Linear SG User manual

SG - SG-D
Barrier Gate Operator
Installation Guide
USA & Canada [phone] & [phone]
[phone] - Toll Free FAX [phone]
www.linearcorp.com
Operator models contained in this manual
conform to UL325 standard for use in
Class I, II, III, and IV applications

SG •SG-D Barrier Gate Operator Installation Guide P1277 Revision X2 8-11-2011
Table of Contents
Pre-installation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Before You Begin... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Gate Operator Classifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Approved Obstruction Detection Devices . . . . . . . . . . . . . . . . . . . . . 1
Safety Information and Warnings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Regulatory Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Wiring Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
AC Power Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
DC Control and Accessory Wiring. . . . . . . . . . . . . . . . . . . . . . . . . . .2
Installation on Concrete Curb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Barrier Gate Arm Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Attaching the Gate Arm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Operator Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Gear Reducer Vent Plug . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Limit Cam Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Operator Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Controller Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
AC Power Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Earth Ground. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Controller Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Indicator Descriptions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Terminal Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Operator Accessory Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Basic Controller Programming. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Programming Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Entering Programming Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Exiting Programming Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Programming Keystrokes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Left or Right Hand Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Dual Gate Enable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Auto Close Timer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Run Alarm and Pre-start Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Maximum Close Direction Current Setting . . . . . . . . . . . . . . . . . . .12
Advanced Controller Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Entering Advanced Programming Mode . . . . . . . . . . . . . . . . . . . . .12
Maximum Run Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Single Button Input Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Stagger Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Stagger Delay Time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Auxiliary Relay Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Reverse Delay Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Low Power Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Power Failure Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Soft Start/Stop Duration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Reset Cycle Count . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Maintenance Alert Trigger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Open/Reset Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Anti-tailgate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Radio Enable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Antenna Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Radio Transmitter Learn . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Radio Transmitter Delete . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
MGT Obstacle Transmitter Learn . . . . . . . . . . . . . . . . . . . . . . . . . .16
MGT Obstacle Transmitter Delete . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Motor Type Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Reset Controller to Factory Defaults . . . . . . . . . . . . . . . . . . . . . . . .16
Free Gate Loop Layout Illustration . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Pay Gate Loop Layout Illustration . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Dual Gate Installations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Gate Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Open Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Close Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Single Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Fire Department Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Open Input. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Open/Reset Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Close Obstruction Input. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Reverse Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Open Loop. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Reverse Loop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Reset Loop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Operation Indications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Power-up Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Idle Condition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Last Gate Position/Condition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Reverse Delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Run Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Error Indications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Entrapment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
COMM LINK Connection Failure . . . . . . . . . . . . . . . . . . . . . . . . . . .20
MGT Obstacle Transmitter Trouble . . . . . . . . . . . . . . . . . . . . . . . . .20
Maximum Run Time Exceeded . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Contacting Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Operator fails to start. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Motor operates, but gate does not move. . . . . . . . . . . . . . . . . . . . .21
Motor sounds like it is working harder than normal . . . . . . . . . . . . .21
Limit switch getting out of time . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Gate stopping part way open or closed . . . . . . . . . . . . . . . . . . . . .21
Gate staying open with automatic system. . . . . . . . . . . . . . . . . . . .21
How to Order Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . .21
Model SG Exploded View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Model SG-D Exploded View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Model SG & SG-D Arm Parts List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Model SG and SG-D Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Battery Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Preventative Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Lubrication. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
6-Month Preventative Maintenance. . . . . . . . . . . . . . . . . . . . . . . . .25
FCC Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Gate Operator Installation Checklist . . . . . . . . . . . . . . . . . . . . . . . . . .26
ONLY QUALIFIED TECHNICIANS
SHOULD WORK ON
LINEAR BARRIER GATE
OPERATORS
WARNING

SG •SG-D Barrier Gate Operator Installation Guide - 1 - P1277 Revision X2 8-11-2011
Pre-installation Information
Before You Begin...
Before unpacking, inspect the carton for exterior damage. If
you find damage, advise the delivery carrier of a potential
claim. Inspect your package carefully. You can check your
accessory box parts with the enclosed packing slip for your
convenience. Claims for shortages will be honored for only
30 days from the date of shipment.
Before installing the operator, read this manual completely
to ensure all requirements for proper installation are present.
Verify that the voltage to be used matches the voltage of the
operator.
If you have any questions about the requirements for proper
installation of this gate operator contact technical support at
800-421-1587
Gate Operator Classifications
All gate operators can be divided into one of four different
classifications, depending on their design and usage. Install
this gate operator only when the operator is appropriate for
the construction and usage class as defined below:
• Class I Residential Vehicular Gate Operator
A vehicular gate operator intended for use in a home or for one to
four single family dwellings with a common garage or parking area
associated with these dwellings.
• Class II Commercial / General Access Vehicular Gate Operator
A vehicular gate operator intended for use in a commercial location
or building such as a multi-family housing unit of five or more single
family units, hotel, retail store or other building servicing the general
public.
• Class III Industrial / Limited Access Vehicular Gate Operator
A vehicular gate operator intended for use in an industrial location
or building such as a factory or loading dock area or other location
not intended to service the general public.
• Class IV Restricted Access Vehicular Gate Operator
A vehicular gate operator intended for use in a guarded industrial
location or building such as an airport security area or other
restricted access locations not servicing the general public, in
which unauthorized access is prevented via supervision by security
personnel.
Linear barrier gate operator models SG and SG-D meet
the requirements for all four classifications.
Approved Obstruction Detection Devices
The following contact or non-contact obstruction detection
devices have been approved for use with this swing gate
operator as part of a UL325 compliant installation:
• Contact Edges
Miller Edge Models MGO20, MGR20, MGS20, ME120
• Photoeyes
MMTC Model IR-55 (165’ range - P/N 2520-441)
MMTC Model E3K (28’ range - P/N 2520-031)
Safety Information and Warnings
Regulatory Warnings
Read the following before beginning to install this swing
gate operator:
THE FOLLOWING FORMATS ARE USED FOR SAFETY NOTES
IN THESE INSTRUCTIONS.
WARNING
This type of warning note is used to
indicate possible mechanical hazards that
may cause serious injuries or death.
CAUTION
This type of warning note is used to
indicate the possibility of damage to the
barrier arm or gate operator.
WARNING
This type of warning note is used to indicate
possible electrical shock hazards that may
cause serious injuries or death.
IMPORTANT INSTALLATION SAFETY INSTRUCTIONS
WARNING
TO REDUCE THE RISK OF SEVERE INJURY OR DEATH
TO PERSONS, REVIEW THESE INSTALLATION SAFETY
STEPS BEFORE PROCEEDING
1. READ AND FOLLOW ALL INSTALLATION INSTRUCTIONS.
2. Read the blue “Safety Instructions” brochure enclosed with the
packet of information. If any pages are missing or are unreadable,
or you do not have the safety instructions, please call Linear at
1-800-333-1717 to request additional copies.
3. ALL ELECTRICAL CONNECTIONS TO THE POWER SUPPLY MUST
BE MADE BY A LICENSED ELECTRICIAN AND MUST OBSERVE ALL
NATIONAL AND LOCAL ELECTRICAL CODES.
4. A separate power-disconnect switch should be located near the
operator so that primary power can be turned off when necessary.
5. Never connect a button station within reach of the barrier gate or on
the side of the gate operator.
6. Do not adjust the operator controller’s current sensing feature too
high. It should be adjusted high enough to keep the gate from falsely
triggering the sensing, but no higher than necessary for the gate to
operate. DO NOT DEFEAT THE PURPOSE OF THIS FUNCTION!
7. You must install all required safety equipment.
8. UL325 Compliance requires the use of contact edges or photoelectric
controls on all automatic or remotely-controlled gate operators.
9. The operator is intended for installation only on gates used for
vehicles. Pedestrians must be supplied with a separate access
opening. The pedestrian access opening shall be designed to
promote pedestrian usage. Locate the gate such that persons will
not come into contact with the vehicular gate during the entire path
of travel of the vehicular gate.

SG •SG-D Barrier Gate Operator Installation Guide - 2 - P1277 Revision X2 8-11-2011
Wiring Specifications
Refer to the following steps for details on power and
accessory wiring for the operator.
AC Power Wiring
1. Find the listing on this page corresponding to the model, voltage and
horsepower rating of your operator.
2. The distance shown in the table is measured in feet from the
operator to the power source. DO NOT EXCEED THE MAXIMUM
DISTANCE. These calculations have been based on standard 115 V
and 230 V supplies with a 10% drop allowable. If your supply is under
the standard rating, the runs listed may be longer than what your
application will handle, and you should not run wire too near the
maximum distance for the gauge of wire you are using.
3. When large-gauge wire is used, a separate junction box (not
supplied) may be needed for the operator power connection.
4. Wire length calculations are based on the National Electrical Code,
Article 430 and have been carefully determined based on motor
inrush, brake solenoids, and operator requirements.
5. Connect power in accordance with local codes. The green ground
wire must be properly connected.
6. Wire insulation must be suitable to the application.
7. Electrical outlets are supplied in all 115 VAC models for convenience
with occasional use or low power consumption devices only. If
you choose to run dedicated equipment from these devices, it will
decrease the distance for maximum length and the charts will no
longer be accurate.
DC Control and Accessory Wiring
1. All control devices are now 24 VDC, which can be run up to 2000
feet with 14 AWG wire.
2. Control wiring must be run in a separate conduit from power wiring.
Running them together may cause interference and faulty signals in
some accessories.
3. A three-wire shielded conductor cable is required to connect two
operators together for dual operation. You must use Belden 8760
Twisted Pair Shielded Cable (or equivalent) only – P/N 2500-1982,
per foot). See Page 19 for details of this connection. Note: The shield
wire should be connected in both the operators.
WARNING
ALL AC ELECTRICAL CONNECTIONS TO THE POWER SOURCE AND
THE OPERATOR MUST BE MADE BY A LICENSED ELECTRICIAN
AND MUST OBSERVE ALL NATIONAL AND LOCAL ELECTRICAL
CODES.
USE COPPER WIRE ONLY!
MODEL SG POWER WIRING
VOLTS & HP MAXIMUM DISTANCE (FEET) WIRE GAUGE
SINGLE DUAL
115 VOLTS
1/2-HP
222 111 12
354 177 10
566 283 8
900 450 6
230 VOLTS
1/2-HP
894 447 12
1422 711 10
2264 1132 8
3600 1800 6
MODEL SG-D POWER WIRING
VOLTS & HP MAXIMUM DISTANCE (FEET) WIRE GAUGE
SINGLE DUAL
115 VOLTS
1/2-HP
222 111 12
354 177 10
566 283 8
900 450 6

SG •SG-D Barrier Gate Operator Installation Guide - 3 - P1277 Revision X2 8-11-2011
Installation on Concrete Curb
The barrier gate operator bolts to a concrete island or curb.
1. Un-crate the gate. Avoid damaging the cabinet finish.
2. Leave the machine bolted to the bottom pallet until ready to install.
3. Open the cabinet door.
4. Remove the bolts holding the gate to its pallet and place the machine
in position on the curb. Refer to your Equipment Layout (EL) drawing
for proper positioning of your gate.
5. With a pencil, mark the location of the mounting holes on the concrete.
6. Set the gate aside. Drill all four mounting holes using a 3/4” diameter
rotary hammer percussion drill bit. Insert lag screw anchors for 1/2”
lag bolts. Place the gate back in position, and anchor it with 1/2” lag
bolts and flat washers. Lubricate the bolts before installation. Flat
washers have been supplied to go between pavement and cabinet.
Linear highly recommends using the corner mounting holes when
mounting barrier gates.
7. Proceed with the rest of the installation process.
48"
ISLAND
WIDTH
(MINIMUM)
48"
36"
24"
24"
4" DIA. GUARD POSTS
4 FT. TALL, BY OTHERS
15"
7-1/2"
6-1/4"
4-3/4" 4-3/4"
6-1/4"
6-1/4"
6-1/4"
7-1/2"
15"
.75
ø 8X
OPEN SPACE FOR
CONDUITS HERE
SERVICE DOOR SIDE
OF BARRIER GATE
(FACES AWAY FROM DRIVE)
14" MINIMUM
TO PROVIDE CLEARANCE FOR
FLANGE AND COUNTERWEIGHTS
Figure 1. Concrete Lag Anchor Detail
Figure 2. Barrier Gate Mounting Specifications
WARNING
The operator is intended for installation only on gates used for
vehicles. Pedestrians must be supplied with a separate access
opening. The pedestrian access opening shall be designed to
promote pedestrian usage. Locate the gate such that persons
will not come into contact with the vehicular gate during the
entire path of travel of the vehicular gate.
WARNING
The gate must be installed in a location so that enough
clearance is supplied between the gate and adjacent
structures when opening and closing to reduce the risk of
entrapment.
CABINET BASE
1/2
ø X4" LAG BOLT
AND FLAT WASHER
SUPPLIED
FLAT WASHER
3/4ø HOLE
IN CONCRETE
LAG SCREW
ANCHOR

SG •SG-D Barrier Gate Operator Installation Guide - 4 - P1277 Revision X2 8-11-2011
Barrier Gate Arm Installation
The barrier gate arm connects to the operator with the arm
attachment channel and gate arm flange. Counterweights
in the attachment channel balance the gate arm for smooth
operation.
✓NOTE: Numbered items in these drawings are for
instructional reference only. For actual part numbers, go
to the parts lists in the back of this booklet.
Attaching the Gate Arm
1. Assemble the SG arm on the ground first, making sure to leave all
fasteners loose, including the spreader arms (Parts #4 & #7).
2. Make sure the barrier gate is in the full closed position.
3. With someone’s assistance, lift the arm up to a height even with
the barrier gate flange. The far end should either be supported by
something of equal height as the flange, or be held by someone
throughout the next steps.
4. Assemble the wood arms (#10) between the attachment channels
(#8) and the flange and bolt together. Tighten these bolts (#9) firmly.
5. Tighten all bolts (#3) where the three pieces of wood arm come
together.
6. Tighten up the nuts (#6) on the spreader arms (#4 & #7) until the
plates (#5) are tight against the wood.
7. The arm should have a curved, wishbone appearance once finished.
Figure 4. Gate Arm Attachment
Figure 3. Wishbone Arm Assembly
8
9
9
10
8
1
2
3
4
5
6
7
GATE
OPERATOR
END
6

SG •SG-D Barrier Gate Operator Installation Guide - 5 - P1277 Revision X2 8-11-2011
Operator Preparation
Gear Reducer Vent Plug
In order to keep gear oil from spilling out during shipping,
gear reducers used in the SG and SG-D barrier gate
operators have a sealed vent plug installed at the factory.
Leaving the vent plug installed, remove the vent plug’s
breather pin to allow the gear box to vent (see Figure 5).
The breather pin can be discarded.
Limit Cam Adjustments
The limit cams for all models of barrier gate operators have
been pre-set at the factory for approximately 90 degrees of
motion. If you need to adjust this further, see Figure 6 and
follow the directions below.
1. For more downward travel, loosen the wingnut on the LSC-1 (down)
limit cam and rotate the cam slightly in the “B” direction.
2. For less downward travel, loosen the wingnut on the LSC-1 (down)
limit cam and rotate the cam slightly in the “A” direction.
3. For more upward travel, loosen the wingnut on the LSO-1 (up) limit
cam and rotate the cam slightly in the “A” direction.
4. For less upward travel, loosen the wingnut on the LSO-1 (up) limit
cam and rotate the cam slightly in the “B” direction.
✓NOTE: If the barrier gate operator has been custom
configured by the factory for reverse arm operation
(where the closed barrier arm sticks out from the service
door side of the operator) the limit switches shown in
Figure 6 will be reversed. The top limit switch will be the
open limit, the bottom limit switch will be the close limit.
GEAR REDUCER
VENT PLUG
REMOVE THE
BREATHER PIN
CLOSE LIMIT
SWITCH LSC-1
CLOSE
LIMIT CAM
OPEN LIMIT
SWITCH
LSO-1
OPEN
LIMIT CAM
DIRECTION
"B"
DIRECTION
"A"
Figure 5. Vent Plug Installation
Figure 6. Limit Cam Adjustment

SG •SG-D Barrier Gate Operator Installation Guide - 6 - P1277 Revision X2 8-11-2011
Operator Setup
Controller Access
The Controller in models SG and SG-D is located under the
operator’s top cover.
To access the Controller, from inside the operator, flip the
two cover release latches up to unlock the operator’s top
cover. Remove the cover to expose the Controller.
The Controller is protected by a plastic dust cover. To
remove the dust cover, loosen the cover’s wing-screw and
lift the cover off.
AC Power Connection
All Linear gate operators are supplied with a power
disconnect switch to turn on and off the power available to
the operator (see Figure 8). Following wiring specifications
on Page 2, incoming power should be brought into the
operator and connected to the labeled pigtails from the
disconnect box.
✓NOTE: FOR SOLAR POWERED UNITS ONLY: The
APeX Controller’s AC power disconnect switch does not
turn off the Apex DC power when connected to solar
panels. It will however, disconnect DC motor power.
Unplug the solar panel input on the front of the Apex
Controller prior to servicing the unit.
Proper thermal protection is supplied with the operator. The
motor contains a thermal overload protector to guard from
overheating the motor due to overload or high-frequency
operation. To reset the motor after an overload, press the
red button on the end of the motor after the motor has
cooled down.
Earth Ground
Install a ground rod and connect it to the operator’s frame
in every gate operator installation. A good earth ground is
necessary to allow the Controller’s built-in surge and lightning
protection circuitry to work effectively. The physical bolting
of the operator to the mounting pad is not sufficient for
a good earth ground.
✓NOTE: Do not splice the ground wire. Use a single piece of solid
copper 12 AWG wire between the ground rod and the operator.
1. Install an 8-foot long copper ground rod next to the operator mounting
pad within three feet of the operator.
2. Use a clamp to connect a solid copper 12 AWG ground wire to the
ground rod.
3. Route the ground wire to the operator.
4. Connect the ground wire to the operator’s frame.
COVER
RELEASE
LATCH
Figure 7. Cover Release Latch
Figure 8. Power Disconnect Box Wiring
CONNECT AC POWER
PIGTAIL LEADS TO
AC POWER SOURCE
115 VAC WIRING
GREEN - GROUND
BLACK - HOT
WHITE - NEUTRAL
230 VAC WIRING
GREEN - GROUND
BLACK - HOT
WHITE - HOT
SERVICE OUTLET
ON 115 VAC UNITS
ONLY
WARNING
ALL AC ELECTRICAL CONNECTIONS TO THE POWER SOURCE AND
THE OPERATOR MUST BE MADE BY A LICENSED ELECTRICIAN AND
MUST OBSERVE ALL NATIONAL AND LOCAL ELECTRICAL CODES.
POWER SUPPLY MUST BE OF CORRECT VOLTAGE AND PHASE.
WARNING
Always disconnect power from operator before servicing.
Always keep clear of gate arm during operation.

SG •SG-D Barrier Gate Operator Installation Guide - 7 - P1277 Revision X2 8-11-2011
Controller Features
SHADOW/RESET
OPEN/RESET
PROGRAMMING
BUTTONS
POWER
INDICATORS
DISPLAY
WHIP
ANTENNA
OPERATION
BUTTONS
OPERATION AND
PROGRAMMING
INDICATORS
ANTENNA
CONNECTOR
MOTOR
BOARD
COVER
INPUT
POWER
TERMINALS
ACCESSORY
POWER
TERMINALS
RESET
BUTTON
TERMINALS
SOLAR
PANEL
TERMINALS
BATTERY
TERMINALS
PLUG-IN
LOOP
DETECTOR
CONNECTORS
PRIMARY/
SECONDARY
COMM LINK
TERMINALS
SINGLE
INPUT
TERMINALS
FIRE DEPT
INPUT
TERMINALS
OPEN INPUT
TERMINALS
3-BUTTON
STATION
TERMINALS
OPEN/RESET AND
CLOSE OBSTRUCTION
INPUT TERMINALSREVERSE
INPUT
TERMINALS
OPEN LOOP
INPUT TERMINALS
REVERSE LOOP
INPUT TERMINALS
SHADOW/RESET LOOP
INPUT TERMINALS
LIMIT SWITCH
INPUT TERMINALS
ALARM
OUTPUT
TERMINALS
AC MOTOR
OUTPUT
TERMINALS
AUXILIARY
RELAY
TERMINALS
Figure 9. Controller Features

SG •SG-D Barrier Gate Operator Installation Guide - 8 - P1277 Revision X2 8-11-2011
Indicator Descriptions
INDICATOR DEFINITION INDICATION WHEN LIT
DURING NORMAL OPERATION
INDICATION WHEN LIT
DURING PROGRAMMING
OPERATION PROGRAMMING
24 VOLT INPUT
POWER LOW VOLTAGE AC POWER IS PRESENT
24 VOLT DC
ACCY POWER LOW VOLTAGE DC POWER IS PRESENT
OPEN
OPEN SIGNAL PRESENT FROM THE INTERNAL
RECEIVER OR AN EXTERNAL DEVICE
CONNECTED TO THE OPEN INPUT TERMINAL
CLOSE CLOSE SIGNAL IS PRESENT FROM A DEVICE
CONNECTED TO THE CLOSE INPUT TERMINAL
STOP STOP INPUT TERMINAL IS OPEN AND
NOT CONNECTED TO COMMON
PROGRAM CONTROLLER IS IN PROGRAMMING MODE
REVERSE DELAY SET SET REVERSE DELAY TIME
LOCKOUT ALARM SET CONTROLS AND OPERATOR ARE LOCKED OUT
BECAUSE OF EXISTING TROUBLE CONDITION
RADIO LEARN BUILT-IN RECEIVER IS DETECTING A RADIO
SIGNAL FROM A REMOTE CONTROL
TRANSMITTERS CAN BE ENTERED INTO
MEMORY (UP TO 40 TRANSMITTERS)
OPEN CURRENT
OPEN/RESET OPEN/RESET INPUT ACTIVATED
BY LOOP OR SWITCH
OPEN RELAY OPEN RELAY IS ACTIVATED
OPEN LIMIT BRAKE DELAY OPEN LIMIT SWITCH IS ACTIVATED
CLOSE CURRENT SET MOTOR CURRENT HAS EXCEEDED THE
CLOSE CURRENT SETTING WHILE CLOSING SET MAXIMUM CLOSE CURRENT
CLOSE OBSTR MGT 1 SET
CLOSE OBSTRUCTION TERMINAL CONNECTED
TO COMMON BY BEAM OR SAFETY EDGE, OR
SIGNAL FROM MGT OBSTACLE TRANSMITTER
SET MGT #1 FUNCTION
CLOSE RELAY AUTO CLOSE SET CLOSE RELAY IS ACTIVATED SET AUTO-CLOSE TIME
CLOSE LIMIT AC DC SET CLOSE LIMIT SWITCH IS ACTIVATED SET MOTOR TYPE
SINGLE SET SINGLE TERMINAL CONNECTED TO COMMON
BY AN EXTERNAL PUSHBUTTON OR RADIO SET SINGLE BUTTON INPUT FUNCTION
MAX RUN SET MAXIMUM RUN TIMER HAS BEEN EXCEEDED SET MAXIMUM RUN TIME
COMM LINK SET DUAL OPERATOR CONNECTION DETECTED,
BLINKS IF CONNECTION HAS FAILED
MAINT ALERT SET MAINTENANCE IS REQUIRED ON OPERATOR SET MAINTENANCE ALERT CYCLE COUNT
"RL"
LEFT ORRIGHT
HAND OPERATION
"PM"
SINGLE OR
DUAL GATE
"AC"
AUTO CLOSE
TIMER
"RP"
RUN ALARM
PRE-START ALARM
"CC"
MAXIMUM CLOSE
CURRENT
"AD"
ADVANCED
PROGRAMMING
"RT"
MAXIMUM
RUN TIMER
"SB"
SINGLE BUTTON
INPUT SETUP
"SM"
STAGGER
MODE
"ST"
STAGGER
TIME
"AR"
AUXILIARY
RELAY MODE
"RD"
REVERSE
DELAY TIME
"LP"
LOW POWER
MODE
POWER
FAILURE MODE
"FS"
"SS"
SOFT START/STOP
DURATION
"CT"
RESET CYCLE
COUNT
"MA"
MAINTENANCE ALERT
TRIGGER
"RA"
RADIO
ENABLE
"TL"
LEARN
TRANSMITTERS
"TD"
DELETE
TRANSMITTERS
"ML"
LEARN MGT
TRANSMITTERS
"MD"
ERASE MGT
TRANSMITTERS
"CL"
RESET TO
FACTORY DEFAULTS
APEX FUNCTION DISPLAY INDICATIONS
MOTORTYPE
SELECTION
"MO"
"OR"
OPEN/RESET
INPUT
"TG"
ANTI
TAILGATE

SG •SG-D Barrier Gate Operator Installation Guide - 9 - P1277 Revision X2 8-11-2011
Terminal Descriptions
TERMINAL GROUP FUNCTION
AC N 24 VOLT INPUT FACTORY CONNECTED TO 24 VAC FROM TRANSFORMER OR
24 VDC FROM CONTINUOUS DUTY DC SUPPLY.
AC
DC -ACCESSORY POWER PROVIDES 24 VOLT DC POWER FOR ACCESSORIES. (.5A MAX)
DC +
RESET RESET BUTTON NOT USED IN BARRIER GATES.
COMMON
C
COMM LINK FOR 3-WIRE NETWORK CONNECTION TO SECOND OPERATOR IN DUAL GATE INSTALLATIONS.B
A
COMMON SINGLE BUTTON INPUT CONNECT TO NORMALLY OPEN SWITCH FOR SINGLE BUTTON OPERATION. ALTERNATES
BETWEEN OPEN-CLOSE OR OPEN-STOP-CLOSE DEPENDING ON PROGRAMMING.
SINGLE
COMMON FIRE BOX INPUT CONNECT TO NORMALLY OPEN SWITCH IN FIRE BOX FOR FIRE DEPARTMENT ACCESS.
FIRE DEPT
COMMON
OPEN INPUT
CONNECT TO NORMALLY OPEN DEVICES (KEYPAD, CARD READER,
KEYSWITCH, TELEPHONE ENTRY SYSTEM) TO OPEN THE GATE. A CONSTANT
OPEN INPUT WILL HALT THE AUTO CLOSE TIMER UNTIL RELEASED.
OPEN
OPEN
3-BUTTON
STATION INPUT
CONNECT TO 3-BUTTON STATION FOR OPEN-CLOSE-STOP CONTROL. A CONSTANT OPEN INPUT
WILL OVERRIDE THE MID-TRAVEL STOP AND HALT THE AUTO CLOSE TIMER UNTIL RELEASED.
CLOSE
COMMON
STOP
COM
OPEN/RESET
INPUT
PROGRAMMABLE FOR STANDARD RESET LOOP, OPEN COUNTER MODE USING
THE SHADOW/RESET LOOP, OR OPEN SUPERVISED MODE. SEE PAGE 15.
OPEN/RESET
C-OBS
CLOSE
OBSTRUCTION
INPUT
CONNECT TO NORMALLY OPEN DEVICES (GATE EDGE, PHOTO BEAM) TO DETECT AN
OBSTRUCTION DURING CLOSING. WHILE GATE IS MOVING, ANY CLOSE OBSTRUCTION
SIGNAL WILL CAUSE THE GATE TO STOP, THEN REVERSE AND TRAVEL TO THE FULL
OPEN POSITION. SHOULD A OPEN OBSTRUCTION INPUT OR AN OPEN DIRECTION
INHERENT ENTRAPMENT CONDITION OCCUR PRIOR TO THE GATE REACHING THE
OPEN LIMIT, THE OPERATOR WILL LOCKOUT AND SOUND THE CONTINUOUS TONE
ALARM. IF THE AUTO CLOSE TIMER IS SET, WHEN THE CLOSE OBSTRUCTION INPUT
IS CLEARED, THE GATE WILL CLOSE WHEN THE AUTO CLOSE TIMER EXPIRES.
COM
COM
REVERSE
CONNECT TO NORMALLY OPEN DEVICES TO CAUSE A REVERSAL WHEN
THE GATE IS TRAVELING CLOSED. THE GATE WILL REVERSE TO THE FULL
OPEN POSITION. TYPICALLY NOT USED IN BARRIER GATES.
REV
OPEN LOOP
OPEN LOOP
CONNECT TO OPEN LOOP/FREE EXIT LOOP. THE GATE WILL OPEN
WHEN THE LOOP IS TRIGGERED, AND REMAIN OPEN AS LONG AS
THE LOOP IS TRIGGERED. REQUIRES LOOP DETECTOR.OPEN LOOP
REVERSE LOOP
REVERSE LOOP
CONNECT TO REVERSE LOOP. TRIGGERING THE LOOP WILL CAUSE A REVERSAL
WHEN THE GATE IS TRAVELING CLOSED. THE GATE WILL REVERSE TO THE FULL OPEN
POSITION. REQUIRES LOOP DETECTOR. TYPICALLY NOT USED IN BARRIER GATES.
REVERSE LOOP
SHADOW/RESET LOOP
SHADOW/RESET LOOP
CONNECT TO RESET LOOP TO KEEP THE GATE IN ITS FULLY OPEN POSITION AS LONG AS
THE SIGNAL IS PRESENT. USED TO KEEP GATE OPEN WHILE VEHICLE IS PASSING THROUGH.
REQUIRES LOOP DETECTOR. ALSO USED FOR OPEN COUNTER MODE IN BARRIER GATES.SHADOW/RESET LOOP
-ALARM NOT USED IN BARRIER GATES.
+
N.O.
AUX RELAY FOR CONNECTION TO AUXILIARY DEVICES (MAGNETIC LOCK, SOLENOID LOCK,
STROBE LIGHT) FOR ACTIVATION (OR DEACTIVATION) DURING GATE OPERATION.
COM
N.C.
+24 VOLT SOLAR PANEL FOR CONNECTION TO 24 VOLT SOLAR PANEL FOR BATTERY CHARGING.
-
+24 VOLT BATTERY FACTORY CONNECTED TO BATTERIES IN DC MODEL OPERATORS.
-

SG •SG-D Barrier Gate Operator Installation Guide - 10 - P1277 Revision X2 8-11-2011
Operator Accessory Connections
3-BUTTON STATION
KEYSWITCH
FIRE ACCESS SWITCH
PHOTOEYE FOR REVERSE
TELEPHONE ENTRY
KEYPAD
WARNING STROBE OR AUDIBLE SOUNDER
PHOTOEYE FOR CLOSE OBSTRUCTION
OPEN/RESET
WIRELESS GATE EDGE SENSOR
MGT
TRANSMITTER
CHANNEL #1
OPEN/CLOSE
TWO-CHANNEL RADIO RECEIVER
OPEN/RESET
MGT TRANSMITTER
SENDS CLOSE OBSTRUCTION
SIGNAL TO CHANNEL #2
OF MGR-2 RECEIVER
MGR-2
RECEIVER
SINGLE-CHANNEL RADIO RECEIVER
MGR
RECEIVER
WIRED GATE EDGE SENSOR
OPEN/RESET
OPEN/RESET LOOP DETECTOR
OPEN/RESET
WHITE
BLACK
OPTIONAL HEATER
(With built-in switch and thermostat)
115 VOLT HEATER (P/N 2510-262)
230 VOLT HEATER (P/N 2510-273)
Figure 10. Operator Accessory Connections

SG •SG-D Barrier Gate Operator Installation Guide - 11 - P1277 Revision X2 8-11-2011
Basic Controller Programming
Programming Overview
The Controller can be programmed with various options for the operator.
The programming fields are defined as “functions” that have “options”.
To make setup easier for the installer, the Controller’s programming is
divided into two groups: basic and advanced. The basic programming
group contains the functions commonly used in most swing gate
installations. The advanced programming group contains functions less
commonly used (i.e. dual gate stagger delay, maximum run timer, etc.).
Entering Programming Mode
Enter programming mode by pressing the UP and DOWN buttons
together for one second. While in programming mode the PROGRAM
indicator will light.
Exiting Programming Mode
Exit programming mode at any time by pressing the UP and DOWN
buttons together. The Controller will automatically exit programming
mode after three minutes of inactivity.
Programming Keystrokes
(Typical Programming Method)
While in programming mode, press the UP or DOWN buttons to scroll
through the programming functions. When the desired function is
displayed press the ENTER button to display the currently set option for
the function. When an option is displayed, the decimal points are lit.
To change the option, press and hold the ENTER button for 1 second. To
indicate that an option is ready to be changed, the display will flash.While
the display is flashing, press the UP or DOWN button to display the other
options available for that function.
When the desired option is displayed, press the ENTER button to store
it into memory. To select another function, press ENTER, UP, or DOWN.
Left or Right Hand Operation
The function is not used with barrier gates.
Dual Gate Enable
The factory default is for single gate operation. For dual gate operation,
wire the two gate controllers together through the COMM LINK terminals
(see Page 19) and enable dual gate operation with this programming
step.
Auto Close Timer
The factory default turns off the Auto Close Timer. The timer can be set
from 1 to 59 seconds and from 1 to 9 minutes. When the Auto Close
Timer is set, after opening, the gate will wait for the length of the Auto
Close Timer then close automatically.
Run Alarm and Pre-start Alarm
The function is not used with barrier gates.
PRESS DOWN AND UP
BUTTONSTOGETHER
FORONE SECOND
PROGRAM INDICATOR
WILL LIGHT WHEN SYSTEM
ISIN PROGRAM MODE
PROGRAM
INDICATOR
AND
DOWN UP
ENTERING
PROGRAMMING
FUNCTION
"RL"
FUNCTION
DUAL GATE INSTALLATION
SINGLE GATE INSTALLATION
OPTIONS
PRESS UP OR
DOWN TO CYCLE
THROUGH OPTIONS
PRESS ENTERTO
SELECT AN OPTION
SINGLE GATE
DUAL GATE
"PM"
PRESS UP ORDOWN
TO SCROLL DISPLAY
THROUGH FUNCTIONS
PRESS ENTERFOR
ONE SECOND TO
SELECT OPTION
(THE DISPLAY
WILL FLASH)
PRESS UP
ORDOWN
TO CHANGE
OPTION
ENTER
PROGRAMMING
KEYSTROKES
SELECT
FUNCTION
CURRENTLY
SET OPTION
OPTION READY
TO CHANGE
PRESS ENTERTO
DISPLAY CURRENTLY
SET OPTION
CHOOSE
OPTION
OR
UP
DOWN
OR
UP
DOWN
OPTION
STORED
PRESS ENTER
TO STORE
OPTION
SELECT
FUNCTION
ENTER ENTER ENTER
OR
UP
DOWN
OR
PRESS UP, DOWN
ORENTERSELECT
NEXT FUNCTION
FUNCTION
SET TIMERVALUE
1 TO 59SECONDS
AUTO CLOSE TIMERDISABLED
SET TIMERVALUE
1 TO 9MINUTES
OPTIONS
PRESS UP OR
DOWN TO CYCLE
THROUGH OPTIONS
PRESS ENTERTO
SELECT AN OPTION
AUTO CLOSE
TIMER
"AC"
FUNCTION
"RP"

SG •SG-D Barrier Gate Operator Installation Guide - 12 - P1277 Revision X2 8-11-2011
Basic Controller Programming (Cont.)
Maximum Close Direction Current Setting
To detect obstacles or mechanical problems with the gate, the operator
can monitor its motor current. If the close current load exceeds the
programmed maximum load range number, the gate arm will stop,
reverse, and travel to the full open position. Another close request will
be required to start the operator again. If after restart, the overload or
a close obstacle happens again before the close limit is reached, the
operator will lockout and activate the alarm output. If the auto close timer
is set, when the close obstruction input is cleared, the gate arm will close
when the auto close timer expires.
The factory default setting of “OF” disables the close direction
current sensing for the operator. The maximum close direction
current setting can be adjusted using the following procedure:
To measure the motor load used during closing, while this function is
being displayed, push and hold the CLOSE button to close the gate.
During movement, the motor current will be displayed as a load number
from 0 to 99. This number is useful for troubleshooting but not used for
setting the motor current. At the end of travel, a different number will flash.
This number indicates the range above and below the average motor
current during the run. Using the + and - buttons, set the programmed
range number so that a minimal force will activate a reversal should an
obstruction occur, but high enough to keep the gate arm operating under
normal conditions without interruption.
Advanced Controller Programming
Entering Advanced Programming Mode
To access and program the Advanced Programming functions, for each
programming session, Advanced Programming must be enabled.
After exiting programming, the Advanced Programming functions
will be available on the programming display during the next
programming session unless the operator has run 50 or more
cycles. After that, Advanced Programming must be enabled again.
Maximum Run Time
The factory default for the Maximum Run Time (MRT) is 10 seconds.
When the operator starts, a timer will begin counting. If a open or close
limit is not reached or an obstacle or reversing input is not received before
the timer expires, the operator will stop, the unit locks out and the alarm
sounds. The timer can be set for 10 to 99 seconds, but should be left at
10 seconds in most applications. Setting it too close to the actual run time
may cause the time to expire with changing ambient temperature, gate
conditions, etc…
If AC is present and an open or close limit is not reached or an obstacle
or reversing input is not received before this timer exceeds MRT, the
operator will stop, the unit locks out and the alarm sounds.
In the case that AC is not present and MRT expires, it will be ignored as
long as the actual run time is under 10 seconds. When the gate reached
full open or full close position, MRT will be interpreted as fail safe/secure.
EN05 will occur. If FS as set to fail safe, the gate will open. If FS is set to
fail secure, the gate will close. However, if the actual run time is higher
than 10 seconds, it will be interpreted as a physical mechanical problem,
EN01 will occur and the gate will stop immediately.
FUNCTION
ADVANCED PROGRAMMINGFUNCTIONS
WILL NOT BE DISPLAYED
OPTIONS
PRESS UP OR
DOWN TO CYCLE
THROUGH OPTIONS
PRESS ENTERTO
SELECT AN OPTION
ADVANCED
PROGRAMMING
"AD"
ADVANCED PROGRAMMINGOPTIONS
WILL BE DISPLAYED
NOTE: ADVANCED PROGRAMMING
WILL STAY ENABLED AFTER
EXITING PROGRAMMING UNTIL
THE GATE CYCLES 50 TIMES
FUNCTION
PRESS ENTERFOR1 SECOND
WHILE DISPLAY ISFLASHING, PRESS
UP ORDOWN TO CHANGE THE
MAXIMUM RUN TIME (10-99 SECONDS)
OPTIONS
MAXIMUM RUN
TIMER
DISPLAY SHOWSCURRENT
MAXIMUM RUN TIME SETTING
ENTER
ENTER
PRESS ENTERTO STORE THE VALUE
"RT"
FUNCTION
SUGGESTED MINIMUM NUMBERWILL
FLASH, ADJUST TO THE PROPERFORCE
OPTIONS
MAX CLOSE
CURRENT
PRESS AND HOLD THE CLOSE BUTTON
UNTIL THE OPERATORRUNSFULLY CLOSED
ENTER
PRESS ENTERTO STORE THE FORCE
"CC"

SG •SG-D Barrier Gate Operator Installation Guide - 13 - P1277 Revision X2 8-11-2011
Advanced Controller Programming (Cont.)
Single Button Input Setup
This function is used for selecting the operation for single button controls
and radio receivers.
The factory default sets the SINGLE input terminal so successive inputs
will cycle the operator in OPEN-STOP-CLOSE-STOP order.
Alternately, the SINGLE input can be set to cause the gate to OPEN
unless the gate is fully open. If the gate is closing, the input will cause
the gate to reverse. If the gate is fully open, the input will cause the gate
to CLOSE.
Stagger Mode
This function is not used in dual barrier gate installations.
✓NOTE:This function will only be displayed if dual
gate operation is selected.
Stagger Delay Time
This function is not used in dual barrier gate installations.
✓NOTE:This function will only be displayed if dual
gate operation is selected.
Auxiliary Relay Mode
The Auxiliary Relay has normally open and normally closed contacts.
The factory setting disables the Auxiliary Relay. The relay can be set for:
• Maglock: To deactivate a magnetic or solenoid gate lock, the relay
will energize during any pending or actual gate motion (open only).
• M4: To deactivate a magnetic or solenoid gate lock, the relay will
energize during any pending or actual gate motion (open only).
3 seconds after the gate starts to move, the relay will de-energize.
This option is used for higher current solenoid locks.
• Ticket Dispenser: The relay will energize while the gate is moving
in the open direction and at the full open limit, or in an entrapment
condition.
• Strobe: To activate a warning strobe light, the relay will energize
during any pending or actual gate motion (either open or close).
• Alarm: The relay will energize if the gate is manually forced open
from the full closed position.
Reverse Delay Time
The factory default sets the Reverse Delay to 0 seconds. The operator
will wait the length of the delay before reversing direction. This feature
will not change the reversal time when the operator is responding to an
entrapment condition from an obstruction input or inherent entrapment
protection sensor. The Reverse Delay can be set from 0 to 9 seconds.
Heaver gates require a longer delay to allow time for the gate to stop.
The Reverse Delay is active when the gate first stops on either limit or in
between limits.
FUNCTION
SINGLE INPUT WILL OPEN OPERATOR,
IF OPERATORISALREADY OPEN, SINGLE
INPUT WILL CLOSE OPERATOR
SINGLE INPUT WILL CYCLE OPERATOR
IN ORDEROF OPEN-STOP-CLOSE-STOP
OPTIONS
PRESS UP OR
DOWN TO CYCLE
THROUGH OPTIONS
PRESS ENTERTO
SELECT AN OPTION
SINGLE BUTTON
INPUT SETUP
"SB"
FUNCTION
"SM"
FUNCTION
"ST"
FUNCTION
AUXILIARY RELAY USED FOR
MAGLOCK CONTROL
AUXILIARY RELAY DISABLED
AUXILIARY RELAY USED FOR
TICKET DISPENSERCONTROL
OPTIONS
PRESS UP OR
DOWN TO CYCLE
THROUGH OPTIONS
PRESS ENTERTO
SELECT AN OPTION
AUXILIARY
RELAY MODE
"AR"
AUXILIARY RELAY USED FOR
WARNINGSTROBE LIGHT
AUXILIARY RELAY USED FOR
CONNECTION TO ALARM DEVICE
AUXILIARY RELAY USED FOR
MAGLOCK ORSOLENOID CONTROL
3SECOND DELAY TO RE-ENERGIZE
FUNCTION
SET TIMERVALUE
0 TO 9SECONDS
OPTIONS
PRESS UP OR
DOWN TO CYCLE
THROUGH OPTIONS
PRESS ENTERTO
SELECT AN OPTION
REVERSE
DELAY TIME
"RD"

SG •SG-D Barrier Gate Operator Installation Guide - 14 - P1277 Revision X2 8-11-2011
Advanced Controller Programming (Cont.)
Low Power Mode
This function is only used with DC barrier gate Model SG-D. The factory
default disables the Low Power Mode. When Low Power Mode is enabled,
and AC power fails, the controller will assume Low Power Mode after 60
seconds of gate inactivity. Low power mode turns off all accessory power
and indicators. Only inputs from the radio receiver, reverse loop, open loop
(optional by programming), fire department input, or restoring AC power
will wake the Controller from Low Power Mode. Programming Mode can
still be accessed while the Controller is awake in Low Power Mode.
✓NOTE:This function will only be displayed in Model SG-D operators.
Power Failure Mode
This function is only used with DC barrier gate Model SG-D. The
factory default is set for Fail Safe, alternately the Controller can be set for
Fail Secure, Open Immediate, or Close Immediate.
• Fail Safe: If the AC power fails and the battery voltage drops below
approximately 22 Volts, 5 seconds later the operator will cycle open
if not already open. When AC power is restored, or the battery gets
charged by solar panels, the operator will resume normal operation
and auto-close if programmed to do so.
• Fail Secure: If the AC power fails and the battery voltage drops
below approximately 22 Volts, 5 seconds later the operator will
cycle closed if not already closed. When AC power is restored, or
the battery gets charged by solar panels, the operator will resume
normal operation.
✓NOTE:Fail Safe and Fail Secure are disabled if Stagger Mode is enabled.
• Open Immediate: If the AC power fails, the operator will cycle
open if not already open and cease operation. When AC power is
restored, the operator will resume normal operation and auto-close
if programmed to do so.
• Close Immediate: If the AC power fails, the operator will cycle
closed if not already closed and cease operation. When AC power is
restored, the operator will resume normal operation.
✓NOTE:This function will only be displayed in Model SG-D operators.
Soft Start/Stop Duration
This function is only used with DC barrier gate Model SG-D. This
function causes the operator to start and stop the DC motor slowly
reducing gate wear and tear (at the full open or closed positions only).
The factory default sets the Soft Start/Stop Duration to 3 seconds. The
Soft Start/Stop Duration can be set from 1 to 10 seconds.
✓NOTE:Changing the Soft Start/Stop Duration will reset the open and
close current setting value to zero. It will be necessary to reprogram
maximum open and close current settings.
✓NOTE:This function will only be displayed in Model SG-D operators
set for DC motor operation with soft start motor selection.
Reset Cycle Count
The Controller counts of the number of times the operator has been cycled
full open and close. The cycle count can be displayed. The display will
scroll the cycle count number, flashing two digits at a time from left to right.
To reset the Cycle Count, press and hold the ENTER button for 2 seconds
while the Cycle Count is displayed.
If the Maintenance Alert has been triggered, resetting the Cycle Count
will also reset the Maintenance Alert indicator.
FUNCTION
SET TO FAIL SAFE MODE
OPTIONS
PRESS UP OR
DOWN TO CYCLE
THROUGH OPTIONS
PRESS ENTERTO
SELECT AN OPTION
POWER
FAILURE MODE
"FS"
SET TO FAIL SECURE MODE
DC MODELS
ONLY
SET TO OPEN IMMEDIATE MODE
SET TO CLOSE
IMMEDIATE MODE
FUNCTION
SET SOFT START DURATION TIME
FROM 1 TO 10 SECONDS
SOFT START DISABLED
OPTIONS
PRESS UP OR
DOWN TO CYCLE
THROUGH OPTIONS
PRESS ENTERTO
SELECT AN OPTION
SOFT START/STOP
DURATION
"SS"
DC MODELS
ONLY
FUNCTION
PRESS ENTERTO START THE CYCLE COUNT DISPLAY
1ST DISPLAY
NOTE: PRESS ENTER FOR 2 SECONDS
WHILE THE "CT" FUNCTION IS DISPLAYED
TO RESET THE CYCLE COUNT TO ZERO
RESET CYCLE
COUNT
"CT"
2ND DISPLAY 3RD DISPLAY 4TH DISPLAY
EXAMPLE ABOVE SHOWS10,420 CYCLES
DECIMAL POINT LIT
ON 4TH DISPLAY
FUNCTION
LOW POWERMODE DISABLED
OPTIONS
PRESS UP OR
DOWN TO CYCLE
THROUGH OPTIONS
PRESS ENTERTO
SELECT AN OPTION
LOW POWER
MODE
"LP"
LOW POWERMODE #1
RADIO WILL WAKE AND ACTIVATE,
REVERSE LOOP WILL JUST WAKE
DC MODELS
ONLY
LOW POWERMODE #2- RADIO OR
OPEN LOOP WILL WAKE AND ACTIVATE,
REVERSE LOOP WILL JUST WAKE
THE FIRE DEPARTMENT INPUT
WILL ALWAYSWAKE UP CONTROLLER

SG •SG-D Barrier Gate Operator Installation Guide - 15 - P1277 Revision X2 8-11-2011
Advanced Controller Programming (Cont.)
Maintenance Alert Trigger
The Controller has a MAINT ALERT indicator that can be programmed
to light when the number of activations exceeds a set number of cycles.
The factory default sets the Maintenance Alert Trigger to 10,000 cycles.
The Maintenance Alert Trigger can be programmed for 5, 10, 15, or
25 thousand cycles.
The Maintenance Cycle Count can be reset independently from the
operator’s absolute Cycle Count.
Open/Reset Input
✓NOTE:For use in single gate installations only.
The Controller can be programmed to partially or fully open the gate with
an OPEN/RESET input, or to count the number of open commands and
leave the gate open until an equal number of SHADOW/RESET loop
triggers occur.
The OPEN/RESET terminals can connect to a loop detector or normally
open switch (see accessory wiring in Figure 10 on Page 10). The
SHADOW/RESET loop uses a plug-in loop detector.
The factory default is setting is Off (OF).
• OF Open Mode Off: The OPEN/RESET input acts as a standard
RESET loop and holds the gate arm open as long as a vehicle is on
the loop. If the gate arm is opening or fully open when the vehicle
exits the loop, the gate arm will close.
• CT Open Counter Mode: The Controller can count and remember
the number of open commands received, and will count the same
number of SHADOW/RESET loop triggers before the gate will close.
✓NOTE:Set the Auto Close Timer to OFF when using the CT option.
• SU Open Supervised Mode: The OPEN/RESET input opens the
gate arm fully on the initial command. Once open, the arm will
close on the removal of the command.
Anti-tailgate
The Controller can be programmed to have the barrier gate arm prevent
“tailgating” when a second vehicle attempts to drive through closely
following a prior vehicle that has been granted access.
The factory default disables this feature. If the SHADOW/RESET loop is
activated while the gate arm is closing, the gate arm will stop. When anti-
tailgate is enabled, the SHADOW/RESET loop will be ignored once the
arm begins traveling downward.
Radio Enable
The Controller contains a built-in MegaCode®radio receiver to allow
activation from up to 40 access control transmitters and two Model MGT
(gate edge) transmitters. The factory default enables the internal radio
receiver. Alternately, the internal receiver can be disabled.
Antenna Installation
A local whip antenna is included for use with the operator as a remote
antenna. If using a remote antenna, connect coax cable from the antenna
to the ANTENNA connector.
FUNCTION
SETSTHISMAINTENANCE ALERT TRIGGER
FOR5, 10, 15, OR25 THOUSAND CYCLES
DISABLESTHE MAINTENANCE ALERT
FUNCTION
RESETSTHE MAINTENANCE ALERT
INDICATORAND SETSTHE MAINTENANCE
ALERT COUNT TO ZERO
OPTIONS
PRESS UP OR
DOWN TO CYCLE
THROUGH OPTIONS
PRESS ENTERTO
SELECT AN OPTION
MAINTENANCE
ALERT TRIGGER
"MA"
FUNCTION
INTERNAL RADIO RECEIVERDISABLED
OPTIONS
PRESS UP OR
DOWN TO CYCLE
THROUGH OPTIONS
PRESS ENTERTO
SELECT AN OPTION
RADIO
ENABLE
"RA"
INTERNAL RADIO RECEIVERENABLED
FUNCTION
ANTI-TAILGATE FUNCTION DISABLED
OPTIONS
PRESS UP OR
DOWN TO CYCLE
THROUGH OPTIONS
PRESS ENTERTO
SELECT AN OPTION
ANTI-
TAILGATE
"TG"
ANTI-TAILGATE FUNCTION ENABLED
FUNCTION OPTIONS
PRESS UP OR
DOWN TO CYCLE
THROUGH OPTIONS
PRESS ENTERTO
SELECT AN OPTION
OPEN/RESET
INPUT
"OR"
OPEN COUNTERMODE
OPEN MODE OFF
OPEN SUPERVISED MODE

SG •SG-D Barrier Gate Operator Installation Guide - 16 - P1277 Revision X2 8-11-2011
Advanced Controller Programming (Cont.)
Radio Transmitter Learn
The Controller’s built-in MegaCode® radio receiver can store the IDs of
up to 40 transmitters. Refer to the figure for the steps required to learn
transmitters.
✓NOTE:This function will NOT be displayed if the transmitter memory
is full, or if the radio receiver is disabled.
Radio Transmitter Delete
Transmitters can be deleted from the Controller’s memory either
individually, or all at the same time. Refer to the figure for the steps
required to delete transmitters.
✓NOTE:This function will NOT be displayed if no transmitters are
stored in memory, or if the radio receiver is disabled.
MGT Obstacle Transmitter Learn
The Controller supports one or two Model MGT Obstacle Transmitters.
The transmitters can be programmed to function as Open Obstruction,
Close Obstruction, Reverse, or Stop. Refer to the figure for the steps
required to learn MGT transmitters.
✓NOTE:This function will NOT be displayed if two MGT transmitters
are already stored in memory, or if the radio receiver is disabled.
MGT Obstacle Transmitter Delete
MGT transmitters can be deleted from the Controller’s memory either
individually, or all at the same time. Refer to the figure for the steps
required to delete MGT transmitters.
✓NOTE:This function will NOT be displayed if no MGT transmitters are
stored in memory, or if the radio receiver is disabled.
Motor Type Selection
The factory sets the default for the Controller to match the type of motor in
the operator. If required, change the motor selection option to a different
type of motor used in the operator. The only two options used for barrier
gates are:
• Ac - AC Motor
• d2 - DC Motor with Electronic Soft Start/Stop
Reset Controller to Factory Defaults
The Controller can be reset with this function. ALL PROGRAMMED
DATA WILL BE LOST, and the factory defaults will be loaded. This
function will not erase radio transmitters, current sense values, or motor
type. Transmitters must be deleted with the two functions above.
FUNCTION
RESET TO
FACTORY DEFAULTS
"CL"
ENTER
WHILE "CL" ISDISPLAYED, PRESS ENTER
ALL PROGRAMMED DATA WILL BE CLEARED
AND THE FACTORY DEFAULTSWILL BE
STORED IN MEMORY.
NOTE: THIS FUNCTION WILL NOT ERASE
TRANSMITTERS, CURRENT SENSE VALUES,
OR MOTOR TYPE.
FUNCTION
DO NOT SELECT
NOT USED WITH BARRIERGATES
AC MOTOR
DC MOTORWITH SOFT START/STOP
OPTIONS
PRESS UP OR
DOWN TO CYCLE
THROUGH OPTIONS
PRESS ENTERTO
SELECT AN OPTION
MOTOR TYPE
SELECTION
NOTE:SELECTION
MUST MATCH
MOTORBOARD!
"MO"
DO NOT SELECT
NOT USED WITH BARRIERGATES
DO NOT SELECT
NOT USED WITH BARRIERGATES
DO NOT SELECT
NOT USED WITH BARRIERGATES
FUNCTION
TO DELETE ALL MGT TRANSMITTERS, PRESS ENTERFOR
2SECONDS, (TO EXIT WITHOUT DELETINGANY, QUICKLY
PRESS ENTER)
ERASE MGT
TRANSMITTERS
"MD" WILL BLINK FOR30 SECONDSWHILE THE CONTROLLER
ISREADY TO DELETE ALL MGT TRANSMITTERS
"MD"
ENTER
PRESS ENTER
ENTER
THE DISPLAY WILL SHOW "DELETE ALL" AND THE
CONTROLLERRETURNSTO PROGRAMMINGMODE
FUNCTION
ACTIVATE THE MGT TRANSMITTER, THE DISPLAY WILL
FLASH "rE" - IF THE TRANSMITTERISALREADY ENTERED,
"DU" WILL BE DISPLAYED, IF DECODE ISBAD "ERROR" WILL
BE DISPLAYED
LEARN MGT
TRANSMITTERS
PRESS ENTER, "ML" WILL BLINK FOR30 SECONDSWHILE
THE CONTROLLERISREADY TO LEARN AN MGT
TRANSMITTER
"ML"
ENTER
OR
UP DOWN
ENTER
DISPLAY WILL SHOW "--" FOR5 SECONDS, THEN SHOW THE
TRANSMITTER'SID NUMBER- REPEAT STEPSFOR
SECOND MGT TRANSMITTERIF USED
PRESS ENTERTO ACCEPT THE SELECTION
PRESS UP ORDOWN TO SELECT THE MGT FUNCTION:
"rE" = REVERSE "St" = STOP
"OP" = OPEN OBSTRUCTION "CL" = CLOSE OBSTRUCTION
FUNCTION
TO DELETE ALL TRANSMITTERS, PRESS ENTERFOR
2SECONDS, ORTO PICK TRANSMITTERS GO TO NEXT STEP
DELETE
TRANSMITTERS
"TD" WILL BLINK FOR30 SECONDSWHILE THE CONTROLLER
ISREADY TO DELETE ONE ORMORE TRANSMITTERS,
(TO EXIT WITHOUT DELETINGANY, PRESS ENTER)
"TD"
ENTER
PRESS ENTER
ENTER
OR
UP DOWN
ENTER
PRESS UP ORDOWN TO SCROLL THROUGH THE LIST
OF TRANSMITTERID NUMBERS
THE TRANSMITTERID NUMBERISDISPLAYED
(TO EXIT WITHOUT DELETING, PRESS ENTER)
(TO PICK A DIFFERENT TRANSMITTERID, PRESS UP ORDOWN)
PRESS ENTERFOR2SECONDSTO DELETE THE
TRANSMITTERDISPLAYED
FUNCTION
ACTIVATE THE TRANSMITTER
DISPLAY WILL SHOW "- -" THEN THE
TRANSMITTERID NUMBER- IF TRANSMITTER
ISALREADY ENTERED, "dU" WILL BE DISPLAYED,
IF DECODE ISBAD "ERROR" WILL BE DISPLAYED
LEARN
TRANSMITTERS
"TL" WILL BLINK FOR30 SECONDSWHILE
THE CONTROLLERISREADY TO
LEARN A TRANSMITTER
"TL"
ENTER
PRESS ENTER(ONCE FOREACH TRANSMITTER,
UP TO 40 TRANSMITTERS TOTAL)

SG •SG-D Barrier Gate Operator Installation Guide - 17 - P1277 Revision X2 8-11-2011
Free Gate Loop Layout Illustration
TWIST WIRE FROM END OF
LOOPS BACK TO OPERATOR
AT LEAST SIX TIMES PER
FOOT
2" MAX.
2"
3/8"
LOOP SEALANT
USE RELIEF CUTS
AT CORNERS
MULTIPLE TURNS
REFER TO LOOP
INSTALLATION NOTES
FOR DETAILS
THIS SYSTEM IS TYPICALLY USED AS AN ENTRANCE OR EXIT IN CONJUNCTION WITH A CONTROLLED ENTRANCE OR EXIT.
OPERATION OF FREE GATE SYSTEM: WHEN VEHICLE PASSES OVER OPEN DETECTOR LOOP, THE ARM RAISES. WHEN VEHICLE PASSES OVER AND OFF OF RESET DETECTOR LOOP, THE ARM LOWERS.
FREE GATE LAYOUT
LOCATE BARRIER GATE EQUIPMENT 35' FROM ROADWAY SO THAT APPROCHING VEHICLES ARE ABLE TO COMPLETE RIGHT TURN BEFORE REACHING ACTUATING DEVICE.

SG •SG-D Barrier Gate Operator Installation Guide - 18 - P1277 Revision X2 8-11-2011
Pay Gate Loop Layout Illustration
2"
3/8"
LOOP SEALANT
USE RELIEF CUTS
AT CORNERS
MULTIPLE TURNS
REFER TO LOOP
INSTALLATION NOTES
FOR DETAILS
TWIST WIRE FROM END OF
LOOPS BACK TO OPERATOR
AT LEAST SIX TIMES PER
FOOT
2" MAX.
WHEN DRIVER INSERTS CARD INTO CARDLOCK, KEY INTO KEYLOCK, ETC., THE GATE ARM WILL RAISE TO ALLOW PASSAGE OF THE VEHICLE. WHEN VEHICLE PASSES OVER AND OFF RESET DETECTOR LOOP, THE GATE ARM WILL LOWER. THIS SYSTEM IS SUITABLE FOR DAILY, MONTHLY, OR PERFERRED PARKING AND IS WIDELY USED BY HOSPITALS, MEDICAL CLINICS, UNIVERSITIES, OFFICE BUILDINGS, FACTORIES, ETC., WHEN THERE IS NEED FOR CONTROLLED PARKING.
OPERATION OF PAY GATE SYSTEM:
PAY GATE LAYOUT
LOCATE BARRIER GATE EQUIPMENT 35' FROM ROADWAY SO THAT APPROCHING VEHICLES ARE ABLE TO COMPLETE RIGHT TURN BEFORE REACHING ACTUATING DEVICE.
