EtherFast®Network Attached
Storage (80GB)with PrintServer
•Add 80GB of External Hard Disk Space to Your Network
•Built-in Print Server Allows Addition of a Network Printer
•Internet Attached Storage (IAS)—Remote Users Easily
Retrieve Files Using Web Browser
•Internet Printing Protocol (IPP) Support Allows Remote Users
to Print to GigaDrive’s Network Printer
•Built-in FTP Server Lets You Conveniently Transfer Files
Using Your Favorite FTP Client
•Automatically Adjusts to 10Mbps or 100Mbps Ethernet
Speeds
•Web-based Configuration Accessible from Networked PCs
•Acts as a Stand-Alone DHCP Server for Your Network
•Diverts Traffic From Your Primary File Server to Increase
Network Productivity
•Setup Utility Allows for Speedy Configuration
•Designate Access to Shared Data By Groups
•Small, Compact Footprint Makes Portability Easy
EtherFast®Network Attached Storage
(80GB) with PrintServer
Model Number: EFG80
Easily Add 80GB of Storage and a Print Server to
Your Network!
Features
Features
Benefits
Benefits
NNeettwwoorrkkAAttttaacchheeddSSttoorraaggee
wwiitthhBBuuiilltt--iinnPPrriinnttSSeerrvveerr
• Affordable, easy-to-use 80-gigabyte Network
Attached Storage,print server and Internet FTP
server
• An available second hard drive bay lets you
add up to 120GB more storage when you need
it
• Share music, video, or data files, with man-
aged access by user name or group
• Built-in disk utilities -- backup, self test, scan-
disk, and defrag
Instant GigaDrive™Series
ow you can quickly and easily add eighty gigabytes of storage
space onto your network with the EtherFast®Instant
GigaDrive™fromLinksys. Thisstand-aloneNetworkAttached
Storagedevicefeaturestwoharddrivebays--onewithan80GBdrive
init,andtheother availableso you canaddanadditional up to 120GB
IDE hard drive as your storage needs grow. You can even replace the
original 80GB drive with another 120 for a total of 240GB!
InstallationoftheInstant Gigadriveissimple --justplugitdirectlyinto
your 10/100 network,and it's instantly available. It can serve as your
network'sDHCPserver,andalsohasabuilt-inPrintServersoyoucan
add a network printer without burdening a PC with spooling chores.
TheInstantGigadrivefeaturesbuilt-indiskutilities,accessiblethrough
your web browser. You can run a self test, and scan or defrag the
disk(s). If you've installed a second disk drive, you can back up one
drive to the other,either manually or on a schedule. Additional quick-
connect hard drive trays are available, so you can quickly swap the
backup drive to create rotating backups.
Forevenmoreflexibilityandutility,theInstantGigadrive canbesetup
to be accessible directly from the Internet -- up- or downloading files
either via a web browser,or by FTP. Files can be available publicly,or
create password-protected accounts for your authorized users. You
can even use the Instant Gigadrive as an Internet print server,saving
fax machine phone charges and using the internal hard drive space
to spool and print high-resolution color pages from anywhere in the
world.
The EtherFast Instant GigaDrive is a powerful, flexible and economi-
cal addition to your network.
N

Specifications
Model Number EFG80
Standards IEEE 802.3, IEEE 802.3u
Protocols SMB/CIFS over TCP/IP
Network Port One 10/100 RJ-45 Port
Printer Port One DB-25 Standard Parallel Port
Cabling Type 10BaseT/100BaseTX: UTP CAT 5 or better
Topology Star
LED Indicators Rear:10 and 100Mbps Mode
Front: Ready, Error, LAN, Disk, Disk Full, Back Up
Switches Power, Reset, Uplink
Environmental
Dimensions 7.0" x 6.5" x 13.6"
(W x H x D) (180 mm x 166 mm x 346 mm)
Weight 11.29 lbs without HDD (5.13 kg)
Power 12V DC, Maximum 5 Amps,
100-240V AC,50-60Hz Power Cable Provided
Certifications FCC Class A, CE Mark
Operating Temp. 41°F to 104°F (5°C to 40°C)
Storage Temp. 14°F to 140°F (-10°C to 60°C)
Operating Humidity 10% to 80%, Non-Condensing
Storage Humidity 5% to 90%, Non-Condensing
Package Contents
EtherFast®Instant GigaDrive™
• One EtherFast Instant GigaDrive
• One Power Cable
• One Setup Utility CD-ROM with User Guide
• One Quick Installation and Registration
Card
• Windows 98, 2000, Millennium, and XP
• 200 MHz CPU
• 64MB RAM Recommended
• CD-ROM Drive
• Network Connection
System Requirements
