DC1298
1
DESCRIPTION
Demonstration circuit 1298 is an evaluation board featur-
ing Linear Technology Corporation’s LT 9002 14-bit
Dual Receiver Subsystem. DC1298 demonstrates good
circuit layout techniques and recommended external cir-
cuitry for optimal system performance.
DC1298 comes with Linear Technology’s 14-bit
LT 9002 amplifier/ADC subsystem installed. The board
includes a wideband input transformer (for evaluation
with a single-ended RF signal generator) and output
C OS buffers. DC1298 plugs into the DC890 Data Ac-
quisition demo board and the output can be easily ana-
lyzed with Linear Technology’s PScope data processing
software, which is available for no charge on our website
at http://www.linear.com.
Design files for this circuit board are available. Call
the LTC factory.
L , LTC, LT , LT, Burst ode, OPTI-LOOP, Over-The-Top and PolyPhase are registered
trademarks of Linear Technology Corporation. Adaptive Power, C-Load, DirectSense, Easy
Drive, FilterCAD, Hot Swap, LinearView, µ odule, icropower SwitcherCAD, ultimode
Dimming, No Latency ∆Σ, No Latency Delta-Sigma, No RSENSE, Operational Filter, PanelPro-
tect, PowerPath, PowerSOT, SmartStart, SoftSpan, Stage Shedding, SwitcherCAD, ThinSOT,
UltraFast and VLDO are trademarks of Linear Technology Corporation. Other product names
may be trademarks of the companies that manufacture the products.
QUICK START PROCEDURE
Validating the performance of the LT 9002 is simple
with DC1298, and requires only two input sources, a
clock source, a computer, and a lab power supply. Refer
to Figure 1 for proper board evaluation equipment setup
and follow the procedure below:
1. Connect the power supply as shown in Figure 1.
There is an on-board low-noise voltage regulator
that provide the four supply voltages for the
DC1298. The entire board and all components
share a common ground. The power supply should
be a low-noise lab power supply capable of supply-
ing at least 1 Amp.
2. Provide an encode clock to the ADC via S A con-
nector J1. Use a low-phase-noise clock source
such as a filtered RF signal generator or a high-
quality clock oscillator. Obtain DC1216 for a low-
phase-noise DC clock source that can plug di-
rectly into DC1298.
NOTE. Similar to having a noisy input, a high-jitter (phase noise) encode
clock will degrade the signal-to-noise ratio (SNR) of the system.
Table 1: DC1298 Connectors and Jumpers
REFERENCE FUNCTION
J1 (+INA) Board IF Signal Input, channel A single-ended.
Impedance-matched to 50 Ω for use with lab
signal generators.
J2 (-INA) Board IF Signal Input, channel A. Normally not
used, but can be configured as the negative
side of a differential input.
J3 (+INB) Board IF Signal Input, channel B. Normally not
used, but can be configured as the negative
side of a differential input.
J4 (-INB) Board IF Signal Input, channel B single-ended.
Impedance-matched to 50 Ω for use with lab
signal generators.
J6 (CLKIN) Board Clock Input. Impedance-matched to
50 Ω. Drive with a low-phase-noise clock oscil-
lator or filtered sine wave signal source.
E1 (EXT REF A) Reference input to adjust the full-scale range of
the FT107, channel A. Connects to the SENSE
pin; by default, tied to VDD for internal refer-
ence.
E2 (EXT REF B) Reference input to adjust the full-scale range of
the FT107, channel B. Connects to the SENSE
pin; by default, tied to VDD for internal refer-
ence.
JP1 (DAC I/O) DAC serial interface.
JP2 (SENSE) ADC sense voltages, default is VDD.
DEMO CIRCUIT DC1298
QUICK START GUIDE
LTM9002 14 bit Dual Channel
I /Baseband Re
ceiver Subsystem
Downloaded from Elcodis.com electronic components distributor

DC1298
2
3. Apply an input signal to the board. For best re-
sults, use a low distortion, low noise signal genera-
tor with sufficient filtering to avoid degrading the
performance of the receiver.
4. Observe the ADC output with demo circuit
DC890B, a USB cable, a Windows computer, and
Linear Technology’s PScope data processing soft-
ware.
Figure 1. Proper Measurement Equipment Setup
USING PSCOPE SOFTW RE
PScope, downloadable from Linear Technology’s website http://www.linear.com/, processes data from the DC890B
FastDAACS board and displays FFT and signal analysis information on the computer screen.
Signal
Generator
HP 8644B or
equiv.
RF Signal Ge
n
erator
(HP 8644B) or other
low phase noise
clock source (e.g. DC1216)
Power Supply
(3.3V-6V @ 1.0A)
To DC890B
BPF
NOTE.
Even a high
-
quality signal
synthesizer will still have noise and
harmonics that should be attenuated
with a low-pass or band-pass filter. For
good-quality high order filters, see TTE,
Lark Engineering, or equivalent.
BPF
Signal
Generator
HP 8644B or
equiv.
BP
F
Downloaded from Elcodis.com electronic components distributor

DC1298
3
The on-board EEPRO U5 should enable automatic board detection and auto-configuration of the software, but if the
user wishes to change the settings, they can easily do so.
From the Configure menu in the toolbar, uncheck “Autodetect Device”. The default settings for DC1298 are shown in
Figure 2.
Figure 2. Entering the correct device information for your DC. Select the correct parameters for the DC1298. Under normal
conditions, PScope should automatically recognize the board and adjust the software settings accordingly.
Downloaded from Elcodis.com electronic components distributor

DC1298
4
Figure 3. Schematic
