BUSINESS SERIES
PRODUCT DATA
Model: SLM2005
5-Port 10/100/1000 Gigabit
Smart Switch with PD and
AC Power
Cost-effective Gigabit switching
with entry-level management for
small business
New Linksys Business Series Smart Gigabit Ethernet Switches deliver cost-effective
switching solutions that are ideal for small businesses or workgroups within larger
organizations. These high-speed switches offer entry-level management without the
cost and complexity of a full Layer 2 managed switch.
The SLM2005 switch is ideal for conference rooms, labs, shipping/receiving
departments or in marketing, design or audio/visual workgroups. The five 10/100/1000
Mbps (Gigabit Ethernet) ports enable companies to link to other Gigabit devices
on the network (servers, workstations and network storage) to quickly move
bandwidth-intensive files while still supporting 10/100 Mbps clients.
The SLM2005 supports the IEEE802.3af standard for Power over Ethernet (PoE) for
obtaining its power over a designated PD port or from an external AC power adapter. This
gives companies the option to install the switch in places where a power outlet may not be
present, such as in ceilings and in walls.
The SLM2005 is able to secure the network through IEEE 802.1Q VLANs and IEEE 802.1X
port authentication. For environments where IP multicast applications are used, the switch is
capable of limiting the traffic to only the ports that have requested that traffic with support
of IGMP Snooping. Additional QoS capabilities like IEEE 802.1p, DSCP, and 4 hardware queues
make it possible to maintain good quality for real-time applications like voice and video.
The SLM2005 offers an easy-to-use browser interface for the management and configuration
of the features, making it ideal for small businesses without an IT staff or that have minimal
technical expertise.
5 Gigabit Ethernet ports
ideal for small workgroups
moving large files
Can obtain power from
a standard 802.3af PoE
switch or from an external
AC power outlet
Entry-level management at
a cost-effective price point
Easy to use Web browser
interface makes installation
quick and easy
SLM2005

PRODUCT DATA
BUSINESS SERIES
Features
5 10/100/1000 Gigabit
Ethernet ports
10 Gbps, non-blocking,
Store-and-Forward
switching capacity
Support IEEE 802.3af PoE-PD
(Powered Device) on port 1
as an optional power supply
Simplified QoS management
using 802.1p and DSCP
traffic prioritization
specifications
WebSmart management
enables configuration and
monitoring from a standard
web browser
802.1Q based VLANs enable
segmentation of networks
for improved performance
and security
Port level security via 802.1X
authentication
Increased the bandwidth
and added link redundancy
with Link Aggregation
Control Protocol (LACP)
Storm control on multicast
and broadcast traffic
Many to one port mirroring
for noninvasive monitoring
of switch traffic
Jumbo frame support (9KB)
Simple interface counters
support
•
•
•
•
•
•
•
•
•
•
•
•
5-Port 10/100/1000 Gigabit Smart Switch with PD
and AC Power
Specifications
Model SLM2005
Ports 5 RJ-45 Connectors for 10BASE-T/100BASE-TX/1000BASE-T
Auto MDI/MDI-X
Autonegotiate/Manual Setting
Buttons Reset
Cabling Type UTP CAT5 or Better for 10BASE-T/100BASE-TX,
UTP CAT5e or Better for 1000BASE-T
LEDs Link/Act, System
PoE
802.3af PoE-PD Compatible on Port 1. Supply System Power Without
an External Power Adapter
Performance
Switching Capacity 10 Gbps, Non-Blocking
Forwarding Rate 7.44 Mpps Wire-Speed Performance
Layer 2
MAC table size 8K
Number of VLANs 16 Active VLANs (4096 Range)
VLAN Port-Based and 802.1Q Tag-Based VLANs
HOL Blocking Head of Line Blocking Prevention
Management
Web User Interface Built-in Web UI for Easy Browser-Based Configuration
Firmware Upgrade Web Browser Upgrade (HTTP)
Port Mirroring Traffic on a Port can be Mirrored to Another Port for Analysis with
a Network Analyzer
Other Management
RADIUS
Port Mirroring
DHCP Client
PING
Security
IEEE 802.1x 802.1x - RADIUS Authentication. MD5 Encryption
Availability
Link Aggregation Link Aggregation using IEEE 802.3ad LACP
Up to 5 Ports in up to 2 Groups
Storm Control Broadcast and Multicast
Spanning Tree IEEE 802.1D Spanning Tree
IGMP Snooping IGMP (v1/v2) Snooping Limits Bandwidth-Intensive Video Traffic to Only
the Requestors. Support 16 Multicast Groups
QoS
Priority levels 4 Hardware Queues
Scheduling Priority Queuing and Weighted Round Robin (WRR)
Class of Service Port-Based
802.1p VLAN Priority Based
IPv4/v6 IP DSCP Based
Standards
802.3 10BASE-T Ethernet, 802.3u 100BASE-TX Fast Ethernet,
802.3ab 1000BASE-T Gigabit Ethernet, 802.3z Gigabit Ethernet,
802.3x Flow Control, 802.3 ad LACP, 802.3af PoE, 802.1D STP,
802.1Q/p VLAN, 802.1X Port Access Authentication

PRODUCT DATA
BUSINESS SERIES
Linksys
A Division of Cisco Systems, Inc.
121 Theory
Irvine, CA 92617 USA
E-mail: [email protected]
[email protected]
Web: www.linksys.com
Linksys products are available in more
than 50 countries, supported by
12 Linksys Regional Offices throughout
the world. For a complete list of local
Linksys Sales and Technical Support
contacts, visit our worldwide website
at www.linksys.com
Check the product package and contents for specific features supported. Specifications are subject to change without notice. Linksys is a registered trademark or
trademark of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2007 Cisco Systems, Inc. All rights reserved. Other brands
and product names are trademarks or registered trademarks of their respective holders.
7050310NC-RR Model: SLM2005
Environmental
Dimensions
W x H x D 5.12" x 1.12" x 5.12" (130 x 28.5 x 130 mm)
Unit Weight 0.84 lb (0.382 kg)
Power External AC Power Adapter, and IEEE 802.3af Compatible PoE-PD
Certification FCC Part15 Class B, CE Class A, UL, cUL, CE mark, CB
Operating Temp. 0 to 40˚C (32 to 104˚F)
Storage Temp. -20 to 70˚C (-4 to 158˚F)
Operating Humidity 10 to 90%
Storage Humidity 10 to 95%
Package Contents
SLM2005 with 5 10/100/1000 Ports
AC Power Adapter with Power Cord
CD with User Guide in PDF Format
Online Registration Card
Minimum Requirements
Web-Based Utility: Web Browser–Microsoft Internet Explorer (Version 6.0 or Above), Firefox (Version 2.0.0.1
or Above)
CAT5 Ethernet Network Cable
Switch/Router with Power Over Ethernet (PoE) Support Or PoE Injector when used with PoE
Operating System: Windows®, XP or Above
Warranty
5 Years
•
•
•
•
•
•
•
•
•
