Linear HSLG User manual

HSLG
INSTALLATION GUIDE
UL325 COMPLIANCE REQUIRES THE USE OF CONTACT EDGES
OR PHOTOELECTRIC CONTROLS ON ALL AUTOMATIC OR
REMOTELY-CONTROLLED GATE OPERATORS.
USA & Canada [phone] & [phone]
[phone] - Toll Free FAX [phone]
www.linearcorp.com

HSLG OPERATOR INSTALLATION GUIDE
- 2 -
TABLE OF CONTENTS
PRE-INSTALLATION INFORMATION
Gate Operator Classifications ...................................................................................................................................... 3
Safety Information and Warnings ................................................................................................................................. 3
Pre-Installation Information .......................................................................................................................................... 3
INSTALLATION
Wiring Specifications.................................................................................................................................................... 4
Post Mounting Instructions ........................................................................................................................................... 5
Gate Bracket and Chain Assembly Instructions ........................................................................................................... 6
Torque Limiter Adjustments.......................................................................................................................................... 7
Electrical Connection and Adjustments........................................................................................................................ 8
Limit Nut Adjustments .................................................................................................................................................. 8
CONTROL BOARD ADJUSTMENTS and ACCESSORY CONNECTIONS
Control Board Adjustments .......................................................................................................................................... 9
Terminal Connection Descriptions.............................................................................................................................. 10
Current Sensing Adjustments .................................................................................................................................... 11
Close Direction Current Sense Adjustment................................................................................................................ 11
Open Direction Current Sense Adjustment ................................................................................................................ 11
Maximum Run Timer Adjustment ............................................................................................................................... 11
Auto Close Timer Adjustment..................................................................................................................................... 11
Master/Slave Connection ........................................................................................................................................... 11
Onboard L.E.D. Indicator Descriptions ....................................................................................................................... 12
Important Notes for Installation of Master/Slave Applications.................................................................................... 13
Surge Protector Instructions....................................................................................................................................... 13
Control and Accessory Connection Illustrations....................................................................................................14-17
ILLUSTRATIONS
Loop Layout Illustration .............................................................................................................................................. 18
Edge Layout Illustration #1......................................................................................................................................... 19
Edge Layout Illustration #2......................................................................................................................................... 20
Photo Eye Illustration ................................................................................................................................................. 21
Picket Gate Illustration ............................................................................................................................................... 22
Track Gate Illustration................................................................................................................................................. 23
TROUBLESHOOTING .................................................................................................................................................. 24
PARTS LISTS
How to Order Replacement Parts .............................................................................................................................. 24
Model HSLG Mechanical Parts Exploded View.......................................................................................................... 25
Model HSLG Mechanical Parts List ........................................................................................................................... 26
Model HSLG Single Phase Control Box Exploded View and Parts List ..................................................................... 27
Model HSLG Three Phase Control Box Exploded View and Parts List ...................................................................... 28
PREVENTATIVE MAINTENANCE ................................................................................................................................ 29
GATE OPERATOR INSTALLATION CHECKLIST ........................................................................................................ 30
CAUTION!
DO NOT INSTALL
CONTROLS ON A
GATE OR FENCE
LINE
CAUTION!
ONLY QUALIFIED SERVICE
TECHNICIANS SHOULD
WORK ON AN LINEAR
SLIDE GATE OPERATOR
CAUTION!
DO NOT INSTALL
CONTROLS
ON THE OPERATOR

HSLG OPERATOR INSTALLATION GUIDE
- 3 -
Read the following before beginning to install LINEAR slide
gate operators:
1. Read the yellow “Safety Instructions” brochure enclosed
with the packet of information. If you do not have one,
please call LINEAR at 1-800-333-1717 to request one.
Read and follow all instructions.
2. All electrical connections to the power supply must be
made by a licensed electrician and must observe all
national and local electrical codes.
3. A separate power-disconnect switch should be located
near the operator so that primary power can be turned
off when necessary.
4. A minimum of two (2) WARNING SIGNS shall be in-
stalled, one on each side of the gate where easily vis-
ible.
5. Never reach between, through or around the fence to
operate the gate.
6. You must install all required safety equipment.
GATE OPERATOR
CLASSIFICATIONS
PRE-INSTALLATION INFORMATION
Before unpacking, inspect the carton for exterior damage. If
you find damage, advise the delivery carrier of a potential
claim.
Inspect your package carefully.You can check your accessory
box parts with the enclosed packing slip for your convenience.
Claims for shortages will be honored for only 30 days from
the date of shipment.
Before installing the operator, read this manual completely
to ensure all requirements for proper installation are pres-
ent. Verify that the voltage to be used matches the voltage
of the operator.
SAFETY INFORMATION
AND WARNINGS
IMPORTANT!!
Before installing the gate operator, make sure the gate’s slide
is free and level throughout the entire opening distance. If
the gate does not seem to operate properly, it may affect the
operator performance or greatly shorten the life of the unit.
The gate should be designed so that airflow through the fabric
is ample to prevent wind resistance and drag.
All gate operators can be divided into one of four different
classifications, depending on their design and usage.
Class I: Residential
A vehicle gate operator (or system) intended for use in a
home of one to four single-family dwellings, or a garage or
parking area associated therewith.
Class II: Commercial or General Public Access
A vehicular gate operator (or system) intended for use in
a commercial location or building such as a multi-family
housing unit (five or more single-family units), hotel, garage,
retail store, or other building servicing the general public.
Class III: Industrial or Limited Access
A vehicular gate operator (or system) intended for use in
an industrial location or building such as a factory or load-
ing dock area or other locations not intended to service
the general public.
Class IV: Restricted Access
A vehicular gate operator (or system) intended for use in
a guarded industrial location or building such as an airport
security area or other restricted access locations not ser-
vicing the general public, in which unauthorized access is
prevented via supervision by security personnel.
The following contact or non-contact obstruction
detection devices have been approved for use
with LINEAR slide gate operators as part of a UL325
compliant installation:
Contact Edges:
Miller Models*: MG0-20, MGR-20, MGS-20, and
ME-120
Photoeyes:
2520-441 MMTC Model IR-55 photoeye, 165’ with
mounting hardware
2520-031 MMTC Model E3K photoeye, 28’ with
mounting hardware
*for LINEAR part numbers, contact a sales representative for details

HSLG OPERATOR INSTALLATION GUIDE
- 4 -
USE COPPER WIRE ONLY!
ACCESSORY WIRING
All Models
24VDC
*Over 350 ft. use DC power.
0-2000 14
24VAC
250
350*
14
12
Volts
Maximum
Distance (ft.)
Wire
Gauge
1. Select from the chart at the bottom of this page corresponding to the
model, voltage and horsepower rating of your operator.
2. The distance shown on the chart is measured in feet from the operator
to the power source. DO NOT EXCEED THE MAXIMUM DISTANCE.
These calculations have been based on standard 115V and 230V sup-
plies with a 10% drop allowable. If your supply is under the standard
rating, the runs listed may be longer than what your application will
handle, and you should not run wire too near the upper end of the chart
for the gauge of wire you are using.
3. When large-gauge wire is used, a separate junction box (not supplied)
may be needed for the operator power connection.
4. All control devices are now 24VDC, which can be run considerable
distances. 24VAC is available for other devices, such as loop detectors
and photo eyes.
5. Wire run calculations are based on the National Electrical Code, Article
430 and have been carefully determined based on motor inrush, brake
solenoids, and operator requirements.
WIRING SPECIFICATIONS
6. Connect power in accordance with local codes. The green ground
wire must be properly connected.
7. Wire insulation must be suitable to the application.
8. Control wiring must be run in a separate conduit from power wiring.
Running them together may cause interference and faulty signals in
some accessories.
9. Electrical outlets are supplied in all 115VAC models for convenience with
occasional use or low power consumption devices only. If you choose
to run dedicated equipment from these devices, it will decrease the
distance for maximum run and the charts will no longer be accurate.
10. A three-wire shielded conductor cable is required to connect master and
slave operators.You must use Belden 8760 Twisted Pair Shielded Cable
(or equivalent) only – LINEAR part number 2500-1982, per foot). See
page 9for details of this connection, as well as dip switch selection.
Note: The SHIELD wire should be connected in both the master
and slave operators.
MODEL HSLG – SINGLE PHASE
gniriWrewoP
stloV
PH&
ecnatsiDxaM
lauDelgniS
eriW
eguaG
stloV
PH&
ecnatsiDxaM
lauDelgniS
eriW
eguaG
stloV
PH&
ecnats
iDxaM
lauDelgniS
eriW
eguaG
V511
2/1
PH
222
453
665
009
0341
111
771
382
054
517
21
01
8
6
4
V802
2/1
PH
067
0021
4291
0603
4684
083
006
269
0381
2342
21
01
8
6
4
V032
2/1
PH
498
2241
4622
0063
4275
744
117
2311
0081
2682
21
01
8
6
4
V511
4/3
PH
871
282
054
617
0411
98
14
1
522
853
075
21
01
8
6
4
802
4/3
PH
406
859
6251
4242
6583
203
874
367
2121
8291
21
01
8
6
4
V032
4/3
PH
017
8211
6971
2582
8354
553
465
898
6241
9622
21
01
8
6
4
V511
PH1
061
452
604
646
6201
08
721
302
323
315
21
01
8
6
4
V802
PH1
445
468
4731
4812
6743
272
234
686
2901
8371
2
1
01
8
6
4
V032
PH1
046
6101
6161
0752
0904
023
805
808
5821
5402
21
01
8
6
4
esahP3:gniriWrewoP
stloV
PH&
ecnatsiDxaM
lauDelgniS
eriW
eguaG
stloV
PH&
ecnatsiDxaM
lauDelgniS
eriW
eguaG
stloV
PH&
ecnatsiDxaM
lauDelgniS
eriW
eguaG
V802
2/1
PH
2411
6181
0982
175
809
5441
21
01
8
V032
2/1
PH
4431
7312
0043
276
9601
0071
21
01
8
V064
2/1
PH
1483
6016
2179
1291
3503
6584
21
01
8
V802
4/3
PH
029
4641
0332
064
237
5611
21
01
8
V032
4/3
PH
4801
3271
1472
245
2
68
1731
21
01
8
V064
4/3
PH
9723
2125
1928
0461
6062
6414
21
01
8
V802
PH1
417
6311
4081
753
865
209
21
01
8
V032
PH1
048
6331
4212
02
4
866
2601
21
01
8
V064
PH1
9862
4724
8976
5431
7342
9933
21
01
8
MODEL HSLG – THREE PHASE

HSLG OPERATOR INSTALLATION GUIDE
- 5 -
POST MOUNTING INSTRUCTIONS FOR MODEL HSLG
Before installing, make sure the gate rolls or slides freely,
and that all exposed rollers are properly covered. The gate
must be covered with fabric with openings no larger than
2 1/4” in size, to a minimum height of 48 inches from ground
level. On picket-style gates, if pickets are spaced less than
2 1/4” apart, mesh is optional.
Use two 3 - 3 1/2” OD galvanized posts and secure with
concrete footings as shown, length to be determined by lo-
cal codes, frost line depth and soil conditions. Secure the
operator to the posts using the 4” U-bolts, side plates,
and hardware. There are a total of eight side plates. There
are six 3/16” side plates which should be mounted on the
outside top and bottom of the cabinet, two 3/16” side plates which
go on the top inside and two 1/2” side plates which should be
mounted on the inside top of the cabinet as shown in the illustra-
tion at the right.
To assemble the drive chain and gate brackets, refer to page 6.
Make sure that the chain sag does not exceed recommended
sizes and that the chain does not come into contact with the
moving parts of the gate or ground.
For optional pad mounting instructions, see LINEAR drawing
#2700-360.
SIDE PLATE INSTALLATION
The operator is intended for installation only on
gates used for vehicles. Pedestrians must be sup-
plied with a separate access opening. The pedestrian
access opening shall be designed to promote pedes-
trian usage. Locate the gate such that persons will
not come in contact with the vehicular gate during
the entire path of travel of the vehicular gate.

HSLG OPERATOR INSTALLATION GUIDE
- 6 -
Assemble a gate bracket (1) to the front edge of the gate,
using two U-bolts (2), and mounting hardware (3). Before
tightening down completely, be sure the bracket is paral-
lel to the gate. Tighten the U-bolt hardware the rest of the
way, then screw the square head bolts (4) into the threaded
holes in the gate plate until they bottom out against the
gate. These will help keep the bracket from twisting on
the pipe.
Slide a threaded chain pin (5) through the bracket as shown,
with spring (6), flat washer (10), and two hex nuts (7).
Attach one end of the drive chain (8) to the chain pin using
master link (9) and begin unrolling it toward the operator.
Remove the rain cover from the back of the slide gate op-
erator. Carefully thread the drive chain under the first idler,
over the drive sprocket, and then under the last idler. Make
sure you feed most of the chain through the sprockets for
attaching to the back end of the gate.
Assemble the other gate bracket on the rear edge of the
gate, using the same process as you did with the front gate
bracket. Once this is done, take the other chain pin, spring
and jam nuts and assemble with the end of drive chain and
the other master link.
At this point you should be able to adjust the chain tension
by tightening the jam nuts on each end. Approximately 1/4”
to 3/8” of slack per foot of drive chain is acceptable. Make
sure the chain does not drag on the ground, across the
gate rollers or the idler frame of the operator.
Additional mounting holes have been provided in the gate
bracket for installer convenience.
GATE BRACKET AND CHAIN ASSEMBLY INSTRUCTIONS
Numbered items in these
drawings are for instruc-
tional reference only. For
actual part numbers, go to
the parts lists in the back of
this booklet.

HSLG OPERATOR INSTALLATION GUIDE
- 7 -
TORQUE LIMITER ADJUSTMENTS
Before adjusting the torque limiter, make sure the gate is in good working condition. One per-
son should be able to move the gate by hand. Be certain the gate moves freely and without
binding throughout its travel. Torque limiters are set light at the factory and must be adjusted
during installation. Adjust the torque limiter tight enough to keep it from slipping during normal
operation.
To adjust the torque limiter in model HSLG:
1. Loosen the jam nut.
2. To increase the output, turn the adjustment nut clockwise one flat, or 1/6 turn, at a time
until desired output is obtained.
To reduce the output, turn the adjustment nut counterclockwise one flat, or 1/6 turn, at a
time until desired output is obtained.
3. Tighten the jam nut against the adjustment nut when finished.
MODEL HSLG

HSLG OPERATOR INSTALLATION GUIDE
- 8 -
ELECTRICAL CONNECTION AND ADJUSTMENTS
All LINEAR gate operators are supplied with a power disconnect switch to turn on and off the power supply available to the
operator. Incoming power should be brought into the operator and connected to the labeled pigtails in the disconnect box
following wiring specifications on page 4. A wiring connections print can be found on the inside cover of the operator.
Proper thermal protection is supplied with the operator. The motor contains a thermal overload protector to protect from
overheating the motor due to overload or high-frequency operation. This overload will automatically reset after the motor
cools down.
LIMIT NUT ADJUSTMENTS
The limit nuts are not preset at the factory and must be adjusted for the length of the gate the operator is installed on. The
limit switches are activated by two threaded nylon rotary limit nuts which are attached to a threaded shaft and driven by chain
and sprockets from the main drive shaft. Remove the cardboard filler before attempting to adjust the limit nuts.
With the gate connected to the gate operator in a mid-travel position, and the power disconnect switch turned OFF, discon-
nect the operator by using the manual disconnect lever. Instructions for the manual disconnect can be found in the individual
operator owner’s guides. Once the operator has been disconnected, manually move the gate by hand to within a foot of its
fully open position (the foot of distance is necessary to allow for coasting of the operator after the limit switch is tripped).
Once the gate is in this position, adjust the open limit nut until it activates the limit switch for open, LSO-1. Press down on
the detent plate and rotate the nut along the threaded shaft. Refer to the illustration below for additional details.
Once the open limit nut is set, repeat the above process for the close direction nut and the LSC-1 limit switch.
After finishing the initial limit nut adjustments, reposition the gate to approximately its center of travel. Re-engage the operator
and turn the power disconnect ON. Stand clear of any moving parts and press the OPEN button on the three-button station.
If the gate begins to close instead of open, press the STOP button immediately. Find the dip switch block on the main control
board and switch the hand of operation (dip switch #4, see page 9) and try to open the gate again. Observe the gate as it
runs through a complete cycle in both directions, and adjust your limits again if necessary. Fine levels of adjustment can also
be achieved by adjusting a few teeth on the nut at a time. If the gate stops in mid travel, the open or close current sensor
adjustment or the maximum run timer may need adjustment (see page 11).
Power supply must be of correct voltage and phase.
Always disconnect power from operator before servicing.
Keep clear of gate during operation.
POWER DISCONNECT BOX
(115VAC VERSION SHOWN)
L1
(WHITE)
L2
(BLACK)
GROUND
(GREEN)
ON A RIGHT-HAND OPERATOR:
OPEN LIMIT SWITCH IS THE ONE CLOSER
TO THE FRONT OF THE OPERATOR. ON A
LEFT-HAND OPERATOR, THE OPEN LIMIT
SWITCH IS THE ONE FURTHEST AWAY
FROM THE FRONT OF THE OPERATOR.
LIMIT SWITCHES
LIMIT NUTS
ROTARY LIMIT BOX ASS’Y
(SWITCHES AND BOX MAY
LOOK SLIGHTLY DIFFERENT
DEPENDING ON MODEL)

HSLG OPERATOR INSTALLATION GUIDE
- 9 -
CONTROL BOARD ADJUSTMENTS
NOTE: DO NOT FORCE 270-DEGREE POTENTIOMETERS
BEYOND THEIR NORMAL RANGE OF MOTION
OR DAMAGE MAY RESULT!
Control Board
with AC
Motor Board
DIAGNOSTIC
L.E.D.s
TERMINAL STRIP #2
CONNECTOR
TERMINAL STRIP #1
CONNECTOR
LIMIT SWITCH
CONNECTOR
LIMIT SWITCH
L.E.D.s
3A Fuse
2A Fuse
Auto Close Timer Adjustment: This 270-degree adjustable potentiometer will signal the operator to close automatically,
provided no open, reversing or obstruction signals are present from the fully-open position. This timer is adjustable from 0
to 124 seconds. This feature is turned on or off using dip switch #1.
Maximum Run Timer Adjustment: This 270-degree adjustable potentiometer will signal the operator to stop running once
it counts down, unless a limit switch is reached or an input is received first. Each time the motor starts, this timer will begin
counting. This timer is adjustable from 15 to 100 seconds. If the timer expires, the unit locks out and the emergency alarm
sounds.
Open Direction Current Sense Adjustment: This multi turn potentiometer is used to calibrate the built-in current sensing
feature for detection of obstructions while running in the open direction.
Close Direction Current Sense Adjustment: This multi turn potentiometer is used to calibrate the built in current sensing
feature for detection of obstructions while running in the closed direction.
Master/Slave Connection Block: This terminal block is used in conjunction with two operators to configure two gates to
open and close together.
Dip Switches:
#1 This switch turns the auto close timer off/on.
#2 This switch is used in conjunction with alarms and flashing lights that may be added to the operator. When the switch
is in the ON position, these devices will start approximately two seconds prior to the operator starting. In the OFF
position, the devices will only work while the operator is running.
#3 This switch is used in conjunction with single-button controls and radio receivers. In the ON position, successive inputs
will cause signals in the order of OPEN-STOP-CLOSE-STOP. In the OFF position, inputs will cause an OPEN signal
unless the gate is fully open, in which case it will signal CLOSE.
#4 This switch determines right-hand vs. left-hand behavior. When looking from inside the protected area toward the gate,
the side of the drive the operator is on determines its hand of operation. In the OFF position, the operator is set for
right-hand.
#5 When turned ON, this switch will allow a one-second delay for solenoid locks to unlock before the motor starts.
#6 In the ON position, the reverse delay is three seconds. In DC operators only, this also disables the inherent DC brake
(provided the R2 brake resistor is cut, see picture above). In the OFF position, the reverse delay is 1 1/2 seconds and
the DC inherent brake is enabled.
#7 Not used at this time.
#8 This switch is used to set Master/Slave configuration. Operators which are stand-alone or master units should be set
to OFF, while only slave units should have this switch set to ON.

HSLG OPERATOR INSTALLATION GUIDE
- 10 -
TERMINAL CONNECTION DESCRIPTIONS
TERMINALS FUNCTION DESCRIPTION OF FUNCTION
24VAC 24VAC Provides 24Volt AC power for accessories.
24VAC N Note: DC models will NOT have 24Volt AC power available.
24VDC+ 24VDC Provides 24Volt DC power for accessories.
24VDC- COMM.
1 & 4 OPEN Opens the operator. Several accessories such as button stations, keypads, trans-
mitters and card readers can be wired to open.
3 & 4 CLOSE Closes the operator. Use caution when wiring accessories to these terminals. The
gate must be clearly visible from the location of any accessories wired to
close.
4 & 5 SINGLE-BUTTON Performs the single-button function which will alternate between open and close
or open, stop and close - depending on dip switch #3. (See page 9for details.)
2 & 4 STOP Stops the operator. If no stop button is used, a jumper is required across 2&4.
4 & 6 REVERSE This function will cause a reversal when the gate is traveling closed and will travel
back to the fully open position. Loop detectors are often wired for reverse.
4 & 50 OPEN This function works only while the operator is opening. Any signal to this function
will cause the gate to stop, reverse a short distance, and then stop again. At this
time the auto close timer is disabled, and a renewed input will be required to start
the gate again. Should the gate be restarted and the signal occur again prior to
reaching a limit, the gate will stop again, and this time will sound the emergency
alarm and lock out.
4 & 51 CLOSE This function works exactly like the OPEN OBSTRUCTION, except that it will only
work in the closing direction.
4 & 11 SHADOW/HOLD This function will keep the gate in its fully open position while the signal is present.
This is typically used with a loop and loop detector to keep a large swing gate
open while vehicular traffic is passing through.
24VDC+ & 60 RUN/PRE-START A 24Volt DC device such as a strobe light or alarm can be wired to these terminals.
Depending on dip switch #2, these devices will either begin three seconds before
the operator starts, or only while the motor is running. (See page 9for details.)
OBSTRUCTION
OBSTRUCTION
You must follow all required safety precautions and instructions at all times. Review the safety brochure in-
cluded with the operator. If any pages are missing or unreadable, contact LINEAR at 1-800-333-1717 to request
additional copies.
Do not adjust the circuit board current sensing feature too high. It should be adjusted high enough to keep the
gate from falsely triggering the sensing, but no higher than necessary for the gate to operate. Do not defeat
the purpose of this function!
Controls intended for user activation must be located at least six feet (6’) away from any moving part of the
gate and where the user is prevented from reaching over, under, around or through the gate to operate the
controls. Outdoor or easily accessible controls shall have a security feature to prevent unauthorized use.

HSLG OPERATOR INSTALLATION GUIDE
- 11 -
CURRENT SENSING ADJUSTMENTS
Because gates vary in construction and may have different force requirements in the open and close directions to move, the
LINEAR control board has separate Multi-turn potentiometers for adjusting in both directions independently. The adjustment
should be set light enough to maintain minimal force (50-75 lbs.) should an obstruction occur, but high enough to keep the
gate moving under normal conditions without interruption.
Prior to adjusting the operator current sensing functions, make sure the gate moves freely in both directions. A badly aligned
or poorly maintained gate may cause false triggering of the current sensor. Refer to page 9when following the instructions
below. A factory adjustment tool has been supplied to make these adjustments easier.This tool has been taped to the control
box for your convenience.
CLOSE DIRECTION CURRENT SENSE ADJUSTMENT
When the gate operator leaves the factory, it has been preset for a relatively light gate function and will require additional
adjustment. Begin by starting the gate going closed. If the operator stops and reverses, turn the close direction potentiometer
(see page 9) one turn higher, press the STOP button, and try again. Repeat this process until the gate no longer causes
false tripping of the current sensor. Note that each time the gate operator reverses, the STOP button must be pressed. Next,
turn the close direction potentiometer lower slowly while the operator is running the gate closed until the gate operator stops
and reverses again. From this point, turn the close direction potentiometer higher by 1 1/2 turns for all 115 Volt AC and 24
Volt DC operators, and by 3/4 of a turn higher for all 230 Volt AC operators. Additional fine adjustment by 1/4 turns may be
necessary to eliminate false triggering.
OPEN DIRECTION CURRENT SENSE ADJUSTMENT
Repeat the same process with the open direction potentiometer while running the gate in the open direction. Once this is
done, run the gate through several complete cycles and make sure the gate does not false trip in either direction.
MAXIMUM RUN TIMER ADJUSTMENT
This adjustable potentiometer sets the maximum length of time the motor will run before shutting down. It should be configured
for the time it takes to run the gate fully open or closed, plus an additional 15 seconds. See page 9for details.
Multi-turn Potentiometer
Remember it is important not to set the adjustment
too high! Doing so will defeat the purpose of the cur-
rent sensing as an obstruction detecting feature.
MASTER/SLAVE CONNECTION
A three-wire shielded conductor cable is required to connect master and slave operators.You must use Belden 8760 Twisted
Pair Shielded Cable (or equivalent) only – LINEAR part number 2500-1982, per foot). See page 9for details of this connec-
tion, as well as dip switch selection. Note: The SHIELD wire should be connected in both the master and slave operators. In addition,
you must run power to both the master and slave operators.
AUTO CLOSE TIMER ADJUSTMENT
This adjustable potentiometer sets the length of time which elapses before the gate operator automatically closes the gate,
from the fully open position, provided no open, reversing, or obstruction signals are present. This feature can be turned on
or off via dip switch selection. See page 9for details. Do not use the auto close timer without an appropriate reversing
device installed!

HSLG OPERATOR INSTALLATION GUIDE
- 12 -
ONBOARD L.E.D. INDICATOR DESCRIPTIONS
Control Board L.E.D. Indicators:
OPEN This indicator is lit when an open signal is present. This signal can come from such devices as button
stations, radio receivers, keypads and telephone entry systems.
CLOSE This indicator is lit when a closed signal is present. This signal typically comes from three-button sta-
tions.
STOP This indicator is lit when there is a break in the stop circuit. Make sure there is a stop button wired in
andworking properly.
SINGLE This indicator is lit when a signal from a single-button station or radio receiver is present.
CLOSE OBST This indicator is lit when a close obstruction signal is present. This signal can come from edges and
photo eyes which have been wired to the close obstruction inputs.
OPEN OBST This indicator is lit when an open obstruction signal is present. This signal can come from edges and
photo eyes which have been wired to the open obstruction inputs.
SAFETY LOOP This indicator is lit when a reversing signal is present. This signal is generated by a loop detector wired
to the safety loop terminals.
SHADOW LOOP This indicator is lit when a shadow/hold open signal is present.This signal is generated by a loop detector
wired to the shadow loop terminals.
This indicator is lit when the open #1 limit switch is activated on a right-hand operator, or the close #1
switch on a left-hand. If this indicator is lit and the gate is not in its full open/closed position, the limit may
need adjusting or the limit switch may need replacing.
This indicator is lit when the open #2 limit switch is activated on a right-hand operator, or the close #2
switch on a left-hand.
This indicator is lit when the close #1 limit switch is activated on a right-hand operator, or the open #1
on a left-hand. If this indicator is lit and the gate is not in its full open/closed position, the limit may need
adjusting or the limit switch may need replacing.
This indicator is lit when the close #2 limit switch is activated on a right-hand operator, or the open #2
switch on a left-hand.
Motor Board L.E.D. Indicators:
NON LABELED One of these two indicators will be lit when the motor is running the gate open, and the other is lit when
the motor is running the gate closed.
BRAKE REL. This indicator is lit when the brake is NOT applied.
LSO-1
LSO-2
LSC-1
LSC-2
LSC-1
LSC-2
LSO-1
LSO-2
LH RH

HSLG OPERATOR INSTALLATION GUIDE
- 13 -
IMPORTANT NOTES FOR
INSTALLATION OF MASTER/SLAVE APPLICATIONS
When setting up Master/Slave gate operators, it is best to make adjustments and run each operator individually. To do this,
simply:
a. Set Dip Switch #4 to proper hand of operation (right-hand or left-hand)
b. Set Dip Switch #8 as Master (off)
Run each operator making current sensing adjustments as necessary, as indicated on the Control Board Adjustments page
of this installation guide. When both operators have been adjusted, turn power off, then turn on Dip Switch #8 in the operator
chosen as the Slave.
The timer to close and radio/single button behavior are set in the Master operator.
The following selections are set individually:
Current Sensing
Maximum Run Timer
One-Second Lock Release
Three-Second Pre-Start Warning
Right/Left-Hand Selections
SURGE PROTECTOR INSTRUCTIONS
The optional surge protector should be connected
to any inputs that have an accessory connected to
it. This includes the 3-button station, so it must be
connected to 1, 2A and 3 in all cases. The green
wire connected to ground, which is electrically
the same as terminal 4. The red wires connect to
terminals 2A and 24VDC+. This will cause the
2 amp fuse to blow if this section of the module
becomes shorted. With any of the other inputs
connected to the surge protector, if their protection
line becomes shorted due to a surge over the rating
of the module, the corresponding LED on the main
board will remain lit, causing a constant signal to
the controller. If this is found, please replace the
entire surge protector with a new unit.
Do not simply unhook the shorted wire, as this
removes the protection from the circuit that was
saved by the protector in the first place!

HSLG OPERATOR INSTALLATION GUIDE
- 14 -
CONTROL and ACCESSORY CONNECTION ILLUSTRATIONS

HSLG OPERATOR INSTALLATION GUIDE
- 15 -
CONTROL and ACCESSORY CONNECTION ILLUSTRATIONS

HSLG OPERATOR INSTALLATION GUIDE
- 16 -
CONTROL and ACCESSORY CONNECTION ILLUSTRATIONS

HSLG OPERATOR INSTALLATION GUIDE
- 17 -
CONTROL and ACCESSORY CONNECTION ILLUSTRATIONS

HSLG OPERATOR INSTALLATION GUIDE
- 18 -
LOOP LAYOUT ILLUSTRATION
Refer to Connection Descriptions on page 10 and Loop Accessory Connections on page 17 for details.

HSLG OPERATOR INSTALLATION GUIDE
- 19 -
EDGE LAYOUT ILLUSTRATION #1
Refer to Connection Descriptions on page 10 and Contact Edge Connections on page 16 for details.

HSLG OPERATOR INSTALLATION GUIDE
- 20 -
EDGE LAYOUT ILLUSTRATION #2
Refer to Connection Descriptions on page 10 and Contact Edge Connections on page 16 for details.
