Linksys OGV200 - Network Optimizer For Gaming User manual

A Division of Cisco Systems, Inc.
®
Wired
User Guide
Model
OGV200
Network Optimizer
for Gaming and VoIP

Network Optimizer for Gaming and VoIP
Copyright and Trademarks
Check the product package and contents for specific features supported. Specifications are subject to change
without notice. Linksys is a registered trademark or trademark of Cisco Systems, Inc. and/or its affiliates in the
U.S. and certain other countries. Copyright © 2006 Cisco Systems, Inc. All rights reserved. Other brands and
product names are trademarks or registered trademarks of their respective holders.
How to Use this User Guide
This User Guide has been designed to make understanding networking with the Network Optimizer for Gaming
and VoIP easier than ever. Look for the following items when reading this User Guide:
In addition to these symbols, there are definitions for technical terms that are presented like this:
word: definition.
Also, each figure (diagram, screenshot, or other image) is provided with a figure number and description,
like this:
Figure 0-1: Sample Figure Description
Figure numbers and descriptions can also be found in the “List of Figures” section.
Warning: This product contains chemicals, including lead, known to the State of California to cause cancer, and
birth defects or other reproductive harm. Wash hands after handling.
This checkmark means there is a note of interest and is something you should pay special attention to while
using the Network Optimizer for Gaming and VoIP.
This exclamation point means there is a caution or warning and is something that could damage your property
or the Network Optimizer for Gaming and VoIP.
This question mark reminds you about something you might need to do while using the Network Optimizer for
Gaming and VoIP.
OGV200-UG-50210NC CB

Network Optimizer for Gaming and VoIP
Table of Contents
List of Figures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Chapter 1: Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
What’s in this Guide? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Chapter 2: Getting to Know the Network Optimizer . . . . . . . . . . . . . . . . . . . . . . 3
LEDs, Ports, and Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Chapter 3: Setting up and Installing the Network Optimizer . . . . . . . . . . . . . 4
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Using the Web-Based Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Appendix A: Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Common Problems and Solutions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Frequently Asked Questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Appendix B: Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Appendix C: Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Appendix D: Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Appendix E: Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Appendix F: Contact Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Network Optimizer for Gaming and VoIP
List of Figures
Figure 3-1: ROUTER port. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Figure 3-2: MODEM port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Figure 3-3: Power port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Figure 3-4: Network Optimizer Login Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Figure 3-5: Web-based Utility Setup Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Figure 3-6: Web-based Utility Administration Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Figure 3-7: Web-based Utility Status Tab. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

1
Chapter 1: Introduction
Welcome
Network Optimizer for Gaming and VoIP
Chapter 1: Introduction
Welcome
Thank you for choosing the Network Optimizer for Gaming and VoIP. The Network Optimizer streamlines your
home network for next-generation Internet applications. By applying various Quality of Service (QoS) techniques
to your network traffic, the Network Optimizer makes sure time-sensitive applications like online gaming and
VoIP calls run smoothly.
The Network Optimizer sits between your home router and broadband cable or DSL modem, and monitors the
data going through. It automatically determines what data is time-sensitive and what isn't, and prioritizes
delivery of that data to its destination, ensuring the best-possible performance for the various types of data that
go through your network.
Traffic prioritization helps make sure that your online games don't lag when someone else on the network is
surfing the web or sending email. Voice over IP phone calls sound cleaner. Outgoing streamed video from your
Internet Video Camera runs smoother.
And the best part is that the Network Optimizer takes care of prioritizing the data automatically, with no user
setup of QoS policies required. After a simple installation it gets right to work, enhancing your network's
performance and helping you get the most out of your high-speed Internet connection.

2
Chapter 1: Introduction
What’s in this Guide?
Network Optimizer for Gaming and VoIP
What’s in this Guide?
This User Guide covers the steps for setting up and using the Network Optimizer.
• Chapter 1: Introduction
Describes the Network Optimizer’s applications and the contents of this User Guide
• Chapter 2: Getting to Know the Network Optimizer
Describes the physical features and explains how to connect the Network Optimizer
• Chapter 3: Setting up and Installing the Network Optimizer
Explains how to install and configure the Network Optimizer
• Appendix A: Troubleshooting
Describes potential problems and solutions regarding installation and use of the Network Optimizer
• Appendix B: Glossary
Gives a brief glossary of terms frequently used in networking
• Appendix C: Regulatory Information
Provides regulatory information for the Network Optimizer
• Appendix D: Specifications
Provides technical specifications for the Network Optimizer
• Appendix E: Warranty Information
Provides Warranty information for the Network Optimizer
• Appendix F: Contact Information
Provides contact information for a variety of Linksys resources, including Technical Support

3
Chapter 2: Getting to Know the Network Optimizer
LEDs, Ports, and Button
Network Optimizer for Gaming and VoIP
Chapter 2: Getting to Know the Network Optimizer
LEDs, Ports, and Button
The Network Optimizer’s LEDs display information about network activity and the MODEM and ROUTER ports
allow you to connect the Network Optimizer to your network. Refer to the table below for LED, port, and button
descriptions:
With these, and many other, Linksys products, your networking options are limitless. Go to the Linksys website at
www.linksys.com for more information about products that work with the Network Optimizer.
LED/Port Name Description
POWER LED The POWER LED remains solid green when the Network Optimizer is receiving power from the
included power adapter.
ACT LED The ACT LED flashes green when the Network Optimizer is sending or receiving data.
MODEM LED The MODEM LED flashes green when the Network Optimizer is connected to a
broadband modem.
ROUTER LED The ROUTER LED flashes green when the Network Optimizer is connected to a network router.
ROUTER port The ROUTER port allows you to connect the Network Optimizer to a network router.
MODEM port The MODEM port allows you to connect the Network Optimizer to a broadband modem.
Power port The Power port allows you to connect the included AC adapter to the Network Optimizer.
Reset button The Reset button allows you to reset the Network Optimizer to its factory default settings.
POWER port
ACT LED
MODEM LED
ROUTER LED
ROUTER port
Reset button MODEM port
POWER LED

4
Chapter 3: Setting up and Installing the Network Optimizer
Overview
Network Optimizer for Gaming and VoIP
Chapter 3: Setting up and Installing the Network Optimizer
Overview
This chapter explains how to set up and install the Network Optimizer. Before you begin, make sure you have an
active Internet Connection, then follow the steps below to install the Network Optimizer.
Installation
1. Remove the Ethernet network cable from your broadband modem and connect it to the Network Optimizer’s
ROUTER port.
2. Connect the included Ethernet network cable to your broadband modem, then connect the other end to the
Network Optimizer’s MODEM port.
3. Connect the included power adapter to the Network Optimizer’s Power port, then connect the other end to a
standard electrical outlet.
When the MODEM and ROUTER lights start flashing, about one minute, the Network Optimizer is ready for use.
Congratulations! Installation is complete.
Figure 3-1: ROUTER port
ROUTER Port
Figure 3-2: MODEM port
MODEM port
Figure 3-3: Power port
Power port

5
Chapter 3: Setting up and Installing the Network Optimizer
Using the Web-Based Utility
Network Optimizer for Gaming and VoIP
Using the Web-Based Utility
Use the Web-based utility to make changes to the Network Optimizer’s settings, update the firmware, change the
administrator password, or check its status. Follow the steps below to access the Web-based utility.
1. On one of your networked computers, open your web browser.
2. Access the Network Optimizer’s Web-based utility by going to http://192.168.188.1.
You see a login screen like this one:
3. Enter admin in the User Name field and the Network Optimizer’s password (the default password is admin)
in the Password field, then click the OK button.
You see the Network Optimizer’s Web-based Utility. Refer to the sections below for more information on the
the options available in the Web-based Utility.
Setup
The Setup tab allows you to change the Network Optimizer’s basic settings. Refer to the table below for a list
of settings available on the Setup tab. When you have finished making changes, click the Apply button to save
your settings.
Setting Description
Rate Detection Allows you to set the upstream data rate of your Internet connection
to Auto or Manual. For the best results, select Auto.
Connection Type Allows you to select Auto-Detect, Cable (DHCP), or DSL (PPPoE) as the
type of Internet connection you’re using. If you’re unsure of the type of
Internet connection you’re using, select Auto-Detect.
ISP Router IP Allows you to specify the network address of your Internet Service
Provider’s (ISP) network router.
Figure 3-4: Network Optimizer Login Screen
Figure 3-5: Web-based Utility Setup Tab

6
Chapter 3: Setting up and Installing the Network Optimizer
Using the Web-Based Utility
Network Optimizer for Gaming and VoIP
Administration
The Administration tab allows you to reboot the Network Optimizer, change the administrator password, upgrade
the firmware, and restore all settings to their factory defaults. Refer to the table below for more information on
the options available on the Administration tab.
Status
The Status tab allows you to view status information about the Network Optimizer and its network connection.
Option Description
Detect Upstream Allows you manually detect your Internet connection’s upstream rate.
Reboot Allows you to remotely reboot the Network Optimizer.
Firmware Upgrade Allows you to upgrade the Network Optimizer’s firmware.
Administrative
Password
Allows you to change the Network Optimizer’s Administrator
password
Restore Factory
Defaults
Allows you to reset all of the Network Optimizer’s settings to their
factory defaults.
Figure 3-6: Web-based Utility Administration Tab
Figure 3-7: Web-based Utility Status Tab

7
Appendix A: Troubleshooting
Common Problems and Solutions
Network Optimizer for Gaming and VoIP
Appendix A: Troubleshooting
Read the descriptions below to solve your problem. If you can't find an answer here, check the Linksys website at www.linksys.com.
Common Problems and Solutions
1. I forgot my password to the Network Optimizer.
Press and hold the Reset button for 10 seconds, then release it to reset the Network Optimizer to its factory default settings.
2. I received an “Upload Failed” message when trying to upgrade the firmware.
Make sure that you downloaded the correct firmware version for the Network Optimizer and that it is complete.
3. I need to set the Network Optimizer to its factory default settings.
Press and hold the Reset button for 10 seconds, then release it to reset the Network Optimizer to its factory default settings.
4. I’m unable to access the Internet.
• Make sure that you give the Network Optimizer about one minute to boot up after plugging it in or resetting it, then try to access the Internet again.
• If you reset your network router, wait one minute after the network router has finished booting up, then try to access the Internet again.
• Check your network cable connections, then wait one minute before trying to access the Internet.
5. There’s a slight lag durring gaming.
Use the Detect Upstream button on the Web-based Utility’s Administration tab to manually detect your Internet connection’s upstream data rate.
6. When I make a voice call the sound is unclear.
Use the Detect Upstream button on the Web-based Utility’s Administration tab to manually detect your Internet connection’s upstream data rate.

8
Appendix A: Troubleshooting
Frequently Asked Questions
Network Optimizer for Gaming and VoIP
Frequently Asked Questions
How do I upgrade the Network Optimizer’s firmware?
You will need to download the latest firmware at www.linksys.com, then follow the steps below:
1. Access the Network Optimizer’s Web-based Utility at http://192.168.188.1.
You see a login screen.
2. Enter admin in the User Name field and the Network Optimizer’s password (the default password is admin) in the Password field, then click the OK button.
3. When you see the Network Optimizer’s Web-based Utility, click the Administration tab.
4. Click the Browse button to locate the firmware you downloaded from the Linksys website, then click the Upgrade button.
How do I test my Internet connection?
• Check your TCP/IP settings.
For Windows 98SE, Me, 2000, and XP, refer to Windows Help for details. Make sure Obtain IP addresses automatically is selected in the settings.
• Open a command prompt and ping your Internet or WAN IP address.
1. Click Start and Run.
2. Type command (Windows 98SE and Me) or cmd (Windows 2000 and XP) in the Open field, then click the OK button.
3. Type ping followed by Internet or WAN’s IP address, in the command prompt, then press the Enter key.
Your Internet IP address can be found on the Status tab of the Network Optimizer’s Web-based Utility. For example, if your Internet or WAN IP address is 1.2.3.4, you would
type ping 1.2.3.4 in the command prompt and press the Enter Key.
4. If you get a reply, the computer is communicating with the Internet or WAN. If you do not get a reply, try to ping your Internet or WAN IP address a different computer to
verify that the original computer is not the cause of the problem.
5. Type ping www.yahoo.com, in the command prompt, then press the Enter key.
6. If you get a reply, the computer is connected to the Internet. If you cannot open a webpage, try the ping command from a different computer to verify that the original
computer is not the cause of the problem. If you do not get a reply, there may be a problem with the connection. Try the ping command from a different computer to verify
that the original computer is not the cause of the problem.

9
Appendix B: Glossary
Network Optimizer for Gaming and VoIP
Appendix B: Glossary
This glossary contains some basic networking terms you may come across when using this product. For more
advanced terms, see the complete Linksys glossary at http://www.linksys.com/glossary.
Bandwidth - The transmission capacity of a given device or network.
Bit - A binary digit.
Boot - To start a device and cause it to start executing instructions.
Broadband - An always-on, fast Internet connection.
Browser - An application program that provides a way to look at and interact with all the information on the
World Wide Web.
Byte - A unit of data that is usually eight bits long
Cable Modem - A device that connects a computer to the cable television network, which in turn connects to the
Internet.
Daisy Chain - A method used to connect devices in a series, one after the other.
DDNS (Dynamic Domain Name System) - Allows the hosting of a website, FTP server, or e-mail server with a
fixed domain name (e.g., www.xyz.com) and a dynamic IP address.
Default Gateway - A device that forwards Internet traffic from your local area network.
DHCP (Dynamic Host Configuration Protocol) - A networking protocol that allows administrators to assign
temporary IP addresses to network computers by “leasing” an IP address to a user for a limited amount of time,
instead of assigning permanent IP addresses.
DMZ (Demilitarized Zone) - Removes the Router's firewall protection from one PC, allowing it to be “seen” from
the Internet.
DNS (Domain Name Server) - The IP address of your ISP's server, which translates the names of websites into
IP addresses.
Domain - A specific name for a network of computers.
Download - To receive a file transmitted over a network.
DSL (Digital Subscriber Line) - An always-on broadband connection over traditional phone lines.
Dynamic IP Address - A temporary IP address assigned by a DHCP server.

10
Appendix B: Glossary
Network Optimizer for Gaming and VoIP
EAP (Extensible Authentication Protocol) - A general authentication protocol used to control network access.
Many specific authentication methods work within this framework.
Encryption - Encoding data transmitted in a network.
Ethernet - IEEE standard network protocol that specifies how data is placed on and retrieved from a common
transmission medium.
Firewall - A set of related programs located at a network gateway server that protects the resources of a
network from users from other networks.
FTP (File Transfer Protocol) - A protocol used to transfer files over a TCP/IP network.
Full Duplex - The ability of a networking device to receive and transmit data simultaneously.
Gateway - A device that interconnects networks with different, incompatible communications protocols.
Half Duplex - Data transmission that can occur in two directions over a single line, but only one direction at
a time.
HTTP (HyperText Transport Protocol) - The communications protocol used to connect to servers on the World
Wide Web.
IP (Internet Protocol) - A protocol used to send data over a network.
IP Address - The address used to identify a computer or device on a network.
IPCONFIG - A Windows 2000 and XP utility that displays the IP address for a particular networking device.
IPSec (Internet Protocol Security) - A VPN protocol used to implement secure exchange of packets at the
IP layer.
ISP (Internet Service Provider) - A company that provides access to the Internet.
LAN - The computers and networking products that make up your local network.
MAC (Media Access Control) Address - The unique address that a manufacturer assigns to each networking
device.
Mbps (MegaBits Per Second) - One million bits per second; a unit of measurement for data transmission.
NAT (Network Address Translation) - NAT technology translates IP addresses of a local area network to a
different IP address for the Internet.
Network - A series of computers or devices connected for the purpose of data sharing, storage, and/or
transmission between users.
Packet - A unit of data sent over a network.

11
Appendix B: Glossary
Network Optimizer for Gaming and VoIP
Ping (Packet INternet Groper) - An Internet utility used to determine whether a particular IP address is online.
POP3 (Post Office Protocol 3) - A standard mail server commonly used on the Internet.
Port - The connection point on a computer or networking device used for plugging in cables or adapters.
Power over Ethernet (PoE) - A technology enabling an Ethernet network cable to deliver both data and power.
PPPoE (Point to Point Protocol over Ethernet) - A type of broadband connection that provides authentication
(username and password) in addition to data transport.
PPTP (Point-to-Point Tunneling Protocol) - A VPN protocol that allows the Point to Point Protocol (PPP) to be
tunneled through an IP network. This protocol is also used as a type of broadband connection in Europe.
RADIUS (Remote Authentication Dial-In User Service) - A protocol that uses an authentication server to
control network access.
RJ-45 (Registered Jack-45) - An Ethernet connector that holds up to eight wires.
Router - A networking device that connects multiple networks together.
Server - Any computer whose function in a network is to provide user access to files, printing, communications,
and other services.
SMTP (Simple Mail Transfer Protocol) - The standard e-mail protocol on the Internet.
SNMP (Simple Network Management Protocol) - A widely used network monitoring and control protocol.
SPI (Stateful Packet Inspection) Firewall - A technology that inspects incoming packets of information before
allowing them to enter the network.
Static IP Address - A fixed address assigned to a computer or device that is connected to a network.
Static Routing - Forwarding data in a network via a fixed path.
Subnet Mask - An address code that determines the size of the network.
Switch - 1. A data switch that connects computing devices to host computers, allowing a large number of
devices to share a limited number of ports. 2. A device for making, breaking, or changing the connections in an
electrical circuit.
TCP (Transmission Control Protocol) - A network protocol for transmitting data that requires
acknowledgement from the recipient of data sent.
TCP/IP (Transmission Control Protocol/Internet Protocol) - A set of instructions PCs use to communicate
over a network.
Telnet - A user command and TCP/IP protocol used for accessing remote PCs.

12
Appendix B: Glossary
Network Optimizer for Gaming and VoIP
TFTP (Trivial File Transfer Protocol) - A version of the TCP/IP FTP protocol that has no directory or password
capability.
Throughput - The amount of data moved successfully from one node to another in a given time period.
Topology - The physical layout of a network.
TX Rate - Transmission Rate.
Upgrade - To replace existing software or firmware with a newer version.
Upload - To transmit a file over a network.
URL (Uniform Resource Locator) - The address of a file located on the Internet.
VPN (Virtual Private Network) - A security measure to protect data as it leaves one network and goes to
another over the Internet.
WAN (Wide Area Network) - The Internet.

13
Appendix C: Regulatory Information
Network Optimizer for Gaming and VoIP
Appendix C: Regulatory Information
FCC Statement
This product has been tested and complies with the specifications for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used according to the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which is found by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment or devices
• Connect the equipment to an outlet other than the receiver's
• Consult a dealer or an experienced radio/TV technician for assistance
Safety Notices
Industry Canada (Canada)
This device complies with Canadian ICES-003 rule.
Cet appareil est conforme à la norme NMB-003 d'Industry Canada.
Caution:
•To reduce the risk of fire, use only No.26 AWG or larger telecommunication line cord.
•To reduce the risk of fire, use only No.26 AWG or larger telecommunication line cord.
•Avoid using this product during an electrical storm. There may be a remote risk of electric shock
from lightning.

14
Appendix C: Regulatory Information
Network Optimizer for Gaming and VoIP
User Information for Consumer Products Covered by EU Directive 2002/96/EC on Waste Electric and Electronic
Equipment (WEEE)
This document contains important information for users with regards to the proper disposal and recycling of
Linksys products. Consumers are required to comply with this notice for all electronic products bearing the
following symbol:

15
Appendix C: Regulatory Information
Network Optimizer for Gaming and VoIP

16
Appendix C: Regulatory Information
Network Optimizer for Gaming and VoIP
