Gigabit 8-Port
Workgroup Switch
he Gigabit 8-Port Workgroup Switch provides non-block-
ing, wire speed switching for your 10, 100, and 1000
megabit network clients. Drop this switch in place of your
current workgroup hub or switch, and you can upgrade your
high-requirement workstations to full Gigabit speeds as neces-
sary, while continuing to service other clients at their current
speeds. Or build your network from the ground up, with appro-
priate link speeds for each user's requirements.
Apply this switching power to your current hub-based Ethernet
network, and your data traffic efficiency will improve several
times over. Connect your Gigabit-equipped workstations to the
Switch's 10/100/1000 ports for full-duplex, dedicated bandwidth
of up to 2000Mbps! It's perfect for graphics, multimedia, and
other applications that have to move large files across the net-
work quickly.
With the Gigabit 8-Port Workgroup Switch, you can connect your
existing 10/100 Ethernet network to your Gigabit server back-
bone without any additional equipment. All ports are auto-nego-
tiating, and have automatic MDI/MDI-X crossover detection, so
you don't have to worry about the cable type. Address learning
and aging is supported, as well as 802.3x flow control with
head-of-line blocking prevention to keep your high-speed clients
from bogging down in lower-speed traffic.
The Gigabit 8-Port Workgroup Switch from Linksys is the perfect
solution for your desktop Gigabit and 10/100 networking needs.
• 8 RJ-45 10/100/1000Mbps auto-sensing half/full duplex
switched ports
• All ports suppport auto MDI/MDI-X cable detection
• Fully compliant with IEEE 802.3, 802.3u, 802.3x, 802.3ab
• Non head-of-line blocking architecture
• Full-duplex IEEE 802.3x flow control and half-duplex back-
pressure with intelligent port-based congestion detection
and broadcast rate control
Gigabit 8-Port Workgroup Switch
Model No.: EG008W
Connects network devices together, managing
the flow of data between them.
Features
Features
Benefits
Benefits
• Eight 10/100/1000Mbps, half/full duplex,
switched ports
• Forwards and filters packets at non-blocking,
full wire speed
• All ports have auto speed negotiation and auto
MDI/MDI-X crossover detection
• Supports address learning and aging, 802.3x
flow control and head-of-line blocking preven-
tion
Instant Gigabit®Series
T

Package ContentsSpecifications
Model Number EG008W
Standards IEEE 802.3, 802.3u, 802.3x, 802.3ab
Ports 8 RJ-45 10/100/1000 Mbps ports
Cabling Type Category 5e Recommended
LEDs Power, Link/Act, Speed, FDX
Environmental
Dimensions 7.32" x 1.89" x 6.06"
(186 mm x 48 mm x 154 mm)
Unit Weight 1.1 lbs. (0.5 kg)
Power External Power Supply 12V DC, 2A. Input
110 V AC Consumption 18W
Certifications FCC Part 15 Class A
Operating Temp. 32ºF to 122ºF (-1ºC to 50ºC)
Storage Temp. -40ºF to 158ºF (-40ºC to 70ºC)
Operating Humidity 20% to 95%, Non-Condensing
Storage Humidity 20% to 95%, Non-Condensing
• One Gigabit 8-Port Workgroup Switch
• One AC Power adapter
• One registration card
• One User Guide
• 200Mhz or Faster Processor
• 64MB RAM Recommended
• Ethernet or Gigabit Network Adapter
• Cat5e Ethernet Network Cable
Minimum Requirements
