LinTronic RELAY 208 User manual

http://lintronic.dk
LINTRONIC RELAY 208
RELAY 208
LinTronic
Updated: 130622

http://www.lintronic.dk
LINTRONIC RELAY 208
LinTronic Relay 208 has been carefully designed
to control curtains, blinders, screens, lifts, motors, etc.
Curtains control
IMPORTANT
If you are controlling ac-motors, make sure you always select "mode 01-32".
Mode 01-32 has automatic protection against UP and DOWN beeing active
at the same time, which will destroy the motor.
If you are controlling dc-motors, optionally select mode 01-32 or 01-64.

http://www.lintronic.dk
LINTRONIC RELAY 208
6 5 4 3 2 1
12 volt power supply
RELAY 208
12 volt 0
volt
220 vac
Switch / relay controlled curtains
Typically powered by 12 volt
C A R C A R
UP DOWN

http://www.lintronic.dk
LINTRONIC RELAY 208
Switch / relay controlled curtains
Powered by 220 volt
4 3 2 1
Connector for 220 volt
Connector for IR receiver
IR receiver can be removed
or left working in parallel with
the Relay 208, using the
original remote control.
1 = 15 volt output, do not use
2 = Ground
3 = Open
4 = Close
RELAY 208
C A R C A R
UP DOWN

http://www.lintronic.dk
LINTRONIC RELAY 208
1 2 3
C A R C A R C A R C A R
C A R C A R C A R C A R
1 2 3 4
5 6 7 8
GND 12V G B A 2 1
COM1 COM2
Relays (controlling motors)
CURTAIN 1
CURTAIN 2
CURTAIN 3
CURTAIN 4
Up
Down
Up
Down
Up
Down
Up
Down
Suggested mode: 1-32, Up/Down

http://www.lintronic.dk
LINTRONIC RELAY 208
MOTOR
12 - 48 volt dc
Up
Down
Relays (controlling motors)
Motors powered by 12 - 48 volt dc
Suggested mode: 1-32, Up/Down
1 2 3
C A R C A R C A R C A R
C A R C A R C A R C A R
1 2 3 4
5 6 7 8
GND 12V G B A 2 1
COM1 COM2

http://www.lintronic.dk
LINTRONIC RELAY 208
SOMFY REMOTE CONTROLLED CURTAINS
MOTOR
12 or 24 volt
If curtains are not already installed, then save the RF receiver
and the remote control and control curtains motors directly as
normal 12 or 24 volts motors.
POWER
If curtains are already installed … see next page.
Plus
Minus
230 vac
C A R C A R

http://www.lintronic.dk
LINTRONIC RELAY 208
MOTOR RF RECEIVER 230 vac
POWER
SOMFY REMOTE CONTROLLED CURTAINS
12 or 24 volt
If you want both SOMFY control as well as B&O control and/or
computer control, use the below wiring.
Plus
Minus
C A R C A R

http://www.lintronic.dk
LINTRONIC RELAY 208
RADIO
LIGHT
TV
CD
DVD
SAT
ATAPE
VTAPE
RECORD
9
8
7
6
5
4
3
2
1
MENU
0
TEXT
GO
EXIT
LIST
STOP
>
>
BANG & OL
UFSEN
>
>
>>
>>
Open the RF remote and connect/solder
the relays directly to the buttons.
This solution will work
on any kind of RF remote control
RF CONTROLLED CURTAINS
1 2 3
C A R C A R C A R C A R
C A R C A R C A R C A R
1 2 3 4
5 6 7 8
GND 12V G B A 2 1
COM1 COM2

http://www.lintronic.dk
LINTRONIC RELAY 208
Open the RF remote and connect/solder
the relays directly to the buttons.
This solution will work
on any kind of RF remote control
RF CONTROLLED FIREPLACE
1 2 3
C A R C A R C A R C A R
C A R C A R C A R C A R
1 2 3 4
5 6 7 8
GND 12V G B A 2 1
COM1 COM2
UP
DOWNOFF

http://www.lintronic.dk
LINTRONIC RELAY 208
MOTOR
115 - 230 vac (fused)
Relays (controlling motors)
Suggested mode: 1-32, Up/Down
Controlling 115 - 230 vac
Up
Down
1 2 3
C A R C A R C A R C A R
C A R C A R C A R C A R
1 2 3 4
5 6 7 8
GND 12V G B A 2 1
COM1 COM2

http://www.lintronic.dk
LINTRONIC RELAY 208
115 - 230 vac (fused)
Relays (controlling all type of lamps)
Controlling 115 - 230 vac
Suggested mode: 1-64, On/Off
1 2 3
C A R C A R C A R C A R
C A R C A R C A R C A R
1 2 3 4
5 6 7 8
GND 12V G B A 2 1
COM1 COM2
