liniLED PCB Photon Series User manual

LED strip manual
liniLED® PCB Photon
BEND RADIUS
R
20 mm
FRoHS
24
V D
C
IP00
CRI
80
+
MAC
ADAM
2
S D C M

General
Handling
Installation
Operation and use
Cleaning and maintenance
Environment and waste
Warning
Area advice
Product dimensions
Product information
Product specications
Cable selection
Product care and handling
Cutting instructions
Soldering
Connect IP00
Power supply
Symbols
4
4
4
4
4
4
5
5
5
5
6
7
9
10
11
12
13
14
LED strip PCB Photon

4LED strip manual | liniLED® PCB Photon
Read the instructions and safety precautions before installation, usage and storage of the products to secure safety of the user and reliability of the product.
- Hand over the instructions to the end user and those responsible for installation and usage.
- Triolight B.V. cannot be held responsible for improper handling, product installation, usage or storage.
Handling
- Handle with care.
- The product may not be modied or converted otherwise than prescribed.
- Products are transported in proper packaging. Products should remain packed until installation.
- Take ESD (Electrostatic Discharge) protection measures when handling liniLED® products.
- The products and their components may not be exposed to mechanical, static loads and other tension/compression other than from the product itself.
Installation
- Attention: The power has to be switched o the main power supply or the connection before installation. Not doing so may damage the product.
- Use a suitable LED power supply/driver: 24 V DC constant voltage. Do not drive the product on other voltages than described in their datasheet/products
specications.
- Installation has to be done by a certied professional with knowledge of electrical circuits or a specialised maintenance person known with valid directives.
- General and local construction-, safety- and installation regulations should be respected.
- Use only supplied parts, accessories and required tools as prescribed in the installation manual to guarantee a safe installation and use of the product.
- Products may solely be installed in the areas according to their prescribed IP-rating, IK-rating, temperature range and chemical resistances.
- The LED strip should be installed on an adequate cooling body for proper heat dissipation to ensure smooth operation and long lifetime.
- Do not fasten anything on the product, same applies for hanging.
- Do not install the product in the following cases:
- Damage is visible on the product or its cables.
- The inside of the product is moistened or dirty.
- The product or its cables have been modied. It could lead to an electrical shock or a short circuit may occur.
- Children may not play unsupervised with electrical products as they cannot judge the dangers in dealing with electrical circuits correctly.
- Use proper mounting surfaces when installing in environments with large variations in temperature and operating lengths more than 2m. This should
absorb the stress of any mismatch in expansion.
Operation and use
Solely use the product when its working correctly. If not, switch the power o immediately and advise an electrical specialist in the following cases:
- Damage is visible on the product and/or the product does not function.
- The product is overheating and/or smoke or steam rises from the product.
- Crackling sounds are noticeable.
- Repairs on the installation may only be performed by qualied electricians. Product repairs may solely be done by Triolight B.V.
Cleaning and maintenance
- Attention: Disconnect the power before maintenance and cleaning.
- Dust and dirt accumulated over time should be removed from the light emitting surface to assure optimal functioning of the product.
- Paints, solvents and corrosive cleaning chemicals may not contact and thus aect the product.
Environment and waste
- Exterior decorative lighting should only be used after sunset.
- This product may not be treated as household waste. Dispose of the material through the waste recycling of electrical and electronic equipment.
Warranty
This product comes with a 2 year warranty. Warranty void if:
- The installation guide has not been consulted (installation mistake).
- The installation is not done by a certied installer.
- Local rules and guidelines are not respected.
- The invoice cannot be shown and/or has been altered.
- Damage is caused by negligence, abnormal use or improper handling, use, maintenance and/or cleaning of the product.
Technical notes

5LED strip manual | liniLED® PCB Photon
Area advice
Indoor environment (IP00)
Solder
Indoor environment (IP00) | liniLED® PCB Connector set
Product code: 11808
Depending on the area where the liniLED® LED strip is installed we oer a range of solutions to cope with external factors. The product portfolio
for the liniLED® PCB LED strip only includes a range of IP00 connectors.
LED strip top view
LED strip front view
Product dimensions
8
1/2.2
100
8

6LED strip manual | liniLED® PCB Photon
Product information
Product specications
Colour
2000K
2400K
2700K
3000K
4000K
6500K
Colour
2000K
2400K
2700K
3000K
4000K
6500K
Colour
2000K
2400K
2700K
3000K
4000K
6500K
Colour
2000K
2400K
2700K
3000K
V DC
24
24
24
24
24
24
V DC
24
24
24
24
24
24
V DC
24
24
24
24
24
24
V DC
24
24
24
24
Temp ˚C
-30...55
-30...55
-30...55
-30...55
-30...55
-30...55
Temp ˚C
-30...55
-30...55
-30...55
-30...55
-30...55
-30...55
Temp ˚C
-30...55
-30...55
-30...55
-30...55
-30...55
-30...55
Temp ˚C
-30...55
-30...55
-30...55
-30...55
LED/m
70
70
70
70
70
70
LED/m
70
70
70
70
70
70
LED/m
70
70
70
70
70
70
LED/m
70
70
70
70
W/m
10.6
10.6
8.9
8.9
8.1
8.1
W/m
17.9
17.9
15
15
13.6
13.6
W/m
28.9
28.9
23.7
23.7
21.8
21.8
W/m
28.9
28.9
28.9
28.9
Max. Length
9 m
9 m
9 m
9 m
9 m
9 m
Max. Length
4.5 m
4.5 m
4.5 m
4.5 m
4.5 m
4.5 m
Max. Length
3 m
3 m
3 m
3 m
3 m
3 m
Max. Length
3 m
3 m
3 m
3 m
lm/m
1002
1170
1208
1230
1221
1223
lm/m
1536
1709
1742
1798
1831
1813
lm/m
2292
2545
2631
2785
2663
2614
lm/m
3300
3401
3415
3404
B50/L70
> 50.000 h
> 50.000 h
> 50.000 h
> 50.000 h
> 50.000 h
> 50.000 h
B50/L70
> 50.000 h
> 50.000 h
> 50.000 h
> 50.000 h
> 50.000 h
> 50.000 h
B50/L70
> 50.000 h
> 50.000 h
> 50.000 h
> 50.000 h
> 50.000 h
> 50.000 h
B50/L70
> 50.000 h
> 50.000 h
> 50.000 h
> 50.000 h
The liniLED® LED strip PCB Photon (IP00) is a high quality, exible LED strip with an outstanding eciency. Thanks to the small dimensions, the
PCB LED strip is ideal to use in small spaces (indoor use only!). With 3M double sided tape on the back, the PCB LED strip is easy to mount. The
liniLED® LED strip PCB Photon serie is available in various white colours and lumen (1200-4000).
* Connect the PCB LED strips with the PCB Connector Set and the PCB Inline Connector. See datasheet for more information.
Photon 1200Photon 2000Photon 3000Photon 4000

7LED strip manual | liniLED® PCB Photon
The liniLED® LED strips need a minimum voltage at the beginning of the LED strip to function according to the specications. The table below gives an indication
of the maximum cable length based on the cable thickness and power supply voltage. The connection between the cable and LED strip is with a
liniLED® Connector.
In case the required length is larger than the length mentioned in this table, the supply voltage is dierent or if a detailed wire plan with
branches is planned, please contact your distributor for a detailed cable calculation.
1 m
2 m
5 m
9 m
1 m
2 m
5 m
9 m
1 m
2 m
5 m
9 m
1 m
2 m
5 m
9 m
1 m
2 m
5 m
9 m
27.95 m
13.33 m
4.56 m
1.96 m
42.04 m
20.05 m
6.86 m
2.95 m
55.90 m
26.66 m
9.12 m
3.92 m
84.09 m
40.11 m
13.72 m
5.91 m
139.96 m
66.76 m
22.84 m
9.83 m
33.53 m
16.12 m
5.68 m
2.58 m
50.45 m
24.25 m
8.54 m
3.88 m
67.07 m
32.25 m
11.36 m
5.17 m
100.90 m
48.51 m
17.08 m
7.77 m
167.92 m
80.74 m
28.44 m
12.94 m
36.97 m
17.84 m
6.36 m
2.96 m
55.62 m
26.84 m
9.57 m
4.46 m
73.95 m
35.69 m
12.73 m
5.93 m
111.24 m
53.69 m
19.15 m
8.92 m
185.14 m
89.35 m
31.88 m
14.85 m
54.85 m
26.78 m
9.94 m
4.95 m
82.51 m
40.29 m
14.95 m
7.45 m
109.70 m
53.56 m
19.88 m
9.90 m
165.02 m
80.58 m
29.91 m
14.90 m
274.64 m
134.10 m
49.78 m
24.80 m
65.57 m
32.14 m
12.08 m
6.14 m
98.64 m
48.35 m
18.18 m
9.24 m
131.14 m
64.29 m
24.17 m
12.28 m
197.28 m
96.71 m
36.36 m
18.48 m
328.33 m
160.95 m
60.52 m
30.76 m
72.17 m
35.44 m
13.40 m
6.87 m
108.57 m
53.32 m
20.16 m
10.34 m
144.35 m
70.89 m
26.81 m
13.75 m
217.15 m
106.64 m
40.33 m
20.69 m
361.40 m
177.48 m
67.13 m
34.44 m
liniLED® cable (2 x 0.50 mm)
0.035 Ω/m
liniLED® cable (2 x 0.75 mm)
0.023 Ω/m
liniLED® cable (2 x 1.00 mm)
0.018 Ω/m
liniLED® cable (2 x 1.50 mm)
0.012 Ω/m
liniLED® cable (2 x 2.50 mm)
0.007 Ω/m
Cable X information LED strip Max. cable length 2000, 2400K Max. cable length 2700, 3000K Max. cable length 4000, 6500K
@ 24 V DC @ 24 V DC @ 24 V DC@ 25V DC @ 25V DC @ 25V DC
Cable Selection Photon 1200
Cable Selection Photon 2000
The liniLED® LED strips need a minimum voltage at the beginning of the LED strip to function according to the specications. The table below gives an indication
of the maximum cable length based on the cable thickness and power supply voltage. The connection between the cable and LED strip is with a
liniLED® Connector.
In case the required length is larger than the length mentioned in this table, the supply voltage is dierent or if a detailed wire plan with
branches is planned, please contact your distributor for a detailed cable calculation.
1 m
2 m
3 m
4.5 m
1 m
2 m
3 m
4.5 m
1 m
2 m
3 m
4.5 m
1 m
2 m
3 m
4.5 m
1 m
2 m
3 m
4.5 m
16.02 m
7.37 m
4.48 m
2.56 m
24.11 m
11.09 m
6.74 m
3.85 m
32.05 m
14.74 m
8.97 m
5.12 m
48.22 m
22.18 m
13.49 m
7.71 m
80.26 m
36.91 m
22.46 m
12.83 m
19.37 m
9.04 m
5.60 m
3.30 m
29.14 m
13.60 m
8.42 m
4.97 m
38.75 m
18.09 m
11.20 m
6.61 m
58.29 m
27.21 m
16.85 m
9.95 m
97.02 m
45.29 m
28.05 m
16.55 m
21.50 m
10.10 m
6.31 m
3.77 m
32.34 m
15.20 m
9.49 m
5.68 m
43.00 m
20.21 m
12.62 m
7.55 m
64.69 m
30.41 m
18.98 m
11.37 m
107.67 m
50.62 m
31.60 m
18.92 m
31.95 m
15.33 m
9.79 m
6.10 m
48.07 m
23.07 m
14.73 m
9.18 m
63.91 m
30.67 m
19.59 m
12.20 m
96.14 m
46.14 m
29.47 m
18.36 m
160.01 m
76.79 m
49.05 m
30.55 m
38.38 m
18.55 m
11.93 m
7.53 m
57.74 m
27.90 m
17.95 m
11.32 m
76.77 m
37.10 m
23.87 m
15.06 m
115.48 m
55.81 m
35.91 m
22.65 m
192.19 m
92.88 m
59.78 m
37.71 m
42.46 m
20.59 m
13.30 m
8.43 m
63.88 m
30.97 m
20.00 m
12.69 m
84.93 m
41.18 m
26.60 m
16.87 m
127.76 m
61.95 m
40.01 m
25.38 m
212.64 m
103.10 m
66.59 m
42.25 m
liniLED® cable (2 x 0.50 mm)
0.035 Ω/m
liniLED® cable (2 x 0.75 mm)
0.023 Ω/m
liniLED® cable (2 x 1.00 mm)
0.018 Ω/m
liniLED® cable (2 x 1.50 mm)
0.012 Ω/m
liniLED® cable (2 x 2.50 mm)
0.007 Ω/m
Cable X information LED strip Max. cable length 2000, 2400K Max. cable length 2700, 3000K Max. cable length 4000, 6500K
@ 24 V DC @ 24 V DC @ 24 V DC@ 25V DC @ 25V DC @ 25V DC

8LED strip manual | liniLED® PCB Photon
The liniLED® LED strips need a minimum voltage at the beginning of the LED strip to function according to the specications. The table below gives an indication
of the maximum cable length based on the cable thickness and power supply voltage. The connection between the cable and LED strip is with
a liniLED® Connector.
In case the required length is larger than the length mentioned in this table, the supply voltage is dierent or if a detailed wire plan with branches is planned,
please contact your distributor for a detailed cable calculation.
1 m
2 m
3 m
1 m
2 m
3 m
1 m
2 m
3 m
1 m
2 m
3 m
1 m
2 m
3 m
9.43 m
4.07 m
2.29 m
14.19 m
6.13 m
3.44 m
18.87 m
8.15 m
4.58 m
28.39 m
12.26 m
6.89 m
47.26 m
20.41 m
11.46 m
11.79 m
5.25 m
3.07 m
17.73 m
7.90 m
4.62 m
23.58 m
10.50 m
6.14 m
35.47 m
15.80 m
9.25 m
59.04 m
26.30 m
15.39 m
12.93 m
5.82 m
3.45 m
19.45 m
8.76 m
5.19 m
25.86 m
11.64 m
6.90 m
38.90 m
17.52 m
10.39 m
64.75 m
29.16 m
17.29 m
19.30 m
9.01 m
5.57 m
29.04 m
13.55 m
8.39 m
38.61 m
18.02 m
11.15 m
58.08 m
27.10 m
16.78 m
96.66 m
45.11 m
27.93 m
23.82 m
11.26 m
7.08 m
35.83 m
16.95 m
10.65 m
47.64 m
22.53 m
14.16 m
71.67 m
33.90 m
21.31 m
119.28 m
56.42 m
35.47 m
26.01 m
12.36 m
7.81 m
39.12 m
18.59 m
11.75 m
52.02 m
24.72 m
15.62 m
78.25 m
37.19 m
23.50 m
130.24 m
61.90 m
39.12 m
liniLED® cable (2 x 0.50 mm)
0.035 Ω/m
liniLED® cable (2 x 0.75 mm)
0.023 Ω/m
liniLED® cable (2 x 1.00 mm)
0.018 Ω/m
liniLED® cable (2 x 1.50 mm)
0.012 Ω/m
liniLED® cable (2 x 2.50 mm)
0.007 Ω/m
Cable X information LED strip Max. cable length 2000, 2400K Max. cable length 2700, 3000K Max. cable length 4000, 6500K
@ 24 V DC @ 24 V DC @ 24 V DC@ 25V DC @ 25V DC @ 25V DC
Cable selection Photon 3000
Cable selection Photon 4000
The liniLED® LED strips need a minimum voltage at the beginning of the LED strip to function according to the specications. The table below gives an indication
of the maximum cable length based on the cable thickness and power supply voltage. The connection between the cable and LED strip is with
a liniLED® Connector.
In case the required length is larger than the length mentioned in this table, the supply voltage is dierent or if a detailed wire plan with branches is planned,
please contact your distributor for a detailed cable calculation.
1 m
2 m
3 m
1 m
2 m
3 m
1 m
2 m
3 m
1 m
2 m
3 m
1 m
2 m
3 m
9.43 m
4.07 m
2.29 m
14.19 m
6.13 m
3.44 m
18.87 m
8.15 m
4.58 m
28.39 m
12.26 m
6.89 m
47.26 m
20.41 m
11.46 m
19.30 m
9.01 m
5.57 m
29.04 m
13.55 m
8.39 m
38.61 m
18.02 m
11.15 m
58.08 m
27.10 m
16.78 m
96.66 m
45.11 m
27.93 m
liniLED® cable (2 x 0.50 mm)
0.035 Ω/m
liniLED® cable (2 x 0.75 mm)
0.023 Ω/m
liniLED® cable (2 x 1.00 mm)
0.018 Ω/m
liniLED® cable (2 x 1.50 mm)
0.012 Ω/m
liniLED® cable (2 x 2.50 mm)
0.007 Ω/m
Cable X information LED strip Max. cable length 2700 t/m 6500K
@ 24 V DC @ 25V DC

9LED strip manual | liniLED® PCB Photon
Do not bend the LED strip sidewards. Do not twist the LED strip.
The LED strip has to be unreeled on a horizontal surface at the time of installation. Do not unreel the spool of LED strip before installation.
Product care and handling
20 mm
20 mm
Do not compress or stretch the LED strip.
Maximum bending radius is 20 mm. Solely bend up- or downwards.

10 LED strip manual | liniLED® PCB Photon
Cutting instructions
Dispose of the unnecessary material through waste recycling of
electrical and electronic equipment.
Top view | Only cut on the dotted lines to prevent damaging the LED
strip.
Turn o the power before cutting the LED strip.
Work in an ESD protected environment. Make use of an anti-static
strap.
Top view | Make sure the cut is vertical as illustraded in the image
above.

11 LED strip manual | liniLED® PCB Photon
0.5 mm
2
8 mm
Solder
Work in an ESD protected environment. Make use of an anti-static
strap and use lead-free solder.
Turn o the power. Make sure the wires are not under electric
current.
Solder the wires to the PCB. We advise to use a cable with an area not
bigger then 0.5 mm
Pre-solder the wires.
Pre-solder the connector pads.
Solder the wires to the connector pads.
350 C
350 C
350 C

12 LED strip manual | liniLED® PCB Photon
5 mm
Remove tape protection from back. Peel o tape carefully from the
PCB and fold the rst 5 mm.
Make sure the PCB and connector are at on the surface and insert
PCB into connector.
Press connector rmly untill it clicks.
Connect IP00
Use a at screwdriver to open the connector.
Finished product.
In order to maintain adequate electrical contact, the
connectors are designed for single use. Remove is possible
but will result in the destruction of the connector.

13 LED strip manual | liniLED® PCB Photon
Power supply
liniLED® Cable 1 m
L
N
Power Supply
24 V DC
-+
230 V AC
Cable X
Control
IP00
Connect the LED strip as indicated in the gure above. The wires should be connected as follows: Red (+) and Black (-).
Turn o the power before connecting the LED strip to the power
supply.
Insert the power plug.

14 LED strip manual | liniLED® PCB Photon
Symbols
F
RoHS
IP00
BEND RADIUS
R
20 mm
24
V DC
Manufacturer’s declaration that the product meets the applicable EC directives.
Electro Static Discharge (ESD) sensitive device, apply standard ESD precautions when handling the product
Restriction of Hazardous Substances (RoHS): product complies with the RoHS directive and each homogeneous material does
not exceed the limits for the materials mentioned under the RoHS directive (Pb, Hg, Cd, Cr6+, PBB and PBDE).
Not protected against ingress of solid foreign objects. Not-protected against ingress of water.
Suitable for mounting on all surfaces and suitable to cover with insulating material.
Current Voltage. 24 Volt.
Bending of the LED strip is possible with a radius of ≥ 20millimetres in the specied direction.
Electrical appliance class III: this product is designed to be supplied from an extra-low voltage
(≤ 60.0 V DC or ≤ 42.4 V AC).
CRI
80
+
MAC
ADAM
2
S D C M
The binning tolerance of this product is 2 MacAdam.
The CRI value of this product is 80 or higher.

liniLED® is a registered trademark of Triolight B.V.
Subject to misprints, errors and modications. No legal rights can be derived from this document. V0319
