LIPOWER G2000 User manual

Portable Solar Generator Power Station EN
Model:G2000
User Manual
Attention:
This portable power station ACoutput range between of 100V~120V or
220V~240V 50/60Hz,actual product specification, actual AC outlets will be
different according to different countries, areas or customers. Please refer to
the actual products before you buy this product.
1

Handle
AC ON/OFF
USB ON/OFF
AC output
DC charge input
PV input USB output
Type-c output
Cigar output
DC output
DC ON/OFF
LCD Display
POWER ON/OFF
Thanks for purchasing our portable solar generator power station. Please
read this manual carefully before use and keep it for review.
This manual helps you to operate this device correctly. But it is not the
introduction of the software and hardware configuration. To know the configu-
ration of the product, please refer to the related contract or consult with your
distributor. The images in this manual are for reference only.
Thank you!
Product Description
2

Specifications
Model G2000
Battery Capacity 3.7V 600000mAh 2220Wh
Rated Power 2000W, Peak 4000W
Battery Type High Quality Lithium Ion Batteries
Adaptor CC/CV 25.5V/8A
AC Output 100V~120V or 220V~240V 50/60Hz
USB Output 5V/2.4A
QC 3.0 Output 5V/3A, 9V/2A,12V/1.5A
DC Output 12V±1V /8A
Type C Output PD 60W: 5V/3A, 9V/3A, 12V/3A,15V/3A, 20V/3A
Solar Charge Input
Output Waveform
Gross Weight
Product Size
Operation Temperature
18V~30V 8A max,200W max
Car Charge Input 12V/24V 8A max,200W max
Pure Sine Wave
About 21.5KG
L320*W230*H330mm
-10°C14°F~60°C140°F
Protection Circuit
Short Circuit Protection
Over Current Protection
Over Power Protection
Over Discharge Protection
Over Charge Protection
Over Temperature Protection
Package Included
1 x Portable Power Station
1 x AC Adaptor
1 x Car Charger
1 x Power Cable
1 x User Manual
3

LCD Display
AC output voltage and frequency will be different according to
different countries or areas. Please refer to the actual product
before using.
①②③④⑤
⑥ ⑦ ⑧
①It will light up when AC ports start work.
②It will light up when USB ports start work.
③It will light up when Type-c ports start work.
④It will light up when DC ports start work.
⑤It will light up when the power station temperature over 40℃
(104℉)or AC output over 600W,the fan start working to cool down.
⑥It will light up when the power station temperature over 60℃(140℉) or
below -10℃14℉,please turn off the AC output.
⑦It will light up when the power station is faulty and show the
corresponding error code.
⑧It will lights up when Circuit Frequency is switched manually.
ATTENTION
4

Error Code & Troubleshooting
Explain:The output will be cut off when the battery temperature is over
-10℃（14℉
Battery low temperature protection when discharging
Battery over temperature protection when charging
Battery low temperature protection when charging
Charge input over voltage protection
Battery over voltage protection
Battery low voltage protection
Explain: There is potentially a short circuit inside your device or the power station.
Troubleshooting:Please plug out the devices firstly ,press the button to recover
the function.
Explain:The output will be cut off when the battery temperature is over 60℃
140℉
Troubleshooting:Press the AC button 3s to eliminate it.let the power station
stay for a period of time until temperature down.
Explain:the loading power of the electrical applications over 2000W.
Troubleshooting:Press the AC button 3s to recover the function.choose our
models >2000W to fit your devices.
Explain:The inverter will automatically cut off the output if the temperature
over 80℃176℉
USB short circuit or overload protection
Battery over temperature protection when discharging.
QC3.0 short circuit or overload protection
DC short circuit or overload protection
AC short circuit protection
AC overload protection
AC inverter over temperature protection
5

1.Power Button:Press 3s could turn off all output.
Pressing any one of the buttons 1s could wake up the
display,the display will automatically turn off after detecting
no output for 20s.
2.AC outputPress 2s to turn on/off the inverter
—— When the AC output power is lower than 5W for up to 3 hours, the AC
will automatically turn off to save energy.
SmartPhone,Digital camera,Tablet,Etc.
How to use your portable power station?
6
According to the power station you currently have,Limited Device
Wattage<2000W, Laptop, Fan,TV,CPAP etc. AC will shutdown
when it’s short circuited or power overloaded. Remove the device
to recover from short circuit or overpower protection.

Support DC12V Devices,such as Vacuum Cleaner,
Inflation Pump,Electric wrench, car fridge, etc.
3.USB outputPress 1s to turn on/off .
—— When the USB output power < 1W for up to 1 hour, the USB ports will
automatically turn off to save energy.
4.DC outputPress 1s to turn on/off .
—— When the DC output power < 2W for up to 1 hour, the DC ports will
automatically turn off to save energy.
Circuit Frequency Change:
Turn on AC output,click AC button 5 times constantly in 3s to change
the frequency.
7

Place your solar panel where it will get as much direct sunlight as
possible.
Plug the output of the solar panel(DC 5.5*2.1mm or PV) into the
input of the unit to start charging. connect with the DC input
interface or of this product,you’ll know the unit is charging
when the battery icon light up, When the product is full of power,
thebattery icon will fully light.
Please connect our original adaptor to the household AC socket,
connect the DC plugof standard charging adapter with the DC
input interface of this product, you’ll know the unit is charging
when the battery icon light up, the light will twinkle, at the same
time , When the product is full of power, the battery icon will fully
light, After the power station is fully charged, please remove the
charger in time.
2.Charge by Solar Panel
1.Charge by AC adaptor
■
▲Charging this unit with
AC adapter
■
■
How to charge the Portable Power Station?
8

1)This product is built in high quality original lithium ion battery, it
has no memory effect but high-capacity, and it is durable. However,
we still recommend you to apply in the range of 10℃~30℃ , so as to
obtain the optimal charging capacity.
2)When charging, in order to avoid interference, please stay away
from TV, radio and other equipment.
3)If the device has not been used for a long time, please disconnect
the cable and store.
4)Some portable devices may need to be set in charge mode to
charge, see thecorre-sponding equipment use manual for more
information.
5)After starting, if there is no any output, it displays to automatically
shut down within 20 seconds, so as to achieve better energy-saving
effect.
Product Application Skills
9

Avoid extreme
temperatures
Avoid dropping
Don’t disassemble
To preserve lifespan
recharge every 3 months
Don’t expose
to liquids
Use original
or certified cables
1) To avoid short-circuiting, keep the unit away from all metal objects (e.g.
coins, hair -pins, keys, etc).
2) Do not heat the unit, or dispose of it in fire, water or other liquids. Keep away
from high temperatures. Do not expose the unit to direct sunlight.
3) This appliance is not intended for use by persons (including children) with
reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
4) Children should be supervised to ensure that they do not play with the
appliance.
5) The unit may become hot when charging, this is normal. Do not cover the
device with towels, clothing and other item.
6) Please deal with scrap products in accordance with the regulations, do not
treatment the built-in battery as a household garbage, so as not to cause the
explosion and pollution.
7) The product is only used for emergency power station, it can not replace the
standard DC or AC power of household appliances or digital products.
8) Your device has and intemal, non-removable, rechargeable battery. Do not
attempt to remove the battery, as you may damage the device.
Attention
10
