Litrastudio Ls3000 User manual

QUICK START GUIDE

studio

THANK YOU for purchasing the LitraStudio!

LitraStudio™ is the World’s Most Powerful and Portable RGBWW Photo and Video Light. With over a million

unique colors available anytime, anywhere, the LitraStudio™ allows you to light your world in a whole new

way, no cords attached.

PARTS

1. Optical Lens

2. USB C Charging Door / Port

3. Control Panel

4. Battery Door

5. ¼20 Mount

6.Pressure Valve

7. Aluminum Housing

8. Rechargeable Quick Swap Battery

9. Silicone Diffuser

10. Quick Charge Adapter

11. ¼20 Handle

12. Carry Bag

WARNING

0.1m

10.

11.

12.

SETUP

CONTROL PANEL MENU

1. Remove contents from box and remove protective film from

lens and control panel.

2. Charge light to 100% before use.

3. For manual use, power light on and start creating!

4. For Bluetooth control, download Litra App to smartphone

device.

4. Power on light.

5. Make sure the Bluetooth on your device is on.

6. Connect to LitraStudio and start creating!

7. To upgrade the LitraStudio software, connect to light, select

“Settings,” select “Firmware Update.”

8. See FAQs, App Tutorial, and Troubleshooting Guide for

additional information.

9. Contact Support@Litra.com if needed.

10. Register your product at Litra.com

CONTROL PANEL BASICS

3. 4. 5.

CCT

95%

80% 5600k 20GN

8. 9. 10. 11. 12.

1. Home Button

2. Back Button

3. Dimming/Intensity, Select,

Overdrive Control

4. CCT, Hue, Flash Control

5. Green Shift, Saturation Control

6. Program Button

7. Power Button

8. Mode

9. Intensity

10. Kelvin / HUE / Mode Dependent

11. Battery Level

12. Mode Dependent

Home Menu Mode Notes

Light Mode

Light Effects

DMX

Factory Reset

CCT

HIS

Gel

RGBWW

OD > Press and Hold Dim/Select

Flash > Press and Hold CCT/HUE

Various customizable parameters

for each effect

Light Info

Assigned Band Protocols:

1-50 CCT

51-100 HSI

101-150 GEL

151-200 RGBWW

Select DMX Mode > DMX Mode Active.

Requires separate DMX Dongle accessory

not included wit the basic LitraStudio

Light Temp

Serial Number

Firmware Version

Will delete saved presets and reset

Bluetooth connection

Details / Special Controls

DIM / Select

CCT / HUE

Home

Back

“P” Program

Flash

Press and hold for Overdrive ON/OFF

Press and Hold for Flash ON/OFF

Top level Menu / Back to Past Menu Location

Back on level in Menu

Short Press to bring up saved settings. Long Press to save current

setting

Press and hold CCT/HUE control. Requires separate PC to USB

cable accessory not included with the basic LitraStudio

WARNING: Tampering with or disassembling the LitraStudio may result in electric shock and will void the manufacturer’s warranty.

WARNING: To reduce the risk of electric shock or fire, do not expose the LitraStudio to rain, moisture, or liquids WHILE CHARGING

OR WITH USB AND BATTERY DOOR OPEN. Consult with a qualified dealer or Litra representative if light does not operate normally.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) this device may not cause

harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

WARNING: LitraStudio™ is a high-performing, powerful LED light. Like all lights, LitraStudio™ will produce heat while in use.

Heat levels will increase depending on how long the light has been in continuous operation and at what lighting level.

Please handle LitraStudio™ carefully during long use periods. We recom mend you mount the light to a camera or tripod.Do not place

LitraStudio™ face down on a surface while turned on. Do not place light closer than 0.1 m to wall or other surface on max. This can

cause over heating.LitraStudio™ is very, very bright. Do not look directly at the beam at close range or for any extended period

as retinal damage could occur.

WARNING: LitraStudio is waterproof to 10m. BEFORE using in water, user is responsible for ensuring the USB Door and Battery

Door are closed properly. 1) Ensure the rubber gaskets are in place and free of dirt and debris; 2) Ensure the doors are completely

closed by pushing them firmly into closed position; 3) Ensure the USB lock snaps into place when door is closed and ensure the Battery

door lock is snaps into place when door is closed. DOUBLE CHECK THE DOORS ARE SECURE BY PULLING ON THE DOORS AND

CONFIRMING THEY ARE LOCKED CLOSED. DO NOT RUN THE LIGHT OUT OF WATER AT HIGH LIGHT OUTPUT AND TEMPERATURE

AND THEN SUBMERGE UNDERWATER. This may result in the Goretex pressure equalization gasket to leak.

QUICK START GUIDE

studio

WARNING

0.1m

CARE & MAINTENANCE

Care / Cleaning Information: Use a clean, dry, non-abrasive

cloth only. Do not use chemicals or solvents to clean. After use

in salt water, rinse in fresh water.

Storage: For best battery performance always store with

battery fully charged. Charging every three months is

recommended. Do not store battery on low power for

prolonged time. Do not use, mount, transport, or store the

LitraStudio near heat sources (open fire, heaters, stoves, etc)

or in an environment with an ambient temperature greater

than 65°C [149° F]. The LitraStudio is suitable for operation

only in an environment as follows: ambient air temperature

between -20°C and 45°C [between -4°F and 113°F].

Charging: Recommended to use provided 45W quick charge

adapter or certified adapters with 45W or higher rating.

WARRANTY

Litra warrants LitraStudio™ against defects in material or workmanship for a period of 1 year from the original date of purchase of the product by the original end

user (the “Warranty Period”). Litra does not warrant, and is not responsible for, any device made by anyone other than Litra. If a material or workmanship defect

arises with LitraStudio™, and a valid claim is received within the Warranty Period, Litra will (i) repair LitraStudio™ using new or refurbished parts or (ii) replace

LitraStudio™ with a new or refurbished LitraStudio™ product at our sole discretion. For purposes of this limited warranty, “refurbished” means a product or part

that has been substantially returned to its original specifications. In the event of a defect, these are your exclusive remedies. Our warranty does not cover any

damage resulting from use, accident, third party parts or normal wear and tear is not covered by this warranty. Litra, LLC. (dba Litra) assumes no liability for any

accident, injury, death, loss or other claim relating to or resulting from the use or this product or product family. Always follow appropriate laws and use common

sense. Never attempt anything you see in our or any third party videos. Using Litra and all of its mounts including any and all homemade mounts/equipment can

cause serious injury or even death. Always be mindful of how LitraStudio™ and/or any Litra accessories can impact clearance, movement, weight, momentum, or

interference with other equipment etc. In no event shall Litra be liable for incidental or consequential damages relating to or resulting from the use of this product

or any of its parts. Never alter any type or path of safety equipment for Litra. Litra’s maximum combined liability shall be limited to the cost for the specific

product only.

We will not offer warranty on the following:

• Abuse, misuse, or improper handling

• Safety of any device you use with LitraStudio™. (You use this device at your own risk.)

• Purchases made from a non-authorized reseller.

• The LitraStudio™ LEDs are NOT replaceable. Warranty is void if the user attempts to disassemble or disassembles the light. Disassembly will void waterproof

specification.

FCC / SAR WARNING

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2)

this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications to this unit not

expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found

to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio TV technician for help

The equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.

This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

LitraStudio™ is certified to be in compliance with the

following safety directives: CE, RoHS, WEEE

LS3000

5-20V 3A;

MODEL:

INPUT:

QUICK START GUIDE

studio

IC WARNING

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference,

and (2) this device must accept any interference, including interference that may cause undesired operation of the device

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes :

(1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en

compromettre le fonctionnement.

This Class B digital apparatus complies with Canadian ICES-003.

Cetappareilnumérique de la classe B estconformeà la norme NMB-003 du Canada.
