
users when the device is activated.
2When the Type-C cable is
connected to a computer or an adaptor, the
Power status button would always appear
RED until the battery is fully charged, during
which the light would appear White.
Press the button to mute all
microphones when using, and the light
would remain RED until the button is
pressed again.
8、PreCharge the LincPlus Speak
erphone
1Via a computer. Simply connect this
device to a computer by using a Type-C cable
2Via an adaptor. Connect this device to
any adaptor with an output of 5V/2A.
6、Mute
5、Answer/End Calls
Press the button to answer or end a call,
during which a GREEN light would appear.
7、Volume
Press + or – to increase or decrease the
volume.
2.2 USB connection:
1Press the power button for 3 seconds to
activate the device.
2The USB connection is enabled when
the light of Bluetooth status bar is turned off.
3When the status light is RED or BLUE,
press the button for 3 seconds to switch to The
USB connection mode.

Notes
1Do not place the battery in direct sunlight
or fire exposure places..
2If the batter is improperly replaced, there
might be a chance of explosion. Only
authorized technicians or engineers can
replace the battery of the same or
equivalent type.
3This device along with its accessories
should be replace in dry areas where
raindrops and water can be avoided.
4To protect the environment, please put
any discarded component into designated
trash bins and do not discard directly.
Speaker output rating
3W RMS
Frequency response
20Hz~20KHz(±1dB)
SNR
>80dB
Bluetooth version
V5.0
Bluetooth distance
20m
Microphone sensitivity
-26dB
Microphone
frequency response
100Hz~8KHz
Microphone directivity
360 degree omnidirectional
Battery specification
3.7V/2600mAh
Charge time
2hours
Usage time
Talk time: 12
hours(Depending on the
usage, the talk time varies)
Charge specification
5V/2A
Size
125x125x35mm
Weight
300g

Deutsche

3
Verpack ungsinhalt
①Bluetooth Status ②Strom status
③Lautstärke runter ④Annehmen / Beenden
(nur für Anrufe)
⑤Stumm ⑥Lautstärke erhöhen
①Typ-C-Anschluss ②Ein / Aus
③Bluetooth / USB-Schaltertaste
Product description
LincPlus-C1 ist ein intelligentes Gerät für Audio-
und Videokonferenzen. Es unterstützt viele
Verbindung smethoden, wodurch es ermöglicht
wird, verschiedene Anforderungen unter
verschiedenen Umständen zu erfüllen.
Hervorzuheben sind die hervorragenden, auf die
menschliche Stimme zugeschnittenen Tieftöner
und Mikrofone, die die besten AEC- und
ANS-Werte ihrer Klasse aufweisen, ohne die
AGC-Funktionalität zu beeinträchtigen. Alle
werden eingeführt, um ein angenehmes
Meeting-Erlebnis zu ermöglichen. Im
Lieferumfang enthalten sind eine LincPlus-C1,
ein USB-Typ-C-Kabel und ein
Benutzerhandbuch.
Wie benutzt man
1. Ein / Aus
Drücken Sie die Taste drei Sekunden lang,
um das Gerät zu aktivieren oder
herunterzufahren.
2. Bluetooth /USB-Schaltertaste
2.1 Bluetooth-Verbindung:
1Drücken Sie den Netzschalter 3
Sekunden lang, um das Gerät zu aktivieren.
2Im Bluetooth-Verbindungsmodus ist die
Bluetooth-Statusanzeige ROT, wenn keine
Verbindung zu einem Bluetooth-Gerät besteht.
Während dieser Zeit kann der Name LincPlus
Speakerphone über Bluetooth gefunden werden.
Die Statusanzeige wird BLAU, wenn das Gerät
erfolgreich gekoppelt wurde.
