10W Handheld LED Dimmable Spotlight
120-277VAC - Inline Transformer + On/Off Switch + Dimmer - General Cord Cap
Instruction Manual
Thank you for your purchase of the Larson Electronics HUL-P10WR-DM-ILS-1227.
WARNING:
READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
CRITICAL SAFETY INSTRUCTIONS:
•INSTALLATION SHOULD ONLY BECONDUCTED BY A QUALIFIED ELECTRICIAN IN ACCORDANCE WITH NEC AND ANY
RELEVANT LOCAL BUILDING CODES.
•RISK OFFIRE OR ELECTRIC SHOCK. FIXTURE INSTALLATION REQUIRES KNOWLEDGE OF FIXTURE'S ELECTRICAL
SYSTEMS. IFNOTQUALIFIED, CONTACT A QUALIFIED ELECTRICIAN.
•BE CERTAIN ELECTRICAL POWER IS OFF BEFORE AND DURING INSTALLATION AND MAINTENANCE.
•MAKE SURE THE SUPPLY VOLTAGE IS THE SAME AS THE FIXTURE'S RATED VOLTAGE.
•TO PREVENT WIRING DAMAGE OR ABRASION, DO NOT EXPOSE WIRING TO EDGES OF SHEET METAL OR SHARP
OBJECTS. SUITABLE FOR DAMP LOCATIONS.
IMPORTANT
READ CAREFULLY BEFORE INSTALLING THIS FIXTURE. SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE. THE HUL-P10WR-DM-ILS-1227 MUST BE WIRED IN ACCORDANCE WITH NATIONAL ELECTRICAL
CODE AND ALL APPLICABLE LOCAL CODES. PROPER GROUNDING IS REQUIRED FOR SAFETY.
WE STRONGLY ENCOURAGE ONLY A LICENSED ELECTRICIAN INSTALL, OPERATE AND MAINTAIN THIS
PRODUCT. IF YOU ARE NOT QUALIFIED OR UNFAMILIAR WITH ANY ASPECT OF THIS INSTRUCTION SHEET,
CONSULT AN ELECTRICIAN. THERE ARE NO SERVICEABLE PARTS INSIDE.
WARNING: MAKE SURE POWER IS TURNED OFF BEFORE STARTING THE
INSTALLATION OR PERFORMING ANY MAINTENANCE.
RISK OF FIRE/ELECTRIC SHOCK –DISCONNECT POWER AT BREAKER BEFORE INSTALLING OR SERVICING.
RISK OF PERSONAL INJURY –FIXTURE MAY BECOME UNSTABLE OR DAMAGED IF NOT INSTALLED PROPERLY.
RISK OF BURN –ALLOW FIXTURE TO COOL BEFORE SERVICING.
Never place spotlight face down when light ison. Doing so could burn/ignite surfaces such as seats, carpeting, etc. and
cause major property damage. Always turn spotlight off when not inuse.
Avoid direct eye exposure the light source when light ison. DO NOTshine light into the face of someone else.
DO NOTtouch lens of light when on or recently on. The lens/cooling fins will be hot after long periods.
DO NOTallow children to handle or operate this light.
DO NOTuse this product for other than its intended use.
DO NOToperate in close proximity of combustible or flammable materials.
DO NOTattempt to operate this light if cord, plug, battery, lens or any part of the light isdamaged or corroded.
WARNING:
USER SHOULD BE TRAINED IN THE PROPER USE AND MAINTENANCE OF THIS DEVICE. THIS LINE
CORD IS INTENDED TO ALLOW OPERATORS TO EXTEND POWER TO EQUIPMENT WHEN STATIONARY OUTLETS ARE NOT
READILY AVAILABLE.
IMPROPER USE OF THIS CORD, PLUG, AND RECEPTACLE CAN LEAD TO SERIOUS INJURIES OR DEATH TO
PERSONNEL.
PERIODIC INSPECTION OF THE CORD IS NECESSARY.
THE CORD MUST BE ROUTINELY CHECKED FOR CUTS, BREAKS, OR ANY SEVERE ABRASIONS, AND IF ANY ARE FOUND,
THE CORD MUST BE REPLACED BEFORE RESUMING USE.
The HUL-P10WR-DM-ILS-1227 from Larson Electronics is a Dimmable LED Spotlight that is rugged and effective and designed to
provide users with a powerful, durable, and easy to use source of reliable light. This spotlight has a 10 watt LED bulb which produces a
light beam approximately 280' long. This spotlight includes 2.5 feet of 16/2 SOOW straight cord between the spotlight and PWM dimmer
switch, 20 feet of 16/3 cord between the dimmer switch and the transformer, a 120-277 V AC inline waterproof transformer, and 5 feet of
16/3 SOOW cable terminated with a general area cord cap for easy connection to household outlets and equipment power sources.

0
HUL-P10WR-DM-ILS-1227
Larson Electronics, LLC Phone: [phone] Fax: [phone] www.larsonelectronics.com
2of 3
WIRING
Warning: Check product label for correct input voltage!
Attach supply line wires to the appropriate light fixture wires as shown
in thediagram 
Secure each pair of wires according to the diagram. Utilize a junction box or
similar device and take precautionary steps for weatherproofing all
connections if installed in a location where water may come in contact with the
unit. Ensure the unit is properly grounded and that wiring is done according to
all local and national electrical/building codes.
Standard Cord Cap
This unit comes pre-wired from factory with the selected cord cap. Take
precautionary steps for weatherproofing all connections if installed in a
location where water may come in contact with the unit. All outdoor
installations and indoor installations near a wet location require the use of a
GFCI device for safety, according to the National Electrical Code® (NEC).
Ensure the unit is properly grounded.
This low profile industrial LED light fixture is equipped with 2.5 feet of 16/2 straight cord between the spotlight and the on/off
dimmer switch, 20 feet of 16/3 chemical and abrasion resistant SOOW cord between the switch and transformer, and 5 feet
of 16/3 cord extending from the transformer that is fitted with an industrial grade cord cap for easy connection to common
wall outlets. Plug options include standard 5-15 15 amp straight blade plug for 110 V wall outlets with ground, standard
5-20 20 amp straight blade plug for 110 V wall outlets with ground, standard 6-15 15 amp straight blade plug for 220-240 V
wall outlets with ground, standard 6-20 20 amp straight blade plug for 220-240 V wall outlets with ground, NEMA L5-15 15
amp twist lock plug for 125V twist lock outlets, NEMA L5-20 20 amp twist lock plug for 125 V twist lock outlets, NEMA L6-15
15 amp twist lock plug for 240V twist lock outlets, NEMA L6-20 20 amp twist lock plug for 240 V twist lock outlets, British
BS1363 13 amp fused 3-blade plug for United Kingdom outlets, or a two pin 16 amp rated Schuko plug with ground contact
and socket for European outlets up to 250 V. Alternatively, we can provide flying leads with no plug for hard wire
applications or for operators who prefer to wire in user provided cord caps. Please choose pigtail option below for flying
leads with no plug.
Standard pigtail(flying leads) wiring
We strongly encourage a licensed electrician install this product,in all locations especially in outdoor areas
where weatherproofing may be required. Universal voltage driver permits operation at 120V - 277V AC, 50 or 60Hz.
POWER
The HUL-P10WR-DM-ILS-1227 is equipped with both a dimmer switch and an on/off switch. The dimmer is a rotary dial that
can adjust the brightness of the spotlight. Once the desired brightness level is found, operators can leave the dimmer in
position and then use the on/off switch to power the light while retaining the same brightness setting. The on/off switch is of
the toggle variety.
DIMMER
The dimmer included with this unit is a Pulse Width Modulator Controller designed to dim the LED light of the HUL-P10WR-
DM-ILS-1227. Basically, this is a voltage regulator for LED lights drawing 12 amps or less. PWM controllers are CPU
controlled, digital alternatives to resistance based rheostats. This PWM controller has a rotating switch that enables the
operator to control the brightness of the LED light. Thus, many operators will use this as a "dimmer" switch.

0
HUL-P10WR-DM-ILS-1227
Larson Electronics, LLC Phone: [phone] Fax: [phone] www.larsonelectronics.com
3of 3
The light head is mounted to the handle with an adjustable hinge that allows the head to be adjusted vertically. The
five inch tall handle is ergonomically designed to fit the contours of your hand for a comfortable grip.
OPERATION
The LED light is designed to work on either 12 or 24 volts DC depending on the
option selected. Check product nameplate for the correct voltage of your unit.
Use the polycarbonate Handle on base of light for hand-held movement.
Adjust tightness of tilt movement using the tightening bolts on sides of base
hinge.
POWER
1. Connect deutsch connector/cord to light.
2. Run cord and plug into compatible receptacle outputting voltage listed on
product.
3. This light is “instant-on”and will illuminate once plugged in.
4. Attach magnetic base to ferrous metal surface. Clean off magnet prior to applying to painted surfaces.
If spotlight gets loose, tighten adjustment screws on trunnion mount.
If spotlight does not illuminate, check deutsch connector and/or power source.
DETACHABLE CORDS
Cordis attached via a weatherproof 2-pinDeutsch connector.
The cord is detachable by depressing the tab on the top of the connectors. This
enables the operator to leave the cordconnected to the power source and
remove to store the light.
Additional or replacement cords canbe ordered from our website. Contact us
for more information.
Power transformers (DCP-xx-DP series) can be purchased through our website
to run this spotlight from household wall outlets.
Tightening Bolt
QUICK DISCONNECT
DEUTSCH CONNECTOR
MAINTENANCE
There are no serviceable parts inside the fixture. However, it is good practice to routinely clean and check the
fixture for proper function.
•Disconnect power running to the lamp and be sure the fixture is cool to the touch.
•Use a non-abrasive glass cleaning solution to clean the lens.
Note: It is not necessary to open the fixture and clean or touch the LED’s.
USE AND CARE
Unauthorized modification may impair the function and/or safety of this device and could affect the life of the equipment.
Always check for damaged or worn out parts before using the device. Store it in a secure place out of the reach of
children when not in use.Inspect for good working condition prior to storage and before re-use.
REPLACEMENT PARTS
The HUL-P10WR-DM-ILS-1227is designed to provide years of reliable performance. Should the need for replacement
parts arise, please contact Larson Electronics.
THESE INSTRUCTIONS MAY NOT COVER ALL DETAILS OR VARIATIONS OF THIS PRODUCT FOR YOUR EQUIPMENT OR INSTALLATION REQUIREMENTS.
SHOULD FURTHER INFORMATION NOT COVERED BY THESE INSTRUCTIONS BE REQUIRED, PLEASE CONTACT LARSON ELECTRONICS BY EMAIL AT
[e-mail] OR BY PHONE AT 1-800-369-6671 FOR FURTHER ASSISTANCE.
PLEASE VISIT LARSONELECTRONICS.COM FOR WARRANTY AND RETURN INFORMATION.
