Link2Home EM-SL245B User manual

Solar Motion Security LED Light
EM-SL245B
Introduction .
We congratulate you on the purchase of your LED Solar Sensor Light. You have chosen a high quality
product. Before using your LED Solar Sensor Light, please familiarize yourself with the instructions and
safety information below. Only use the product as described and for the specified applications.
This product is intended to illuminate outdoor areas for private use and is not suitable for commercial use
or for use in other applications.
Technical Data
Material: PC+ABS
LED Type: 88*3014
Battery: 1*3.7V 18650 1800mA (included)
Solar Panel: 6V 600mA 3.5W, size:5.9*7.9in
Motion sensor angle: 140º
Detection range: approx. 26.2ft -39.4ft
Time setting: approx. 3seconds to 7min (+/-10%)
Lumen: 280LM (+/-10%)
Protection type: IP44(splash-proof)
General safety instructions .
1. Children should not be allowed to play with the product. Cleaning and user maintenance should not be
performed by children without adult supervision.
2. Never leave children unsupervised with the packaging material. The packaging material represents a
danger of suffocation.
3. Do not use this product if you notice any damage
4. The illuminants are not replaceable. If the illuminants fail, the entire product must be replaced
Function
The LED light will switch on during twilight or darkness when the motion detector
detects infrared radiation given off by people passing by.
User can turn the control knob TIME to adjust the duration of the illumination from approx. 3 seconds to 7
minutes (+/-10%).
User can turn the control knob LUX to adjust the daylight level at which to activate the motion detector.
Note: Once the light is activated by the motion detector, any subsequent detection will restart the timed
period again from the beginning.
Note: The motion detector responds to heat radiation. When outdoor temperatures are low, it is more

sensitive to body heat than when outdoor temperatures are warm.
Note: If the light is not activating during nighttime, a street light, house light or other ambient light could
be affecting activation. Turn the control knob LUX towards position to increase the daylight level. If
the light is unnecessarily activating during daytime, turn the control knob LUX towards position to
decrease the daylight level.
Note: Regularly clean the motion detector to ensure proper functionality(refer to “Cleaning and Care“).
Installation
When selecting the mounting location, pay attention to the following:
Note: The included mounting material is suitable for solid concrete or masonry construction. Other wall
substrates may require additional fastening materials.
Note: An electric drill is required
CAUTION! RISK OF INJURY! Please read the operating instructions for your drill.
CAUTION! Ensure that you do not damage any electrical cables in the wall or ceiling.
1. To choose the mounting location, make sure the LED light illuminates the desired area, the solar panel
has direct and opulent sunshine and that the product will not be directly exposed to rain.
2. Depending on the mounting height (roughly at 6.5ft) the motion detector has a detection range of max.
39.4ft with a detection angle of 140°.
3. Be sure the motion detector is not illuminated by street lighting at night. This can influence the light.
4. Use the holes on the mounting plate intended for the screws to mark the positions for drilling.
5. Drill two holes on the mounting location, insert wall plugs and fix the mounting plate with screws.
6. Fit the main unit to the mounting plate with screws.
7. Rotate and adjust the solar panel to a position for direct sunlight.
8. Turn the control knob TIME to adjust the duration of the illumination. The lighting duration can be
adjusted from approx. 3 seconds to 7 minutes (+/-10%).
9. Turn the control knob LUX to adjust the daylight level: At the position , the motion detector will only
react at night. In the position , the motion detector will respond at daylight levels.
10. After initial installation, the product may need about 2 days for charging under direct and opulent
sunlight, before it can normally operate.

Cleaning and Care
Use a slightly dampened, lint-free cloth and mild cleaning agent to clean.
Regularly check the motion detector for dirt.
Regularly clean the motion detector to ensure proper functionality
Troubleshooting
Problem Cause Solution
The light does not switch on
during nighttime
Motion detector is dirty Clean motion detector
LUX control is not properly set Turn LUX control to increase
LUX level.
Batteries are drained Charge under direct sunlight
The light switches on during
daytime
LUX control is not properly set Turn LUX control to decrease
LUX level
The light is dim Batteries are almost drained Charge under direct sunlight
The light flickers Batteries are almost drained Charge under direct sunlight

Disposal
The packaging is made entirely of recyclable materials, which you may dispose of at local recycling
facilities.
To help protect the environment, please dispose of the product properly when it has reached the end of
its useful life and not in the household waste. Information on collection points and their opening hours
can be obtained from your local authority.
Batteries may not be disposed of with the usual domestic waste. They may contain toxic heavy metals
and are subject to hazardous waste treatment rules and regulations.
Made in China
Imported by Paragon Group USA
Englewood, NJ 0 631 USA
1.888. 83.6082
