Linn Aqua-Handy User manual

Water Aerator
Operating Instructions
(Translation of the operating instructions)
“Aqua-Handy”
This user information should be read and observed before installation and use of the
apparatus supplied.
Should your chosen aerator require assembly before operation, please read carefully the
separate assembly information enclosed. These guidelines should be read and followed
first.
The aeration apparatus has been manufactured to circulate and ventilate water. Any other
use is absolutely prohibited.
Before operation, examination by a qualified technician should take place to ensure that
necessary electrical precautions are available. An electrical fault switch (FI) with a nominal
current of up to 30mA is stipulated. The voltage displayed on the label of the apparatus
must agree with that of the mains voltage. Standard models are delivered completely
sealed and ready for use. All apparatus are equipped with a motor (overheating) protector
(either by a motor protection device attached to the cable end or by a heat sensor inside the
motor itself). If you have received apparatus without motor protection or with a free cable
end, then a qualified technician should install the motor protector and/or attachment before
operation.
Before connecting the aerator to the mains, please ensure that no one remains in the water.
Working on the aerator while in the water (in particular, swimming to the apparatus or
clambering onto the aerator) is strictly prohibited on the grounds of safety. Warning!
Injury risk. For small pools/ponds, touching of the apparatus while in operation is prohibited
The water/waste aerator can now be connected to the mains. Warning –Please ensure that
the plug connection is dry.
Maintenance
All water aerators supplied require little or no maintenance. From time to time simply clean
all parts of the apparatus. To do this you must remove the apparatus from the water.
Warning –first disconnect from the mains!
If the apparatus is supplied with a screen, this, in particular, should be kept clean, for perfect
functioning of the apparatus can only be assured if the surface of the screen is clean.
At least once a year, the apparatus should be examined for perfect running of the propeller
and, in the case of submersible motors, for the condition of the motor’s watertight flanges. If
you experience any problems, please contact us.
Guarantee
This apparatus carries a 12-month guarantee of proper use. A change to the apparatus or
opening of the motor parts is prohibited and renders the guarantee invalid. We can accept
no liability for damage and losses incurred as a result of breakdown of the aerator. The
operator is advised to obtain protection (an alarm system), which would alert them to any
eventual breakdown of the apparatus.
Further Information
We would advise you that, in accordance with product liability law, we do not accept liability
for damage caused by our apparatus, if the information and advice given within these
operating instructions has not been followed.
The aerator should never be pulled, carried or fixed into place, by the connection cable.
Only suitably qualified persons should carry out replacement of the connection cable. The
connection lead should be no lighter than a rubber hose HO7 RN-F (EN 60335-2-41). Avoid
wear and tear on the connection cable!
The electric lead should be kept in an area where there is no risk of flooding and should be
protected from damp. Connection cable and plug should be examined for damage before
use.
The aerator should not be operated out of water! In the event of aerator defects, repairs
should be carried out only by the manufacturer or by an authorised dealer. In addition, only
original spare parts should be used.
The aerator is fitted with a rubber over-current device, designed to protect the motor from
overload. It is fitted next to the round site plug, and has a reset button. It is not weatherproof,
and should be protected from rain and direct sunlight. If the overcurrent device trips out the
power to the aerator, investigate the cause promptly. Repeated pushing of the reset button,
may damage the motor. Consult your supplier about servicing the motor. Removal of the
overcurrent device will invalidate the warranty.

Aqua-Handy“
(Translation of the operating instructions)
You receive a water-circulation-pump completely ready installed for operaration. Please pay
attantion to following instructions and we guarantee a secure application in your waters.
Electric connection
Condition for a regular operation of water-circulation-pump is an electrical connection
according to VDE. The ELCB is absolutely stipulated. Repair works electrical connection or
at motor the manufacturer or an electrican expert carries out.
Starting operation
a) We supply the water-circulation-pump completely ready for application with robust
rubber-cable H07.
b) For installation use the stainless steel holder at the machine. Please fasten the
aerator so, that is hanging about 40 –50 cm below downwards. Please pay
attention to cushion the back-pressure, caused by water-circulation.
c) It is possible to reduce or completely seal the tube if no air in yet of water is
wanted. This will cause no damages at motor.
d) Please absolutely prevent connection cable against eventual damages, otherwise
water can run through the cable into the submersible motor.
Maintenance
The water-circulation-pump “Aqua-Handy” works almost free of maintenance. You only
have to clean the input-screen and appliance now and then. Besides please check at least
once a year the perfect running of axial-paddle-wheel.For this device we give 1 year’ s
guarantee, correct application provided.
EG-Konformitätserklärung
im Sinne der EG-Maschinenrichtlinie
2006/42/EG, Anhang IIA
EG –Declaration of Comformity
In accordance with Machine Guidelines
2006/42/EG, Appendix IIA
Der Hersteller
The manufacturer
LINN Gerätebau GmbH
An der Sauerlandkaserne 1 –D - 57368 Lennestadt - Oedingen
erklärt hiermit, dass die folgenden Wasserbelüfter
state herewith, that the water aerator models:
Aqua-Handy
in Ihrer Konzipierung und Bauart sowie in der von uns in Verkehr gebrachten
Ausführung den Bestimmungen der oben genannten Richtlinie entsprechen.
Die Konformitätserklärung erlischt bei nicht verwendungsgemäßer Benutzung
sowie bei konstruktiver Veränderung, die nicht von uns als Hersteller schriftlich
bestätigt wurde.
Bevollmächtigter der LINN Gerätebau GmbH für die Zusammenstellung aller
technischen Unterlagen: Ulrich Bischopink, Prokurist –Adresse wie oben
on account of their design, construction and circulation by us, to
above mentioned guidelines. In the event of a change being made to these
apparatus, without our consent, this declaration will be rendered invalid.
Lennestadt, 05.02.2014 Linn Gerätebau GmbH
gez. Ulrich Bischopink –Prokurist
LINN Gerätebau GmbH
An der Sauerlandkaserne 1 D-57368 Lennestadt –Oedingen
Tel. [phone] Fax. [phone]
www.linn.eu - [email protected]
