LTM8008: 72VIN,
6-Output DC/DC SEPIC
µModule Regulator
Demonstration circuit 1630A features the LTM
®
8008, a
72VIN μModule
®
SEPIC converter with six post regulators:
one 5V output at 500mA, one 3.3V output at 300mA, and
four 5V outputs at 150mA. The demonstration circuit is
designed to operate from a 3V to 72V input source and
the output of the SEPIC converter is internally set to 5.6V.
BOARD PHOTO
PERFORMANCE SUMMARY
(TA= 25°C)
The data sheet must be read in conjunction with this demo
manual forworking onor modifyingthe democircuit1630A.
Design files for this circuit board are available at
http://www.linear.com/demo
L, LT, LTC, LTM, Linear Technology, the Linear logo and μModule are registered trademarks of
Linear Technology Corporation. All other trademarks are the property of their respective owners.
PARAMETER VALUE
Input Supply Range 3V to 72V
VOUT1 Output Voltage Accuracy 4.95V to 5.05V
VOUT2, 3, 4, 5 Output Voltage Accuracy 4.95V to 5.05V
VOUT6 Output Voltage Accuracy 3.267V to 3.333V
SPV Regulation Voltage 5.6V ±3%
SEPIC Converter Switching Frequency 300kHz
Downloaded from Arrow.com.

2
dc1630af
DEMO MANUAL DC1630A
QUICK START PROCEDURE
Demonstration circuit 1630 is an easy way to evaluate the
performance of the LTM8008.
Referto Figure1 forproper measurementequipment setup
and follow the procedure below:
Note: When measuring the input or output voltage ripples,
care must be taken to avoid a long ground lead on the
oscilloscope probe. Measure the input or output voltage
ripples by touching the probe tip directly across the VIN
or VOUT and GND terminals. See Figure 2 for proper scope
probe technique.
1. Place JP1 on the ON position.
2. With power off, connect the input power supply to VIN
and GND.
3. Turn on the power at the input. The minimum VIN start
voltage is 6V. Once it starts, the converter can operate
down to 3V.
4. Check for the proper output voltages.
Note: If there is no output voltage, temporarily disconnect
the load to make sure that the load is not set too high.
Once the proper output voltages are established, adjust
the loads within the operating range and observe the
output voltage regulation, ripple voltage, efficiency and
other parameters.
Downloaded from Arrow.com.Downloaded from Arrow.com.

3
dc1630af
DEMO MANUAL DC1630A
QUICK START PROCEDURE
Figure 1. DC1630A Proper Equipment Setup
Figure 2. Measuring Input or Output Ripple
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

4
dc1630af
DEMO MANUAL DC1630A
PARTS LIST
ITEM QUANTITY REFERENCE DESCRIPTION MANUFACTURERS PART NUMBER
Required Circuit Components
1 1 C13 Capacitor, NPO, 100pF, 50V, 5%, 0603 AVX, 06035A101JAT2A
21 C9 Capacitor, X7R, 0.1μF, 50V, 10%, 0603 AVX, 06035C104KAT2A
3 1 C14 Capacitor, X7R, 22nF, 50V, 10%, 0603 AVX, 06035C223KAT2A
4 6 C7, C8, C10, C11, C12, C15 Capacitor, X7R, 10μF, 10V, 1206 Murata, GCM31CR71A106KA64
5 1 C16 Capacitor, X7S, 4.7μF, 10V, 0805 Murata, GCM21BC71A475KA73
6 4 C2, C3, C4, C5 Capacitor, X7R, 22μF, 10V, 1210 Murata, GCM32ER71A226KE12L
7 2 C1, C6 CCapacitor X7R, 10μF, 100V, 20%, 2220 TDK, CKG57NX7R2A106MT
8 1 D1 Diodes, Barrier Rectifer Diodes Inc., SBR3U100LP-7
9 1 L1 Inductor, High Temperature Coilcraft, MSD1278T-472MLD
10 1 R6 Resistor, Chip, 0Ω 0603 Vishay, CRCW06030000Z0EA
11 1 R3 Resistor, Chip, 10k 5% 0603 Vishay, CRCW060310K0JNEA
12 1 R5 Resistor, Chip, 4.99k 1% 0603 Vishay, CRCW06034K99FKED
13 1 R4 Resistor, Chip, 42.2k 1% 0603 Vishay, CRCW060342K2FKED
14 1 U1 IC., Linear LTM8008HV LGA 15 × 15 Linear Technology, LTM8008HV
Additional Demo Board Circuit Components
10C
IN (TBD) Capacitor, Aluminum Electrolytic 100V Suncon, CE-PC Series
2 0 D2 (Optional) Zener Diode, SOD523
3 0 R1, R2 (Optional) Resistor, Chip 0603
Hardware, for Demo Board Only
1 17 E1-E17 Turret, Testpoint Mill-Max, 2501-2-00-80-00-00-07-0
2 1 JP1 Header, 1 × 3 Pins, 2mm Samtec, TMM-103-01-L-S
3 1 JP1 Shunt, 2 Pins, 2mm Samtec, 2SN-BK-G
4 1 FAB, Printed Circuit Board Demo Circuit 1630A
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

5
dc1630af
DEMO MANUAL DC1630A
SCHEMATIC DIAGRAM
A A
B B
C C
D D
E E
4 4 3 3 2 2 1 1
T
TT T
SEPIC MODULE REGULATOR
72VIN, 6 OUTPUT DC/DC
5V / 150mA 5V / 150mA 5V / 150mA 5V / 500mA 5V / 150mA 3.3V / 300mA
RUN
ON
OFF
5.6V3V - 72V
10/11/10
VIN
5(9,6,21+,6725< '(6&5,37,21 '$7($33529('(&2 5(9
WEI GUPRODUCTION2 10/11/10
5(9,6,21+,6725< '(6&5,37,21 '$7($33529('(&2 5(9
WEI GUPRODUCTION2 10/11/10
5(9,6,21+,6725< '(6&5,37,21 '$7($33529('(&2 5(9
WEI GUPRODUCTION2 10/11/10
