LINK-MI LM-DT103 User manual

LM-DT103
HDMI Extender
User manual

1. Description
The LM-DT103 extender provides extension of HDMI signals long distances over a
single CAT5e/6 cable, it supports high resolution up to 1080p. The extender can use
for a wide range of applications requiring long distance transmission of high
resolution with high quality by its good stability and powerful security.
2. Features
Transmits HDMI video and audio signals up to 120m over a single CAT5e/6
cable;
Support video resolution up to 1920*1080P@60Hz;
Support one to many application with Ethernet switch;
Compliance with HDMI 1.3 and HDCP 1.2 standard;
High compatibility, can auto-match source and display device;
Built-in automatic adjustment system, make the image smooth, clear and
stable;
Built-in ESD protection system;
Simple to install, plug and play;

3. Specifications
Parameter
Description
Video
Standards
HDMI 1.3; HDCP 1.2
Maximum pixel clock
165MHz
Maximum data rate
6.75Gbps
Resolution
1920X1080P@60Hz
Connector
HDMI-A
Impedance
100Ω
Ethernet
Interface
RJ45
Transmission distance
CAT6---120m
Other
Power supply
The power adapter: DC 5V/1A
Power dissipation
MAX 3W
Temperature
Operating: -5℃~ +70℃
Humidity
Operating: 5% ~ 90%
Dimension
100*60*25mm
The warranty
1 year free warranty

4. Panel
Port name
Description
HDMI IN/OUT
HDMI signal input/output
RJ45
Ethernet interface
DC/5V
Power adapter socket
IR IN/OUT
IR signal input/output
RESET
Press for 5 second to restore system setting to
factory default
LED indicator
Description
STATUS
Video signal connection indicator
POWER
System power indicator

5. Package list
HDMI transmitter ……………………….…. 1 pc
HDMI receiver ……………………………….. 1 pc
Power adapter ……………………………….. 2 pcs
User manual …………………………………… 1 pc
6. Installation
1、Connect the provided DC/5V power supplies to the power socket of the
transmitter and the receiver,
2、Connect an HDMI cable between the HDMI input port of transmitter and the
HDMI output port of the video source,
3、Connect the HDMI output port of receiver to the display device with HDMI cable,
4、Connect the transmitter RJ45 port to the receiver RJ45 port using a single CAT6
cable.
7. Diagram
One to one One to many
