Linear Technology Sys-Pro 114438 User manual

●apply to single color LED controller, dimming driver or smart lamp.
●each remote can match one or more receiver.
●CR2032 battery powered.
●operate with LED indicator light.
●Magnet on the back which can be easily stuck on any metal
surfaces.
User Manual Ver 1.0.4 www.iskydance.com
Technical Parameters
Input and Output
Warranty
5 years
Warranty
Operation temperature
Case temperature (Max.)
Environment
IP20
IP rating
Ta: -30
O
C ~ +55
O
C
Tc: +85
O
C
Model No.: R1-1
Features
One-key RF Remote Controller
Output signal RF(2.4GHz)
Working voltage 3VDC(CR2032)
Working current <5mA
Standby current <2μA
Standby time 2 years
Remote distance 30m
Safety and EMC
EMC standard (EMC) EN301 489,EN 62479
Radio Equipment(RED) EN300 328
Certification CE,EMC,LVD,RED
EN60950
Safety standard(LVD)
LVDRED
Page 1
114438 | Sys-Pro SingleColor 1 zones remote control
round, white
114439 | Sys-Pro SingleColor 1 Zones Remote Control
Round, Black

Use Power Restart
Match:
Switch off the power, then switch on power again, then repeat
the procedure again. After the second ON/OFF procedure
immediately short press on/off key (single zone remote) zone
key (multiple zone remote) 3 times on the remote. The light
blinks 3 times means match is successful.
Delete:
Switch off the power, then switch on power again,
immediately short press on/off key 5 times on the remote.
The light blinks 5 times means all matched remotes were
deleted.
Use the controller’s Match key
Match:
Short press match key, immediately press on/
off key (single zone remote) or zone key
(multiple zone remote) of the remote.
Delete:
Press and hold match key for 5s to delete all
match, The light blinks 5 times means all
matched remotes were deleted.
R1-1 One-key RF Remote Controller
43.00 mm
17.00 mm
Safety information
1. Read all instructions carefully before you begin this installation.
2. When installing battery, pay attention to the batter y positive and negative polarity. A
long time without the remote control, remove the battery.
When remote distance becomes smaller and insensitive, replace the battery.
3. If no response from the receiver, please re-match the remote.
4. Gently handle remote, beware of falling.
5. For indoor and dry location use only.
CR2032 Battery
Note: Before the first use,
please remove the protective film on the
battery.
LED indicator
Click to turn on/off,
Press and hold 1-6s to
increase/decrease brightness.
Back holder with magnet
Mechanical Structures and Installations
26.50 mm
To fix the remote, three options are offered for selection:
Option 1: stuck on any metal surfaces directly.
Option 2: fix it on the wall with two screws .
Option 3: adhere it to the wall with 3M paster.
Match Remote Control (two match ways)
User Manual Ver 1.0.4 www.iskydance.com Page 2
114438 | Sys-Pro SingleColor 1 zones remote control
round, white
114439 | Sys-Pro SingleColor 1 Zones Remote Control
Round, Black
