CLOSED CAPTION SERIES
MADE IN THE USA
LINK ELECTRONICS, INC.
SD SDI VIDEO
CLOSED CAPTION ENCODER/DECODER
MODEL PDP-886
FEATURES
Dual Microprocessor
EDH Processing
SD SDI Input/Output
Optional, Dual Modem
RS232 OR RS422 Data Inputs
Encode/Decode Field 1 and Field 2
Two Encoded Serial Digital Outputs
Two Open-Caption Decoded SD Analog
Two Closed Caption Encoded SD Analog
V-Chip Compatible
SD SDI PDP-886. When the PDP-886 is used with
closed caption software, the unit inserts Closed
Caption data into a component serial digital data-
stream. There are two encoded serial digital outputs
plus four SD Analog NTSC/PAL outputs. One set of
the SD Analog outputs are open caption and the
secondSDAnalogsetofoutputsareclosedcaption.
Serial control is handled via two RS-232/422 ports,
selectable by an internal switch. A front panel LCD
indicatesEncode,Standard,DecodeandBaudRate.
There are two microprocessors incorporated, two
ports for each microprocessor (RS-232/422 and
modem). The SD SDI signal will bypass in case of
AC failure on one output.
Anencodedtestmessagemayalsobeselectedfrom
the front panel, showing Link as the manufacturer
name, model number and firmware version. A total
of nine data channels for video line 21 may be
selected:CC1,CC2,T1,andT2in Field 1 along with
CC3, CC4, T3, T4, and XDS in Field 2.
A built-in EDH (Error Detection and Handling)
processor can monitor the incoming signal for
impairments and insert new EDH data. This function
will insure that the output EDH Checksum will reflect
the new Line 21 waveform. An optional internal
telephone modem is available for each processor.
Three LED’s on the front panel indicate RI, OH, and
CD.
LINKELECTRONICS, INC. 2137 Rust Avenue Cape Girardeau, MO 63703-7668
Phone [phone] FAX [phone]

MODEL PDP-886
CLOSED CAPTION ENCODER, DECODER
SPECIFICATIONS
INPUT:
Number: ................................................................... One(1)
Standard: ..................................................... SMPTE259M-C 270Mb/s
Connector: .................................................................75ΩBNC
Impedance: ................................................................ 75Ω±1%
ReturnLoss: ........................................................ >18dB to 270MHz
Signal Level: ............................................................800mV ±10%
SD SDI OUTPUT:
Number: ................................................................... Two(2)
Standard: ..................................................... SMPTE259M-C 270Mb/s
Connector: .................................................................75ΩBNC
Impedance: ................................................................ 75Ω±1%
ReturnLoss......................................................... >18dB to 270MHz
Signal Level: ............................................................800mV ±10%
SD ANALOG DECODER OUTPUT:
Number: ....................................... Two,SDSDAnalogNTSC/PALComposite
Level:........................................................................1Vpp
Impedance: ................................................................ 75Ω±1%
Connector: .................................................................75ΩBNC
Standard: ..................................................... NTSC/PALCOMPOSITE
SNR: ....................................................................... >65dB
DifferentialPhase:.............................................................. <1.0°
DifferentialGain: .............................................................. <1.5%
DATA INPUTS, Common to Both Versions
Number: ........................................................................ 4
RS-232/422: ........................................................Two,9-pinDSub
Modem: ............................................................... Two,RJ-11
Protocol: ................................................................. 1200,n,8,1
Baud Rate: ...................................................1200, 2400, 4800, & 9600
FRONT PANEL:
ACPower:..................................................................ON/OFF
By-Pass: ....................................................... Push/Push,Maintained
Test: ..........................................................Push/Push,Momentary
ThreePositionDIPSwitch: .......... SelectsBaud rate of 1200, 2400, 4800 or 9600, plus pedestal
LEDIndicators: .............................Video Presence, RS232 Data Presence, Pedestal
Modem LED’s: .................................................RI,OH,CD,EachModem
LCDDisplay: ............................................EncodingMode, Field 1 or Field 2
Decoding Mode: ..................................... CC1,CC2,T1,T2,CC3,CC4,orXDS
Standard: .............................................................. NTSCorPAL
Baud Rate: ................................................... 1200, 2400, 4800 & 9600
ENVIRONMENTAL:
Temperature:....................................................... 0°to50°CAmbient
Humidity: .................................................. 10%to90%non-condensing
AC Input: ...................................................... 85to265 VAC, 50/60Hz
Power:..................................................................... 36VAR
MECHANICAL:
Height:...................................................................... 1.750"
Width: .........................................................................19"
Depth: .........................................................................12"
