Linear 45 VDC User manual

REV101905
REV101905























 
 
 
45 VDC
MECHANICAL SPECIFICATIONS
Dimensions in Inches (mm)
FORCE-SPEED CURVES
LEAD SCREWS
Available screw types:
Screw A.......................................................... 0.00125” Travel/Full Step
Screw B ....................................................... 0.000625” Travel/Full Step
Screw C...................................................... 0.0003125” Travel/Full Step
Screw D ................................................... 0.00015625” Travel/Full Step
Linear Actuator is non-captive style. Consult factory regarding external and captive shaft versions.
50
45
40
35
30
25
20
15
10
5
001000 2000 3000 4000 5000 6000 7000
22
44
66
88
111
133
177
200
222
155
Force (N)
Load Limit
S
p
eed in Full Ste
p
s
p
er Second
Force (lbs)
Screw D
Screw C
Screw B
Screw A
50
45
40
35
30
25
20
15
10
5
001000 2000 3000 4000 5000 6000 7000
22
44
66
88
111
133
177
200
222
155
Force (N)
Load Limit
S
p
eed in Full Ste
p
s
p
er Second
Force (lbs)
Screw D
Screw C
Screw B
Screw A
24 VDC




 






1.8 � HYBRID
LINEAR ACTUATOR
1.8 � HYBRID
LINEAR ACTUATOR
Part Number Max Thrust
lbf
(N)
Phase
Current
Amps
Number
of Leads
Phase
Resistance
ohms
Phase
Inductance
mH
BackLash
inches
(mm)
Length
inches
(mm)
Weight
oz
(g)
MH2 - 1713 - L[X]*
50
(222) 1.5 4 1.56 1.9 0.005 (0.127)
1.33
(33.7)
8.0
(226.79)
*Specify Screw Type
STANDARD LENGTHS
The NEMA 17 Linear Actuator comes
standard with a 6” (152.4mm) screw
length plus the mounting end thread.
CUSTOM LENGTHS
Custom lengths are available from 2.0”
to 24.0”. Custom length screws do not
include a mounting end thread.
