DEMO MANUAL DC2749A
DESCRIPTION
LTC7003
Fast 60V Protected High Side
NMOS Static Switch Driver
Demonstration circuit 2749A is a 60V protected, high
side switch featuring the LT C
®
7003. The demo board is
designed to switch a 14.5A output load from input volt-
ages from 6V to 60V. The wide input range and low shut-
down current (1µA typical) make it suitable for automo-
tive, industrial, medical instrument and telecom applica-
tions. This board offers a low 45ns (typical) propagation
delay, fast switching times (<10ns) and 100% duty cycle
operation.
The LTC7003 is a fast protected high side N-channel
MOSFET driver. An internal charge pump fully enhances
an external N-channel MOSFET switch, allowing it to
remain on indefinitely. Its powerful gate driver can drive
large gate capacitance MOSFETs with very short transition
times, ideal for both high frequency switching and static
switch applications. The LTC7003 operates over a 3.5V to
60V input supply range. When an external current sense
resistor and internal comparator sense that the switch
current has exceeded a preset level, a fault flag is asserted
and the switch is turned off after a period of time set
by an external timing capacitor. After a cooldown period,
the LTC7003 can be configured to automatically retry or
remain off until the input is recycled. All registered trademarks and trademarks are the property of their respective owners.
PERFORMANCE SUMMARY
The demo board includes input capacitors and output
diode to accommodate input and output supply induc-
tance when switching loads. The switch can be controlled
directly with external signal or using the on-board on/off
switch. A single-shot pulse generator is included for evalu-
ating switching times while limiting output power. Optional
auxiliary VCC input accommodates gate power associated
with high frequency switching. Positions for RC delay net -
work to control inrush current are also included.
The LTC7003 data sheet gives a complete description of
the part, operation and application information. The data
sheet must be read in conjunction with this demo manual
for demo circuit 2749A. Proper board layout is essential
for maximum thermal and electrical performance. See the
data sheet sections for details. The LTC7003 is available
in 16-lead MSOP package and three operating junction
temperature grades extended and industrial from –40°C
to 125°C, high temp automotive from –40°C to 150°C and
a military grade from –55°C to 150°C.
Design files for this circuit board are available at
http://www.linear.com/demo/DC2749A
Specifications are at TA= 25°C
SYMBOL PARAMETER CONDITIONS MIN TYP MAX UNITS
VIN Input Voltage 60 V
IOUT Output Current 14.5 A
Insertion Drop VIN – VOUT, 14.5A Load, Input to Output Terminals 81 mV
VIN Start-Up Voltage VINP = 4V
100kΩ Load
7.0
6.0
V
V
VCCUV VCC Undervoltage Lockout VCC Rising
VCC Falling
Hysteresis
5.1
4.6
0.5
V
V
V
Overcurrent to VOUT Low Turn-On into a 25A Resistive Load 19 µs
Input to Output Propagation Delay VIN = 60V, 50Ω Load, INP = 2.2V to VOUT = 6V 45 ns
Output Rise Time VIN = 60V, 50Ω Load, 10% to 90% 9 ns

2
dc2749af
DEMO MANUAL DC2749A
QUICK START PROCEDURE
Refer to Figure 1 for proper measurement equipment
setup and follow the procedure below:
NOTE:When measuring the output voltage during switch-
ing transitions, care must be taken to avoid a long ground
lead on the oscilloscope probe. Measure the output volt-
age by touching the probe tip and ground ring directly
across the output capacitor as shown in Figure 2.
1. Place SW1 to OFF position. Move JP1 from the PULSE
(default position) to ON/OFF position (load on continu-
ously when SW1 is ON).
2. With input power supply set to zero volts and power
off, connect the input power supply to +VIN and GND.
3. With power off, connect load from +VOUT to GND.
4. Turn on the input power supply and increase the input
voltage slowly to 7V minimum. The input range is up
to 60V but hot-plugging with long leads may result in
input voltages in excess of 60V.
5. Place SW1 to ON position.
6. Check for the proper output voltage using a voltmeter.
Output voltage should be close to input voltage.
NOTE: If there is no output, temporarily disconnect the
load and cycle SW1 (the ON/OFF switch) or press reset
pushbutton SW2. If output is good, the load may be
set too high.
7. Once the proper output voltage is established, adjust
the load, if desired, to test current limit.
8. Placing SW1 to OFF position, moving JP1 to PULSE
position then placing SW1 in ON position will allow
pulse operation. Pushing SW2 will turn the high side
switch on for 300µs time.
9. Placing SW1 to OFF position, moving JP1 to INPUT
position connects INPUT terminal to LTC7003 INP pin.
An INPUT pin voltage of 2.2V or more will turn-on the
high side switch.
Figure 1. Proper Measurement Equipment Setup
+
–
IOUT
VOUT
LOAD
+–
A+
–
V
+
–
IIN
VIN
+–
A
+
–
V
POWER
SUPPLY

3
dc2749af
DEMO MANUAL DC2749A
QUICK START PROCEDURE
Figure 2. Measuring Output Voltage During Switching across C9. Note that C9 May Not Be Installed
Figure 3. Rise Time into 50Ω Load (VIN = 60V, VINP 2V/DIV, VOUT 20V/DIV, 20ns/DIV)
Figure 4. Board Photo
+ –
VOUT GND
C9
VOUT
20V/DIV
VINP
2V/DIV
TYPICAL PERFORMANCE CHARACTERISTICS

4
dc2749af
DEMO MANUAL DC2749A
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
Required Circuit Components
1 5 C3, C4, C5, C7, C8 CAP, 4.7µF, X7R, 100V, 1210 MURATA, GRM32DC72A475ME01
2 2 C11, C14 CAP, 1000pF, X7R, 25V, 10%, 0603 MURATA, GRM188R71E102KA01D
3 1 C12 CAP, 0.22µF, X7R, 25V, 10%, 0805 AVX, 08053C224KAT2A
4 1 C13 CAP, 0.1µF, X7R, 100V, 10%, 1206 AVX, 12061C104KAT2A
5 1 C17 CAP, 1µF, X7R, 25V, 10%, 0805 AVX, 08053C105KAT2A
6 1 D1 DIODE, SCHOTTKY, 100V, 3A, SOD128 NEXPERIA USA INC, PMEG10030ETPX
7 1 Q1 MOSFET, N-CH, 60V, POWERPAK-SO-8 FAIRCHILD/ON SEMI, FDMS86500L
8 1 RS1 RES, SENSE, 0.0015Ω, 1W, 1%, 2512 PANASONIC, ERJM1WTF1M5U
9 2 R7 RES, 100Ω, 1/10W, 1%, 0603 VISHAY CRCW0603100RFKEA
10 2 R15, R46 RES, 100k, 1/10W, 1%, 0603 VISHAY CRCW0603100KFKEA
11 1 R19 RES, 75k, 1/10W, 0603 VISHAY CRCW060375K0FKEA
12 1 R35 RES, 0Ω, 1/10W, 1%, 0603 VISHAY CRCW06030000Z0EA
13 1 R40 RES, 1MEG, 1/10W, 1%, 0805 VISHAY CRCW08051M00FKEA
14 1 U1 IC, LTC7003EMSE, MSE-16 LINEAR TECH, LTC7003EMSE#PBF
Additional Demo Board Circuit Components
1 1 C1 CAP, 10nF, X7R, 100V, 10%, 1206 AVX, 12061C103KAZ2A
2 1 C2 CAP, 100µF, ELECT, 63V, 20%, TH C-10X12.5 WURTH ELECTRONIC, 860040775006
3 0 C6, C9 CAP, OPTIONAL, 1210 OPTIONAL
4 0 C10 CAP, OPTIONAL, TH C-10X12.5 OPTIONAL
5 0 C16 CAP, OPTIONAL, 1206 OPTIONAL
6 2 C18, C19 CAP, 0.1µF, X7R, 25V, 10%, 0603 AVX, 06033C104KAT2A
7 0 C21, C22, C23, C24 CAP, OPTIONAL, 0603 OPTIONAL
8 0 D2, D3, D4, D8, D11, D12 DIODE, OPTIONAL, SOT23 OPTIONAL
9 1 D5 DIODE, MMSZ5V1T1, SOD-123 ON SEMICONDUCTOR, MMSZ5V1T1G
10 1 D6 DIODE, MMBD4148, SOT23 DIODES INC, MMBD4148-7-F
11 0 D7 DIODE, OPTION, PDS4150, POWERDI5 OPTIONAL
12 0 D9 DIODE,OPTION, CMMR1U, SOD-123F OPTIONAL
13 0 D10 DIODE, OPTIONAL, SOD128 OPTIONAL
14 0 Q2 MOSFET, OPTIONAL, N-CH, 80V, PSOF08A FAIRCHILD/ON SEMI, FDBL86361_F085
15 0 Q3 MOSFET, OPTIONAL, POWERPAK-SO-8 OPTIONAL
16 1 Q4 TRANS, PNP 40V 0.2A SOT-23 FAIRCHILD/ON SEMI, MMBT3906
17 1 Q5 MOSFET, P-CH, -200V, SOT23 DIODES INC, ZXMP2120FFTA
18 1 RS2 RES, SENSE, 0Ω, 1/2W, 1%, 1225 TEPRO, RN5326
19 1 R2 RES, 0Ω, 1/10W, 1%, 0805 VISHAY CRCW08050000Z0EA
20 1 R4 RES, 100Ω, 1/2W, 5%, 1210 NIC, NRCP25J101TRF
21 9 R6, R12, R14, R22, R25, R43, R45, R47 RES, 0Ω, 1/10W, 0603 VISHAY CRCW06030000Z0EA
22 0 R9, R17, R41, R42 RES, OPTIONAL, 0805 OPTIONAL
23 0 R13, R18, R33, R34, R36, R39, R44 RES, OPTIONAL, 0603 OPTIONAL
24 3 R21, R37, R38 RES, 100k, 1/10W, 1%, 0603 VISHAY CRCW0603100KFKEA
PARTS LIST

5
dc2749af
DEMO MANUAL DC2749A
PARTS LIST
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
25 1 R23 RES, 787Ω, 1/10W, 1%, 0603 VISHAY CRCW0603787RFKEA
26 2 R27, R31 RES, 240k, 1/10W, 1%, 0805 VISHAY CRCW0805240KFKEA
27 1 R28 RES, 976k, 1/10W, 1%, 0603 VISHAY CRCW0603976KFKEA
28 1 R29 RES, 232k, 1/10W, 1%, 0603 VISHAY CRCW0603232KFKEA
29 1 R30 RES, 182k, 1/10W, 1%, 0603 VISHAY CRCW0603182KFKEA
30 1 SW1 SWITCH, SUB MINITURE SLIDE C&K COMPONENTS, JS202011CQN
31 1 SW2 SWITCH, MICRO MINATURE PUSHBUTTON TE CONNECTIVITY, FSM4JSMA
32 1 U2 IC, LTC6993CS6-3, TSOT23-6 LINEAR TECH, LTC6993CS6-3#PBF
Hardware: For Demo Board Only
1 8 E1 TO E8 TESTPOINT, TURRET 0.094" MILL MAX 2501-2-00-80-00-00-07-0
2 1 JP1 CONN., HEADER, 2X3, 2mm WURTH ELEKTRONIK, 62000621121
3 4 J1, J2, J3, J4 CONN, BANANA JACK KEYSTONE 575-4
4 1 XJP1 SHUNT, 2MM WURTH ELEKTRONIK, 60800213421
5 4 MTGS. AT 4 CORNERS STAND-OFF, NYLON 0.625" TALL WURTH ELEKTRONIK, 702936000
Misc:
1 1 PCB, DC2749A DEMO CIRCUIT 2749A
2 2 STENCIL (TOP & BOTTOM) STENCIL DC2749A

6
dc2749af
DEMO MANUAL DC2749A
SCHEMATIC DIAGRAM
5
5
4
4
3
3
2
2
1
1
D D C C B B A A
FAST 60V PROTECTED HIGH-SIDE NMOS STATIC SWITCH DRIVER
16V
1%
5%
Note: Unless otherwise specified: All resistors are in ohms, 1%, 0603. All capacitors are in microfarads 0603. All capacitors are 25V. 1/16W = 0402, 1/10W = 0603, 1/8W = 0805, 1/4W = 1206, 1/2W =1210, 1W = 2512. 4.7uF 100V Murata GRM32DC72A475ME01 (1210, X7R, -75% at 60V). 100uF 63V Wurth Electronic 860040775006 (10x12.5mm, 640mA@100KHz@105°C, 0.34Ohm@100KHz) 5.1V Zener On Semi MMSZ5V1T1. 0 Ohm 1225 TEPRO RN5326 100ohm 1210 NIC NRCP25J101TRF (0.5M, 400W for 0.1ms) Fairchild FDMS86500L (60, 3.7mOh max and 117nCtyp at 10V) 0.0015ohms 1W Panasonic ERJ-M1WTF1M5U (2512).
IMON
14.5A MAX
60VIN MAX
Note: OPT = (OPT) = Optional = Not Used
ISET
2512
PULSE
ON/OFF INPUT
Vccuv rising = 5.1V typ Vccuv falling = 4.6V typ
See Page 2 for SW1 (ON/OFF) and SW2 (PULSE)
VCC
VCC
TD TS
TG
VIN2
VCC
BST
BST
+VOUT
VIN
TRIGOUTONOFF
SNS-SNS+
SIZE DATE:
IC NO. REV.
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
TECHNOLOGY Fax: [phone]
Milpitas, CA 95035 Phone: [phone] McCarthy Blvd. LTC Confidential-For Customer Use Only
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
www.linear.com
1
Tuesday, October 10, 2017
12
HTOO K.
N/A
LTC7003EMSE
LT
DC2749A
SIZE DATE:
IC NO. REV.
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
TECHNOLOGY Fax: [phone]
Milpitas, CA 95035 Phone: [phone] McCarthy Blvd. LTC Confidential-For Customer Use Only
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
www.linear.com
1
Tuesday, October 10, 2017
12
HTOO K.
N/A
LTC7003EMSE
LT
DC2749A
SIZE DATE:
IC NO. REV.
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
TECHNOLOGY Fax: [phone]
Milpitas, CA 95035 Phone: [phone] McCarthy Blvd. LTC Confidential-For Customer Use Only
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
www.linear.com
1
Tuesday, October 10, 2017
12
HTOO K.
N/A
LTC7003EMSE
LT
DC2749A
REVISION HISTORY DESCRIPTION DATEAPPROVEDECO REV
HTOO K.
PRODUCTION1 10-10-17
__
REVISION HISTORY DESCRIPTION DATEAPPROVEDECO REV
HTOO K.
PRODUCTION1 10-10-17
__
REVISION HISTORY DESCRIPTION DATEAPPROVEDECO REV
HTOO K.
PRODUCTION1 10-10-17
__
J2
GND
R42 OPT 0805
E2
GND
R44 OPT
C22 OPT
U1
LTC7003EMSE
BST 14
VCC 3
RUN
1
SNS- 15
SNS+ 16
TGUP 12
VCCUV 4
TIMER
6
INP
7
GND
17
TS 13
TGDN 11
FAULT
5
VIN
2
OVLO 8
ISET
9
IMON
10
R40
1MEG 0805 C21
OPT
R6
0
C14 1nF
JP1
MODE
12 34 56
R14
0
C8 4.7uF 100V 1210 R35
0
R17
OPT
0805
E6
FAULT
C1
10nF 1206 100V
C13 0.1uF 1206 100V
D1 PMEG10030ELP
SOD128
C23 OPT
C17
1uF 0805
R46
100K
P1 D4
OPT
R15 100k
R39
OPT
E7
INPUT C16
OPT 1206
100V
E8
GND
R7
100
R45
0
R2 0 0805
RS1
0.0015
1W
E3 +VOUT
R4 100 1210
J3 +VOUT
R19
75K
Q1
FDMS86500L
4
5
2 3
6 7 8
1
E1
+VIN
J4
GND
P2
C9 OPT 1210
C11
1nF
R41 OPT 0805
C12
0.22uF
1206-0805
R43
0
R47
0
R36
OPT
J1
+VIN
R18
OPT
RS2
0
1225
R12
0
E4
GND
+
C2
100uF
63V
C7 4.7uF 100V 1210

7
dc2749af
DEMO MANUAL DC2749A
Information furnished by Analog Devices is believed to be accurate and reliable. However, no responsibility is assumed by Analog
Devices for its use, nor for any infringements of patents or other rights of third parties that may result from its use. Specifications
subject to change without notice. No license is granted by implication or otherwise under any patent or patent rights of Analog Devices.
SCHEMATIC DIAGRAM
5
5
4
4
3
3
2
2
1
1
D D C C B B A A
OPTIONAL ON/OFF and SINGLE SHOT
PowerDI5
SOT23 SOD-123F
ON OFF
T=300us
PULSE or RESET
FAST 60V PROTECTED HIGH-SIDE NMOS STATIC SWITCH DRIVER
+VOUT
TS TG
VCC
TD
BST TG TS
VIN2VIN
VIN
5V
5V
5V
TRIGOUT
ONOFF
VIN2
SNS-SNS+
SIZE DATE:
IC NO. REV.
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
TECHNOLOGY Fax: [phone]
Milpitas, CA 95035 Phone: [phone] McCarthy Blvd. LTC Confidential-For Customer Use Only
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
www.linear.com
1
Tuesday, October 10, 2017
22
HTOO K.
N/A
LTC7003EMSE
LT
DC2749A
SIZE DATE:
IC NO. REV.
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
TECHNOLOGY Fax: [phone]
Milpitas, CA 95035 Phone: [phone] McCarthy Blvd. LTC Confidential-For Customer Use Only
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
www.linear.com
1
Tuesday, October 10, 2017
22
HTOO K.
N/A
LTC7003EMSE
LT
DC2749A
SIZE DATE:
IC NO. REV.
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
TECHNOLOGY Fax: [phone]
Milpitas, CA 95035 Phone: [phone] McCarthy Blvd. LTC Confidential-For Customer Use Only
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
www.linear.com
1
Tuesday, October 10, 2017
22
HTOO K.
N/A
LTC7003EMSE
LT
DC2749A
D7 OPT
12
3
D2
OPT
C24 OPT
R31 240K 0805
C19 0.1uF
+
C10 OPT
63V
U2
LTC6993CS6-3
TRG
1
GND
2
SET
3DIV 4
V+ 5
OUT 6
Q4 MMBT3906
C5
1210
4.7uF
100V
R29
232k
SW1
JS202011CQN
4 1 5 2 6 3
C6 1210 OPT 100V
D3
OPT (CMPZ5242B)
SW2
FSM4JSMA
1 23
4
D11 OPT
2 1
D9
OPT
21
R21
100K
R33 OPT
Q5
ZXMP2120FF
R25
0
Q2
OPT PSOF08
SD
G
R38
100k
D5 5.1V
C4
1210
4.7uF
100V
R28
976k
R27 240K 0805
E5
AUX_VCC R13
OPT
R9 OPT 0805
Q3 OPT POWERPAK-SO-8
4
5
2 3
6 7 8
1
C18 0.1uF
R22 0
R30
182k
R34
OPT
R23 787
D6
MMBD4148
D12 OPT
2 1
D8
OPT
R37 100k
D10 OPT SOD128
C3
1210
4.7uF
100V

8
dc2749af
DEMO MANUAL DC2749A
LT 1117 • PRINTED IN USA
 ANALOG DEVICES, INC. 2017
ESD Caution
ESD (electrostatic discharge) sensitive device. Charged devices and circuit boards can discharge without detection. Although this product features patented or proprietary protection
circuitry, damage may occur on devices subjected to high energy ESD. Therefore, proper ESD precautions should be taken to avoid performance degradation or loss of functionality.
Legal Terms and Conditions
By using the evaluation board discussed herein (together with any tools, components documentation or support materials, the “Evaluation Board”), you are agreeing to be bound by the terms and
conditions set forth below (“Agreement”) unless you have purchased the Evaluation Board, in which case the Analog Devices Standard Terms and Conditions of Sale shall govern. Do not use the Evaluation
Board until you have read and agreed to the Agreement. Your use of the Evaluation Board shall signify your acceptance of the Agreement. This Agreement is made by and between you (“Customer”)
and Analog Devices, Inc. (“ADI”), with its principal place of business at One Technology Way, Norwood, MA 02062, USA. Subject to the terms and conditions of the Agreement, ADI hereby grants to
Customer a free, limited, personal, temporary, non-exclusive, non-sublicensable, non-transferable license to use the Evaluation Board FOR EVALUATION PURPOSES ONLY. Customer understands and
agrees that the Evaluation Board is provided for the sole and exclusive purpose referenced above, and agrees not to use the Evaluation Board for any other purpose. Furthermore, the license granted
is expressly made subject to the following additional limitations:Customer shall not (i) rent, lease, display, sell, transfer, assign, sublicense, or distribute the Evaluation Board;and (ii) permit any Third
Party to access the Evaluation Board. As used herein, the term “Third Party”includes any entity other than ADI, Customer, their employees, affiliates and in-house consultants. The Evaluation Board is
NOT sold to Customer;all rights not expressly granted herein, including ownership of the Evaluation Board, are reserved by ADI. CONFIDENTIALITY. This Agreement and the Evaluation Board shall all
be considered the confidential and proprietary information of ADI. Customer may not disclose or transfer any portion of the Evaluation Board to any other party for any reason. Upon discontinuation of
use of the Evaluation Board or termination of this Agreement, Customer agrees to promptly return the Evaluation Board to ADI. ADDITIONAL RESTRICTIONS. Customer may not disassemble, decompile
or reverse engineer chips on the Evaluation Board. Customer shall inform ADI of any occurred damages or any modifications or alterations it makes to the Evaluation Board, including but not limited
to soldering or any other activity that affects the material content of the Evaluation Board. Modifications to the Evaluation Board must comply with applicable law, including but not limited to the RoHS
Directive. TERMINATION. ADI may terminate this Agreement at any time upon giving written notice to Customer. Customer agrees to return to ADI the Evaluation Board at that time. LIMITATION OF
LIABILITY. THE EVALUATION BOARD PROVIDED HEREUNDER IS PROVIDED “AS IS”AND ADI MAKES NO WARRANTIES OR REPRESENTATIONS OF ANY KIND WITH RESPECT TO IT. ADI SPECIFICALLY
DISCLAIMS ANY REPRESENTATIONS, ENDORSEMENTS, GUARANTEES, OR WARRANTIES, EXPRESS OR IMPLIED, RELATED TO THE EVALUATION BOARD INCLUDING, BUT NOT LIMITED TO, THE
IMPLIED WARRANTY OF MERCHANTABILITY, TITLE, FITNESS FOR A PARTICULAR PURPOSE OR NONINFRINGEMENT OF INTELLECTUAL PROPERTY RIGHTS. IN NO EVENT WILL ADI AND ITS
LICENSORS BE LIABLE FOR ANY INCIDENTAL, SPECIAL, INDIRECT, OR CONSEQUENTIAL DAMAGES RESULTING FROM CUSTOMER’S POSSESSION OR USE OF THE EVALUATION BOARD, INCLUDING
BUT NOT LIMITED TO LOST PROFITS, DELAY COSTS, LABOR COSTS OR LOSS OF GOODWILL. ADI’S TOTAL LIABILITY FROM ANY AND ALL CAUSES SHALL BE LIMITED TO THE AMOUNT OF ONE
HUNDRED US DOLLARS ($100.00). EXPORT. Customer agrees that it will not directly or indirectly export the Evaluation Board to another country, and that it will comply with all applicable United States
federal laws and regulations relating to exports. GOVERNING LAW. This Agreement shall be governed by and construed in accordance with the substantive laws of the Commonwealth of Massachusetts
(excluding conflict of law rules). Any legal action regarding this Agreement will be heard in the state or federal courts having jurisdiction in Suffolk County, Massachusetts, and Customer hereby submits
to the personal jurisdiction and venue of such courts. The United Nations Convention on Contracts for the International Sale of Goods shall not apply to this Agreement and is expressly disclaimed.
