Linegrip lineScale 3 User manual

PPE certied
Electronic Bluetooth
Load Cell / Dynamometer
Designed in Germany
Made in China
PPE Instruction Manual
PPE-R/11.114 V3:2021
UIAA 130 V1:2021 (25kN)
Regulation (EU) 2016/425
Personal Protective Equipment against falls from a height
EU declaration of conformity: www.linegrip.com/LS3
Technical specication No. 1LGC/2021
lineGrip Corporation Ltd.
Hauptstr. 41
67714 Waldschbach
Germany
Contact: Mr. Andy Riedrich
Phone: [phone]
Whatsapp: [phone]

Page 1 of 5
LS3-PPE-M_rev.3_201021

PPE Instruction Manual
PPE-R/11.114 V3:2021
Page 2 of 5
LS3-PPE-M_rev.3_201021
1. Specications
1.1. Technical
Minimum Breaking Strength (MBS): 90 kN
Working Load Limit (WLL): 30 kN
PPE Load Limit: 25 kN
Operating temperature range: -10° to +40° C
Relative operating humidity: 10% to 80% RH
Weight: 520 g
Measure L x H x W: 190 x 90 x 20 mm
Size load eyes: 60 x 40 mm (R30 D-Shape)
Material body: Aviation aluminum alloy LY12CZ
Protection Class: IP66
1.2. Designation of use
The LineScale is an electronic Bluetooth load cell designed for industrial and rescue PPE application.
For PPE application use is limited to suspension of one person only!
It is highly recommend to not exceed 10kN load in PPE application.
In PPE relevant applications this equipment is to be used by trained PPE personnell only.
Ensure a rescue plan is in place to deal with any emergencies that could arise during PPE use.
Warning: May only be used when no medical pre-conditions apply that could impede safe PPE use.
2. Nomenclature of parts & Marking
Load eye
Load eye
Device
Serial-No.
Display
Body
XX:XX:XX
USB-Ports
Master
Slave
LineGrip LineScale-3
Electronic Bluetooth Load-Cell
www.linegrip.com/ls3
WLL 30 kN (3t)
MBS 90 kN (9t)
Designed in Germany
by LineGrip Corp. Ltd.
67714 Waldfischbach
[phone]
www.linegrip.com
Manufactured in China
DOM08/21 • Batch 001
PPE-R/11.114 V3:2021 • 1019
This device is certified to be used as
Personal Protective Equipment
(PPE) Recommendation: do not exceed 10 kN (1000kg) !
UIAA 130 V1:2021 (25kN)
(load sharing devices)
RF regulations
BQB BLE 4.2/5.0
CE ETSI RED, IC
FCC ID: 2ADXE-
HY-40R204PC
WLL designation
MBS designation
Notied body
no. 1019 (CE)
Recommended
PPE load
QR-Code to
product website
Date of
manufacturing
& Batch-No.
Certication
regulations
3. Compatibility
3.1. Connectors
Depending on the eld of application, for the connection only use EN 362 connectors specic for
work at height or EN 12275 connectors specic for mountaineering activities, equipped with
locking gates, or attach ropes & slings directly to the load eyes.
3.2. Anchor Points
Only use anchor points complying with EN 795 standards (minimum strength 12 kN or 18 kN for
non-metallic anchors), located above the user’s position.
RF regulations
Note: CE = Conformité Européenne (European Conformity)
Read manual
before use!
RF regulations
BQB BLE 4.2/5.0
CE ETSI RED, IC
FCC ID: 2ADXE-
HY-40R204PC
Device name

PPE Instruction Manual
PPE-R/11.114 V3:2021
Page 3 of 5
LS3-PPE-M_rev.3_201021
4. Instructions for use
4.4. Multi directional loading
The load eyes are specically designed for multi directional loading of up to 180°.
The weakest direction of load is 180° loading of one single eye (see illustration 4.4.1). Please
do not exceed 50% of specied load according to section 1.1. in this conguration.
4.5. Edge loading
Make sure the LineScale is clear of any edges and protruding elements to
avoid crossloading! Danger: in the event of crossloading severe injury or
death may be the consequence!
4.6. Connecting methods
Any permissible connector according to section 3.1 is allowed, in addition to any direct
„soft“ connection to the load eyes, like ropes, slings, soft shackles, etc.
Note: Do NOT mix „hard“ connectors with „soft“ connections in the same load eye!
4.1
DANGER!
DANGER! DANGER!
OK NO!
4.2.1
4.3
4.2.2
4.4.1
-50%

PPE Instruction Manual
PPE-R/11.114 V3:2021
Page 4 of 5
LS3-PPE-M_rev.3_201021
5. Warnings & Inspection
5.1. Hazardous materials
Aluminum can be structurally damaged by various chemicals such as acids and bases. Keep the
LineScale clear of any agressive chemicals at any time!
5.2. Sharp metals
Aluminum is softer than steel. Sharp or burred objects can damage the LineScale body. Do not
use any connectors with damaged, sharp or burred edges.
5.3. Falls from great height
Aluminum can suer internal micro fracturing when dropped from great height. Never drop the
LineScale from any height and always protect it from hard impacts.
5.4. Inspection before use
Always visually inspect the LineScale thoroughly before any PPE use!
Do not use the LineScale at any doubt of integrity.
Do not use the LineScale when signicant wear or damage is visible.
Please ensure ligibility of all product markings.
In case of doubt or visual damage or suspected hard impacts or falls from great height, always
have a professional inspect and verify the LineScale integrity before using it in PPE rigs.
5.5. Prohibited use
The LineScale may NOT be:
5.5.1. used for industrial lifting purposes!
5.5.2. used for suspension of multiple persons!
5.5.3. used for tie-downs & lashing.
5.5.4. used for towing with vehicles.
5.5.5. connected to high abrasive connectors (e.g. moving steel ropes).
5.5.6. altered in any way without the written prior consent of the manufacturer.
Any undesignated use renders the LineScale PPE certication NULL and VOID!
5.6. Periodic professional inspection/examination
For industrial and rescue work all your local and industry specicinspection intervals must be
followed! A periodic examination and/or inspection is to be conducted at least every 12 months.
Periodic inspections are to be conducted by a competent PPE certied body in accordance with
the manufacturer‘s periodic examination, and load testing procedures.
It is highly recommended to keep a record of these inspections in a detailed inspection record,
as for example supplied in Annex-1 on the last page of this manual.
5.7. Retirement
The LineScale shall be retired from PPE use if:
5.7.1. any doubts arise from it‘s condition for safe use
5.7.2. it has been used to arrest a factor-2 fall (or greater)
5.7.3. it has been exposed to a load of more than 25kN

PPE Instruction Manual
PPE-R/11.114 V3:2021
Page 5 of 5
LS3-PPE-M_rev.3_201021
A1. Annex 1 -Equipment Inspection Record
LineScale-3 LineGrip LineScale-3
LineGrip Corp. Ltd. Hauptstr. 41
67714 Waldschbach, DE www.linegrip.com
Electronic Bluetooth PPE Load Cell
A2. Annex 2 -Certication Body
EU type-examination and EU conformity to type is performed by:
NB1019, VVUÚ, a.s., Pikartská 1337/7, 716 07 Ostrava – Radvanice, Czech Republic.
6.1. Storage
The LineScale shall be stored in a dark, dry, cool place, free of chemicals and chemical fumes.
Before storage the unit shall be cleaned according to section 6.2.
6.2. Cleaning & Disinfection
When the LineScale was in contact with salt water, always rinse with warm water, wipe with a dry
and soft cloth, and leave to fully dry before storing.
The LineScale my be disinfected with a cloth dapened with Isopropyl acohol or any commercially
available object disinfection liquid. Note: do not spray desinfection liquid directly on the unit!
6.3. Lifespan
The LineScale lifespan is not limited by time. It is dependent on assessment according section 5.
6. Storage, Cleaning, Disinfection, Lifespan

Stay safe!
(c) 2021 LineGrip Corp. Ltd.
