Lisle 76000 User manual

OIL FILTER CRUSHER
76000
★ Best Value
★ Fast Cycle Time
★ Operates With Shop Air
★ One Year Limited Warranty
★ Safe, Simple Operation
★ Removes up to 95% of Free Flowing Oil
CONVERTS OIL FILTERS INTO SCRAP, AND OIL
INTO A RECYCLABLE PRODUCT IN SECONDS.
Patent 5,297,479

FEATURES:
CYCLE TIME: 25 to 30 seconds, depending on air pressure used and filter size.
FILTER RANGE: Up to 5’’ diameter and up to 7 3/4’’ in height.
CRUSHING PRESSURE:
ACCESSORY: AUTOMATIC VALVE RETROFIT KIT,
Part #76520. With this kit you can convert from
manual to automatic operation. Allows operator to
push start button and crush filter without holding the
button down. (See Figure A).
SAFETY: Operates only when door is shut on
containment area.
DIMENSIONS: 25’’ long, 14’’ wide and 14’’ deep.
SHIPPING WEIGHT: 64 lbs., will ship by UPS.
MAINTENANCE:
• Periodic maintenance of filter, regulator and lubricator on your air supply will prolong
the life of your filter crusher.
• Periodically check for leakage. If leakage occurs, locate source of leak. Order 76310
Cyclinder Seal Replacement Set to repair any cylinder leak. Order 76300 Valve Repair Kit,
if only valve seals need replacing.
• Periodically clean enclosure area of debris. First, disconnect air supply and remove air
fitting. Next remove two exhaust silencers and the six 3/8’’ hex head screws that attach
to casting. Now enclosure can be cleaned of debris.
*WARNING: Do Not exceed 150
psi input air pressure.
Input Air
Pressure
Crushing
Pressure
*150 psi 16,950 lbs.
140 psi 15,820 lbs.
130 psi 14,690 lbs.
120 psi 13,560 lbs.
110 psi 12,430 lbs.
100 psi 11,300 lbs.
90 psi 10,170 lbs.
Figure A
MANUFACTURER’S LIMITED WARRANTY:
What is covered: This warranty covers any defects in material or worksmanship of your Filter Crusher.
How Long Coverage Lasts: This Warranty, runs for one year from the date of original purchase by the purchaser, provided the Filter Crusher is still
owned by the first purchaser. Further, all implied warranties are limited to the duration of this limited warranty. Some states do not allow limitations on how
long an implied warranty lasts, so the above limitation may not apply to you.
What is Not Covered: This warranty does not cover damage to the Filter Crusher caused by the use of excessive air pressure (over 150 psi) or by impurities
from the air line. Further, this warranty does not cover any problem that is caused by abuse, misuse, neglect, improper operation or act of God (such as a
flood). The manufacturer
consequential damages, so the above limitation or exclusion may not apply to you.
What the Manufacturer Will Do: The manufacturer will repair or replace, free of charge, any part of your Filter Crusher that proves to be defective in
materials or workmanship.
How to Get Service: If something goes wrong with your Filter Crusher, send it UPS Prepaid along with a receipt or other proof of purchase date and a brief
description of the problem to: Filter Crusher Warranty, 807 E. Main St., Clarinda, IA 51632, Phone [phone]
How State Law Relates to this Warranty: This warranty gives you specific legal rights, and you may also have other rights which very from state to state.
BEFORE AND AFTER

INSTRUCTIONS:
BACK VIEW
Mounting Instructions:
Mount Filter Crusher with three
3/8’’ diameterbolts, see (X).
See mounting diagram above
for dimensions. Make sure the
unit is securely mounted to a
sturdy location.
Figure 1
1. Attach air line to 1/4’’ NPT
air inlet. Warning: Do not
exceed 150 psi maximum air
pressure. It is recommended
that a fi lter, regulator, and
lubricator be attached to your
air supply. A hose fi tting is
provided if you want to run
the waste oil to an oil drum or
other receptacle. (See Figure 1).
Figure 3 Figure 4 Figure 5
4. After cycle is completed
door can be opened and fi lter
removed. Make sure fi lter
gasket and any debris are
removed with crushed fi lter.
3. Press button to crush fi lter. When ram movement stops, crushing is
complete and button can be released.
Note: Button must be pushed in during entire crushing cycle. If button
is released the ram will return to bottom position. (See fi gures 3 and 4).
Order 76520 Automatic Valve Retrofi t Kit for automatic crushing
operation. Installation of timer allows fi lter crushing without holding
button down. See page 2 for accessory information.
X
X
X
Figure 2
2. Open the door to place
fi lter over center post. Insert
fi lter, close door and now you
are ready to crush the fi lter. (See
Figure 2).
Note: Filter cannot be crushed
until door is shut. Also, door
will not open until ram has
returned to original position.

PARTS LIST:
LISLE CORPORATION, CLARINDA, IOWA 51632 712/542-5101 FAX: [phone] www.lislecorp.com
© 2005 Lisle Corporation Form #76/95 900220.86 Printed in U.S.A.
WARNING: Wear eye protection when in operation.
Oil filter crusher is designed for crushing oil filters only. Not liable for improper use.
