Listen LA-490 User manual
2
Dear Valued Customer,
Thank you for choosing Listen! We are dedicated to providing you with the
highest quality products available and take pride in delivering outstanding
performance to ensure you are completely satisfied. We independently
certify each of our products to the highest quality standards and back
them with a limited lifetime guarantee. We are available to answer any
questions you might have during installation or in the operation of our
products. At Listen, it’s all about you, should you have any comments or
suggestions we’re here to listen.
Here’s how to reach us:
+1.801.233.8992 +1.800.330.0891 North America
+1.801.233.8995 fax support@listentech.com www.listentech.com
Thank you and enjoy your listening experience!
Best regards,
Russell Gentner and the Listen Team
3
Table Of Contents
Table Of Contents.............................................................................................................................................3
Introduction.......................................................................................................................................................4
Important Information ....................................................................................................................................5
Important Safety Instructions........................................................................................................................6
LA-490 Beacon Quick Reference ..................................................................................................................7
Unpackage .........................................................................................................................................................7
Installation..........................................................................................................................................................8
Basic Operation ................................................................................................................................................8
Setup/Configuration.........................................................................................................................................8
Compliance Information .................................................................................................................................9
Warranty.......................................................................................................................................................... 12
Contact information...................................................................................................................................... 13
4
Introduction
The LA-490 Listen Bluetooth/IR Beacon (the ‘Beacon’) is a small, battery-powered or
USB powered device that transmits a Bluetooth™ low-energy (BLE) and/or Infrared (IR)
signal that can be detected by other devices (e.g., receivers, smartphones or other
devices capable of receiving the signal) to trigger audio or events by the receiving
device in a variety of applications. This includes applications such as Training and
Collaboration, Assistive Listening, Guided Tour Groups, Language
Interpretation/Translation, Event Production and Intercom.
The Beacon works by periodically waking up, transmitting this signal via short-range
radio (BLE and/or IR) and then returning to a low-power state. The Beacon has no user
interface (UI), cellular or GPS capabilities. The Beacon’s identity is encoded within the
signal it transmits and includes a sub-segment device type.
This product can be used for residential or commercial purposes. It is considered
improper use when used for any application not named above. Listen Technologies
does not accept liability for damage arising from improper use or misuse of this
product and its attachments/accessories. Before putting the products into operation,
please observe the respective country-specific regulations.
5
Important Information
Read the following Information before you use your Listen LA-490 Beacon.
This device is a proximity Beacon operating in the 2.4 GHz frequency band from 2.400
GHz to 2.482 GHz at a maximum power of -1.5 dBm. The usage of this device is
generally allowed in the United States, Canada, all EU countries, Australia, New
Zealand, Singapore, and Hong Kong. Product labeling information such as serial
number, manufacturer, and additional regulatory information is found on the product
label on the back of the device or in the battery compartment. To view, remove device
from the mounting bracket.
Recycling
Help Listen Technologies protect the environment! Please take the time to dispose of
your equipment properly.
Product Recycling Instructions
Please do NOT dispose of your Listen Technologies
equipment in the household trash. Please take the
equipment to an electronics recycling center; OR,
return the product to the factory for proper disposal.
Battery Recycling Instructions
Please do NOT dispose of batteries in the household
trash. Please take the batteries to a retail or
community collection point for recycling.
6
Important Safety Instructions
Read the following Information before you use your Listen LA-490 Beacon.
Important Safety Instructions
Caution
1. Read safety instructions and the instruction manual of the product.
2. Keep safety instructions and the instruction manual of the product. Always include
all instructions when passing the product on to third parties.
3. Heed all warnings and follow all instructions.
4. Do not expose to direct sunlight for long periods of time.
5. Do not store near heat sources such as radiators, heat registers, stoves, or other
apparatus that produce heat.
6. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, when the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.
Safety Instructions for Alkaline Batteries
Warning
This product uses (2) AA Alkaline Batteries.
Always take care to insert batteries correctly according to the designation of polarity
(⊕and ⊖) on the batteries and the equipment.
Do not short-circuit batteries.
Do not charge batteries.
Discard and replace any leaking batteries.
Exhausted batteries should be immediately removed from the equipment and
disposed of properly.
Do not dispose of batteries in fire.
Keep batteries out of the reach of children.
7
LA-490 Beacon Quick Reference
1. Status LED: Flashes blue under normal operation, flashes red when batteries need
to be replaced. Alternates between flashing red and amber when in programming
mode.
2. USB Power/Programming Connector: Powers the device via a USB power supply or
allows programing while connected to a PC.
3. Battery Access: Powers the device with 2 AA Alkaline batteries.
4. Cable Trough: Route and retain power supply cable.
5. Mounting Holes: Allows mounting to wall or standard electrical box.
6. Retaining Tab: Retains the Beacon in the mounting bracket.
7. Cable Access: Allows cable access from the electrical box through the mounting
bracket.
8. Locking Screw: Locks Beacon into the mounting bracket to resist tampering.
Unpackage
Unpack all contents from the box:
(Qty 1) LA-490 Bluetooth/IR Beacon
(Qty 2) AA Alkaline Batteries
(Qty 1) Optional USB Power Supply
(Qty 1) Mounting Hardware
(Qty 1) Quick Start Guide
8
Installation
1. Choose a mounting location with an unobstructed line of sight view of the desired
trigger area.
2. Attach the mounting bracket using the provided hardware/mounting holes or use
other mounting alternatives.
3. Insert 2 AA Alkaline batteries or power the device with the optional USB power
supply.
4. Insert LA-490 Beacon into the mounting bracket and secure the device with the
locking screw.
Basic Operation
1. Beacon is turned ON and OFF when batteries are inserted/removed, or power is
provided or removed via a USB power supply.
2. Status LED flashes blue approximately once a second indicating the Beacon has
good batteries and is transmitting Beacon information.
3. Status LED flashes red indicating batteries are low and need to be changed.
4. Status LED flashes alternately between red and amber while Beacon is being
programmed.
Setup/Configuration
Download the Listen EVERYWHERE (LE) Software Suite for Windows, available at
www.listentech.com/support/software/, to setup and configure your Beacon(s).
Transmission Mode: Bluetooth (default), IR or Both
Transmit Interval: 500 mS (default), range 100 mS –5 seconds
Output Power: High (default), Medium or Low
Normal battery Status LED: ON (default) or OFF
Low battery Status LED: ON (default) or OFF
9
Compliance Information
For Users in the US and Canada
Compliance Notice
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) These devices may not cause harmful interference, and (2)
these devices must accept any interference received, including interference that may
cause undesirable operation.
FCC Statement
This equipment has been tested and found to comply with the limits for a class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. End users must follow the specific operating instructions
for satisfying RF exposure compliance. This transmitter must be at least 20 cm from
the user and must not be co-located or operating in conjunction with any other
antenna or transmitter.
10
The information in this guide may change without notice. The manufacturer assumes
no responsibility for any errors that may appear in this guide.
Changes or modification to this device not expressly approved by Listen Technologies
for compliance could void the user's authority to operate this device.
Industry Canada Statement
CAN ICES-3 (B)/NMB-3 (B)
This device contains licence-exempt transmitter(s)/receiver(s) that comply with
Innovation, Science and Economic Development Canada’s licence-exempt RSS(s).
Operation is subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference, including interference that may cause
undesired operation of the device.
Cet appareil contient des émetteurs/récepteurs exempts de licence qui sont
conformes aux RSS exemptés de licence d'Innovation, Sciences et Développement
économique Canada. L'exploitation est soumise aux deux conditions suivantes:
1. Cet appareil ne doit pas provoquer d'interférences.
2. Cet appareil doit accepter toute interférence, y compris les interférences
susceptibles de provoquer un fonctionnement indésirable de l'appareil.
ISED
Radiation Exposure Statement: This equipment complies with the IC RSS-102 radiation
exposure limits set forth for an uncontrolled environment. This equipment should be
installed and operated with a minimum distance of 20 cm between the radiator and
your body.
Énoncé d'exposition aux rayonnements: Cet équipement est conforme aux limites
d'exposition aux rayonnements ioniques RSS-102 Pour un environnement incontrôlé.
Cet équipement doit être installé et utilisé avec un Distance minimale de 20 cm entre
le radiateur et votre corps.
11
For Users in the European Union
This device is a proximity Beacon operating in the 2.4 GHz frequency band from 2.400
GHz to 2.482 GHz at a maximum power of 2.5 dBm. The usage of this device is
generally allowed in all EU countries, Australia, New Zealand, Singapore, and Hong
Kong. Product labeling information such as serial number, manufacturer, and
additional regulatory information is found on the product label on the back of the
device or in the battery compartment. To view, remove device from the mounting
bracket.
In compliance with the following requirements
WEEE Directive (2012/19/EU)
Battery Directive (2006/66/EC & 2013/56/EU)
If you wish to discard electrical and electronic equipment (EEE), please contact your
dealer or supplier for further information.
Notes on Disposal
The symbol of the crossed-out wheeled bin on the product, the batteries and/or the
packaging indicates that these products must be disposed of separately at the end of
their operational lifetime in accordance with the national legislation. For packaging
disposal, please observe the legal regulations on waste segregation applicable in your
country.
The separate collection of waste electrical and electronic equipment, batteries and
packaging’s is used to promote the reuse and recycling and to prevent negative effects
caused by e.g., potentially hazardous substances contained in these products.
Herewith you make an important contribution to the protection of the environment
and public health.
EU Declaration of Conformity
Radio Equipment Directive 2014/53/EU
RoHS 3 Directive EU 2015/863
12
Hereby, Listen Technologies declares that the radio equipment type Listen Bluetooth/IR
Beacon LA-490 is in compliance with:
Radio Equipment Directive 2014/53/EU
RoHS 3 Directive EU 2015/863
The full text of the EU declaration of conformity is available at the following internet address:
www.listentech.com/support/declaration-conformity-documents/
Warranty
Listen Technologies warrants LA-490 to be free from defects in materials and
workmanship under normal use and conditions for 5 Years from the original date of
purchase.
For the current warranty conditions, please visit our website at
www.listentech.com/support/warranty/ or contact your Listen partner.
FOR AUSTRALIA ONLY
Listen Technologies goods come with guarantees that cannot be excluded under the
Australian Consumer Law. You are entitled to a replacement or refund for a major
failure and compensation for any other reasonably foreseeable loss or damage. You
are also entitled to have the goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to a major failure. This warranty is
in addition to other rights or remedies under law. Nothing in this warranty excludes,
limits or modifies any liability of Listen Technologies which is imposed by law, or limits
or modifies any remedy available to the consumer which is granted by law.
To make a claim under this warranty, contact
Listen Technologies Technical Support
14912 Heritage Crest Way
Bluffdale, Utah 84065
warranty will be borne by the person making the claim.
13
Contact information
LISTEN TECHNOLOGIES 14912 Heritage Crest Way, Bluffdale, Utah 84065-4818 USA
Phone: +1.801.233.8992 Toll-Free: 1.800.330.0891 www.listentech.com
Copyright © 2022 Listen Technologies Corporation. All rights reserved. 20220203
Table of contents
