Linksys EG008W - Instant Gigabit Workgroup Switch User manual

Model No.
Product Data
EG008W
Eight 10/100/1000Mbps,
half/full duplex, switched
ports
Supports address
learning and aging,
802.3x flow control
and head-of-line
blocking prevention
Forwards and filters
packets at non-
blocking, full wire
speed
All ports have auto
speed negotiation
and auto MDI/MDI-X
crossover detection
The Gigabit 8-Port Workgroup Switch provides non-blocking,
wire speed switching for your 10, 100, and 1000 megabit
network clients. Drop this switch in place of your current
workgroup hub or switch, and you can upgrade your high-
requirement workstations to full Gigabit speeds as
necessary, while continuing to service other clients at their
current speeds. Or build your network from the ground up,
with appropriate link speeds for each user's requirements.
Apply this switching power to your current hub-based
Ethernet network, and your data traffic efficiency will
improve several times over. Connect your Gigabit-
equipped workstations to the Switch's 10/100/1000 ports for
full-duplex, dedicated bandwidth. It's perfect for graphics,
multimedia, and other applications that have to move
large files across the network quickly.
With the Gigabit 8-Port Workgroup Switch, you can connect
your existing 10/100 Ethernet network to your Gigabit server
backbone without any additional equipment. All ports are
auto-negotiating, and have automatic MDI/MDI-X crossover
detection, so you don't have to worry about the cable type.
Address learning and aging is supported, as well as 802.3x
flow control with head-of-line blocking prevention to keep
your high-speed clients from bogging down in lower-speed
traffic.
The Gigabit 8-Port Workgroup Switch from Linksys is the
perfect solution for your desktop Gigabit and 10/100
networking needs.
Wire-speed switching and Linksys reliability
in an 8-Port Gigabit desktop switch
8-Port Workgroup Switch
Gigabit

Product Data
Model No.
Features
• Eight 10/100/1000Mbps,
half/full duplex, switched ports
• Supports half duplex and full
duplex modes and auto-
negotiation for all 10BASE-T/
100BASE-TX/1000BASE-TX ports
• Auto MDI/MDI-X cable
detection for all ports
• Efficient self-learning, address
recognition mechanism,
performs forwarding and
filtering at non-blocking full
wire speed
• Supports Head of Line
blocking prevention
• Supports 8K unicast
addresses
• Provides store-and-forward
forwarding scheme
Linksys
A Division of Cisco Systems, Inc.
18582 Teller Avenue
Irvine, CA 92612 USA
E-mail: [email protected]
[email protected]
Web: http://www.linksys.com
Linksys products are available in more than
50 countries, supported by 12 Linksys Regional
Offices throughout the world. For a complete list of
local Linksys Sales and Technical Support contacts,
visit our Worldwide Web Site at www.linksys.com.
EG008W
Specifications
Model EG008W - Gigabit 8-Port Workgroup Switch
Standards IEEE 802.3, 802.3u, 802.3x, 802.3ab
Ports 8 RJ-45 10/100/1000Mbps ports
Cabling Type Cat5e
LEDs Power, 1-8 Green
Environmental
Dimensions 140 mm x 27 mm x 140 mm
(W x H x D) (5.51" x 1.06" x 5.51")
Unit Weight 10.69 oz. (0.30 kg)
Power Input Input: Voltage Range 110VAC,
Frequency Range 50 – 60Hz, 8W max.
Output: 12VDC, 1A
Certifications FCC, UL, CE, CSA
Operating Temp. 0ºC to 40ºC (32ºF to 104ºF)
Storage Temp. -20ºC to 70ºC (-4ºF to 158ºF)
Operating Humidity 10% to 90% Relative Humidity, Non-Condensing
Storage Humidity 10% to 95% Non-Condensing
Check the product package and contents for specific features supported. Specifications are subject to change without notice. Linksys is a registered trademark or trademark of Cisco Systems, Inc.
and/or its affiliates in the U.S. and certain other countries. Copyright © 2003 Cisco Systems, Inc. All rights reserved. Other brands and product names are trademarks or registered trademarks of their
respective holders.
EG008W_V3-DS-51018NC JL
Package Contents
• Gigabit 8-Port Workgroup Switch
• AC Power Adapter
• CD with User Guide in PDF format
8-Port Workgroup Switch
Gigabit
Minimum Requirements
• 200MHz or Faster Processor
• 128MB RAM Recommended
• Ethernet or Gigabit Network Adapter
• Cat5e Ethernet Network Cable
