Sony STR-DE875 User guide

STR-DE875 DESCRIPTION:
DIMENSIONS
(WHD):
WEIGHT:
POWER
REQUIREMENTS:
POWER
CONSUMPTION:
Dolby Digital
Receiver
17" x 6 1/4" x 14 7/8"
Approx 35 lbs
120
V
60
H
300
Watts
Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.
NOTE:
WHERE THERE ARE CLOSE TOLERANCES INVOLVED IN CABINET BUILDING
OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION WE
RECOMMEND THAT THE PRODUCT ITSELF BE USED TO MAKE THE ACTUAL
MEASUREMENTS. SONY WILL NOT BE RESPONSIBLE FOR INACCURACIES
IN THE DESIGN OR MANUFACTURE OF ENCLOSURES .
FRONT VIEW
SIDE VIEW
6 1/4"
1/2"
12 1/4 " 1 7/8 "
1/2"
5 3/4"
1 7/8 "1 " 5/8" 7 1/2" 1 7/8 "
14 7/8 "12 7/8"
1/2"
17"
1 7/8 "
RM-PP505L REMOTE
