Link electronics Variable Delay Video Amplifier IEC-754 User manual

700 SERIES
LINK ELECTRONICS, INC.
VARIABLE DELAY VIDEO AMPLIFIER
MODEL IEC-754
FEATURES
Four Outputs
Delay Trim Adjustment
475 nS Delay, Standard
Video Bandwidth 32 MHZ
Optional delay up to 975 nS
Cable Equalization, 1000 Feet
Input, Differential Loop Through
The IEC-754 Video Delay DA reflects the latest
state of the art inengineering. The IEC-754 is one
of the most versatile video delay DA's on the
market, and provides outstanding performance.
The delay is continuously variable from 30 nS to
475 nS.
The IEC-754 offers transparent transmission, with
-3dB frequency response to 32 MHZ, and -3dB to
16 MHZ with maximum delay. A differential input
is standard in the IEC-754, and provides more
than 80 dB of common mode rejection.
The versatility of the IEC-754 is illustrated by its
choiceofbuilt-infeatures. Aninternal spare32pin
IC socket provides for additional optional delay
that increases the delay by 200, 300, 400, or 500
nS. Cable equalization is adjustable from the front
panel with a calibrated control that compensates
for loss in coax cable for up to1000 feet of Belden
8281. A delay trim on the front panel allows
matchingofsignalpropagationdelayswitharange
of ±5ns. The IEC-754 is a notable addition to the
Link Electronics well recognized "700" series
products.
LINKELECTRONICS, INC. 2137 Rust Avenue Cape Girardeau, MO 63703-7668
Phone [phone] FAX [phone]
MADE IN THE USA

IEC-754 Rear Panel
IEC-754/100302
Model PRT-700
MODEL IEC-754 Variable Delay Video Amplifier
SPECIFICATIONS
INPUT:
Video Level: .............. 1.0Vp-p±3dB
Impedance: ............ >100KΩ, bridging
Common Mode Range: ..... 16Vp-p(60Hz)
MaximumDCIn: ................ ±5VDC
CMRR: ................. >80dB @ 60Hz
OUTPUTS:
Number: ................Foureach,BNC
Level:.................. UnityGain,±3dB
AMPLIFIER PERFORMANCE:
Frequency Response, No Delay:
..................... 0.5dBto18MHz
........................ -1to25MHz
...................... -3dBto32MHz
Frequency Response, Maximum Delay:
.................... ±0.5dBto10MHz
........................ -1to12MHz
...................... -3dBto16MHz
OutputIsolation: .......>-40dB at 3.58 MHz
ReturnLoss: ..............40dB to 6 MHz
High Freq. Overshoot: ............. <0.4%
Ringing:........................ <0.4%
Tilt: ........................... <0.4%
Hum: ............. >70dB, below 1.0V p-p
Differential Phase: . . . <0.1°, 10% to 90% APL
Differential Gain: . . . <0.1%, 10% to 90% APL
FRONT PANEL CONTROLS:
GainControl:....±3dBcontinuous from unity
CableEqualizer: ....Equalizes up to 1000 Ft
Propagation Delay Trim: .............±5ns
ENVIRONMENTAL:
Temperature:.......... 0°to50°C,ambient
Humidity:......10%to90%non-condensing
POWER:
DC Voltage: ........... +15VDC(100 mA)
....................-15VDC(100 mA)
Power:....................... 7.2watts
MECHANICAL:
Height:............................. 1"
Width: ........................... 5.5"
Depth: .......................... 9.25"
Weight: ...................... 2lbs.9oz
LINK ELECTRONICS, INC.
2137 Rust Avenue
Cape Girardeau, MO 63703
Phone: [phone]
FAX: [phone]
PROFESSIONAL SERIES--
stand-alone products--by LINK
