LITETRONICS EB23UQ User manual

Installation
Instructions
Ordering Code:
EB23UQ
LED Emergency Battery Backup
PLEASE READ THESE INSTRUCTIONS
BEFORE INSTALLATION:
TROFFER INSTALLATION
STRIP INSTALLATION

2
WHEN USING ELECTRICAL EQUIPMENT, BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE OBSERVED
INCLUDING THE FOLLOWING:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
• Do not use outdoors.
• Do not let power supply cords touch hot surfaces.
• Do not mount near gas or electric heaters.
• Use caution when servicing batteries. Battery acid can cause burns to skin and eyes. If acid is spilled on skin or in eyes, ush acid with fresh
water and contact a physician immediately.
• Equipment should be mounted in locations and at heights where it will not readily be subjected to tampering by unauthorized personnel.
• The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
• Do not use this equipment for other than intended use.
• Installation should be in accordance with NEC and any relevant local codes.
• Risk of re or electric shock. Emergency Battery Backup installation requires knowledge of electrical system. If not qualied, do not attempt
installation. Contact a qualied electrician.
• Risk of re or electric shock. Luminaire wiring and electrical parts may be damaged when drilling for installation of Emergency Battery Backup.
Check for enclosed wiring and components.
• This Emergency Battery Backup shall only be installed into an UL/CUL Listed Luminaire with a steel enclosure. DO NOT INSTALL THIS EMER-
GENCY BATTERY BACKUP INTO LUMINAIRES WITH NON-FERROUS METAL OR POLYMERIC ENCLOSURES
• To prevent wiring damage or abrasion, do not expose wiring to edges of sheet metal or other sharp objects.
• Voltage could be present in Battery. To prevent high voltage from being present on output leads, Battery connector must be open. Do not connect
Battery connector until installation is complete.
• Make sure that the necessary branch circuit wiring is available. An un-interrupted AC source of power is required.
• THIS PRODUCT CONTAINS A RECHARGEABLE Ni-MH BATTERY. THE BATTERY MUST BE RECYCLED OR DISPOSED OF PROPERLY.
• In all installations, with or without a dimmer, the EB23UQ wires labeled “0-10V Retrot or Luminaire” must be connected to the Retrot or
Luminaire 0-10V wires before power is restored.
DISCONNECT SAFETY INSTRUCTIONS
• Improperly installed electrical wiring can be dangerous and cause electrical res. This product must be used in accordance with the current rating
and wire sizes listed. Consult local building code before doing any electrical work.
• COPPER to COPPER ONLY. Do not use on Aluminum. Temperature rating: 105° C (221° F) maximum. Flame Rated UL94V-0.
• Can be used with and without a switch.
• Battery is replaceable with Litetronics’s ordering code EBA45-12V. Contact the manufacturer for information on replacement battery.
• Easy front access to Dip Switch for adjustments to control output power of 23 watts for 0-10V to various LED retrot models
• Compatible with non-dimmable LED Retrot 120V-277V up to 23W with full power light output.
• Do not use with non-dimmable 32W or 50W or more than 23W LED retrot.
SAVE THESE INSTRUCTIONS
Ordering Code : EB23UQ (23W 120-277V QC WH) EB23UQ is compatible with all Litetronics 0-10V dimmable Retrots. It is also usable with
Litetronics non-dimmable Retrots up to 23 Watts.
Section 1- TROFFER ORWRAP INSTALL 4
Section 2- STRIP FIXTURE INSTALL 7
Section 3- MISCELLANEOUS OPERATING INSTRUCTIONS 10
Section 4- WIRING DIAGRAM A (For 0-10V LED Retrot with dimmer) 11
WIRING DIAGRAM B (For 0-10V LED Retrot with or without switch and without dimmer) 12
WIRING DIAGRAM C (For non-dim LED Retrot <23W with or without switch) 13
INTRODUCTION & TABLE OF CONTENTS
SAFETY INSTRUCTIONS AND WARNINGS
Congratulations on the purchase of your Emergency Battery Backup. It is usable for a range of installations.We have
included some of the most common ones here.

3
1312
What comes in the box:
RETROFIT COMPATABILITY TABLE
Emergency Battery Backup with Magnets (5)Wire Nuts
(2) Self-tapping
screws, #8 x 1/2”
(1) Female Quick Disconnect
(Attached to Male End)
(1) Male Quick Disconnect
(Attached to Female End)
DIMMABLE
ORDERING CODE DESCRIPTION WATTS
RF50UQT4XXDL 0-10V 50W 3-2x4 LED RF QC 50W
RF32UQT4XXDL 0-10V 32W 2-2x4 LED RF QC 32W
RF32UQT1XXDL 0-10V 32W 2-1X4 LED RF QC 32W
RF32UQT2XXDL 0-10V 32W 3-2X2 LED RF QC 32W
RF16UQT1XXDL 0-10V 16W 1-1X4 LED RF QC 16W
RF16UQT1XXCDL 0-10V 16W 1-1X4 LED RF 16W
(2) RF32UQT1XXCDL (2) 0-10V 32W 2-1X4 LED RF QC 64W
(2) RF16UQT1XXCDL (2) 0-10V 16W 1-1X4 LED RF QC 32W
RF32UQT1XXCDL 0-10V 32W 2-1X4 LED RF QC 32W
RF32UHT1XXDL 0-10V 32W 2-1X4 LED RF QC 32W
NON-DIMMABLE
ORDERING CODE DESCRIPTION WATTS
RF16UQT1XXC 16W 1-1X4 LED RF QC 16W
RF22UQT2XX 22W 2-2X2 LED RF QC 22W
Battery accessory
(EBA45-12V)
Emergency battery backup from Litetronics comes with a rechargeable battery installed. Replacement batteries are also available for purchase.
AVAILABLE ACCESSORIES
EB23UQ is compatible with all Litetronics 0-10V dimmable Retrots. It is also usable with Litetronics non-dimmable Retrots up to 23 Watts.
To Switch Line
Green Light Indicator
Test Switch
0-10V Retrot
or Luminaire
(Note: Dimmer
connection wires are
inside box)

4
EB23UQ
TROFFER FIXTURE INSTALL
Section 1
1. Turn o power at circuit breaker. Open the cover of the
existing xture.
2. Remove lid of emergency battery backup by unscrewing
2 screws.
3. Check the corresponding LED RetroFit model number.
Use below table to select and change dip switch position
for setup.
In factory default setting, Position 2 set to ON.You should
set all dip switch positions to OFF, unless a position is
specied as ON for your Retrot model.
CAUTION:IF DIP SWITCH IS
MIS-CONFIGURED,
i) Damage to the emergency
battery backup will occur.
ii) Backup battery time will be
less than 90 minutes and bright-
ness will be less than specied.
DIP SWITCH SETUP FOR EB23UQ
LITETRONICS’ RETROFIT
MODEL NUMBER
EMERGENCY
OUTPUT
WATTS
DIP SWITCH POSITION
123456
RF16UQT1XXC 16W
RF22UQT2XX 22W
RF16UQT1XXDL 16W
RF16UQT1XXCDL 16W
(2) RF16UQT1XXCDL 23W ON
RF32UQT1XXDL 23W ON
RF32UQT1XXCDL 23W ON
(2) RF32UQT1XXCDL 23W ON
RF32UHT1XXDL 23W ON
RF32UQT2XXDL 23W ON
RF32UQT4XXDL 23W ON
RF50UQT4XXDL 23W ON

5
8. Connect halves of white multi-pin battery connector
together.
EB23UQ
TROFFER FIXTURE INSTALL
4. Place emergency battery backup on xture and position
as needed. Recommended placement is close to the junction
box of LED RetroFit and input power wires.
7. Secure emergency battery backup with two of the self-
tapping screws provided.The holes are located inside on the
bottom frame of case.
5. Unscrew junction box cover of existing RetroFit from
luminaire troer.
Section 1
6. For electrical connections, refer to the wiring diagrams on pages 11,12 and 13.
Note: In all installations, with or without a dimmer, the EB23UQ jacketed wires labeled“0-10V
Retrofit or Luminaire“ must be connected to the Retrofit or luminaire 0-10V dimmer control
wires before power is restored.

6
EB23UQ
TROFFER FIXTURE INSTALL
9. Replace lid back on of emergency battery backup and
secure with 2 screws.
Section 1
10. Replace junction box (from step 4) over remaining
wires, and secure with screws.
11. Close the cover, restore the power.

7
EB23UQ
STRIP FIXTURE INSTALL
Section 2
1. Turn o power at the circuit breaker. Open the cover of the
existing xture.
2. Remove lid of emergency battery backup by unscrewing
2 screws. You will not need to replace the cover for this
installation.
4. Place emergency battery backup in strip xture and
position as needed. Recommended to place close to the
LED RetroFit and input power wires. Extend wires for push
button tester and LED indicator from unit. Mark position for
emergency battery backup and holes in strip xture wall.
Remove backup.
5. Drill two holes in strip xture
wall for the LED indicator light
1/4”(6.3mm) and push button
tester 9/32”(7.2mm). Replace
emergency backup kit.
3. Remove push button tester
and LED indicator with LED
holder from their positions in
the metal box wall.

8
EB23UQ
STRIP FIXTURE INSTALL
8. Check the corresponding LED RetroFit model number.
Use below table to select and change dip switch position for
setup.
In factory default setting, Position 2 set to ON.You should set
all dip switch positions to OFF, unless a position is specied as
ON for your Retrot model.
7. Insert the push button tester
through hole in the side of strip.
Secure with lock washer and nut.
Section 2
6. Insert the LED indicator light
through hole in the side of strip
and secure with LED holder.
CAUTION:IF DIP SWITCH IS
MIS-CONFIGURED,
i) Damage to the emergency
battery backup will occur.
ii) Backup battery time will be
less than 90 minutes and bright-
ness will be less than specied.
DIP SWITCH SETUP FOR EB23UQ
LITETRONICS’ RETROFIT
MODEL NUMBER
EMERGENCY
OUTPUT
WATTS
DIP SWITCH POSITION
123456
RF16UQT1XXC 16W
RF22UQT2XX 22W
RF16UQT1XXDL 16W
RF16UQT1XXCDL 16W
(2) RF16UQT1XXCDL 23W ON
RF32UQT1XXDL 23W ON
RF32UQT1XXCDL 23W ON
(2) RF32UQT1XXCDL 23W ON
RF32UHT1XXDL 23W ON
RF32UQT2XXDL 23W ON
RF32UQT4XXDL 23W ON
RF50UQT4XXDL 23W ON

9
9. Secure emergency battery backup to strip xture with
two of the self-tapping screws.The holes are located inside
on the bottom frame of case.
EB23UQ
STRIP FIXTURE INSTALL
11. Connect halves of white multi-pin battery connector
together.
12. You do not need to replace the cover on the emergency
backup.The strip xture cover is all that is required.
10. For electrical connections, refer to the wiring diagrams on pages 11,12 and 13.
13. Close the cover, restore the power.
Section 2
Note: In all installations, with or without a dimmer, the EB23UQ jacketed wires labeled“0-10V
Retrofit or Luminaire“ must be connected to the Retrofit or luminaire 0-10V dimmer control
wires before power is restored.

10
Section 2
TEST/OPERATION:
1.When AC power is applied, charge indicator light illuminates green.That indicates the battery is
charging.
2. Press button“PUSH toTEST”for 3 seconds to simulate power failure and conrm LED RetroFit is
functioning in emergency mode. Charge indicator light will be o.
3.When power fails, the emergency battery backup automatically switches to emergency power. The
charge indicator light is o and the RetroFit will operate at about 23W.
4.When AC power is restored, the emergency battery automatically returns to charge mode.
5. EB23UQ must be charged for 24 hours before 90 minute test can be completed.
MAINTENANCE:
Although no routine maintenance is required to keep the emergency battery backup functional, it should
be checked periodically to ensure that it is working.The following schedule is recommended:
1.Visually inspect the charge indicator light monthly. It should be illuminated.
2.Test the emergency operation of the xture at 30-day intervals for a minimum of 30 seconds.
3. Conduct a 90-minute discharge test once a year. LED tubes should operate at about 23W for at least 90
minutes.
SERVICE:
Should be performed as indicated above by qualied personnel.
EB23UQ
MISCELLANEOUS OPERATING INSTRUCTIONS
Section 3

11
EB23UQ
WIRING DIAGRAM A
Section 4
0-10V LED Retrofit with dimmer. Connect wires as outlined. Follow wiring diagram A below:
a. Connect purple (+) and gray(-) coming out of emergency backup to purple (+) and gray (-) from LED
RetroFit using wire nuts.
b. Connect yellow (+) and gray(-) wires wrapped in emergency backup to purple (+) and gray (-) from LED
dimmer using wire nuts.
c. Plug Out-N (white) and Out-L (black/white) of emergency backup connector with LED RetroFit together.
d. Connect AC-N (white) and AC-L (black) of emergency backup to un-interrupted power supply wires.
e. Connect SW (red) coming out of emergency backup to dimmer.
WIRING DIAGRAM B
FOLLOW WIRING DIAGRAM B (i)
BUT CONNECT AC-L (BLACK) AND SW (RED) TOGETHER.
AC-N
SW
AC-L
LED EMERGENCY
BATTERY BACKUP
LED RETROFIT (0-10V)
WHITE
RED
0-10V DIMMER (+)YELLOW
*
*
HOT UNINTERRUPTED BLACK
0-10V DIMMER (-)GRAY
0-10V RETROFIT OR LUMINAIRE DIM (+)PURPLE
0-10V RETROFIT OR LUMINAIRE DIM (-)GRAY
OUT-NWHITE
OUT-LBLACK/WHITE
B. (i) 0-10V LED RETROFIT WITH SWITCH AND WITHOUT DIMMER
B. (ii) 0-10V LED RETROFIT WITHOUT SWITCH AND WITHOUT DIMMER
WIRING DIAGRAM A
#FOLLOW DIMMER INSTRUCTION MANUAL FOR CONNECTION
AC-N
SW
AC-L
LED EMERGENCY
BATTERY BACKUP
LED RETROFIT (0-10V)
WHITE
LINE (HOT)
NEUTRAL
RED
0-10V DIMMER (+)
HOT UNINTERRUPTED BLACK
0-10V DIMMER (-)GRAY
0-10V RETROFIT OR LUMINAIRE DIM (+)PURPLE
0-10V RETROFIT OR LUMINAIRE DIM (-)GRAY
OUT-NWHITE
OUT-LBLACK/WHITE
YELLOW
Updated: 10/17/16
Updated: 10/21/16
Updated: 10/27/16
Created: 9/20/16
0-10V LED RETROFIT WITH DIMMER
#
0-10V DIMMER
WIRING DIAGRAM C
FOLLOW WIRING DIAGRAM C (i)
CONNECT AC-L (BLACK) AND SW (RED) TOGETHER
AC-N
SW
AC-L
LED EMERGENCY
BATTERY BACKUP
LED RETROFIT (NON-DIM)
WHITE
RED
0-10V DIMMER (+)YELLOW
*
*
*
*
*
HOT UNINTERRUPTED BLACK
0-10V DIMMER (-)GRAY
0-10V RETROFIT OR LUMINAIRE DIM (+)PURPLE
0-10V RETROFIT OR LUMINAIRE DIM (-)GRAY
OUT-NWHITE
OUT-LBLACK/WHITE
C. (i) NON-DIM LED RETROFIT <23W WITH SWITCH
C. (ii) NON-DIM LED RETROFIT <23 WITHOUT SWITCH
0-10V DIMMER
WIRES INSIDE
0-10V DIMMER
WIRES INSIDE
0-10V DIMMER
WIRES INSIDE
A. 010V LED RETROFIT WITH DIMMER
AC-N / AC-L / SW
0-10V Retrot or Luminaire Dim (+) / Retrot or Luminaire Dim (-)
OUT-N / OUT-L
NOTE:
0-10V dimmer
wires inside

12
EB23UQ
WIRING DIAGRAM B
Section 4
0-10V LED Retrofit with switch and without dimmer. Connect wires as outlined. Follow wiring
diagram B(i) below:
a. Connect purple (+) and gray(-) coming out of emergency backup to purple (+) and gray (-) from LED
RetroFit using wire nuts.
b. Cover the yellow (+) and gray (-) coming out of emergency backup with wire nuts.
c. Plug Out-N (white) and Out-L (black/white) of emergency backup connector together with LED RetroFit.
d. Connect AC-N (white) and AC-L (black) of emergency backup to un-interrupted power supply wires.
e. Connect SW (red) coming out of emergency backup to switch.
0-10V LED Retrofit without switch and without dimmer. Connect wires as outlined. Follow wiring
diagram B(ii) below:
a. Connect purple (+) and gray(-) coming out of emergency backup to purple (+) and gray (-) from LED
RetroFit using wire nuts.
b. Cover the yellow (+) and gray (-) coming out of emergency backup with wire nuts.
c. Plug Out-N (white) and Out-L (black/white) of emergency backup connector together with LED RetroFit.
d. Connect AC-N (white) and AC-L (black) of emergency backup to un-interrupted power supply wires.
e. Connect AC-L (black) and SW (red) together.
WIRING DIAGRAM B
FOLLOW WIRING DIAGRAM B (i)
BUT CONNECT AC-L (BLACK) AND SW (RED) TOGETHER.
AC-N
SW
AC-L
LED EMERGENCY
BATTERY BACKUP
LED RETROFIT (0-10V)
WHITE
RED
0-10V DIMMER (+)YELLOW
*
*
HOT UNINTERRUPTED BLACK
0-10V DIMMER (-)GRAY
0-10V RETROFIT OR LUMINAIRE DIM (+)PURPLE
0-10V RETROFIT OR LUMINAIRE DIM (-)GRAY
OUT-NWHITE
OUT-LBLACK/WHITE
B. (i) 0-10V LED RETROFIT WITH SWITCH AND WITHOUT DIMMER
B. (ii) 0-10V LED RETROFIT WITHOUT SWITCH AND WITHOUT DIMMER
WIRING DIAGRAM A
#FOLLOW DIMMER INSTRUCTION MANUAL FOR CONNECTION
AC-N
SW
AC-L
LED EMERGENCY
BATTERY BACKUP
LED RETROFIT (0-10V)
WHITE
LINE (HOT)
NEUTRAL
RED
0-10V DIMMER (+)
HOT UNINTERRUPTED BLACK
0-10V DIMMER (-)GRAY
0-10V RETROFIT OR LUMINAIRE DIM (+)PURPLE
0-10V RETROFIT OR LUMINAIRE DIM (-)GRAY
OUT-NWHITE
OUT-LBLACK/WHITE
YELLOW
Updated: 10/17/16
Updated: 10/21/16
Updated: 10/27/16
Created: 9/20/16
0-10V LED RETROFIT WITH DIMMER
#0-10V DIMMER
WIRING DIAGRAM C
FOLLOW WIRING DIAGRAM C (i)
CONNECT AC-L (BLACK) AND SW (RED) TOGETHER
AC-N
SW
AC-L
LED EMERGENCY
BATTERY BACKUP
LED RETROFIT (NON-DIM)
WHITE
RED
0-10V DIMMER (+)YELLOW
*
*
*
*
*
HOT UNINTERRUPTED BLACK
0-10V DIMMER (-)GRAY
0-10V RETROFIT OR LUMINAIRE DIM (+)PURPLE
0-10V RETROFIT OR LUMINAIRE DIM (-)GRAY
OUT-NWHITE
OUT-LBLACK/WHITE
C. (i) NON-DIM LED RETROFIT <23W WITH SWITCH
C. (ii) NON-DIM LED RETROFIT <23 WITHOUT SWITCH
0-10V DIMMER
WIRES INSIDE
0-10V DIMMER
WIRES INSIDE
0-10V DIMMER
WIRES INSIDE

13
EB23UQ
WIRING DIAGRAM C
Section 4
WIRING DIAGRAM B
FOLLOW WIRING DIAGRAM B (i)
BUT CONNECT AC-L (BLACK) AND SW (RED) TOGETHER.
AC-N
SW
AC-L
LED EMERGENCY
BATTERY BACKUP
LED RETROFIT (0-10V)
WHITE
RED
0-10V DIMMER (+)YELLOW
*
*
HOT UNINTERRUPTED BLACK
0-10V DIMMER (-)GRAY
0-10V RETROFIT OR LUMINAIRE DIM (+)PURPLE
0-10V RETROFIT OR LUMINAIRE DIM (-)GRAY
OUT-NWHITE
OUT-LBLACK/WHITE
B. (i) 0-10V LED RETROFIT WITH SWITCH AND WITHOUT DIMMER
B. (ii) 0-10V LED RETROFIT WITHOUT SWITCH AND WITHOUT DIMMER
WIRING DIAGRAM A
#FOLLOW DIMMER INSTRUCTION MANUAL FOR CONNECTION
AC-N
SW
AC-L
LED EMERGENCY
BATTERY BACKUP
LED RETROFIT (0-10V)
WHITE
LINE (HOT)
NEUTRAL
RED
0-10V DIMMER (+)
HOT UNINTERRUPTED BLACK
0-10V DIMMER (-)GRAY
0-10V RETROFIT OR LUMINAIRE DIM (+)PURPLE
0-10V RETROFIT OR LUMINAIRE DIM (-)GRAY
OUT-NWHITE
OUT-LBLACK/WHITE
YELLOW
Updated: 10/17/16
Updated: 10/21/16
Updated: 10/27/16
Created: 9/20/16
0-10V LED RETROFIT WITH DIMMER
#0-10V DIMMER
WIRING DIAGRAM C
FOLLOW WIRING DIAGRAM C (i)
CONNECT AC-L (BLACK) AND SW (RED) TOGETHER
AC-N
SW
AC-L
LED EMERGENCY
BATTERY BACKUP
LED RETROFIT (NON-DIM)
WHITE
RED
0-10V DIMMER (+)YELLOW
*
*
*
*
*
HOT UNINTERRUPTED BLACK
0-10V DIMMER (-)GRAY
0-10V RETROFIT OR LUMINAIRE DIM (+)PURPLE
0-10V RETROFIT OR LUMINAIRE DIM (-)GRAY
OUT-NWHITE
OUT-LBLACK/WHITE
C. (i) NON-DIM LED RETROFIT <23W WITH SWITCH
C. (ii) NON-DIM LED RETROFIT <23 WITHOUT SWITCH
0-10V DIMMER
WIRES INSIDE
0-10V DIMMER
WIRES INSIDE
0-10V DIMMER
WIRES INSIDE
C.(i) For wiring non-dim LED Retrofit <23W with switch. Connect wires as outlined. Follow wiring
diagram C(i) below:
a. Cover both the purple (+) and gray (-) coming out of emergency backup with 2 wire nuts.
b. Cover the yellow (+) and gray (-) coming out of emergency backup with 2 wire nuts.
c. Plug Out-N (white) and Out-L (black/white) of emergency backup connector with LED RetroFit together.
d. Connect AC-N (white) and AC-L (black) of emergency backup to un-interrupted power supply wires.
e. Connect SW (red) coming out of emergency back up to switch
C.(ii) For wiring non-dim LED Retrofit <23W without switch. Connect wires as outlined. Follow
wiring diagram C(ii) below:
a. Cover the purple (+) and gray (-) coming out of emergency backup with 2 wire nuts.
b. Cover the yellow (+) and gray (-) coming out of emergency backup with 2 wire nuts.
c. Plug Out-N (white) and Out-L (black/white) of emergency backup connector together with LED RetroFit.
d. Connect AC-N (white) and AC-L (black) of emergency backup to un-interrupted power supply wires.
e. Connect AC-L (black) and SW (red) coming out of emergency backup together.

vol.10 (11-21-17)
WWW.LITETRONICS.COM
[e-mail] or 1-800-860-3392
6969W. 73rd Street
Bedford Park, IL 60638
Thank you for choosing
