HDE-3000 HIGH DEFINITION CLOSED CAPTION ENCODER, HD SD SDI
SPECIFICATIONS
HD VIDEO INPUT
Standard: ............................................................ SMPTE292M
Number of Inputs: ..............................................................One
Connectors: ....................................................... BNCTrue75Ohm
Equalization: ......................................Automatic,Approx.100 feet at 1.5 Gb/s
HD VIDEO OUTPUT
Standard: .............................................................Sameasinput
NumberofOutput: ................... Two,OneProgramOutput,OnePowerBy-passProtected
Connectors: ....................................................... BNCTrue75Ohm
Signal Level: ........................................................800 mV, nominal
DC Offset: .......................................................... 0Volts,+/-0.5V
RiseTime: .......................................................... 200pS, Nominal
Overshoot: ...................................................................<10%
TimingJitter: ................................................................ <1.0UI
SD VIDEO INPUT
Standard: ........................................................... SMPTE259M-C
Number of inputs: ............................................................... One
Connectors: .....................................BNCTrue75Ohm(SharedwithHDInput)
Equalization: ......................................Automatic,Approx100 feet at 270 Mb/s
SD VIDEO OUTPUT
Standard: ................................................... SMPTE259M-C 270 Mb/s
NumberofOutputs: ...................... TwoProgramOutput,OnePowerBy-passProtected
Connectors: ....................................................... BNCTrue75Ohm
Signal Level: ........................................................800 mV, nominal
DC Offset: .......................................................... 0Volts,+/-0.5V
RiseTime: .......................................................... 200pS, Nominal
Overshoot: ...................................................................<10%
Wideband Jitter: ............................................................. <0.2UI
COMMUNICATIONS
SerialPorts: ............................................................ TwoRS-232
Modem: ........................................................OneInternal,Optional
Ethernet: ................................................. One,RJ-45Connector, IEEE
USB:............................................................... TwoFrontPanel
ENVIRONMENTAL
Temperature ....................................................... 0to50Cambient
Humidity.................................................. 10%to90%non-condensing
Power................................................................... 200 Watts
MECHANICAL
Depth ................................................................... 14Inches
Width ................................................................... 19Inches
Height: .................................................................. 3.5Inches
Weight ................................................................. 15Pounds.
FRONT PANEL LED INDICATORS
Power........................................................... Green/ power on/off
StatusIndication: ........................................................... SixLED
Menu Selection: ....................................................... FourplusEnter
Reset:.............................................................. OneMomentary
USB:................................................................ TwoUSBPorts
Fan: ........................................................... FanGrill with air filter
LINK ELECTRONICS, INC. 2137 Rust Avenue Cape Girardeau, MO 63703-7668
Phone [phone] FAX [phone]
MADE IN THE USA
The HDE-3000 is
setting the standard for
future generations
HIGH DEFINITION & STANDARD DEFINITION
CAPTION ENCODER, HD SD SDI
VERSATILE PLATFORM FOR HD DATA ENCODING AND GRAPHICS
INSERTION
MODEL HDE-3000, Single Encoder
MODEL HDE-3000/2, Dual Encoder
FEATURES
Networkable
HD & SD SDI I/O
USB, 2 Front Panel
Ideal for Broadcast or Post
Field Upgradable Software
Up-Convert 608 to 708 captions
Built-in LTC Time Code Reader
VGA monitor to Preview Captions
Two independent I/O COM Ports
Full Screen Character Inserter (Subtitles)
No PC or Caption/Subtitle Encoding Software Required
Reads Caption Files Directly From Floppy, Server or USB
The HDE-3000 is a high definition HD SDI or
standard definition SD SDI encoder for
professionalsthatmeetsthestrictestrequirements
for broadcast use. The HDE-3000 is capable of
insertingslates,bugs,TVratingiconsandsubtitles
with field 1 synchronization while encoding closed
captiondata.TheHDE-3000encodesdataintothe
vertical ancillary portion of SMPTE 292M HD SDI
video per SMPTE 334. All ATSC video standards
are supported.
The optional dual encoder HDEenc gives the
operator the ability to run two separate caption or
graphics jobs at the same time. It also allows for
two separate time code inputs. The dual HDE-
3000/2 can reduce encoding time by allowing the
operator to encode captions in High Definition or
Standard Definition simultaneously.
A built-in Closed Caption Decoder will display
open captions on the video output for HD or SD.
Thedualencoder,HDE-3000/2 can displayOPEN
on one HDEenc and CLOSED on the second
HDEenc.
The HDE-3000 will encode or monitor popular
XDS packets including VCHIP, CGMS, and TSID.
A selectable safe title area is provided to insure
graphics are displayed in the viewable area. The
optional Drag and Drop software allows for quick
and simple additions of graphics to any job.
With the optional Internet captioning software,
captioning can be accomplished from any location
that has an Internet network connection.
With the HDE-3000 network capability a single or
multiple HDE-3000's can be controlled remotely
from any Windows based PC.
The HDE-3000 supports the following HD SDI
standards, 1080i, 1080p, 1080psf, and 720p. It
also supports SD NTSC and PAL SDI. The HDE-
3000 will support most caption file formats and will
translateEIA-608captionsintotheEIA-708format.
VANC encoding and decoding is also available for
SD SDI. The encoded line in HD is selectable by
theuser.Itis also capableofup-convertingCC2 or
CC3 to EIA-708, Service 2. The offset and
amplitude of inserted line 21 (22 PAL) for SD can
be controlled by the HDE-3000. The HDE-3000
also becomes a selectable format Black Burst
generator with no input signal.
The HDE-3000 is PC based using Windows XPE
and is constructed of modular architecture that
utilizes the industry standard PCI bus. This
concept provides the ability for future options.
EachHDE-3000comes with a1yearwarranty and
atwoyearFirmwareMaintenanceAgreement.The
firmwareiseasilyupgradedthroughthefrontpanel
controls.
Beginninginthe 4th quarterof2008allHDE-3000's
will be equipped with a Solid State Hard drive for
state of the art performance.

STATUS SCREEN
A status screen is displayed on the VGA monitor or
HDE-3000Remoteterminalwheneverthe HDE-3000
is in “run” mode (as opposed to “setup” mode).
The status screen displays several useful items as
shown above.
Many aspects of the HDE-3000 may be customized
by way of user settings. Settings are made from the
front panel, or they may be done via a network. The
HDE-3000 stores all current settings on its hard drive
in a registry file
The dual encoder system, model HDE-3000/2 contains two HDEenc encode/decode cards. The dual encoder
system allows several features, such as;
A. Run two jobs simultaneously
B. NTSC on one card
C. PAL on the second card
D. Closed caption on one card
E. Open caption on the second card
F. SD & HD Captioning Simultaneously
G. Two Different Video Formats Simultaneously
H. Re-insert Captions after format Conversion
I. Re-insert captions after video squeeze
J . Two Indepentant SMPE Time Code Inputs
The HDE-3000/2 contains two encoder cards. This product functions as two independent HDE3000 encoders
inside one chassis. Each independent encoder has its own video and time code connections, and both
encoders run simultaneously. Examples, user can encode an HD feed and an SD feed simultaneously., or
using the second card as a caption decode monitor.
COMMON NAMES ACCEPTS
1080i/60
1080I/59.54
1080I/50
1050P/30
1080P/29.97
1080P/25
1080i/24
1080P/23.98
1080PsF/30
1080PsF/29.97
1080PsF/25
1080PsF/24
1080PsF/23.98
720P/60
720P/59.94
720P/50
720P/30
720P/29.97
720P/25
720P/24
720P/23.98
HDE-3000 & HDE-3000/2, front panels are the same
HDEenc, HD SD SDI Encoder Card
The software automatically detects when it is running on a dual card unit and displays “HDE3000 DUAL Enc x”
in the title line of all of the menus (the “x” is a “1” or a “2” depending on which encoder you have selected).
The two internal encoders share the VGA displays, the front panel buttons, LED’s. and the COM ports.
The COM ports are available to both encoders, and can be cascaded to allow both encoders to use the same
Com Port.
Note Description:
#1, FP Primary Power Switch
#2. Cut a-way showing dual encoders
#3, 2 USB Ports & Reset
#4, LED’s Showing status
#5, Navigation control buttons
#6, AC Power Connector
#7, Secondary Power Switch
#8, Internal Telephone Modem
#9, Serial Port #2
#10, Serial Port #1
#11, Ethernet CAT5
#12, VGA Connector
#13, Keyboard & Mouse
#14, LTC Time Code
#15, HD SD SDI Out
#16, Signal Power By-Pass
#17, Main HD SD SDI Input
